032B0100 PDA Description: Architecture: The 032B0100 Personal Digital Assistant is a Freescale MC9328MXL based device running Windows CE.Net (CE v4.2). The embedded radio in the PDA is a National Semiconductor LMX9820A Bluetooth radio operating in RFComm port mode. The LMX9820A radio module has been previously been certified by FCC as LMX9820ADONGLE, FCC ID ED9LMX9820ASM. Operation: The PDA is used as a graphic user interface for mobile aviation fueling operations. The PDA communicates with another LMX9820A radio enabled device on a fueling truck. The PDA enables and disables the fueling operation and displays the quantity of fuel dispensed.

Operational Description for the LMX9820A Bluetooth Module. The National Semiconductor LMX9820A Bluetooth module used in the 032B0206 board is used to transmit serial data at 115,200bps to an external Bluetooth device. The connections include Power, Ground, Transmit, Receive, Clear to Send, Ready to Send, Host Wakeup, Power down, and ENV0, a control signal to switch the radio into configuration mode. The antenna used is a Tyco surface mount, embedded 4.5db antenna, (p/n 1513150-1). The Bluetooth module is a frequency hopping device with 79 hopping frequencies. The Syn-tech Systems 032B0206 Bluetooth transceiver Board is mounted externally to a 032B0100 Personal Digital Assistant powered by an Arm9 based Dragonball processor.

FCC PART 15.247 FHSS TEST REPORT APPLICANT SYN-TECH SYSTEMS, INC. ADDRESS 100 FOUR POINTS WAY TALLAHASSEE FLORIDA 32305 FCC ID NR3-032B0100 PRODUCT DESCRIPTION PDA WITH BLUETOOTH DATE SAMPLE RECEIVED June 21, 2006 DATE TESTED June 23, 2006 TESTED BY Nam Nguyen APPROVED BY Mario de Aranzeta C.E.T. TIMCO REPORT NO. 209ZUT6TestReport TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 Certificate # 0955-01 APPLICANT: SYN-TECH SYSTEMS, INC. FCC ID: NR3-032B0100 REPORT: V:\S\SYN\209ZUT6\209ZUT6TestReport.doc Page 2 of 21 TABLE OF CONTENTS STATEMENT OF COMPLIANCE.................................................................................. 3 GENERAL INFORMATION AND EQUIPMENT UNDER TEST........................................ 4 TEST EQUIPMENT LIST............................................................................................. 5 TEST PROCEDURE ................................................................................................... 6 POWER LINE CONDUCTED INTERFERENCE............................................................. 7 NUMBER OF HOPPING CHANNELS ......................................................................... 10 DWELL TIME OF A HOPPING CHANNEL .................................................................. 11 20 dB BANDWIDTH ................................................................................................. 12 CARRIER FREQUENCY SEPARATION ...................................................................... 13 POWER OUTPUT ..................................................................................................... 14 SPURIOUS EMISSIONS AT ANTENNA TERMINALS .................................................. 15 FIELD STRENGTH OF SPURIOUS EMISSIONS......................................................... 16 RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND............... 18 RF EXPOSURE REQUIREMENT ............................................................................... 20 Certificate # 0955-01 APPLICANT: SYN-TECH SYSTEMS, INC. FCC ID: NR3-032B0100 REPORT: V:\S\SYN\209ZUT6\209ZUT6TestReport.doc Page 3 of 21 STATEMENT OF COMPLIANCE This equipment has been tested in accordance with the standards identified in the referenced test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report and demonstrate that the equipment complies with the appropriate standards. I attest that the necessary measurements were made by me or under my supervision, at Timco Engineering, Inc. located at 849 NW State Road 45, Newberry, Florida 32669 USA. Authorized by: Mario de Aranzeta Function: Engineer Date: August 16 , 2006 Certificate # 0955-01 APPLICANT: SYN-TECH SYSTEMS, INC. FCC ID: NR3-032B0100 REPORT: V:\S\SYN\209ZUT6\209ZUT6TestReport.doc Page 4 of 21 GENERAL INFORMATION AND EQUIPMENT UNDER TEST Applicable Standards: FCC Part 15.247 Test Result: The test results relate only to the items tested. Manufacturer: SYN-TECH SYSTEMS, INC. 100 FOUR POINTS WAY TALLAHASSEE FLORIDA 32305 FCC ID: NR3-032B0100 Product Description: PDA WITH BLUETOOTH DEVICE Operating Frequency: 2402 - 2480 MHz Max. Output Power (conducted): Conducted - dBm ERP - EIRP Type of Modulation: FHSS- Bluetooth Primary Power 3.6 Vdc Power Supply: Secondary Power 110VAC/50-60Hz Test Item: Pre-Production Antenna Type: Antenna spec attached Antenna Connector: None-permanently attached Modification to the EUT: None Test Facilities Timco Engineering Inc. 849 N.W. State Road 45, Newberry, FL 32669. Test Exercise (e.g. software description, test signal, etc.) The test article was set in a continuous transmit mode of operation Test Conditions Temperature: 78°F Humidity: 55% Certificate # 0955-01 APPLICANT: SYN-TECH SYSTEMS, INC. FCC ID: NR3-032B0100 REPORT: V:\S\SYN\209ZUT6\209ZUT6TestReport.doc Page 5 of 21 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/27/04 3/26/07 3-Meter OATS TEI N/A N/A Listed 1/11/06 1/10/09 Biconnical Antenna Eaton 94455-1 1057 CAL 12/12/05 12/12/07 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/29/05 4/29/07 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303a01690 CAL 12/8/05 12/8/07 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 12/7/05 12/7/07 Analyzer Tan Tower Spectrum Analyzer HP 8566B OPT 462 3188A07786 3144A20661 CAL 12/7/05 12/7/07 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 12/8/05 12/8/07 LISN Electro- Metrics EM-7820 2682 CAL 4/28/05 4/28/07 Log-Periodic Antenna Eaton 96005 1243 CAL 12/14/05 12/14/07 Certificate # 0955-01 APPLICANT: SYN-TECH SYSTEMS, INC. FCC ID: NR3-032B0100 REPORT: V:\S\SYN\209ZUT6\209ZUT6TestReport.doc Page 6 of 21 TEST PROCEDURE POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4- 2003 using a 50uH LISN. Both lines were observed with the UUT transmitting. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. BANDWIDTH 20 dB: The measurements were made with the spectrum analyzer's resolution bandwidth and the span set as shown on plot. POWER OUTPUT: The RF power output was measured radiated EIRP. ANTENNA CONDUCTED EMISSIONS: The RBW = 100 kHz, VBW = 300 kHz and the span set to 10 MHz and the spectrum was scanned from 30 MHz to the 10 th Harmonic of the fundamental. Above 1 GHz the resolution bandwidth was 1 MHz and the VBW = 3 MHz and the span to 50 MHz. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using an Agilent spectrum receiver with pre-selector. The bandwidth (RBW) of the spectrum receiver was 100 kHz up to 1 GHz and 1 MHz above 1 GHz with an appropriate sweep speed. The VBW above 1 GHz was 3 MHz. Th…
