Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
1 GB Oregon Scientific™ OUTBREAKER Sports Watch (TS1X0 series) User Manual TABLE OF CONTENTS Introduction ...................................................................... 2 Key features ..................................................................... 3 OUTBREAKER watch ................................................... 3 Chest belt (TS120/ TS130 only) .................................... 3 Bicycle equipment ......................................................... 3 PC Kit ............................................................................ 4 LCD display symbols ..................................................... 4 How the OUTBREAKER works ....................................... 6 How the altimeter, thermometer and barometer work (TS 110 & 130 only) ....................................................... 6 A multi-system facility .................................................... 6 TOUR Mode .................................................................. 6 PC Kit ............................................................................ 6 Getting started ................................................................. 7 Turn on the watch (first-time use only) .......................... 7 Batteries ........................................................................ 7 Switch between Modes .................................................. 8 Switch between Mode options ....................................... 8 Change setting values ................................................... 8 Use the HI-GLO backlight .............................................. 8 Key lock ......................................................................... 8 Handling the product ..................................................... 8 CLOCK Mode .................................................................... 9 Set clock ........................................................................ 9 Set the alarm ................................................................. 9 Stopwatch ......................................................................... 9 Timer ................................................................................. 10 Temperature display (TS110 / TS130 Only) .................. 10 ALTI Mode (TS110 / TS130 Only) ....................................10 Access altimeter options ................................................ 11 Set current altitude and resolution ................................. 11 Set altitude alert ............................................................. 12 Recall altitude data ........................................................ 12 Switch between view options ......................................... 13 Additional view options .................................................. 13 BARO Mode (TS110 / TS130 Only) ................................. 13 Set sea-level pressure ................................................... 13 View sea-level pressure ................................................ 14 Weather forecast ........................................................... 14 TOUR Mode ...................................................................... 14 TOUR memory .............................................................. 14 Activate TOUR Mode ..................................................... 15 Record markers in TOUR Mode .................................... 15 Pause TOUR Mode ....................................................... 15 Deactivate TOUR Mode ................................................ 16 Clear all TOUR memories ............................................. 16 PULSE (Heart Rate) Mode (TS120 / TS130 only) ........... 16 Wearing the chest belt ................................................... 17 Training Zones ............................................................... 17 Set Training Zones alarm .............................................. 18 Track heart rate during training ..................................... 19 GB 2 BIKE Mode ........................................................................ 20 Set up for BIKE Mode .................................................... 20 Step 1: Attach the equipment to the bicycle .................. 20 Step 2: Enter wheel circumference ............................... 21 Access the BIKE Mode options ..................................... 22 View speed and cadence information ............................ 22 PC Kit ................................................................................ 22 PC Mode ............................................................................ 23 Set up for PC Mode ....................................................... 23 Use the software ............................................................ 23 PC Mode options ........................................................... 23 Download data ............................................................... 24 Effective use and range ................................................... 24 Aquatic and outdoor activities ........................................ 24 Safety and care ................................................................ 25 Safety precautions ......................................................... 25 Care instructions ............................................................ 25 Troubleshooting guide .................................................... 26 Specifications ................................................................... 27 Warnings ........................................................................... 29 Additional resources ....................................................... 29 INTRODUCTION Thank you for selecting the Oregon Scientific OUTBREAKER Sports Watch as your fitness product of choice. Your new sports watch is designed to give you many years of reliable service and includes the following features: •Clock, calendar, stopwatch and timer functions •Barometer with local and sea pressure readings (…
Text truncated - open the document above for the full version.
