NMTPE9813D Pedmeter with 2.4GHz ANT

eHealth wireless activity monitor XL-25ANT A&D Medical eHealth wireless activity monitor Instruction Manual Thank you for selecting the A&D Medical wireless activity monitor. This activity monitor uses advanced sensor technology to detect steps in any dimension it is carried. It can be worn on the waist, around the neck or placed in pockets and handbags by using the adjustable strap or detachable clip provided. It is equipped with clock, alarm, 7-day memory, step counter, distance counter and calorie counter functions. NOTE: Do not immerse the activity monitor in water. Control Buttons 1. 2. 3. 1. SET: Enter Setting Mode; confirm and move to next setting option 2. DISP: Display calories burned and distance walked; increase values 3. MEM: Enter Memory Mode; decrease values 1 LCD Screen 1. : Calories burned is displayed 2. : Beep tone is Off 3. : Battery power is low 4. Displays mode banners, number of steps, calorie reading or distance walked 5. : Alarm is On 6. : Exercise timer is displayed 7. : The number of days (1-7) before, the displayed data was recorded 8. : 12 hour clock 9. Displays time or Setting Mode values 10. : Distance walked is displayed 11. : You are in Memory Mode 12. : There is a following page 13. : Smart indicators point to the correct button 14. : Step counter is On 15. : There is a previous page 2 110 11 12 13 2 3 4 7 8 9 6 5 14 15 16 17 19 18 / / / / / / / / / / / / / 16. : Calorie reading 17. : Distance unit (Miles / Kilometers) 18. : User’s stride length unit (Centimeters / Inches) 19. : Weight unit (Pounds / Kilograms) Getting Started To activate activity monitor: Press and hold any key until the screen is activated. Carrying the activity monitor: The XL-25ANT can be carried on the waist, around the neck or in pockets and handbags by using the adjustable strap or detachable clip provided. If the activity monitor is idle for over 4 seconds, it will display the counted steps after 16 continuous steps have been taken. If less than 16 steps have been taken the activity monitor will judge the steps as invalid vibrations and will not count them. If the interval between steps is less than one second, the number of steps will increase one-by-one. NOTE: When the user’s step interval is 1-2 seconds, it will count the steps inconsistently. If the interval is over 4 seconds the activity monitor will exit the counting function and resume after 16 steps have been taken. 3 Setting time and user data: To effectively use the activity monitor for calculating calories burned (based on step count and user body weight) and distance walked (based on step count and length of user’s stride) you are advised to set the time and your user data in the Setting Mode. Refer to Setting Mode in this manual. NOTE: Remember to set the time and your user data after every battery replacement. Operation Mode The XL-25ANT has 4 modes of operation. The Main Mode is the default display mode, which displays the current step count and time. To enter other modes, press the buttons as shown below. Main Mode: In the Main Mode, you can: • view the time and current step count (default), calories burned, distance walked and exercise time • turn the step counter On or Off 4 To view the current calories burned and distance walked: Press DISP. The display sequence is: calories burned / and distance walked / . The exercise time with icon / is also displayed. To turn the step counter On or Off: In situations where you do not need to record step count, you can turn Off the step counter. Press and hold SET and MEM at the same time for 2 seconds until the following screen is displayed. To turn On the step counter, repeat the same action. / indicates step counter is On. or Remark: If the step counter is Off, there will be no step, calorie and distance calculation or recording into memory. The current step count, calories burned, distance walked, and exercise timer will be reset automatically to zero at midnight. Setting Mode: In the Setting Mode, you can set the time, alarm On/Off and alarm time, user’s weight and stride length, and beep tone On/Off. 5 1. Press SET to enter the Setting Mode. 2. Wait for the setting option to flash, then press DISP or MEM to set values. You can press and hold these buttons to rapidly set the values. 