NIYRFMP0102RF Wireless Mouse

RF Wireless Mouse User’s Manual RF WIRELESS MOUSE USER’S MANUAL Model No. RFMP0102 DEXIN Corporation. 20F-2. No. 37, Sec. 2, San-Ming Rd., Pan-Chiao City, Taipei Hsien, Taiwan, R.O.C. TEL: +886-2-3234-7193 FAX: +886-2-3234-7195 RF Wireless Mouse User’s Manual THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Federal Communications Commission Requirements The equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient of relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. l Consult the dealer or an experienced radio/TV technician for help. The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Wireless Mouse User’s Manual Getting Start (Please refer Fig.1 on Quick Installation) Welcome to purchase this Radio Frequency (RF) wireless multimedia mouse. By using the advanced RF technology, there is no line-of-sight required between receiver and this mouse. The mouse doesn't have to aim at the receiver when using. When you unfold the package, it should contains: 1. Mouse 2. Receiver 3. Driver Diskettes 4. User’s Manual If any part is missing, please contact your dealer for a replacement immediately. Connecting the Receiver (Please refer Fig.3 on Quick Installation) Before using this RF wireless mouse, you need to connect the included receiver to your computer first. PS/2 version If you are purchasing a PS/2 version, please follow the steps to finish the connecting: PS/2 mouse cable connector 1. Turn off your computer 2. Remove the current mouse 3. Plug the mouse cable end into the PS/2 mouse port 4. Restart the computer and the mouse will be automatically detected by Windows95, 98, or NT USB version If you are purchase a USB version RF multimedia mouse, just simply plug the USB connector into a type-A USB connector. USB version is hot-pluggable. Hence it is not necessary to turn off your computer to connect the receiver to your computer. USB connector RF Wireless Mouse User’s Manual Installing the Batteries (Please refer Fig.4-1, Fig.4-2 and Fig.5 on Quick Installation) This RF wireless mouse uses 2 AAA batteries. To apply the batteries, please follow the steps: 1. Turn the mouse to the bottom side 2. Remove the batteries cover by pressing the opening tabs with thumb and pull the battery cover(the top cover of the mouse) out 3. There are signs to indicate batteries' positive and negative poles. Follow the signs to insert the batteries 4. Place the batteries cover back and make sure it is firmly closed Setting up the ID Channels (Please refer Fig.4-3 and 4-4 on Quick Installation) This RF wireless mouse provides 64 different ID channels to avoid interference with other radio devices or other same model RF wireless mouses. Before you using the wireless mouse, please set the same ID channels for receiver and mouse. Please follow the steps to set up: 1. Adjust the ID channel of the receiver: Turn to the bottom of the receiver and you will see a DIP switch. Make sure the ID channel is different from other wireless mouses. The channel is set up by 6 switches with ON or OFF position. 2. Adjust the ID channel of the mouse: Remove the battery cover and batteries. You will see a DIP switch. Adjust the position to the same as the receiver. Setting up the RF wireless mouse Once you connect the receiver to your computer and install the batteries to the mouse, you can start to use the RF wireless mouse. Since the mouse is using RF wireless technology, it doesn't matter where you put the receiver. Even it is put behind the computer. When using the mouse, it's not necessary to aim at the receiver. The maximum effective distance between the mouse and the receiver is 30 feet (10 meters) depending on the situation of surrounding interference. The RF wireless mouse is full compatible with Windows95, 98, and NT. Plug the mouse to the appropriate interface port before you start the computer, and the mouse will function when the computer starts up. The mouse will be detected as a standard RF Wireless Mouse User’s Manual PS/2 or USB mouse. The right and left buttons are functional without any special driver. To utilized the middle and side (third and fourth) buttons, you need to install the included multimedia driver. Installing the Software (Please refer Fig.7 and Fig.8 on Quick Installation) To install the software, please follow the steps below to finish: 1. Insert the disk onto floppy driver 2. Type "A:\setup" (or "B:\setup") from RUN, START 3. Click OK or press ENTER 4. The setup program will guide you to finish the installation step by step After you finish the installation, select "Restart" to reboot your system and active multimedia hot keys and wheel scrolling functions. Using the Multimedia Functions When you install the included software driver the left, middle, and side (second, third, and fourth) buttons are all definable to …

Text truncated - open the document above for the full version.

