NIYKB22Cordless Slim Multimedia Keyboard

Cordless Multimedia-Internet Keyboard Mouse Set USER’S MANUAL (Model #: KS-2251) The set contains: a wireless multimedia-internet keyboard, KB-22, a mini RF optical mouse, MWP2051-L, and a mini size receiver, RX2051. Important Ergonomic Information Some experts believe that using any mouse or trackball may cause serious injury to hands, wrists, arms, neck, or back. If you feel pain, numbness, or weakness in these areas, see a qualified health professional. TO REDUCE THE RISK OF INJURY, FOLLOW THESE PRECAUTIONS: y Take frequent breaks, get up and walk around several times every hour. y Vary your tasks throughout the day. y Keep your shoulders relaxed with your elbows at your side. Position your keyboard and mouse so you do not have to reach. y Adjust your chair and keyboard so your upper arms and wrists are straight y Avoid resting your wrists on sharp edges SYSTEM REQUIREMENT y The mouse is compatible with standard Microsoft mode. y 3 rd button and wheel function require Win98/2000/ME/NT/XP. y If your operating system (OS) is Windows98/98SE, please prepare the Windows98 or 98SE compact disk for system’s request during the installation of mouse. y Keyboard is compatible with standard Microsoft mode. y These Multimedia-Internet hot-keys will require additional driver as attached with this product. y The Multimedia/ Internet Hot-keys require Windows 2000/XP/ME to function. Getting Started Congratulations on your purchase the KS-2251 set, wireless multimedia-internet keyboard and optical mouse set. The slim type keyboard is an all new design keyboard, the most interesting part is the key top, slim and thin, different from any one in the market. The mini wireless mouse is also such an incredible product, using and knowing. The product will bring you a special experience in using computer and surfing web. Package Contains Your Keyboard/Mouse Set package includes the following: 1. Wireless mouse (MWP2051-L) 2. Wireless keyboard (KB-22) 3. Receiver with cable (RX2051) 4. CD-ROM 5. User’s manual 6. 2 AA batteries for mouse 7. 2 AAA batteries for keyboard NoteIf any part is missing, please contact your dealer for a replacement immediately. Precaution For optimal performance, place the receiver at least 8 inches or 20 centimeters away from other electrical devices, such as the computer, the computer monitor, speakers or other external storage drives. Battery Warning! When replace the batteries, use alkaline. You may use rechargeable NiMH or other type of batteries, but do not mix then with alkaline. Do not mix used and new batteries together! BEFORE YOU BEGIN y Keep this installation guide for future reference! It contains Important Troubleshooting Information. y Keep your old mouse as a back-up device. HARDWARE INSTALLATION Connecting Receiver 1. Turn off your computer 2. Disconnect the current keyboard and mouse. 3. The receiver comes with a two-headed cable. You just need to plug the USB connector into USB port because the USB connector is for the keyboard and the mouse simultaneously. 4. Turn on your computer Inserting the Batteries The RF cordless keyboard uses 2 AAA batteries. They are inserted as follows: 1. Turn the keyboard over to show the underside. 2. Release the battery cover. 3. There are signs to indicate positive and negative orientation for the batteries. Take care to insert the batteries correctly. 4. Clip the battery cover back into place and make sure it is firmly closed. ID pairing button Battery cover ID pairing button Optical Lens Push and open 2 AA butteries The RF wireless mouse uses 2 AA batteries. They are inserted as follows: 1. Turn the mouse to the bottom side. 2. Remove the batteries cover (Upper case) by moving the opening tabs. 3. There are signs to indicate batteries' positive and negative poles. Follow the signs to place the batteries 4. Place the batteries cover back and make sure it is firmly closed Selecting the ID Channel The RF wireless keyboard & mouse provide the possibility of 256 different ID to avoid interference with other users of the same model RF wireless keyboards or mice. Before using the wireless keyboard and mouse, you must ensure that the same ID is set for the receiver, keyboard and mouse. Please follow the steps as below to set up: 1. Turn to the bottom of receiver and you will see a small button (ID code connection, refer to picture). 2. Establish communication between the receiver and the mouse (Select identification codes). y Press and release the connect ID button on the bottom of receiver. y Within 6 seconds of the previous step, press and release the “connect” button on bottom of the wireless mouse, and the “connect” small button on the top-right of the keyboard. y After above “connect” procedure, the same ID is selected on both of the receiver and the mouse. y Please move the mouse to operate its cursor and test some keyboard’s function. If there is problem, please do the connect setting procedure again or check the trouble shooting guide. Operation Guide Battery Low Indication When the voltage level of the battery goes down under the preset level, the scrolling wheel will flash at least three times on moving or clicking the mouse. Although the mouse can still work for a while, the user, at this time, should have a new set of batteries ready for replacement. Or, if the user has a companion charger base, and two re-chargeable batteries are inside the mouse, charge the mouse as soon as possible. Power off the mouse 1. Be sure the mouse is NOT in sleep mode. If it is, press any key to wake it up. 2. Press and hold the Connect button on the bottom of the mouse for more than 2 seconds. (The red light will go off while the Connect button is depressed.) 3. Wait until the red light flash once. Release the Connect button. 4. Now, the mouse is in power off mode. No operation can be done. Power on the mouse To activate the mouse again, press the Connect button on the bottom of the mouse once. (DO NOT depress the Connect button for more than 1.5 se…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID Label Location (FCC ID: NIYKB22)

