NIYKB2090Multimedia Wireless Keyboard

OFFICE-WEB KEYBOARD MOUSE SET USER’S MANUAL (Model #: KS-2090) Important Ergonomic Information Some experts believe that using any mouse or trackball may cause serious injury to hands, wrists, arms, neck, or back. If you feel pain, numbness, or weakness in these areas, see a qualified health professional. TO REDUCE THE RISK OF INJURY, FOLLOW THESE PRECAUTIONS: z Take frequent breaks, get up and walk around several times every hour. z Vary your tasks throughout the day. z Keep your shoulders relaxed with your elbows at your side. Position your keyboard and mouse so you do not have to reach. z Adjust your chair and keyboard so your upper arms and wrists are straight. z Avoid resting your wrists on sharp edges. SYSTEM REQUIREMENT z Mouse compatible with standard Microsoft mode. z 3 rd button and wheel function require Win98/2000/ME/XP. z 4 th & 5 th button require Win2000/XP to function, or will require to install additional driver as attached with this product. z 6 th & 7 th button require installing additional driver as attached with this product. z If your computer’s operating system uses Windows98/98SE, please prepare the Windows98 or 98SE compact disk for system’s request during the installation of mouse. z Keyboard compatible with standard Microsoft mode. z These multimedia/office/Net hot-keys will require to install additional driver as attached with this product. z The Office hot-keys require MS-Office software to function. z The Multimedia Hot-keys require Windows 2000/XP/ME to function. 1 Getting Started Congratulations on your purchase of an 800dpi Office-Web mouse. The 800dpi high resolution will bring users the best operation accuracy and efficiency, especially for a display at 1024*768 or higher. It has a double operation speed and only requires 1/4 space by comparing with a 400dpi mouse. With the ergonomic design in extra buttons, the short-cut functions about MS-Office and Internet provide you an efficient operation to access defaulted path or hot-functions chosen by yourself. Package Contains Your Radius Mouse package includes the following: 1. Wireless Mouse 2. Wireless keyboard 3. Receiver with cable 4. CD-ROM 5. User’s manual 6. 2 AA batteries for mouse 7. 2 AA batteries for keyboard NoteIf any part is missing, please contact your dealer for a replacement immediately. Precaution ! For optimal performance, place the receiver at least 8 inches or 20 centimeters away from other electrical devices, such as the computer, the computer monitor, speakers or other external storage drives. Battery Warning! When replace the batteries, use alkaline. You may use rechargeable NiMH or other type of batteries, but do not mix then with alkaline. Do not mix used and new batteries together! BEFORE YOU BEGIN z Keep this installation guide for future reference! It contains Important Troubleshooting Information. z Keep your old PS/2 mouse as a back-up device. 2 HARDWARE INSTALLATION Connecting Receiver 1. Turn off your computer 2. Disconnect the current keyboard and mouse. 3. The receiver comes with a two-headed cable. You just need to plug the USB connector into USB port because the USB connector is for the keyboard and the mouse simultaneously. The USB Connector Inserting the Batteries The RF wireless keyboard uses 2 AA batteries. They are inserted as follows: 1. Turn the keyboard over to show the underside. 2. Release the battery cover. 3. There are signs to indicate positive and negative orientation for the batteries. Take care to insert the batteries correctly. 4. Clip the battery cover back into place and make sure it is firmly closed. Insert 2 AA Batteries. 3 The RF wireless mouse uses 2 AA batteries. They are inserted as follows: 1. Turn the mouse to the bottom side. 2. Remove the batteries cover by moving the opening tabs and pull the battery cover out. 3. There are signs to indicate batteries' positive and negative poles. Follow the signs to place the batteries 4. Place the batteries cover back and make sure it is firmly closed Insert 2 AA Batteries. Selecting the ID Channel The RF wireless keyboard & mouse provide the possibility of 256 different ID to avoid interference with other users of the same model RF wireless keyboards or mice. Before using the wireless keyboard and mouse, you must ensure that the same ID is set for the receiver, keyboard and mouse. Please follow the steps as below to set up: 1. Turn to the bottom of receiver and you will see a small button (ID code connection, refer to picture). 2. Establish communication between the receiver and the mouse (Select identification codes). „ Press and release the connect ID button on the bottom of receiver. 4 1. Click the connect ID button on the Receiver side. „ Within 6 seconds of the previous step, press and release the “connect” button on bottom of the wireless mouse, and the “connect” small button on the top-right of the keyboard. 2. Click the connect ID button on the Mouse side. 3. Click the connect ID button on the keyboard side. „ After above “connect” procedure, the same ID is selected on both of the receiver and the mouse. „ Please move the mouse to operate its cursor and test some keyboard’s function. If there is problem, please do the connect setting procedure again or check the trouble shooting guide. 5 Operation Guide Battery Low Indication When the voltage level of the battery goes down under the preset level, the scrolling wheel will flash at least three times on moving or clicking the mouse. Although the mouse can still work for a while, the user, at this time, should have a new set of batteries ready for replacement. Or, if the user has a companion charger base, and Two re-chargeable batteries are inside the mouse, charge the mouse as soon as possible. Power off the mouse 1. Be sure the mouse is NOT in sleep mode. If it is, press any key to wake it up. 2. Press and hold the Connect button on the bottom of the mouse for more than 2 seconds. (The red light will go off while the Connect button is depressed.) 3.…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