3. Wait 3 seconds for the activity monitor to automatically confirm and move to the next setting option. The setting sequence is: stride length unit, stride length value, weight unit, weight value, 12/24 time format, time (hour and minute), alarm On/Off, alarm time (hour and minute) (if alarm On is selected) and beep tone On/Off. NOTE: You can press SET to skip through settings. REMARK: Press any button to silence an activated alarm. If not deactivated, the alarm will be activated at the same time the following day. Memory Mode: In the Memory Mode, you can view the records of your steps and calories burned for the past 7 days. 1. MEM to enter the Memory Mode. 2. Press DISP or MEM to select which day to view. NOTE: • When toggling between days, the record displayed will be of the same category (either step count or calories burned). • When viewing a day’s record, the activity monitor will automatically toggle for 3 seconds between step count and calories burned display. 6 REMARK: Toggle through all 7-day records to return to the Main Mode. To reset records: You cannot reset the records manually. The activity monitor is designed to automatically reset the records. Data Transfer Mode: In the Data Transfer Mode, the activity montor will send data to an available ANT receiver. 1. Press and hold DISP for 3 seconds to enter Data Transfer Mode. 2. Press and hold DISP for 3 seconds to exit Data Transfer Mode. NOTE: This product is designed to work with different ANT wireless solutions. Please refer to the ANT receiver for more detailed instructions on linking the scale to the receiver. Battery Replacement The XL-25ANT uses a CR2032 3V battery, which has already been installed. / Indicates battery powe…

Text truncated - open the document above for the full version.

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z 2.450GHz PRODUCT SPECIFICATION nRF24AP1 Single Chip 2.4 GHz Radio Transceiver with Embedded ANT Protocol Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0 Page 4 of 25 September 2006 1. BLOCK DIAGRAM DVDD VDD=3VVDD=3V XC1 XC2 100Ω+j175Ω IREF VDD_PA=1.8V VSS_PA=0V ANT1 ANT2 22kΩ VSS=0V VSS=0V VDD=3V VSS=0VVSS=0V ANT Protocol Engine PORTSEL 1 Mbps RF Transceiver UART or Synchronous Serial Interface BR2 / SCLK BR1 / SFLOW EXT32K RTS / SEN RXD / SIN TXD / SOUT SUSPEND / SRDY SLEEP / SMSGRDY Timing Figure 1: nRF24AP1 with external components. The “ANT Protocol Engine” shown in Figure 1 is described in the “ANT Message Protocol and Usage” document.

INTERTEK TESTING SERVICE Report No.: HK10051139-1 FCC ID: NMTPE981 Equipment Photographs Model :XL-25ANT (External)

Rated Voltage DC 3.0V Rated Voltage DC 3.0V Size:16X1.3MM, FONT 5PT Size:10X1MM, FONT 4PT Size:11.4X3MM, FONT 5PT Size:11X2MM, FONT 8PT Size:5.6X7.9MM

INTERTEK TESTING SERVICE Report No.: HK10051139-1 FCC ID: NMTPE981 Equipment Photographs Model : XL-25ANT (Internal) INTERTEK TESTING SERVICE Report No.: HK10051139-1 FCC ID: NMTPE981 Equipment Photographs Model : XL-25ANT (Internal) INTERTEK TESTING SERVICE Report No.: HK10051139-1 FCC ID: NMTPE981 Equipment Photographs Model : XL-25ANT (Internal) INTERTEK TESTING SERVICE Report No.: HK10051139-1 FCC ID: NMTPE981 Equipment Photographs Model : XL-25ANT (Internal)

FCC ID: NMTPE981 Technical description of XL-25ANT / PE981 XL-25ANT / PE981 is a sensor type pedometer. Among the traditional pendulum type pedometer, accelerator pedometer can allow users to place the device in any dimensions to detect step counts. Users can place it in and hanging to bags, placing in shirt pockets, surely, it can be traditionally hang on the waist. The schematic should be fashionable and suitable for daily use. It can accurately detect the number of steps, calculate calorie consumptions and walked distance, 7-Day memory is available for monitoring user's daily performance. Easy-to-use user interface and simple LCD are designed for all ranges of users. The microcontroller calculates the number of steps and transmits the data to the receiver via a radio link that operates at 2.450 GHz only. The data wireless transferred through NRF24AP1 system upload to PC review the data. The NRF24AP1 is a single-chip 2.4GHz transceiver for operation in the world wide ISM band. The radio front end uses GFSK modulation. it has user configurable parameters like frequency channel, output power and air data rate. The brief circuit description is listed as follows: U1 act as Microcomputer U2 act as Micromachined Accelerometer UU1 act as 2.4GHz transceiver U3 act as Regulator PRODUCT SPECIFICATION Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0 Page 1 of 25 September 2006 Single chip 2.4 GHz Transceiver with