BLOCK DIAGRAM OF 4-BUTTON RF MOUSE Model No. RFMP0102 BUTTON INPUT X-AXIS Encoder Y-AXIS Encoder 914.4MHz TX MODULE MOUSE CONTROLLER AND DATA ENCODER ID Switch

Photo # 1 Front View Photo # 2 Unit Partially Disassembled Photo # 3 Unit Partially Disassembled Photo # 4 Unit Partially Disassembled Photo # 5 Unit Partially Disassembled Photo # 6 Unit Partially Disassembled Photo # 7 Unit Partially Disassembled

1. Product Labeling 1.1 FCC ID label Model : RFMP0102 FCCID: NIYRFMP0102 S/N : 990700001 Made in China 78-100-136 3.6cm 2.5cm 1-2 Location of Label on EUT

FCC ID:NIYRFMP0102 TEST CONDICTION : VIDEO BW:100KHz , RESOLUTION BW:100KHz

NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 1/13 MEASUREMENT/TECHNICAL REPORT APPLICTNT: Dexin Corp MODEL NO.: RFMP0102 FCC ID: NIYRFMP∅1∅2 This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type: RF Wireless Mouse Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House : Neutron Engineering Inc. for Company : Name Dexin Corp Address 20F-2, No. 37, Sec. 2, San-Ming Rd., Pan-Chiao City, Taipei Hsien, Taiwan, R.O.C. Applicant Signature : Cliff Chen / Manager of R&D NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 2/13 CERTIFICATION We hereby certify that: The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15, Subpart C. NEUTRON ENGINEERING INC. 20, Alley 50, Lane 119, Dong Hwu Rd., P.O. Box 6-158, Nei Hwu, Taipei, Taiwan TEL °G(02) 2646-5426 FAX°G(02) 2646-6815 Prepared by : Sherry Kuo Reviewed by : Andy Chiu Approved by : George Yao Issued Date : Oct. 28, 1999 Report No. : NEI-FCCB-99175 Company Stamp: NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 3/13 Table of Contents 1. General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Test Methodology...................................................................................................................4 1-4 Test Facility............................................................................................................................4 2. System Test Configuration............................................................................................................ 2-1 EUT Configuration................................................................................................................5 2-2 EUT Exercise..........................................................................................................................5 2-3 Test Procedure........................................................................................................................5 2-4 Limitation................................................................................................................................6 2-5 Special Accessories.................................................................................................................6 2-6 Equipment Modifications.........................................................................................................6 2-7 Test Set-UP.............................................................................................................................7 2-8 Test Equipments......................................................................................................................8 3. Radiated Measurement Photos................................................................................................ Figure 3-1 Radiated Emission .......................................................................................................9 4. Radiated Emission Datas .............................................................................................................. 4-1 Reaiated Emission Data...........................................................................................................10 4-2 Field Strength Calculation.......................................................................................................12 4-3 Correction Factor Table VS Frequency....................................................................................13 NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 4/13 1. GENERAL INFORMATION 1-1. Product Description The Dexin Corp Model: RFMP0102 (referred to as the EUT in the report) is a RF wireless mouse that use radio frequency energy to operate a special designed receiver which associated with an IBM compatible PC. Carrier frequency designed for EUT operation is 914.40 MHz (fundamental frequency). It is considered as a low power transmitter. 1-2. Related Submittal(s) / Grant (s) 1-2-1.Models Covered This submittal(s) (test report) is intended for FCC ID: NIYRFMP∅1∅2 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. The receiver in compliance with Subpart B is authorized under a Declaration of Conformity by the Applicant. 1-2-2.Models Difference N/A 1-3. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4 (1992). Radiated testing was performed at an antenna to EUT distance 3 meters. 1-4. Test Facility The open area test site and conducted measurement facility used to collect the radiated data is located on the address of No. 132-1, Lane 329, Sec. 2, Palain Road, Shijr Jen, Taipei, Taiwan, R.O.C. of NEUTRON ENGINEERING INC. This site has been fully described in report dated Jun. 4, 1999 Submitted to your office, and accepted in a letter dated Sep. 02, 1999 (Reg. No. 95335). NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 5/13 2. System Test Configuration 2-1. EUT Configuration The EUT was placed on a turn table which is 0.8m above ground plane. The turn table shall rotate 360 degrees to determine the position of maximum emission level. EUT is set…

Text truncated - open the document above for the full version.

NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 1/13 MEASUREMENT/TECHNICAL REPORT APPLICTNT: Dexin Corp MODEL NO.: RFMP0102 FCC ID: NIYRFMP∅1∅2 This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type: RF Wireless Mouse Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House : Neutron Engineering Inc. for Company : Name Dexin Corp Address 20F-2, No. 37, Sec. 2, San-Ming Rd., Pan-Chiao City, Taipei Hsien, Taiwan, Applicant Signature °G Cliff Chen / Manager of R&D NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 2/13 CERTIFICATION We hereby certify that: The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15, Subpart C. NEUTRON ENGINEERING INC. 20, Alley 50, Lane 119, Dong Hwu Rd., P.O. Box 6-158, Nei Hwu, Taipei, Taiwan TEL°G(02) 2646-5426 FAX°G(02) 2646-6815 Prepared by: Sherry Kuo Reviewed by: Andy Chiu Approved by: George Yao Issued Date : Oct. 28, 1999 Report No. : NEI-FCCB-99175 Company Stamp: NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 3/13 Table of Contents 1. General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Test Methodology...................................................................................................................4 1-4 Test Facility............................................................................................................................4 2. System Test Configuration............................................................................................................ 2-1 EUT Configuration..................................................................................................................6 2-2 EUT Exercise..........................................................................................................................6 2-3 Test Procedure........................................................................................................................6 2-4 Limitation................................................................................................................................7 2-5 Special Accessories.................................................................................................................7 2-6 Equipment Modifications.........................................................................................................7 2-7 Test Set-UP.............................................................................................................................8 2-8 Test Equipments......................................................................................................................9 3. Radiated Measurement Photos................................................................................................. Figure 3-1 Radiated Emission .......................................................................................................11 4. Radiated Emission Datas .............................................................................................................. 4-1 Reaiated Emission Data...........................................................................................................12 4-2 Field Strength Calculation.......................................................................................................14 4-3 Correction Factor Table VS Frequency....................................................................................15 NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 4/13 1. GENERAL INFORMATION 1-1. Product Description The Dexin Corp Model: RFMP0102 (referred to as the EUT in the report) is a RF wireless mouse that use radio frequency energy to operate a special designed receiver which associated with an IBM compatible PC. Carrier frequency designed for EUT operation is 914.40 MHz (fundamental frequency). It is considered as a low power transmitter. 1-2. Related Submittal(s) / Grant (s) 1-2-1.Models Covered This submittal(s) (test report) is intended for FCC ID: NIYRFMP∅1∅2 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. The receiver in compliance with Subpart B is authorized under a Declaration of Conformity by the Applicant. 1-2-2.Models Difference N/A 1-3. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4 (1992). Radiated testing was performed at an antenna to EUT distance 3 meters. 1-4. Test Facility The open area test site and conducted measurement facility used to collect the radiated data is located on the address of No. 132-1, Lane 329, Sec. 2, Palain Road, Shijr Jen, Taipei, Taiwan, R.O.C. of NEUTRON ENGINEERING INC. This site has been fully described in report dated Jun. 4, 1999 Submitted to your office, and accepted in a letter dated Sep. 02, 1999 (Reg. No. 95335). NEUTRON EMC LAB. FCC ID: NIYRFMP∅1∅2 5/13 2. System Test Configuration 2-1. EUT Configuration The EUT was placed on a turn table which is 0.8m above ground plane. The turn table shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3m aw…

Text truncated - open the document above for the full version.
