MWP103-P1MH HP Wireless Optical Mobile Mouse Page 1 of 12 1.0 Edition HP Wireless Optical Mobile Mouse MWP103-P1MH USER’S MANUAL (27MHz) Important Ergonomic Information Some experts believe that using any mouse or trackball may cause serious injury to hands, wrists, arms, neck, or back. If you feel pain, numbness, or weakness in these areas, see a qualified health professional. TO REDUCE THE RISK OF INJURY, FOLLOW THESE PRECAUTIONS:
Take frequent breaks, get up and walk around several times every hour.
Vary your tasks throughout the day.
Keep your shoulders relaxed with your elbows at your side. Position your keyboard and mouse so you do not have to reach.
Adjust your chair and keyboard so your upper arms and wrists are straight.
Avoid resting your wrists on sharp edges. System Requirement
Mouse compatible with standard Microsoft OS
3 rd button and wheel function require Win98/ ME/ 2000/ XP/ Vista
If your computer’s operating system is Windows 98/ 98SE, please prepare the Windows98 or 98SE compact disk for system’s request during the installation of mouse. Before you begin
Keep this installation guide for future reference! It contains Important Troubleshooting Information.
Keep your old PS/2 or USB mouse as back-up devices. MWP103-P1MH HP Wireless Optical Mobile Mouse Page 2 of 12 1.0 Edition Getting Started Congratulations on your purchase of an 800dpi Wireless Optical Mouse. By using the advanced RF technology a 360° operation is possible and no line-of-sight is required between the receiver and the mouse. The 800 high resolution will bring users the best operation accuracy and efficiency, especially when the pixel of display over 1024*768 pixel. It operates at twice the speed and only requires 1/4 of the space in comparison to a 400 dpi mouse. Battery and power consumption are always the key issues for a wireless product. There two modes of power on/off setting: by simply pressing the “connect” button; or slide the power ON/OFF switch in the bottom, and low-power Indicator on the mouse wheel will blink to indicate battery status makes MWP103-P1MH a smart companion for laptop users. Package Contains Your MWP103-P1MH Optical Mouse package includes the following: 1. The Wireless Optical mouse 2. USB Storable Receiver 3. User’s manual 4. 2 AAA Duracell Alkaline batteries Note ：If any part is missing, please contact your dealer for a replacement immediately. Precaution The optical mouse can not work on a glass or mirror surface. Avoid operating this mouse on a glossy surface; otherwise, this mouse may not operate normally. For consideration of saving battery power, it is strongly recommended to operate an optical mouse on a bright surface with fine texture to obtain lower power consumption of the high illumination LED. A very dark surface will cause higher power consumption. MWP103-P1MH HP Wireless Optical Mobile Mouse Page 3 of 12 1.0 Edition For optimal performance, place the receiver at least 8 inches or 20 centimeters away from other electrical devices, such as the computer, the computer monitor, speakers or other external storage drives. For a better transmission distance, avoid using this device on a metal plate or desktop because a large surface of iron, aluminum, copper and other metal will act as a shield or ground to the RF antenna of the mouse and receiver. Operating on a metal surface may shorten the transmission distance. If your notebook computer has a metal (contains Al or Mg) case, the metal housing of the LCD panel will isolate partial radiation of the RF signal from the mouse. This could possibly result in reducing the distance of transmission when you operate the mouse right in front of the notebook and when the receiver is connected on the back of the notebook. However, the RF mouse should work properly while you are operating the mouse just beside your desktop computer. Overview MWP103-P1MH HP Wireless Optical Mobile Mouse Page 4 of 12 1.0 Edition Hardware Installation Guide (Mouse) Insert the battery 1. Remove the battery compartment cover. 2. Insert 2 AAA alkaline batteries in correct direction indicated by the battery compartment label. 3. Replace the battery compartment cover. Connect the receiver with computer. 1. Turn off your computer 2. Disconnect the current mouse 3. Plug the USB connector (receiver) into USB port (computer). 4. Turn the computer on a. USB is a PnP device; you can plug the device no matter the computer is on or off. Of course, you can remove USB device in the same way. b. If the device is HD or pen drive or any device which can store files, stop the device than remove is the best way to protect. Synchronize the RF Mouse (Pairing) If the mouse is in sleep mode click the mouse button once to wake it up. 1. Bring the mouse within 1ft range from the receiver. MWP103-P1MH HP Wireless Optical Mobile Mouse Page 5 of 12 1.0 Edition 2. Power on the mouse. 3. Hold the mouse upside-down and use a pointed object, such as a pen tip, to click the CONNECT button (ID button) once. 4. Click the receiver’s connect button once, within 5 seconds after clicking the connect button on the mouse. The green LED will start blinking, when the connection is established. Move the mouse around to test if it was successful. 5. If the synchronization is not successful for some reason please a. Remove the batteries and unplug the receivers b. Wait for 20 sec then to try the step 1 to 4 again Note: * During normal use, please make sure that the mouse is no more than 3ft away from the receiver in order to have reliable connection. ** The green LED on the receiver will light up or blink while the mouse is being used. Operation Guide BATTERY LOW INDICATION When battery voltage level goes under the preset level, the blue LED on the mouse wheel will blink frequency. Although the mouse can still work for a while, the user, at this MWP103-P1MH HP Wireless Optical Mobile Mouse Page 6 of 12 1.0 Edition time, should have a new set of batteries ready for replacement a…