Embedded ANT protocol FEATURES • Integrated PAN (Personal Area Network) • Drop in wireless networking with simple serial interface • 2.4GHz Worldwide ISM Band • Ultra-low power (coin cell battery) • Fully scaleable • Broadcast, Acknowledged or Burst Data • Message rates 0.5Hz -> 200Hz (8byte data payload) • Burst transfer rates up to 20kbps (true data throughput) • Public and private networks • 1 Mbps RF data rate • 125 RF channels APPLICATIONS • Sensor Networks • Industrial Automation • Home Automation • Sports Monitoring GENERAL DESCRIPTION The nRF24AP1 is an ultra-low power single-chip radio transceiver with embedded ANT protocol for personal area networks. The transceiver’s RF operating frequency range falls within the world-wide 2.4 - 2.5 GHz RF ISM band, allowing for regulatory compliance and product sales into global markets. QUICK REFERENCE DATA Parameter Value Unit Minimum supply voltage 1.9 V Maximum output power 0 dBm Maximum data rate (over the air) 1000 kbps Temperature range -40 to +85 °C Sensitivity -80 dBm Average current consumption as low as 30 μA Peak current consumption TX @-5dBm 13.5mA for 350us mA Peak current consumption RX 22mA for 600us mA Max # of simultaneous connections 1 >65000 connections Max # of simultaneous independent 2-way connections 4 2-way connections Maximum sustained transfer rate (all data – no overhead) 2 20 kbps CR2032 Battery life in a typical sensor application 3 5 years Table 1: nRF24AP1 quick reference data 1 Using Shared Channel Network 2 Transfer rate refers to data rate of the end application’s message payload 3 Message interval of 2s, 1 hour/day usage Simple Networks Complex Networks Independent Networks Broadcast Networks Shared Channel Networks nRF24AP1 ANT by Dynastream © 2005 all ri ghts reserved PRODUCT SPECIFICATION nRF24AP1 Single Chip 2.4 GHz Radio Transceiver with Embedded ANT Protocol Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0 Page 2 of 25 September 2006 The transceiver consists of the ANT fully integrated protocol engine, frequency synthesizer, power amplifier, crystal oscillator and modulator, and can be interfaced to a host micro controller over either a synchronous or asynchronous serial interface. Designed to run on a wrist-watch coin cell battery, current consumption of the device is extremely low - a typical sensor application can operate on approximately 30μA average current consumption. Short, low peak current transitions are battery friendly. The embedded ANT protocol makes for easy, low cost integration. Eliminating the need for 3 rd party RF protocol implementation, the on-chip ANT protocol combined with the 2.4GHz transceiver enables system and application developers to interact with the nRF24AP1 as a black box wireless solution. The simple serial interface (asynchronous or synchronous) to the device allows for flexibility and scalability from ultra-low power sensors (30μA) through to higher data rate (20kbps) applications implemented in a multitude of network configurations. Networks can be scaled from as little as two nodes to thousands. With 2 32 unique IDs, multiple radio frequencies, public and private network management and scalable data rates, an unlimited number of network configurations and applications are possible. Prior to reading this document, the “ANT Message Protocol and Usage” document should be read to gain understanding of the ANT protocol capabilities. REFERENCES Ref. No. Doc. No. Revision Title 1 D00000794 1.0 Interfacing with ANT General Purpose Chipset and Modules (Part of nRF24AP1 Specification) 2 D00000652 1.36 ANT Message Protocol and Usage Table 2 nRF24AP1 referenced documents For more information see: www.nordicsemi.no PRODUCT SPECIFICATION nRF24AP1 Single Chip 2.4 GHz Radio Transceiver with Embedded ANT Protocol Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway - Phone +4772898900 - Fax +4772898989 Revision: 1.0 Page 3 of 25 September 2006 TABLE OF CONTENTS FEATURES .....................................................................................................................................................1 APPLICATIONS.............................................................................................................................................1 GENERAL DESCRIPTION............................................................................................................................1 QUICK REFERENCE DA…

Text truncated - open the document above for the full version.

