850 Band 1W Small Cell Amplifier User Guide Page 1 Communication Components Inc. 89 Leuning Street South Hackensack, NJ 07606 Phone: 201-342-3338 Fax: 201-342-3339 www.cciproducts.com UMTS 850 Band MetroCell Amplifier CCI Model Number SCB-850-1W-ALU-OD-1 USER’S GUIDE Product Description: SCB-850-1W-ALU-OD-1 UMTS MetroCell Amplifier (850 Band): The CCI UMTS 850 Band MetroCell Amplifier Module consists of a Digital Pre-Distortion Downlink power amplifier capable of generating a minimum 1 Watt UMTS signal. Operation Description: The SCB-850-1W-ALU-OD-1 850 Band MetroCell Amplifier Module is designed to supply a maximum output power level of 1 Watt (+30.0 dBm). Although the gain of the Amplifier is fixed, the output can be adjusted by setting the input power level. Operation and Installation Instructions: The following instructions should be followed when installing the unit in service: • Apply a 48 VDC input voltage to the POE+ Input connector of the 850 Band MetroCell Amplifier Module. • Insure that the DC Source is capable of delivering up to 0.4 Amps at 48 VDC. • Apply a UMTS signal up to +24 dBm (250 mW) to the BTS Input port of the 850 Band MetroCell Amplifier Module. Note: “System Level” usage (see typical site installation block diagram on page 2) is based on the input signal from the Small Cell BTS set to the maximum rated power of +24 dBm. • Check the Antenna 2 output to insure proper output power is present (BTS IN – 6.0 dB ≤ ANT OUT ≤ BTS IN -4.0dB). • Check the TX/RX output to insure proper output power is present (BTS IN + 5.5dB (± 0.5 dB)). • Adjust the input power level to insure the output power level is in compliance with the values indicated in the table on page 2. 850 Band 1W Small Cell Amplifier User Guide Page 2 Communication Components Inc. 89 Leuning Street South Hackensack, NJ 07606 Phone: 201-342-3338 Fax: 201-342-3339 www.cciproducts.com Figure 1 - “Typical Site Installation Config.” Block Diagram for AWS 80W Cell Extender Setting the RF Output Power to the SCB-850-1W-ALU-OD-1 MetroCell Amplifier: The RF output power is not adjustable on the UMTS850 Band Amplifier. The user must adjust the RF input power to the SCB-850-1W-ALU-D-1 such that the RF output power level does not exceed the levels shown below in order for the RF output spectral emissions to be compliant with the FCC spurious emissions limit of -13 dBm outside of the assigned frequency block. These levels must not be exceeded. The total output power at the TX/RX terminal of the device must not exceed the peak output power of 1W. *Note: The Maximum RF Output Power is after any passive losses after the Small Cell Amplifier Module such as filters and cables. This equipment complies with Part 22 of the FCC rules. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. In order to comply with FCC rules for RF exposure, it must be observed that the antenna connected to this equipment be fixed on an outdoor structure and that it must have a minimum separation distance of 10 meters between it and any person. CCI does not provide antennas, cables and/or coupling devices for this product. Only antennas, cables and/or coupling devices which are authorized by ALU (Alcatel-Lucent) should be utilized with this UMTS 850 Band MetroCell Amplifier. Center Channel Frequency (MHz) Maximum RF Output (Watt)* 869 - 894 1

CCI SCB-850-1W-ALU-OD-1 Block Diagram COMMUNICATION COMMUNICATIONCOMMUNICATION COMMUNICATION COMPONENTS INC COMPONENTS INCCOMPONENTS INC COMPONENTS INC Extending Wireless Coverage 89 Leuning Street Phone: 201-342-3338 2 nd Floor Fax: 201-342-3339 South Hackensack, NJ 07606 www.cciproducts.com

05/07/2014 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent FCC On our behalf, I appoint Jenny Gibbs of Nemko USA, Inc. at 2650 FM 407, Suite 255P, Bartonsville, Tx, 76226 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Communication Components, Inc located at 89 Leuning St., South Hackensack, NJ 07606. Dated this 07th Day of May 20 14 Agency agreement expiration date: 05/07/2015 By: Dennis Nathan Signature Printed Title: President On behalf of : Communication Components, Inc. 201-342-3338 Telephone: COMMUNICATION COMMUNICATIONCOMMUNICATION COMMUNICATION COMPONENTS INC COMPONENTS INCCOMPONENTS INC COMPONENTS INC Extending Wireless Coverage 89 Leuning Street Phone: 201-342-3338 2 nd Floor Fax: 201-342-3339 South Hackensack, NJ 07606 www.cciproducts.com
Page 2

