NJA-LR260SITRANS LR260 Level Probing Radar

SITRANS Radar Transmitters SITRANS LR260 (PROFIBUS PA) Operating Instructions 12/2013 © Siemens AG 2013 Safety Guidelines: Warning notices must be observed to ensure personal safety as well as that of others, and to protect the product and the connected equipment. These warning notices are accompanied by a clarification of the level of caution to be observed. Qualified Personnel: This device/system may only be set up and operated in conjunction with this manual. Qualified personnel are only authorized to install and operate this equipment in accordance with established safety practices and standards. Unit Repair and Excluded Liability:  The user is responsible for all changes and repairs made to the device by the user or the user’s agent.  All new components are to be provided by Siemens Milltronics Process Instruments.  Restrict repair to faulty components only.  Do not reuse faulty components. Warning: Cardboard shipping package provides limited humidity and moisture protection. This product can only function properly and safely if it is correctly transported, stored, installed, set up, operated, and maintained. This product is intended for use in industrial areas. Operation of this equipment in a residential area may cause interference to several frequency based communications. Note: Always use product in accordance with specifications. Copyright Siemens AG 2013. All Rights Reserved Disclaimer of Liability This document is available in bound version and in electronic version. We encourage users to purchase authorized bound manuals, or to view electronic versions as designed and authored by Siemens Milltronics Process Instruments. Siemens Milltronics Process Instruments will not be responsible for the contents of partial or whole reproductions of either bound or electronic versions. While we have verified the contents of this manual for agreement with the instrumentation described, variations remain possible. Thus we cannot guarantee full agreement. The contents of this manual are regularly reviewed and corrections are included in subsequent editions. We welcome all suggestions for improvement. Technical data subject to change. MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments. Contact SMPI Technical Publications European Authorized Representative at the following address: Technical Publications Siemens AG Siemens AG Industry Sector Siemens Milltronics Process Instruments 76181 Karlsruhe 1954 Technology Drive, P.O. Box 4225 Deutschland Peterborough, Ontario, Canada, K9J 7B1 Email: [email protected]  For a selection of Siemens Milltronics level measurement manuals, go to: www. siemens.com/processautomation. Under Process Instrumentation, select Level Measurement and then go to the manual archive listed under the product family.  For a selection of Siemens Milltronics weighing manuals, go to: www. siemens.com/processautomation. Under Weighing Technology, select Continuous Weighing Systems and then go to the manual archive listed under the product family. i mmmmm Table of Contents Ta b l e o f C o n t e n t s Table of Contents ................................................................................................................. i Safety Notes .............................................................................................................................................1 Safety marking symbols ..............................................................................................................1 FCC Conformity ........................................................................................................................................1 The Manual ...............................................................................................................................................2 Application Examples ...................................................................................................................2 Technical Support ....................................................................................................................................2 Abbreviations and Identifications .............................................................................................3 SITRANS LR260 Overview ................................................................................................. 4 Specifications ...................................................................................................................... 5 Dimensions ...............................................................................................................................................9 Threaded Horn Antenna with extension ...............................................................................10 Threaded Horn dimensions ......................................................................................................11 Installation ......................................................................................................................... 13 Mounting location .................................................................................................................................14 Nozzle design ...............................................................................................................................14 Nozzle location .............................................................................................................................14 Orientation in a vessel with obstructions .............................................................................15 Easy Aimer .............................................................................................................................................16 Air Purging System (Optional) ............................................................................................................17 Universal Slotted Flange .......................................................…

Text truncated - open the document above for the full version.

