 EN Wireless PC-connected Professional Weather Station Model: WMR180 / WMR180A USER MANUAL CoNtENtS Introduction ................................................................1 Packaging contents ...................................................1 Base station .............................................................. Wind sensor / temperature & humidity sensor ......... Rain gauge ...............................................................2 Assembly parts .........................................................2 Solar panel ................................................................2 Accessories - Sensors ...............................................2 overview ..................................................................... 2 Top view ....................................................................2 Back view ..................................................................2 LCD display ..............................................................2 Wind sensor ..............................................................3 Rain gauge ...............................................................3 Outdoor temperature / humidity sensor ....................3 USB Communications hub ........................................3 Getting started ............................................................4 Set up remote wind sensor .......................................4 Set up remote temperature / humidity sensor ...........4 Set up rain gauge .....................................................4 Set up base station ...................................................4 Verify connection .......................................................5 Wind sensor ..............................................................5 Temperature / humidity sensor .................................5 Rain gauge ...............................................................5 USB hub ...................................................................5 Mounting / placing of sensors ..................................6 Remote wind sensor on existing pole .......................6 Temperature / humidity sensor mounted separately .6 Rain gauge ...............................................................6 Clock reception ..........................................................7 Clock / Calendar .........................................................7 Moon phase ................................................................7 Auto scanning function .............................................8 Weather forecast ........................................................8 temperature and humidity ........................................ 8 Temperature and humidity trend ...............................8 Wind chill / direction / speed .....................................8 UVI / Barometer / Rainfall ..........................................9 UV Index ...................................................................9 Barometer .................................................................9 Rainfall .................................................................... 0 Backlight ...................................................................1 0 Reset .........................................................................1 0 Specifications ...........................................................1 0 Precautions ...............................................................11 About oregon Scientific .......................................... 11 EU declaration of conformity ..................................11 FCC statement ..........................................................11 INtRodUCtIoN Thank you for selecting the Oregon Scientific™ Wireless PC-connected Professional Weather Station (WMR80 / WMR80A). The base station is compatible with other sensors. To purchase additional sensors, please contact your local retailer. Sensors with this logo are compatible with this unit. NotE Please keep this manual handy as you use your new product. It contains practical step-by-step instructions, as well as technical specifications and warnings you should know about. PACkAGING CoNtENtS BASE StAtIoN  x base station  x USB Communication Hub 4 x AA UM-3 .5V batteries  x 6V adaptor  x USB cable WINd SENSoR / tEMPERAtURE & HUMIdItY SENSoR  x Wind Sensor ( x Wind Vane Above and  x Anemometer Below)  x Aluminium pole 2 x AA UM-3 .5V batteries 2 x AAA UM-4 .5V batteries  x Temperature / Humidity Sensor casing  x Temperature / Humidity Sensor 4 x Screws (Type A)  x sensor connector WMR180_UM_EN_R7.indd 12011/5/30 3:56:17 PM LIGHT 12345 6 E U /U K 1 2 3 4 5 6 1 2 3 A 4 B C D 1 2 7 8 9 3 6 5 4 10 11 WMR180_UM_EN_R7.indd 22011/5/30 3:56:30 PM 3 EN B Wind Speed / Wind direction / Wind Chill Area 1 2 3 45 6 . Wind speed reading (m/s, kph, mph or knots) 2. Outdoor wind sensor battery is low 3. Wind speed level indicator 4. Wind speed level description 5. Minimum wind chill is displayed 6. Wind direction display C UVI / Barometer / Rainfall Area 1 1 3 4 5 6 2 7 . UVI / barometer / rainfall reading is displayed 2. Past 24hrs rainfall is displayed 3. Outdoor UV / rain sensor battery is low 4. UVI / barometric pressure (mmHg, inHg or mb) / rainfall readings (in or mm) for the current hour 5. UVI level indicator 6. Maximum UV is displayed 7. UVI / barometric pressure / rainfall historical bar chart display d Clock / Calendar / Moon Phase Area 1 3645 2 . AM / PM 2. Time zone offset 3. Timestamp is displayed 4. Clock signal reception indicator 5. Time / date / calendar 6. Moon phase WINd SENSoR 1 2 3 4 . Wind direction 2. Wind vane casing 3. Anemometer 4. Solar power socket RAIN GAUGE Base and funnel: 1 2 3 . Rain gauge 2. Battery compartment 3. RESEt button 1 2 . Funnel 2. Indicator oUtdooR tEMPERAtURE / HUMIdItY SENSoR 1 2 3 4 . Temperature / humidity sensor casing 2. Solar power socket 3. RESEt button 4. Battery compartment USB CoMMUNICAtIoNS HUB FRONT VIEW BACK VIEW 1 1 2 3 S E A…

Text truncated - open the document above for the full version.