LS01611 L C D LCD-PDD-019-A TITLE DOC NO. MODEL NO. CAD REF. PAGE OF APPD: CHKD: DRAWN: DIVISION: SCHEMATIC DIAGRAM ISSUE REVISION A B C D 1 3 4 5 6 D C B A 2 DATE: MADE BY APPROVED BY IDT TECHNOLOGY LTD. 1 2 PE981 1.0 First Release For Production May 7,2010 JYZOU ZQWu PE981LS0.SCH JYZOU ZQWU ALEX CHAN substrate connect to vss FOR RS232 PAGE 2 OF 3 For Programming DATE 2010/5/7 DATE 2010/5/7 DATE 2010/5/7 X1 32.768KHz C7A matching C6 27pF B1 3V RESET + C5 22uF C19 0.1uF C1 0.1u C2 3.3n C3 3.3n C4 3.3n C8 0.1u C9 0.1u C10 0.1u C11 0.1u C12 0.1u C15 0.1u C16 0.1u C17 0.1u C13 0.1u C14 0.1u Frequency output R2 16K C18 0.47uF L1 35mH BZ1 R5 47K Q1 BC846 SET DISP MEM C20 0.1uF C21 0.1uF C22 0.1uF 1 OUT 2 VDD 3 NC 4 VSS U3 S80825CNNB SOUT /CLK GND 1 COM0 2 COM1 3 COM2 4 COM3 5 COM4 6 COM5 7 COM6 8 SEG0 9 SEG1 10 SEG2 11 SEG3 12 SEG4 13 SEG5 14 SEG6 15 SEG7 16 SEG8 17 SEG9 18 SEG10 19 SEG11 20 SEG12 21 SEG13 22 SEG14 23 SEG15 24 SEG16 25 SEG17 26 SEG18 27 SEG19 LCD1 PE980LCD R3 NC S G D Q3 BSH205 R4 1M T1 T2 T3 T4 T5 T6 T7 T8 /RESET C24 0.1uF J8 J1 J2 J3 J4 J5 J6 J7 1 N/C 2 XOUT 3 YOUT 4 ZOUT 5 VSS 6 VDD 7 /SLEEP 8 N/C 9 0G-DETECT 10 G-SELECT 11 N/C 12 N/C 13 SELFTEST 14 N/C U2 MMA7361LT J9 1 OSC1 2 OSC2 3 TEST 4 /RESET 5 MCU/MPU 6 K11/BREQ 7 K10/EV_IN 8 K07 9 K06 10 K05 11 K04 12 K03 13 K02 14 K01 15 K00 16 P17/CMP_PM1/AD7 17 P16/CMP_P1/AD6 18 P15/CMP_M0/AD5 19 P14/CMP_P0/AD4 20 P13/S_RDY 21 P12/S_CLK 22 P11/S_OUT 23 P10/S_IN 24 AVDD 25 AVSS 26 AVREF 27 VDD 28 P07/D7 29 P06/D6 30 P05/D5 31 P04/D4 32 P03/D3 33 P02/D2 34 P01/D1 35 P00/D0 36 R00/A0 37 R01/A1 38 R02/A2 39 R03/A3 40 R04/A4 41 R05/A5 42 R06/A6 43 R07/A7 44 R10/A8 45 R11/A9 46 R12/A10 47 R13/A11 48 R14/A12 49 R15/A13 50 R16/A14 51 R17/A15 52 R20/A16 53 R21/A17 54 R22/A18 55 R23/RD 56 R24/WR 57 R25/CL 58 R26/FR/TOUT 59 R27/T_OUT 60 R30/CE0 61 R31/CE1 62 R32/CE2 63 R33/CE3 64 R34/F_OUT 65 R35 66 R36 67 R37 68 VSS 69 R50/BZ 70 R51/BACK/BZ 71 COM0 72 COM1 73 COM2 74 COM3 75 COM4 76 COM5 77 COM6 78 COM7 79 COM8 80 COM9 81 COM10 82 COM11 83 COM12 84 COM13 85 COM14 86 COM15 87 SEG0 88 SEG1 89 SEG2 90 SEG3 91 SEG4 92 SEG5 93 SEG6 94 SEG7 95 SEG8 96 SEG9 97 SEG10 98 SEG11 99 SEG12 100 SEG13 101 SEG14 102 SEG15 103 SEG16 104 SEG17 105 SEG18 106 SEG19 107 SEG20 108 SEG21 109 SEG22 110 SEG23 111 SEG24 112 SEG25 113 SEG26 114 SEG27 115 SEG28 116 SEG29 117 SEG30 118 SEG31 119 SEG32 120 SEG33 121 SEG34 122 SEG35 123 SEG36 124 SEG37 125 SEG38 126 SEG39 127 SEG40 128 SEG41 129 SEG42 130 SEG43 131 SEG44 132 SEG45 133 SEG46 134 SEG47 135 SEG48 136 SEG49 137 SEG50 138 COM31/SEG51 139 COM30/SEG52 