SITRANS Radar Transmitters SITRANS LR260 (HART) Operating Instructions 12/2013 © Siemens AG 2013 Safety Guidelines: Warning notices must be observed to ensure personal safety as well as that of others, and to protect the product and the connected equipment. These warning notices are accompanied by a clarification of the level of caution to be observed. Qualified Personnel: This device/system may only be set up and operated in conjunction with this manual. Qualified personnel are only authorized to install and operate this equipment in accordance with established safety practices and standards. Unit Repair and Excluded Liability:  The user is responsible for all changes and repairs made to the device by the user or the user’s agent.  All new components are to be provided by Siemens Milltronics Process Instruments.  Restrict repair to faulty components only.  Do not reuse faulty components. Warning: Cardboard shipping package provides limited humidity and moisture protection. This product can only function properly and safely if it is correctly transported, stored, installed, set up, operated, and maintained. This product is intended for use in industrial areas. Operation of this equipment in a residential area may cause interference to several frequency based communications. Note: Always use product in accordance with specifications. Copyright Siemens AG 2013. All Rights Reserved Disclaimer of Liability This document is available in bound version and in electronic version. We encourage users to purchase authorized bound manuals, or to view electronic versions as designed and authored by Siemens Milltronics Process Instruments. Siemens Milltronics Process Instruments will not be responsible for the contents of partial or whole reproductions of either bound or electronic versions. While we have verified the contents of this manual for agreement with the instrumentation described, variations remain possible. Thus we cannot guarantee full agreement. The contents of this manual are regularly reviewed and corrections are included in subsequent editions. We welcome all suggestions for improvement. Technical data subject to change. MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments. Contact SMPI Technical Publications European Authorized Representative at the following address: Technical Publications Siemens AG Siemens AG Industry Sector Siemens Milltronics Process Instruments 76181 Karlsruhe 1954 Technology Drive, P.O. Box 4225 Deutschland Peterborough, Ontario, Canada, K9J 7B1 Email: [email protected]  For a selection of Siemens Milltronics level measurement manuals, go to: www. siemens.com/processautomation. Under Process Instrumentation, select Level Measurement and then go to the manual archive listed under the product family.  For a selection of Siemens Milltronics weighing manuals, go to: www. siemens.com/processautomation. Under Weighing Technology, select Continuous Weighing Systems and then go to the manual archive listed under the product family. i mmmmm Table of Contents Ta b l e o f C o n t e n t s Table of Contents ...............................................................................................................i Safety Notes ...........................................................................................................................................1 Safety marking symbols ............................................................................................................1 FCC Conformity ......................................................................................................................................1 CE Electromagnetic Compatibility (EMC) Conformity ...................................................................2 The Manual ............................................................................................................................................3 Technical Support .................................................................................................................................3 SITRANS LR260 Overview ................................................................................................5 Specifications ....................................................................................................................6 Power ............................................................................................................................................. 6 Performance................................................................................................................................. 6 Interface ........................................................................................................................................ 7 Mechanical (Easy Aimer model) ............................................................................................. 7 Mechanical (Threaded Connection model) .......................................................................... 8 Environmental .............................................................................................................................. 8 Process .......................................................................................................................................... 8 Approvals ...................................................................................................................................... 8 Programmer (infrared keypad) ................................................................................................ 9 Dimensions: .........................................................................................................................................10 Threaded Horn Antenna with extension .............................................................................11 Threaded Horn dimensions ....................................................................................................12 ......…

Text truncated - open the document above for the full version.

Siemens Canada Limited Siemens Milltronics Process Instruments 1954 Technology Drive, P.O. Box 4225 Peterborough, Ontario K9J 7B1 / Canada Tel.: (705) 745-2431 Fax: (705) 741-0466 www.siemens.com/sensorsystems Declaration to FCC Rule 15.256 For open air installations, the following conditions must be observed: The following warning note is applicable to Section 2.1.3, FCC Conformity in place of the current content. Affected manuals are:  A5E32220602 (SITRANS LR250 Hart/mA) (page 14)  A5E32221386 (SITRANS LR250 PROFIBUS) (page 14)  A5E32221411 (SITRANS LR250 Foundation Fieldbus) (page 13)  A5E32337683 (SITRANS LR260 Hart) (page 1)  A5E32337685 (SITRANS LR260 PA) (page 1) WARNING Changes or modifications not expressly approved by Siemens Milltronics could void the user’s authority to operate the equipment. Notes  This device has been tested and found to comply with the limits Class B digital device part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.  This device has also been tested and found to comply with the limits §15.256, Subpart C-Intentional radiators, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.  This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications, in which case the user will be required to correct the interference at his/her own expense.  This device is certified to measure levels in fixed or mobile enclosed tanks made from metal, concrete or materials with similar RF attenuating properties.  Devices equipped with the 3 inch or 4 inch antennas may be used to measure levels in open air environments or outside enclosed tanks, subject to the following conditions: o Devices shall be installed and maintained to ensure a vertically downward orientation of the transmit antenna’s main beam. o Devices shall be installed only at fixed locations. Devices shall not operate while being moved or while inside a moving container. o Hand-held applications and residential use are prohibited. Peterborough, June 30, 2014

July 8, 2014 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Application for Equipment Certification under FCC Part 15, Section 15.256 Operation of Level Probing Radars within the Band 24.05-29.00 GHz Product: SITRANS LR260 Model No.: 7ML5427 FCC ID: NJA-LR260 Dear Sir/Madam: As appointed agent for Siemens Canada Ltd. - Siemens Milltronics Process Instruments, we submit the application for equipment certification of the above product. Kindly review all required documents uploaded to your E-Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRA CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

SITRANS LR260 INTERNAL PHOTOS 1. Board stack 1.1 Board stack top 1.0 2.0 1.2 Board stack bottom 1.3 Board stack long side 1.4 Board stack opposite long side 1.5 Board stack short side 1.6 Board stack opposite short side 2. Board level 2.1 Display board top 2.2 Display board bottom 2.3 Board #1 top 2.4 Board #1 bottom 2.5 Board #2 top 2.6 Board #2 bottom 2.7 Board #3 top 2.8 Board #3 bottom 2.9 Board #4 top 2.10 Board #4 bottom

