Your HTC phone User guide For CE / FCC 2011/01/25 Basics  Your phone Top panel 1 2 1 3.5mm audio jack 2 Microphone 3 POWER/LOCK Front panel 1 2  4 567 8 9 1 Earpiece 2 Touch screen 3 HOME 4 Microphone 5 MENU 6 BACK 7 SEARCH 8 1.3 megapixel front camera 9 Notification LED * You’ll see the HOME, MENU, BACK, and SEARCH buttons when your phone is switched on. And when you turn your phone sideways, these buttons rotate along with the screen. For CE / FCC 2011/01/25 4 Basics Left panel 1 2  1 VOLUME UP 2 VOLUME DOWN 3 USB connector Back panel 2 1  4 1 8 megapixel camera 2 Dual LED flash 3 Back cover 4 Speaker For CE / FCC 2011/01/25 Basics 5 Back cover Removing the back cover Remove the back cover to access the battery compartment and storage card and SIM card slots. With the phone switched off, hold your phone securely with the front facing down. Starting from the small opening at the bottom of the phone, lift the back cover and remove it completely. Replacing the back cover Please handle the back cover with care since your phone’s antennas are placed underneath it. Avoid twisting or bending the back cover. To get the best signal for calls, data connection, or GPS navigation, be sure to secure the back cover tightly to the phone. Align the back cover onto the phone’s top panel. Press all sides of the back cover towards the phone. You’ll hear clicks when the small tabs underneath the back cover are locked in place. 1. 2. 1. 2. For CE / FCC 2011/01/25 6 Basics Battery Your phone uses a rechargeable battery. Please use only original batteries and accessories that came with your phone or replacements that we recommend. How long the battery can last before it needs recharging depends on how you use your phone. Among these are the phone features and accessories you use (for example, leaving your Bluetooth connection always on uses more power). Long phone calls and frequent web browsing use up much battery. Also, consider your location: poor signal strength from your mobile network and extreme temperature make the battery work harder. Removing the battery When you take your phone out from the box, make sure to peel off the thin film of the battery that’s inside your phone. Pull the flap of the film to release the battery. 1. Take the back cover off. See “Removing the back cover”. 2. Lift the battery from the groove at the top of the battery compartment. For CE / FCC 2011/01/25 Basics 7 Inserting the battery Insert the battery (with its exposed copper contacts first) into the battery compartment. Then gently push the battery into place. Charging the battery The battery is partially charged when shipped. Before you turn on and start using your phone, it is recommended that you charge the battery. Some batteries perform best after several full charge/ discharge cycles. Only the power adapter and USB sync cable provided with your phone must be used to charge the battery. Do not remove the battery from the phone while you are charging it using the power or car adapter.   1. From the adapters that are included in your device package, select and insert the appropriate adapter to the AC charger. You can check the wall socket to know which adapter to use. 2. Connect one end of the USB cable to the AC charger. For CE / FCC 2011/01/25 8 Basics 3. Connect the smaller end of the USB cable to the USB Connector on the left side of your wireless device. 4. Plug in the AC charger to a wall socket to start charging the battery. As the battery is being charged, the notification LED shows a solid orange light. The light turns to solid green when the phone is fully charged. When you charge the battery while the phone is on, the charging battery icon is displayed in your phone’s status bar. After the battery has been fully charged, the charging battery icon turns to a full battery icon . As a safety precaution, the battery stops charging when it overheats. For CE / FCC 2011/01/25 Basics 9 Switching your phone on or off Switching your phone on Press and hold the POWER/LOCK button. When you turn on the phone for the first time, you’ll need to set it up. See the Getting started chapter for details. Switching your phone off 1. If the display is off, press the POWER/LOCK button to turn it back on, then unlock the screen by sliding down the bar on the lock screen. See “Unlocking the screen” in the Getting started chapter for details. 2. Press and hold the POWER/LOCK button for a few seconds. 3. When the Power options menu appears, tap Power off. Finger gestures TapWhen you want to type using the keyboard, select items onscreen such as application and settings icons, or press onscreen buttons, simply tap them with your finger. Press and holdTo open the available options for an item (for example, a contact or link in a web page), simply press and hold the item. For CE / FCC 2011/01/25 10 Basics Swipe or slideTo swipe or slide means to quickly drag your finger vertically or horizontally across the screen. DragPress and hold your finger with some pressure before you start to drag. While dragging, do not release your finger until you have reached the target position. FlickFlicking the screen is similar to swiping, except that you need to swipe your finger in light, quicker strokes. This finger gesture is always in a vertical direction, such as when flicking the contacts or message list. RotateFor most screens, you can automatically change the screen orientation from portrait to landscape by turning the phone sideways. When entering text, you can turn the phone sideways to bring up a bigger keyboard. PinchIn some apps, like Gallery or the web browser, you can “pinch” the screen using two fingers (for example, thumb and index finger) to zoom in or zoom out when viewing a picture or a web page. For CE / FCC 2011/01/25 Getting started Setting up your phone for the first time When you switch on your phone for the first time, you’ll be asked to set up your phone. You can choose your language, how you want to connect to the Interne…