COMMUNICATION COMPONENTS INC. NON-DISCLOSURE AGREEMENT (Mutual) for the #SCB-850-1W-ALU-OD-1 2002 THIS AGREEMENT is entered into, by and between Communication Components, Inc., 89 Leuning Street, 2 nd Floor, South Hackensack, NJ 07606 (“CCI”) and ________________ (“Company”), with offices at ___________________ (“Company”). As CCI and Company recognizes that there is a need to disclose to each other certain confidential information, and to provide for mutual agreements to protect such confidential matters, CCI and Company agree as follows: • Information in writing (orally disclosed material must be summarized within thirty (30) days of disclosure in writing) designated as “Confidential” or “Proprietary,” including, but not limited to, product planning information, product specifications, and other proprietary and trade secret business and technical information, shall be held in strictest confidence and not disclosed to any third parties. CCI and Company mutually agree they may disclose such information to responsible employees with a bona fide need to know, provided all such employees are instructed not to disclose such information to third parties. Each party agrees to exercise reasonable care, consistent with its protection of its own confidential information, to prevent such use or disclosure to third parties. • Each party shall not use this information for any commercial purpose other than for general product planning purposes without the prior written permission of the other party. • Information shall not be deemed confidential and the receiving party shall have no obligation regarding any information which is already known to the receiving party at the time it is disclosed, is or becomes publicly known through no wrongful act of the receiving party, is rightfully received from a third party without restriction on disclosure and without breach of this Agreement, is independently developed by the receiving party, is furnished to a third party by the disclosing party without similar restriction on disclosure, or is disclosed pursuant to a requirement of a government agency, court order, or otherwise by law. • All confidential information shall remain the property of the disclosing party, and upon written request of either party, the other party shall return all confidential information disclosed and all copies thereof. Nothing contained in this agreement shall be construed as granting any rights, by license or otherwise, to any confidential information disclosed. All confidential information is provided “as is.” Each party makes no warranties, express, implied, or otherwise, regarding its accuracy, completeness or performance. • This agreement shall not be assignable by either party without the written consent of the other party. This document constitutes the entire agreement between the parties with respect to disclosure of confidential information, and shall supersede all previous communications, representations, understandings and agreements, either oral or written, between the parties or any official or representative thereof. Any changes to this agreement must be in writing and signed by authorized principals on both sides. • Unless earlier terminated by written agreement of both parties, this agreement shall remain in effect for five (5) years from the date as executed below by duly authorized representatives. • The laws of the State of New Jersey shall govern this agreement, without reference to conflict of law principles, and shall be effective on the last of the dates indicated below. COMMUNICATION COMPONENTS, INC. ____________________________________ Signed: ________________________________ Signed: __________________________________ Name: _________________________________ Name: ___________________________________ Title: __________________________________ Title: _____________________________________ Date: __________________________________ Date: _____________________________________

05/07/14 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: NT3SCB8501WA Product Name: UMTS 850 Metrocell Amplifier Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, we hereby request that the following documents be held confidential: • SCB8501WAschematics.pdf (Schematics) • SCB8501WApartslist.pdf (Parts Lists) • SCB8501WAinternal.pdf (Internal Photos) These materials contain trade secrets and proprietary information that is not customarily released to the public. The product is generally installed in secure locations which are not accessible to the general public. The product is only serviceable by Communication Components personnel or a factory-trained and licensed representative. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. We respectfully request that this information remains confidential for a period of no less than 10 years. Dated this 07th Day of May 20 14 By: Dennis Nathan Signature Printed Title: President On behalf of: Communication Components Inc. Communication Components, Inc. 89 Leuning Street Phone: 201-342-3338 South Hackensack, NJ 07606 Fax: 201-342-3339

SCB-850-1W-ALU-OD-1 RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform the FCC that access to equipment and related documentation supplied by Communication Components Inc. is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all times, and only designated professionals shall be allowed to maintain or service the equipment. This notice includes, but is not limited to, internal photographs, schematics and parts lists to be held confidential and out of the public domain. The device will be installed at secure cell tower, roof top or other pole mount locations where access to the equipment enclosures is restricted to certified technicians by the licensee. When the device is installed outdoors, in a fenced area or rooftop site, the unit is integrated directly between the small cell base station and antennae (as pictured below) and cannot be accessed without disabling and disassembling the complete cell site. Thank you, Communication Components Inc. By: ______________________________ Name: __Dennis Nathan____________ _ Title: ____President ______________ Date: ____05/13/14________________ Communication Components, Inc. 89 Leuning Street Phone: 201-342-3338 South Hackensack, NJ 07606 Fax: 201-342-3339