Restricted © Siemens AG 2014 All r ights reserved. siemens.com/answers Test Report3in and 4in LR2503in and 4in LR260Dr. Dominik Müller, May 2014 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 2 Dominik Müller/CT RTC ELE RFT-DE Testing of LR250/LR260 to show compliance with the new FCC Antennas to be characterized: • 3in and 4in LR250 horn antennas • 3in and 4in LR260 horn antennas Measurements:• Antenna beam pattern (normalized radiation pattern for E and H planes at 25 GHz):  Azimuth cut at angle 0 㼻 , 45 㼻 , and 90 㼻  Elevation range: -180 㼻 to +180 㼻 in 0.5 㼻 steps  Currently measurements just possible in 1.0 㼻 steps • Measurement of -3dB beamwidth (for E and H planes at 25 GHz) Deliverables:Test report that includes:• measurement results as data/graphs • statement that the antenna meets/does not meet requirements • diagram and pictures of measurement setup • calibration expiry date for instruments, chamber certification data and measurement error evaluation June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 3 Dominik Müller/CT RTC ELE RFT-DE Anechoic Chamber in Munich Perlach 1) Door2) Reference horn3) 360 㼻 positioner 4) Walkway absorber 1 2 3 4 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 4 Dominik Müller/CT RTC ELE RFT-DE Anechoic Chamber in Munich Perlach 1) Door2) DUT3) 360 㼻 positioner 4) 360 㼻 turn table 5) Walkway absorber6) Reference horn 1 234 5 6 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 5 Dominik Müller/CT RTC ELE RFT-DE Measurement Setup 1 2 3 4 5 1) DC power supply2) E-cal kit for network analyzer3) Network analyzer ZVA-504) Controller unit for positioner/turn table5) Computer with measurement software June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 6 Dominik Müller/CT RTC ELE RFT-DE Setup Alignment z y Elevation  1 2 3 4 1) 360 㼻 positioner 2) 360 㼻 turn table 3) Mounting unit for DUT/laser4) Lot laser for elevation alignment 1) Counter weight2) Cross laser for horizontal alignment 5 x y Azimuth  6 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 7 Dominik Müller/CT RTC ELE RFT-DE Reference Horn Antenna June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 8 Dominik Müller/CT RTC ELE RFT-DE Antennas under test 3inLR250 4inLR250 3inLR260 4inLR260 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 9 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 3inLR250 Horn Antenna H-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 10 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 3inLR250 Horn Antenna E-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 11 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 4inLR250 Horn Antenna H-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 12 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 4inLR250 Horn Antenna E-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 13 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 3inLR260 Horn Antenna H-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 14 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 3inLR260 Horn Antenna E-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 15 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 4inLR260 Horn Antenna H-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 16 Dominik Müller/CT RTC ELE RFT-DE Measurement Results – 4inLR260 Horn Antenna E-plane June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 17 Dominik Müller/CT RTC ELE RFT-DE Summary Antenna Ty pe HPBW 3dB < 12 㼻 㼻 Antenna side lobe gain limit (> 㼼 60 㼻 ) relative to main beam gain < 27 dB 3inLR250 OK OK 4inLR250 OK OK 3inLR260 OK OK 4inLR260 OK OK All values are measured at a frequency of 25.0 GHz.Measurement distance: app. 4.5 meter.Date of measurements: 2014-05-19, 2014-05-28, 2014-06-02 June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 18 Dominik Müller/CT RTC ELE RFT-DE Chamber Certification Data I Measurement of shielding attenuation according to EN 50147-1 ResultsThe shielding attenuation measurement at the specified measurement points (see figure 5.1 - 5.2) showed that the enclosure keeps the specified attenuation values. June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 19 Dominik Müller/CT RTC ELE RFT-DE Chamber Certification Data II Reflectivity Performance (Quiet Zone) Results At 0.80 GHz , the worst-case signal level was measured to be -36 dB while the specified (expected) reflectivity at the same frequency had been set to be better than -25 dB.At 3.00 GHz , the worst-case signal level was measured to be -52.3 dB while the specified (expected) reflectivity at the same frequency had been set to be better than -41 dB.At 10.0 GHz , the worst-case signal level was measured to be -50 dB while the specified (expected) reflectivity at the same frequency had been set to be better than -47 dB.The measurement results show that the installed chamber possesses better reflectivity levels than the expected ones in the design phase. Hence, the results for the antenna patterns measured in this chamber will have lower uncertainty levels than the ones expected. June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 20 Dominik Müller/CT RTC ELE RFT-DE Calibration Expiry Date For Instruments Instrument M odel Manufacturer Calibration Expiry Date Network Analyzer ZVA50 Rohde&Schwarz 2014-08-30 Calibration Unit ZV-Z55 Rohde&Schwarz 2014-09-02 Power Supply HMP2030 Hameg - Motor Controller Unit NCD Maturo GmbH - June 2014 Restricted © Siemens AG 2014 All r ights reserved. Page 21 Dominik Müller/CT RTC ELE RFT-DE Measurement Error Evaluation Instrument Error/ Specifications VNWA ZVA-50 see: R&S®ZVA Vector Network Analyzer Specifications - Version 11.00, March 2014http://cdn.rohde- schwarz.com/dl_downloads/dl_common_library/dl_brochur…

Text truncated - open the document above for the full version.