140 COM29/SEG53 141 COM28/SEG54 142 COM27/SEG55 143 COM26/SEG56 144 COM25/SEG57 145 COM24/SEG58 146 COM23/SEG59 147 COM22/SEG60 148 COM21/SEG61 149 COM20/SEG62 150 COM19/SEG63 151 COM18/SEG64 152 COM17/SEG65 153 COM16/SEG66 154 VREF 155 SPRG 156 CLKW 157 VEPEXT 158 RXD 159 SCLK 160 TXD 161 CE 162 CD 163 CC 164 CB 165 CA 166 VC5 167 VC4 168 VC3 169 VC2 170 VC1 171 OSC3 172 OSC4 173 VD1 174 VDD1 175 VSS1 176 VOSC U1 S1C8F360 RXD TXD CLK GND VDD SPRG RESET J10 R1 510K +3V +3V +3V F_O S_VDD F_O +3V /SLEEP /SLEEP S_VDD RTS/SEN1 TXD/SOUT RXD/SIN BR2/SCLK EXT32K ANT-ON SLEEP/SMSGRDY SUSPEND/SRDY GND LS01611 L C D LCD-PDD-019-A TITLE DOC NO. MODEL NO. CAD REF. PAGE OF APPD: CHKD: DRAWN: DIVISION: SCHEMATIC DIAGRAM ISSUE REVISION A B C D 1 3 4 5 6 D C B A 2 DATE: MADE BY APPROVED BY IDT TECHNOLOGY LTD. 2 2 PE981 1.0 First Release For Production May 7,2010 JYZOU ZQWu PE981LS0.SCH JYZOU ZQWU ALEX CHAN PAGE 3 OF 3 BR2/SCLK BR1/SFLOW EXT32K RXD/SIN TXD/SOUT SLEEP/SMSGRDY RTS/SEN DVDD VSS XC2/OUT XC1/IN SUSPEND/SRDY VDD_PA ANT1 ANT2 VSS_PA VDD VSS IREF VSS VDD VSS PORTSEL VDD (Normal high, active low) To Main PCB DATE 2010/5/7 DATE 2010/5/7 DATE 2010/5/7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 UU1 NRF24AP1 CC1 33n RR2 1M CC2 22p CC3 22p CC4 2n2 CC5 4p7 CC6 NC CC7 NC CC8 NC CC9 3pF ANT1 ANTENNA RR3 22K QQ2 NTR4101P CC15 2n2 CC11 10n CC12 10n RR4 1M CC17 0.1u CC18 47p CC14 470p LL3 4.3nH LL4 4.3nH LL1 18nH LL2 6.8nH XX1 16MHz QQ1 BC846 RR1 1M CC10 0.5pF CC13 1pF BR2/SCLK RXD/SIN TXD/SOUT SLEEP/SMSGRDY SUSPEND/SRDY RTS/SEN ANT-ON VBAT ANT-VDD EXT32K ANT-VDD RTS/SEN1 ANT-VDD GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report No.: HK10051139-1 IDT Technology Limited Application For Certification (Original Grant) (FCC ID: NMTPE981) Transmitter Prepared and Checked by: Approved by: Signed On File Kenneth Wong Engineer Chan Chi Hung, Terry Senior Lead Engineer Date: July 21, 2010 INTERTEK TESTING SERVICES Report No.: HK10051139-1 FCC ID: NMTPE981 i GENERAL INFORMATION IDT Technology Limited BRAND NAME: CHECKPOINT, MODEL: XL-25ANT FCC ID: NMTPE981 Grantee: IDT Technology Limited Grantee Address: Block C, 9/F., Kaiser Estate, Phase 1, 41 Man Yue Street, Hunghom, Kowloon, Hong Kong. Contact Person: Wu Zhi Qiang Tel: 0755-29701188 Fax: 0755-29709021 e-mail: [email protected] Manufacturer: N/A Manufacturer Address: N/A Brand Name: CHECKPOINT Model: XL-25ANT Additional model and Brand name: PE981 Oregon Scientific Type of EUT: Transmitter Description of EUT: 3D Pedmeter with 2.4GHz ANT Serial Number: N/A FCC ID: NMTPE981 Date of