JAMES JAMES
: : . :78-100-558
: : . :78-100-558 S/N： Model:KB2090 Made in ChinaMadeinChina Tested to Comply with FCC Standards TestedtoComply withFCCStandards FOR HOME OR OFFICE USEFORHOMEOROFFICEUSE FCC ID:NIYKB2090FCCID:NIYKB2090 78-100-558 0560 !

Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: NIYKB2090 ADT No.930722L16 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3V Batteries. The type of antenna is Loop antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: NIYKB2090 Report No.: RF930722L161Issued: August 03, 2004 FCC TEST REPORT REPORT NO.: RF930722L16 MODEL NO.: KB2090 RECEIVED: July 27, 2004 TESTED: August 02, 2004 APPLICANT: DEXIN Corporation ADDRESS: 14F-8, No 258,Lian Cheng Rd., Chung Ho City, Taipei Hsien, Taiwan, R.O.C ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2nd rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: NIYKB2090 Report No.: RF930722L162Issued: August 03, 2004 Table of Contents 1CERTIFICATION ......................................................................................................... 3 2SUMMARY OF TEST RESULTS................................................................................. 4 2.1 MEASUREMENT UNCERTAINTY ............................................................................... 4 3GENERAL INFORMATION ......................................................................................... 5 3.1GENERAL DESCRIPTION OF EUT............................................................................ 5 3.2DESCRIPTION OF TEST MODES.............................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................. 6 3.4DESCRIPTION OF SUPPORT UNITS........................................................................ 6 3.5 CONFIGURATION OF SYSTEM UNDER TEST.......................................................... 6 4TEST PROCEDURE AND RESULT ............................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT .............................................................. 7 4.2RADIATED EMISSION MEASUREMENT ................................................................... 7 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................................ 7 4.2.2TEST INSTRUMENT................................................................................................... 8 4.2.3TEST PROCEDURE ................................................................................................... 9 4.2.4DEVATION FROM TEST STANDARD ........................................................................ 9 4.2.5TEST SETUP ............................................................................................................ 10 4.2.6EUT OPERATING CONDITION ................................................................................ 10 4.2.7TEST RESULTS ........................................................................................................ 11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................... 13 6INFORMATION ON THE TESTING LABORATORIES .............................................. 14 FCC ID: NIYKB2090 Report No.: RF930722L163Issued: August 03, 2004 1 CERTIFICATION PRODUCT NAME : MUTILMEDIA WIRELESS KEYBOARD BRAND NO: DEXIN MODEL NO. : KB2090 APPLICANT : DEXIN Corporation TESTED: August 02, 2004 TEST ITEM : ENGINEERING SAMPLE STANDARDS : FCC Part 15, Subpart C(15.227) ANSI C63.4-2001 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY :, DATE:August 03, 2004 ( Wendy Liao ) TECHNICAL ACCEPTANCE :, DATE:August 03, 2004 Responsible for RF ( Gary Chang ) APPROVED BY : , DATE: August 03, 2004 ( Cody Chang / Supervisor ) FCC ID: NIYKB2090 Report No.: RF930722L164Issued: August 03, 2004 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3Vdc from batteries 15.227 15.209 Radiated Emission TestPASS Minimum passing margin is –8.57dB at 212.73MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: MEASUREMENTFREQUENCYUNCERTAINTY Conducted emissions9k~30MHz2.44 dB Radiated emissions30MHz ~ 200MHz3.55 dB 200MHz ~1000MHz3.58 dB 1GHz ~ 18GHz2.20 dB 18GHz ~ 40GHz1.88 dB FCC ID: NIYKB2090 Report No.: RF930722L165Issued: August 03, 2004 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT MUTILMEDIA WIRELESS KEYBOARD MODEL NO. KB2090 POWER SUPPLY 3Vdc from batteries MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.095MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL 1 ANTENNA TYPE Loop antenna copper trace DATA CABLE NA I/O PORTS NA ASSOCIATED DDVCES NA NOTE: 1. The EUT is the transmitter part of a Wireless Keyboard. 2. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. FCC ID: NIYKB2090 Report No.: RF930722L166Issued: August 03, 2004 3.2 DESCRIPTION OF TEST MODES One channel was provided in this EUT. CHENNELFREQUENCY 127.095MHz 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a MUTILMEDIA WIRELESS KEYBOARD. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC Part 15, Subpart C (15.227) ANS…

Text truncated - open the document above for the full version.

FCC ID: NIYKB2090 Report No.: RF930722L1613Issued: August 03, 2004 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