Text truncated - open the document above for the full version.

Safety and regulatory guide  Safety and regulatory guide Please read before proceeding THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX. DO NOT REMOVE THE BATTERY PACK WHEN THE PHONE IS CHARGING. YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE THE DEVICE. Privacy restrictions Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your phone. Disclaimers ANY WEATHER, STOCK, OR OTHER INFORMATION, DATA, OR DOCUMENTATION (“ACCESSED INFORMATION”) ARE PROVIDED “AS IS” AND WITHOUT ANY WARRANTY OR ANY TECHNICAL SUPPORT. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, arising by law or otherwise, related to the Accessed Information, including without limitation any express or implied representation or warranty of merchantability, fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, or usefulness. Without limiting the foregoing, it is further understood that HTC and its Affiliates are not responsible for any use or of the Accessed Information or the results arising from such use, and that you use such information at your own risk. Safety and regulatory guide  Limitation of damages TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS AFFILIATES BE LIABLE TO YOU, ANY USER, OR THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, ARISING IN CONTRACT, TORT, OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS, REGARDLESS OF THE FORESEEABILITY THEREOF OR WHETHER HTC OR ITS AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. AND IN NO EVENT SHALL THE TOTAL LIABILITY OF HTC OR ITS AFFILIATES EXCEED THE AMOUNT RECEIVED FROM YOU, REGARDLESS OF THE LEGAL THEORY UNDER WHICH THE CAUSE OF ACTION IS BROUGHT. THE FOREGOING DOES NOT AFFECT ANY STATUTORY RIGHTS WHICH MAY NOT BE DISCLAIMED. Important health information and safety precautions When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages. Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product. To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions. Electrical safety This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product. Safety precautions for proper grounding installation CAUTION: Connecting to an improperly grounded equipment can result in an electric shock to your device. This product is equipped with a USB Cable for connecting with desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate  Safety and regulatory guide outlet which is properly installed and grounded in accordance with all local codes and ordinances. Safety precautions for power supply unit Use the correct external power source A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product. This product should be operated only with the following designated power supply unit(s). AC adapter: HTC, Model TC P00 Handle battery packs carefully This product contains a Lithium-ion polymer or Lithium-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60 ̊C (10 ̊F). WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (10° F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product. NOTE: This product should be operated only with the following designated Battery Pack(s). HTC, Model BG100(BTR650B). Take extra precautions Keep the battery or device dry and away from water or any liquid as it may cause a short circuit.  •  •  • Safety and regulatory guide 5 Keep metal objects away so they don’t come in contact with the battery or its connectors as it may lead to short circuit during operation. The phone should only be connected to products that bear the USB-IF logo or have completed the USB-IF compliance program. Do not use a battery that appears damaged, deformed, or discolored, or the one that has any rust on its casing, overheats, or emits a foul odor. Always keep the battery out of the reach of babies and small children, to avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed. Only use the battery with a charging system that has been qualified with the system per this standard, IEEE-Std-175- 006. Use of an unqualified battery or charger may present a risk of fire, explosion, le…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 January 26, 2011 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Sporton International Inc. January 26, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _Sporton International Inc._hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Smart Phone Model name: PG32100 We affirm that between SIEMIC and __Sporton Internationl Inc.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Roy Wu Contact information / address: No.52, HwaYa 1st Rd., Kwei-Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C.

Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 1 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 720510 1. External Photograph of EUT Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 2 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 3 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 List of Accessory: Specification of Accessory AC Adapter 1 Brand Name HTC Manufacturer Foxlink Model Name TCP300 AC Adapter 2 Brand Name HTC Manufacturer Delta Model Name TCP300 Battery 1 Brand Name HTC Manufacturer HT Model Name BG32100 Battery 2 Brand Name HTC Manufacturer Formosa Model Name BG32100 USB Cable 1 Brand Name COXOC Model Name DC M411 USB Cable 2 Brand Name Foxlink Model Name DC M411 Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 4 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 1 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 5 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 1 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 6 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 1 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 7 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 2 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 8 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 2 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 9 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Adapter 2 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 10 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Battery 1 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 11 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Battery 2 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 12 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 USB Cable 1 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 13 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 720510 USB Cable 2

Remark: 1. Cell phones or Cordless phones can have the Identifier in the battery compartment under certain conditions. a) The available label area on the phone is limited because they are relatively small and have many contoured surfaces, keypads, LCD displays, charge contacts and/or other connectors. b) The batteries for these devices are designed for easy removal and that the labels will be visible whenever the batteries are removed for charging or replacement c) The label will be readily visible at the time of purchase because the phone will be marketed without the battery installed.

Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 14 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 3. Internal Photograph of EUT Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 15 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 16 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 WWAN Diversity Antenna Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 17 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 WWAN Main Antenna Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 18 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 720510 Bluetooth & WLAN Antenna Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 19 of 19 TEL : 886-3-327-3456 Report Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 GPS Antenna

Photographs of EUT Report No.: EP0N2344-01 Model Name: PG32100 SPORTON INTERNATIONAL INC. Page Number : 1 of 1 TEL : 886-3-327-3456 Issued Date : Jan. 25, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 Antenna location Antenna Distance (cm) WWAN to WWAN Diversity 5.9 Bluetooth & WLAN to WWAN Diversity 0.2 WWAN to Bluetooth & WLAN 9.2 GPS Antenna (Rx Only) WWAN Antenna (Tx / Rx) Bluetooth & WLAN Antenna (Tx / Rx) WWAN Diversity Antenna (Rx Only)

SPORTON INTERNATIONAL INC. Page Number : 1 of 32 TEL : 886-3-327-3456 Report Issued Date : Jan. 14, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 FCC SAR Test Report Report No. : FA0N2344-01A FCC SAR Test Report APPLICANT : HTC Corporation EQUIPMENT : Smart Phone MODEL NAME : PG32100 FCC ID : NM8PG32100 STANDARD : FCC 47 CFR Part 2 (2.1093) IEEE C95.1-1999 IEEE 1528-2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) The product was received on Nov. 23, 2010 and completely tested on Dec. 24, 2010. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Roy Wu / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 32 TEL : 886-3-327-3456 Report Issued Date : Jan. 14, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : NM8PG32100 FCC SAR Test Report Report No. : FA0N2344-01A Table of Contents Revision History ................................................................................................................................................................ 3 1. Statement of Compliance .......................................................................................................................................... 4 2. Administration Data ................................................................................................................................................... 5 2.1 Testing Laboratory ............................................................................................................................................ 5 2.2 Applicant ........................................................................................................................................................... 5 2.3 Manufacturer .................................................................................................................................................... 5 2.4 Application Details ............................................................................................................................................ 5 3. General Information ................................................................................................................................................... 6 3.1 Description of Device Under Test (DUT) ........................................................................................................... 6 3.2 Applied Standards ............................................................................................................................................ 6 3.3 Device Category and SAR Limits ..................................................................................................................... 6 3.4 Test Conditions ................................................................................................................................................. 7 3.4.1 Ambient Condition .................................................................................................................................. 7 3.4.2 Test Configuration ................................................................................................................................... 7 4. Specific Absorption Rate (SAR) ................................................................................................................................ 8 4.1 Introduction ....................................................................................................................................................... 8 4.2 SAR Definition .................................................................................................................................................. 8 5. SAR Measurement System ........................................................................................................................................ 9 5.1 E-Field Probe...................................................................................................................................................10 5.1.1 E-Field Probe Specification ...................................................................................................................10 5.1.2 E-Field Probe Calibration ....................................................................................................................... 11 5.2 Data Acquisition Electronics (DAE) .................................................................................................................. 11 5.3 Robot ............................................................................................................................................................... 11 5.4 Measurement Server .......................................................................................................................................12 5.5 Phantom ..........................................................................................................................................................13 5.6 Device Holder ..................................................................................................................................................14 5.7 Data Storage and Evaluation ...........................................................................................................................16 5.7.1 Data Storage .........................................................................................................................................16 5.7.2 Data Evaluation ...........................................................…