Report Number: 60/760.11.127.01Page 1 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 FCC – Test report Report Number: 60/760.11.127.01 Date of Issue: 27 July 2011 Model: WMR180A Product Type:Wireless Hub Applicant:IDT Technology Limited Address:Block C, 9/F, Kaiser Estate, Phase 1, : 41 Man Yue Street, Hunghom, Kowloon, Hong Kong Production Facility:IDT Technology Limited Address:Block C, 9/F, Kaiser Estate, Phase 1, 41 Man Yue Street, Hunghom, Kowloon, Hong Kong Test Result: „Positive†Negative Total pages including Appendices: 32 TÜV SÜD Hong Kong Ltd. is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO 17025. TÜV SÜD Hong Kong Ltd. reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Hong Kong Ltd. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Hong Kong Ltd. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 60/760.11.127.01Page 2 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 1 Table of Contents 1 Table of Contents.............................................................................................. 2 2 Details about the Test Laboratory......................................................................... 3 3 Description of the Equipment Under Test................................................................ 4 4 Summary of Test Standards/ Results..................................................................... 5 5 General Remarks.............................................................................................. 6 6 Emission Test Results........................................................................................ 7 6.1 Radiated Emission Test.............................................................................. 7 6.2 20dB Bandwidth measurement.................................................................... 14 6.3 Band edge measurement........................................................................... 15 6.4 Conduct Emission Test............................................................................... 17 7 Appendix A....................................................................................................... 20 Photographs of EUT 8 Appendix B....................................................................................................... 29 Photographs of Test Set Up 9 Appendix C....................................................................................................... 32 Product Information Report Number: 60/760.11.127.01Page 3 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 2 Details about the TestLaboratory Details about the Test Laboratory Company name: TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin HK. Telephone:852 2776 1323 Fax:852 2776 1372 Company name: Neutron Engineering Inc. 3,Jinshagang 1st Road, ShiXia, Dalang Town, DongGuan, China FCC Registered Test Site Number 319330 Report Number: 60/760.11.127.01Page 4 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 3 Description of the Equipment Under Test Description of the Equipment Under Test Product:Wireless Hub Model no.:WMR180A Serial number:NIL Options and accessories: NIL Rated Voltage:120 VAC Rated Current:NIL Rated Power:NIL Frequency:60 Hz Description of the EUT:EUT Main unit size:18cm x 11 cm x 5 cm Supply by power supply: Model:CSD0600300U-22 Input:120 VAC 60 Hz 80mA Output:6 VDC 300mA Report Number: 60/760.11.127.01Page 5 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 4 Summary of Test Standards and Results Emission Tests Test Condition Test Requirement Test MethodPagesTest Result PassFailN/A Radiated Emission (Fundamental & Spurious Emission) FCC Part 15 Section 15.249 & 15.209 ANSI C63.4:2003 7-16 Conducted Emission on AC 150kHz to 30MHz FCC Part 15 Section 15.207 ANSI C63.4:2003 17-20 Report Number: 60/760.11.127.01Page 7 of 32 TÜVSÜD HONG KONG LTD., 3/F, W est W ing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 6 Emission Test Results 6.1 Radiated Emission Test (Fundamental) Date of test: 29 June 2011Test Result Passed Test requirement : FCC Part 15 Section 15.249 Not Passed Test method: ANSI C63.4:2003 Operating mode : On mode Antenna polarity : Horizontal Remarks: NIL Freq.Ant.Pol.Ant./CF PeakAV (M Hz)H/VCF(dB)(dBuV/m) (dBuV/m) 914.99H2.94114.0094.00X/F 76.50 Note ReadingA ct.Limit Peak (dBuV/m) Peak (dBuV/m) 73.56 Remark:The EUT was placed on the top of the turntable in test site area. The test shall be made in the operation mode. The turntable was rotated by 360 degrees to determine the position of the highest radiation. For emissions measurement, the …