CCI SCB-850-1W-ALU-OD-1 External Photographs CCI SCB-850-1W-ALU-OD-1 Front View COMMUNICATION COMMUNICATIONCOMMUNICATIONCOMMUNICATION COMPONENTS INC COMPONENTS INCCOMPONENTS INCCOMPONENTS INC Extending Wireless Coverage 89 Leuning Street Phone: 201-342-3338 2 nd Floor Fax: 201-342-3339 South Hackensack, NJ 07606 www.cciproducts.com CCI SCB-850-1W-ALU-OD-1 Rear View CCI SCB-850-1W-ALU-OD-1 Top View CCI SCB-850-1W-ALU-OD-1 Bottom View CCI SCB-850-1W-ALU-OD-1 Left Side View CCI SCB-850-1W-ALU-OD-1 Right Side View CCI SC B-850-1W-ALU-OD-1 Industrial Booster Warning Label CCI SCB-850 -1W-ALU-OD-1 Industrial Booster Warning Label Locat ion

SCB-850-1W-ALU-OD-1 FCC ID Label Location COMMUNICATION COMMUNICATIONCOMMUNICATION COMMUNICATION COMPONENTS INC COMPONENTS INCCOMPONENTS INC COMPONENTS INC Extending Wireless Coverage 89 Leuning Street Phone: 201-342-3338 2 nd Floor Fax: 201-342-3339 South Hackensack, NJ 07606 www.cciproducts.com SCB-850-1W-ALU-OD-1 FCC ID Label COMMUNICATION COMMUNICATIONCOMMUNICATION COMMUNICATION COMPONENTS INC COMPONENTS INCCOMPONENTS INC COMPONENTS INC Extending Wireless Coverage 89 Leuning Street Phone: 201-342-3338 2 nd Floor Fax: 201-342-3339 South Hackensack, NJ 07606 www.cciproducts.com