SITRANS LR260 Model: 7ML5427 FCC ID: NJA-LR260 Applicant: Siemens Canada Ltd. - Siemens Milltronics Process Instruments 1954 Technology Drive Peterborough, ON Canada K9J 6X7 In Accordance With Federal Communications Commission (FCC) Part 15, Subpart C, Section 15.256 UltraTech's File No.: SIE-009F15C256 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: July 8, 2014 Report Prepared by: Dan Huynh Issued Date: July 8, 2014 Tested by: Hung Trinh Test Dates: April 30, May 5, 18 & 19, 2014  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] Korea KCC-RRA 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E- 1119R CA2049 TL363_B TPTDP DA1300 FCC Part 15, Subpart C, Section 15.256 SITRANS LR260, Model: 7ML5427 FCC ID: NJA-LR260 ULTRATECH GROUP OF LABS File #: SIE-009F15C256 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 8, 2014 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION.............................................................................................................................................. 1 1.1. SCOPE ........................................................................................................................................................................ 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ........................................................................................................................ 1 1.3. NORMATIVE REFERENCES ...................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT.................................................................................................................... 2 2.1. CLIENT INFORMATION .............................................................................................................................................. 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ................................................................................................... 2 2.3. EUT’S TECHNICAL SPECIFICATIONS....................................................................................................................... 3 2.4. LIST OF EUT’S PORTS............................................................................................................................................... 3 2.5. ANCILLARY EQUIPMENT ........................................................................................................................................... 3 2.6. GENERAL TEST SETUP............................................................................................................................................. 4 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS............................................... 5 3.1. CLIMATE TEST CONDITIONS.................................................................................................................................... 5 3.2. OPEPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS................................................................ 5 EXHIBIT 4. SUMMARY OF TEST RESULTS ..................................................................................................................... 6 4.1. LOCATION OF TESTS ................................................................................................................................................ 6 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ....................................................................... 6 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ................................................ 6 EXHIBIT 5. TEST DATA ..................................................................................................................................................... 7 5.1. RADIATED EMISSION FROM UNINTENTIONAL RADIATORS (DIGITAL CIRCUITRY) [47 CFR §15.209].............. 7 5.2. FUNDAMENTAL EMISSION BANDWIDTH [47 CFR §15.256(f)] ................................................................................ 9 5.3. FREQUENCY STABILITY [47 CFR§§ 15.215(c) & 15.256] ....................................................................................... 10 5.4. RADIATED FUNDAMENTAL EMISSIONS [47 CFR 15.256(g)]................................................................................. 11 5.5. RADIATED UNWANTED EMISSIONS [47 CFR 15.256(h)] ....................................................................................... 12 EXHIBIT 6. TEST EQUIPMENT LIST ............................................................................................................................... 13 EXHIBIT 7. MEASUREMENT UNCERTAINTY................................................................................................................. 14 7.1. LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY ......................................................................... 14 7.2. RADIATED EMISSION MEASUREMENT UNCERTAINTY .......................................................................................14 FCC Part 15, Subpart C, Section 15.256 Page 1 of 14 SITRANS LR260, Model: 7ML5427 FCC ID: NJA-LR260 ULTRATECH GROUP OF LABS File #: SIE-009F15C256 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 8, 2014 Tel. #: 905-829-…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOGRAPHS Canada Ltd. - Siemens Milltronics Process Instruments SITRANS LR260, Model: 7ML547 FCC ID: NJA-LR260 A1 - 1 Radiated Emissions at 3 m Distance (30 - 1000 MHz) ANNEX 1 - TEST SETUP PHOTOGRAPHS Canada Ltd. - Siemens Milltronics Process Instruments SITRANS LR260, Model: 7ML547 FCC ID: NJA-LR260 A1 - 2 Radiated Emissions at 3 m Distance (above 1 GHz) ANNEX 1 - TEST SETUP PHOTOGRAPHS Canada Ltd. - Siemens Milltronics Process Instruments SITRANS LR260, Model: 7ML547 FCC ID: NJA-LR260 A1 - 3 Radiated Emissions at 3 m Distance (rear view)