Text truncated - open the document above for the full version.

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2010/12/21 System Check_Head_835MHz_101221 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_850_101221 Medium parameters used: f = 835 MHz; σ = 0.916 mho/m; ε r = 41.7; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.6 °C DASY4 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.21, 6.21, 6.21); Calibrated: 2010/5/18 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn577; Calibrated: 2010/8/18 - Phantom: SAM-Right; Type: QD 000 P40 C; Serial: TP-1383 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=100mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.03 mW/g Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 34.7 V/m; Power Drift = -0.010 dB Peak SAR (extrapolated) = 1.41 W/kg SAR(1 g) = 0.957 mW/g; SAR(10 g) = 0.623 mW/g Maximum value of SAR (measured) = 1.03 mW/g 0 dB = 1.03mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2010/12/23 System Check_Body_835MHz_101223 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_850_101223 Medium parameters used: f = 835 MHz; σ = 0.962 mho/m; ε r = 54.6; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.4 °C DASY4 Configuration: - Probe: EX3DV4 - SN3731; ConvF(8.84, 8.84, 8.84); Calibrated: 2010/9/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn778; Calibrated: 2010/10/22 - Phantom: SAM-Left; Type: QD 000 P40 C; Serial: TP-1477 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=100mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.966 mW/g Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 31.7 V/m; Power Drift = -0.010 dB Peak SAR (extrapolated) = 1.31 W/kg SAR(1 g) = 0.893 mW/g; SAR(10 g) = 0.590 mW/g Maximum value of SAR (measured) = 0.959 mW/g 0 dB = 0.959mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2010/12/21 System Check_Head_1900MHz_101221 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_101221 Medium parameters used: f = 1900 MHz; σ = 1.44 mho/m; ε r = 38.1; ρ = 1000 kg/m 3 Ambient Temperature：22.7 °C; Liquid Temperature：21.2 °C DASY4 Configuration: - Probe: ET3DV6 - SN1787; ConvF(5.09, 5.09, 5.09); Calibrated: 2010/5/18 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn577; Calibrated: 2010/8/18 - Phantom: SAM-Left; Type: QD 000 P40 C; Serial: TP-1477 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=100mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 4.93 mW/g Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 60.5 V/m; Power Drift = -0.009 dB Peak SAR (extrapolated) = 7.44 W/kg SAR(1 g) = 4.16 mW/g; SAR(10 g) = 2.15 mW/g Maximum value of SAR (measured) = 4.74 mW/g 0 dB = 4.74mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2010/12/24 System Check_Body_1900MHz_101224 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_101224 Medium parameters used: f = 1900 MHz; σ = 1.52 mho/m; ε r = 53.2; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.6 °C DASY4 Configuration: - Probe: EX3DV4 - SN3731; ConvF(7.13, 7.13, 7.13); Calibrated: 2010/9/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn778; Calibrated: 2010/10/22 - Phantom: SAM-Right; Type: QD 000 P40 C; Serial: TP-1383 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=100mW/Area Scan (91x91x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 4.38 mW/g Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.5 V/m; Power Drift = -0.051 dB Peak SAR (extrapolated) = 7.38 W/kg SAR(1 g) = 3.82 mW/g; SAR(10 g) = 1.93 mW/g Maximum value of SAR (measured) = 4.34 mW/g 0 dB = 4.34mW/g