7/30/2014 Page 1 Revision 1.0 General Information CCI’s MetroCell Amplifier improves the perform- ance of low power Small Cells by increasing the output power and receive sensitivity of the Metro- Cell. CCI’s MetroCell Amplifier increases the overall coverage area while improving the carrier-to-noise ratio and throughput perform- ance. This unit matches the design of the ALU MetroCell to increase its acceptability in challenging urban environments. It mounts di- rectly to the MetroCell and is suitable for indoor or outdoor locations. General Info and Technical Description 1 Electrical Specifications Block Diagram 2 Mechanical Drawing & Block Diagram 3 Contents This MetroCell Amplifier is designed with a very simple interface specifically designed to work with the ALU 9364 MetroCell without the need for retrofitting the original equipment. It mounts directly to the MetroCell without any additional cables or connectors. The MetroCell Amplifier is designed for compatibility with the latest UMTS and HSPA+ standard and is guaranteed to maintain the integrity of the UMTS signal upon amplification. State-of-the-art linearization circuitry in conjunction with LDMOS power amplifier devices are utilized in the transmit path of the amplifier. Monolithic Gallium- Arsenide technology is implemented for low-noise receive amplification of the Rx carrier. Internal fil- tering provides adequate rejection and low system group delay to minimize the Bit-Error-Rate (BER) of digital transmissions. A unique coupler architecture is utilized to insure that the ‘RF Sniffing’ func- tionality of the MetroCell is preserved when detecting neighboring cells. The standard unit is designed to operate from a standard 48 VDC source, or from a 48VDC POE source and has one Tx/Rx input and one Rx input from the MetroCell. The MetroCell Amplifier has two outputs, each going to individual antenna ports. Model SCB-850-1W-ALU-OD-1 Designed for ALU 9364 Outdoor MetroCell UMTS MetroCell Amplifier 850 Band Technical Description Tel: 201‐342‐3338 www.cciproducts.com CCI Confidential 7/30/2014 Page 2 Revision 1.0 Description Preliminary Specifications Electrical Specifications Uplink Downlink Operating Frequency Range 824-849 MHz 869-894 MHz System Gain 10 dB 6 dB System Noise Figure 2.5 dB Typical 10 dB Typical System Group Delay 180 nSecs Max. 180 nSecs Max. Pass-Band Ripple +/- 0.5 dB Max. +/- 0.5 dB Max. Output Third Order Intercept Point +27 dBm Min. +46 dBm Min. Rated UMTS/WCDMA Output Power +10 dBm Max. +30 dBm (1W) Max. Input/Output VSWR 1.5:1 Max. 1.5:1 Max. Uplink/ Downlink Isolation 55 dB Operating Voltage/ Current 48 VDC / 0.5A max Mechanical Specifications Dimensions (Amplifier Only) 10.80” (W) x 4.150 (H) x 1.875” (D) (274.32 (W) x 105.41 (H) x 47.63 (D) mm) Enclosure Aluminum Housing, Wall/Rack Mount Connectors N-Male x 2, N-Female x 2, POE x 1 Weight 2.2 lbs. (1.0 kg) Max Environmental Specifications Operating Temperature -35º C to +50º C (Cold start at -35º C, meets all specs at –25º C) MTBF 500,000 Hours Minimum Enclosure IP65 (Unit Body), IP68 (Connector) Operating Relative Humidity 0% to 99% Operating Altitude Up to 13,000 FT Dimensions (Including Amplifier Bracket) 11.750” (W) x 4.150 (H) x 1.875” (D) (298.45 (W) x 105.41 (H) x 47.63 (D) mm) MetroCell Amplifier Electrical & Mechanical Specification Communication Components Inc. UMTS/WCDMA MetroCell Amplifier for 850 Band Communication Components Inc. Tel: 201-342-3338 Fax: 201-342-3339 All specifications are subject to change. The latest specifications are available at www.cciproducts.com CCI Confidential 7/30/2014 Page 3 Revision 1.0 MetroCell Amplifier Outline Drawing MetroCell Amplifier Block Diagram Ordering Information: Model: SCB-850-1W-ALU-OD-1 FCC ID: NT3SCB8501WA Communication Components Inc. Tel: 201‐342‐3338 www.cciproducts.com CCI Confidential 89 Leuning Street South Hackensack, NJ 07606 Options: Accessories: Optional Mounting Bracket for Mounting SCB-850-1W-ALU-OD-1 and ALU 9364 Outdoor MetroCell to- gether on a Mast (Model # SCB-850-ALU-MBK-01) Optional GPS Antenna w/2 foot Cable recommended for Clearance of the Booster Amplifier (Model # ANT-3914D-GPS-2FT-SMA) Example: SCB-850-1W-ALU-OD-1 Mounted on an Alcatel-Lucent 9364 Outdoor MetroCell Dimensions in inches (mm) 11.750” (298.45 ) 4.150” (105.41 ) 1.875” (47.63 ) 10.80” (274.32 ) RJ-45 Pin # POE (Power Over Ethernet) Description T568 B Wire Color RJ-45 Pin # POE (Power Over Ethernet) Description 10/100 DC on Spares (mode B) 10/100 DC on Spares (mode B) 1 RX+ Orange/White 5 DC+ Blue/White 2 Rx- Solid Orange 6 Tx- Solid Green 3 Tx+ Green/White 7 DC- Brown/White 4 DC+ Solid Blue 8 DC- Solid Brown T568B Wire Color

SCB-850-1W-ALU-OD-1 Tune up Procedure There is no tune up procedure for the CCI# SCB-850-1W-ALU-OD-1. It is simply a single input, single output, single channel full duplex amplifier with a second Rx diversity / Tx bypass channel. Any gain adjustments must be performed by utilizing an external attenuator. All necessary repairs and adjustments are performed at the factory by trained personnel. Dated this 07th Day of May 20 14 By: Dennis Nathan Signature Printed Title: President On behalf of: Communication Components Inc. Communication Components, Inc. 89 Leuning Street Phone: 201-342-3338 South Hackensack, NJ 07606 Fax: 201-342-3339

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:30.0(dBm)* Maximum peak output power at antenna input terminal:1000.0(mW) Antenna gain(maximum):21(dBi)* Maximum antenna gain:125.89(numeric) Time Averaging:100(%)* Prediction distance:1000(cm)* Prediction frequency:869(MHz)* MPE limit for uncontrolled exposure at prediction frequency:0.579(mW/cm^2) Power density at prediction frequency:0.010(mW/cm^2) This equates to:0.10W/m^2 The antenna is specified at the time of licensing for this device. A gain of 21 dBi is used for the MPE prediction as a typical gain. RF exposure is dealt with at the time of licensing. 2 4R PG S π =