Test Setup FCC ID : NMT-TS1X0A External Photo –front (Cadence Sensor) External Photo – rear (Cadence Sensor) Test Setup FCC ID : NMT-TS1X0A External Photo – front (Speed Sensor) External Photo – rear (Speed Sensor)
IDT Technology Limited APPROVAL A/W (PDD) TEXT (ENG) TRANS A/W (CU) TEXT(PMGR) A/W (SUP) DATE DATE DATE DATE DATE DATE MODEL: TS110A CU : OSI-E TITLE: REAR CAB (REV.0) PREPARED BY: ZJCHUN (XX-ART) (DICK) DATE: 27 OCT 03 FILE :TS110A-COLOR SP F/O: P/N.: 052-002199Xxx MKTR:STEPHEN WOL: TS110A FCC ID: NMT-TS1X0A Made in China
Test Setup FCC ID : NMT-TS1X0A Internal Photo – 1 (Cadence Sensor) Internal Photo – 2 (Cadence Sensor) Test Setup FCC ID : NMT-TS1X0A Internal Photo – 1 (Speed Sensor) Internal Photo – 2 (Speed Sensor)
IDT Technology Limited APPROVAL A/W (PDD) TEXT (ENG) TRANS A/W (CU) TEXT(PMGR) A/W (SUP) DATE DATE DATE DATE DATE DATE MODEL: TS110A CU : OSI-E TITLE: REAR CAB (REV.0) PREPARED BY: ZJCHUN (XX-ART) (DICK) DATE: 27 OCT 03 FILE :TS110A-COLOR SP F/O: P/N.: 052-002199Xxx MKTR:STEPHEN WOL: TS110A FCC ID: NMT-TS1X0A Made in China
Block C, 9/F, Kaiser Estate, Phase 1, 41 Man Yue Street, Hunghom, Kowloon, Hong Kong. Tel (852) 2764 7873 Fax (852) 2765 6620 Email: [email protected] Web Site: http://www.idthk.com To : Intertek Testing Services Date : 13 November, 2003 Attn : Ms. Cecilia Ho Page : 1/1 From : Frankie Chan Subject : Speed/Cadence operation/transmission theory Speed/Cadence operation and transmission theory The speed sensor and cadence sensor which are activated by the spoke magnet. The modulated signal (125kHz burst) will be radiated from the antenna after triggered. The modulated signal is generated and controlled by the MCU. There are two different unique coding for speed and cadence sensor. The receiver will determine what RF signal is received and the decoding process will be done by the MCU in the receiver side. Actually, our speed and cadence sensor do not have the modulating signal (pure coded signed before modulation) for checking or monitoring. It is because the overall modulated signal is controlled by the MCU which include the modulated signal (125KHz) and the modulating signal (unique code). As a result, we cannot provide the modulating signal for your testing at the moment. Dated this 12 day of November 2003. By (Frankie Chan) Title Electronic Engineering Specialist
• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com IDT Technology Limited Application For Certification (FCC ID: NMT-TS1X0A) Transmitter 0312461 DL/ Sandy February 6, 2004 INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A ii MEASUREMENT/TECHNICAL REPORT IDT Technology Limited - MODEL: OREGON SCIENTIFIC TS130A OREGON SCIENTIFIC TS120A OREGON SCIENTIFIC TS110A FCC ID: NMT-TS1X0A February 6, 2004 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [08-20-02 Edition] provision. Report prepared by: Derek Leung Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, HONG KONG. Phone: 852-2173-8504 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A iii Table of Contents 1.0 General Description............................................................................................ 2 1.1 Product Description ............................................................................................ 2 1.2 Related Submittal(s) Grants ............................................................................... 2 1.3 Test Methodology............................................................................................... 3 1.4 Test Facility........................................................................................................ 3 2.0 System Test Configuration ................................................................................. 5 2.1 Justification ........................................................................................................ 5 2.2 EUT Exercising Software.................................................................................... 5 2.3 Special Accessories ........................................................................................... 5 2.4 Equipment Modification ...................................................................................... 6 2.5 Measurement Uncertainty .................................................................................. 6 2.6 Support Equipment List and Description ............................................................. 6 3.0 Emission Results ................................................................................................ 8 3.1 Field Strength Calculation................................................................................... 9 3.2 Radiated Emission Configuration Photograph................................................... 11 3.3 Radiated Emission Data ................................................................................... 12 4.0 Equipment Photographs ................................................................................... 16 5.0 Product Labelling.............................................................................................. 18 6.0 Technical Specifications................................................................................... 20 7.0 Instruction Manual ............................................................................................ 22 8.0 Miscellaneous Information ............................................................................... 24 8.1 Emissions Test Procedures .............................................................................. 25 INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: NMT-TS1X0A 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is transmitter operating at 125kHz. The EUT is powered by 12V d.c. (1 x 23A alkaline battery). It is activated by the spoke magnet. The signal will be radiated from the antenna after triggered. The signal will be displayed on the outbreaker watch. The Model: OREGON SCIENTIFIC TS120A and OREGON SCIENTIFIC TS110A are the same as the Model: OREGON SCIENTIFIC TS130A except the package of products. The Model: OREGON SCIENTIFIC TS120A and OREGON SCIENTIFIC TS110A including 1 wireless speed sensor and 1 wired cadence sensor. The Model: OREGON SCIENTIFIC TS130A including 1 wireless speed sensor and 1 wireless c…
Text truncated - open the document above for the full version.
Test Setup FCC ID : NMT-TS1X0A Radiated –front (Cadence) Radiated – rear (cadence) Test Setup FCC ID : NMT-TS1X0A Radiated – front (Speed) Radiated – rear (Speed)
2/F., Garment Centre, · Kowloon, · Hong Kong
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.125 MHz - 0.125 MHz | - |