Sample Submitted: May 24, 2010 Date of Test: June 3, 2010 Report No.: HK10051139-1 Report Date: July 21, 2010 Environmental Conidtions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: HK10051139-1 FCC ID: NMTPE981 ii SUMMARY OF TEST RESULT IDT Technology Limited BRAND NAME: CHECKPOINT, MODEL: XL-25ANT FCC ID: NMTPE981 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 N/A Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for Remote Control) 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement(for 902- 928MHz or 2.4GHz) 15.249 / RSS-210 A2.9 Pass Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 N/A Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: HK10051139-1 FCC ID: NMTPE981 iii Table of Contents 1.0 General Description.........................................................................................1 1.1 Product Description ............................................................................................1 1.2 Related Submittal(s) Grants ...............................................................................1 1.3 Test Methodology...............................................................................................1 1.4 Test Facility ........................................................................................................1 2.0 System Test Configuration ..............................................................................2 2.1 Justification ........................................................................................................2 2.2 EUT Exercising Software ...................................................................................2 2.3 Special Accessories ...........................................................................................2 2.4 Equipment Modification ......................................................................................2 2.5 Measurement Uncertainty ..................................................................................2 2.6 Support Equipment List and Description ............................................................3 3.0 Emission Results ...............................................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No: HK10051139-1 FCC ID: NMTPE981 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model : XL-25ANT Model No.: XL-25ANT Job No.: HK10051139-1 INTERTEK TESTING SERVICE Report No: HK10051139-1 FCC ID: NMTPE981 Configuration Photographs Worst-Case Radiated Emissions (Back View) Model : XL-25ANT Model No.: XL-25ANT Job No.: HK10051139-1