JAMES JAMES 80.00 mm 40.00 mm S/N： Model:KB22 Made in ChinaMadeinChina Tested to Comply with FCC Standards TestedtoComply with FCCStandards FOR HOME OR OFFICE USEFORHOMEOROFFICEUSE FCC ID:NIYKB22FCCID:NIYKB22 78-100-644 0560 ! : : . :78-100- 644 : : . :78-100- 644

Page 2 Page 3 Page 4

FCC ID: NIYKB22 Report No.: RF940321L01 Operational Description The transmitter of the EUT (Cordless Slim Multimedia Keyboard) is powered by 3Vdc Batteries. The EUT use Open Loop Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: NIYKB22 Report No.: RF940321L011Report Format Version 2.0.2 FCC TEST REPORT REPORT NO.: RF940321L01 MODEL NO.: KB22 RECEIVED: Mar. 21, 2005 TESTED: Mar. 22, 2005 ISSUED: Mar. 25, 2005 APPLICANT: DEXIN CORPORATION ADDRESS: 14F-8, No 258, Lian Cheng Rd., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS:No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION:No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 16 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: NIYKB22 Report No.: RF940321L012Report Format Version 2.0.2 Table of Contents 1CERTIFICATION ......................................................................................................... 3 2SUMMARY OF TEST RESULTS................................................................................. 4 2.1MEASUREMENT UNCERTAINTY .............................................................................. 4 3GENERAL INFORMATION ......................................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................................ 5 3.1DESCRIPTION OF TEST MODES.............................................................................. 6 3.1.1CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 6 3.1.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 7 3.2GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................. 8 3.3DESCRIPTION OF SUPPORT UNITS........................................................................ 8 4TEST PROCEDURE AND RESULT ............................................................................ 9 4.1CONDUCTED EMISSION MEASUREMENT .............................................................. 9 4.2RADIATED EMISSION MEASUREMENT ................................................................... 9 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................................ 9 4.2.2TEST INSTRUMENT................................................................................................. 10 4.2.3TEST PROCEDURE ................................................................................................. 11 4.2.4TEST SETUP ............................................................................................................ 12 4.2.5EUT OPERATING CONDITION ................................................................................ 12 4.2.6TEST RESULTS ........................................................................................................ 13 4PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................... 15 5INFORMATION ON THE TESTING LABORATORIES .............................................. 16 FCC ID: NIYKB22 Report No.: RF940321L013Report Format Version 2.0.2 1 CERTIFICATION PRODUCT: Cordless Slim Multimedia Keyboard BRAND NAME: DEXIN MODEL NO: KB22 TEST SAMPLE: ENGINEERING SAMPLE TESTED: Mar. 22, 2005 APPLICANT: DEXIN CORPORATION STANDARDS: FCC Part 15, Subpart C (Section 15.227), ANSI C63.4 -2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Mar. 25, 2005 ( Andrea Hsia ) TECHNICAL ACCEPTANCE :, DATE:Mar. 25, 2005 Responsible for RF ( Gary Chang ) APPROVED BY :, DATE:Mar. 25, 2005 ( Cody Chang, Deputy Manager ) FCC ID: NIYKB22 Report No.: RF940321L014Report Format Version 2.0.2 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3Vdc from batteries 15.227 15.209 Radiated Emission TestPASS Minimum passing margin is –13.08dB at 185.51MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: MEASUREMENTFREQUENCYUNCERTAINTY Conducted emissions9kHz~30MHz2.44 dB 30MHz ~ 200MHz3.55 dB 200MHz ~1000MHz3.58 dB 1GHz ~ 18GHz1.10 dB Radiated emissions 18GHz ~ 40GHz0.91 dB FCC ID: NIYKB22 Report No.: RF940321L015Report Format Version 2.0.2 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Cordless Slim Multimedia Keyboard MODEL NO. KB22 POWER SUPPLY 3Vdc from batteries MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.095MHz NUMBER OF CHANNEL 1 ANTENNA TYPE Loop antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is a Keyboard. 2. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. FCC ID: NIYKB22 Report No.: RF940321L016Report Format Version 2.0.2 3.1 DESCRIPTION OF TEST MODES One channel was provided to this EUT. ChannelFrequency 127.095MHz 3.1.1 CONFIGURATION OF SYSTEM UNDER TEST EUT Test table (Power from battery) FCC ID: NIYKB22 Report No.: RF940321L017Report Format Version 2.0.2 3.1.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL Applicable to EUT configure mode PLCRE<1G Description -- x- Where PLC: Power Line Conducted EmissionRE<1G RE: Radiated Emission below 1GHz Pow…

Text truncated - open the document above for the full version.

FCC ID: NIYKB22 Report No.: RF940321L0115Report Format Version 2.0.2 4 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
