NUL-9490WI-FI SMART LOCK

Installation and Reference Guide 57750-001 Rev 01 English SMART HOME PLATFORM Welcome to the Kwikset family! This guide will get you up and running with your new Wi-Fi Smart Lock. If you have any issues, please visit our support center: kwikset.com/support or call us at 1-800-327-5625. Getting started For an interactive version of this installation guide, scan here or go to kwikset.com/hubspace-install 1 UPDATE NEEDED Parts in the box ..............................................4 Required tools ................................................5 Installation ........................................................7 Reference guide ............................................18 Table of contents 3 Parts in the box Exterior Assembly Interior Assembly Interior Cover 4 Latch Collar Strike 1 Pack 03809 52531 Batteries 2 Pack Smart Plug Required tools Phillips head screwdriver No electric drills 5 Ruler Flat head screwdriver Mounting plate Keys 3 Pack 52367 SmartKey™ tool 52502 Installation 7 If drilling a new door, use the supplied template and instructions available at: kwikset.com/doorprep Remove your existing deadbolt ! 1-3/8” to 2-1/4” (35mm - 57mm) 1-1/2 or 2-1/8” (38mm to 54mm) Your new lock will only support a door thickness of 1-3/8” to 2-1/4” (35mm to 57mm) and a door bore hole diameter of 1-1/2“ or 2-1/8” (38mm or 54mm). 8 1 Install the latch B UP A *Use the longer screws if the holes are worn out. You will have two extra screws. If the rectangle shaped hole is not centered in the door hole, rotate the latch face to extend the latch. 03809* (2X) If your door is not chiseled, install the drive-in collar. [OUTSIDE] UP is on top. wood block Loosen faceplate with flathead screwdriver. DOOR JAMB *Install the longer screws closest to the door jamb. 52531* (4X) 2 Install the strike 1" (25 mm) hole depth 9 10 Install the exterior assembly 3 [OUTSIDE] Cable goes under the latch. A Remove adapter ring if bore hole measures 1-1/2” (38mm) diameter. 11 [INSIDE] Tighten the screws evenly. (2X) [INSIDE] Tighten the screws evenly. DO NOT over-tighten. Keep parallel to the door edge 52367 B C Route the cable through the center hole of the mounting plate, then push the cable down into the bottom hole. Insert the key and test the latch. If the latch does not extend or retract smoothly, adjust the screws. Leave bolt LOCKED/EXTENDED. Before You Continue Ensure the latch bolt is in the extended position. 12 A Install the interior assembly 4 Remove the interior cover from the interior assembly. DO NOT install the batteries. Wait until Step 5. If the turnpiece is not pointing up, rotate the turnpiece until it’s in a vertical position. 13 Secure the interior assembly onto the mounting plate. [INSIDE] D Ensure the flat blade fully engages with the turnpiece shaft. C B Connect the cable. Ensure a tight cable connection. Excess cable will sit inside the bottom of the interior housing. (2X) 52502 Ensure cable remains connected. 14 Install batteries 5 With the door open, install the batteries. NOTE: Lock must be installed on the door before inserting the batteries. Insert (4) AA batteries (included) into the battery pack. [INSIDE] Ensure correct polarity. Use new, non-rechargeable alkaline batteries only. A B Insert the (4) AA batteries. 15 Complete your lock set up If this lock was professionally installed (or installed by someone other than the homeowner), make sure this step is performed by the homeowner. 1. Download the Hubspace app. 2. Add your Lock: Tap the icon to add new device and begin lock setup. Scan the QR code included in the box or located on the lock interior. 3. Add Smart Plug: Tap the icon to add new device and begin smart plug setup. Scan the QR code included in the box or located on the plug. 16 Smart Plug at a Glance Smart Plug LED State Plug State MeaningAction To Take Orange Quick Blink Orange/ Green Quick Blink O> Green Red Orange O> O> O> On On On The plug is o>. The plug is on. Wi-Fi is not connected. There is a Wi-Fi error. No action required. Set up Wi-Fi for the product. If you have already set up Wi-Fi for this product, wait for it to connect. Check the Hubspace app for connectivity status. Go to the device settings in the app and set up Wi-Fi Access Point is allowing the device to join the network. Part Description a Power Socket b Indicator Light c Power Button a b c Note: The range of the Bluetooth® connection is approximately 30 feet (10 meters). However, maximum communication range will vary depending on obstacles (person, metal, wall, etc.). For best connectivity, we recommend plugging Smart Plug in a power outlet near your lock. Reference Guide 18 To lock your door, press the lock icon. The bolt will extend, then the screen will display the Locked LED Indicator and play the locked tone. To unlock your door, enter your access code. The bolt will retract, then the screen will display the Unlocked LED Indicator and play the unlocked tone. LockingUnlocking Amber status LED will remain on for 1.5 seconds. Green status LED will remain on for 1.5 seconds. Re-key the lock to work with your existing key by following the SmartKey® Re-key instructions. NOTE:If Auto-Lock is enabled, remove the batteries before re-keying your lock. SmartKey® Re-key 19 20 Amber: Locked Flashes Red 3x: Low Battery Flashes Red once: Invalid Credentials Green: Unlocked Exterior LED Indicators Flashes Red 15x: Lockout Red and Keypad flashes alternatively: Lock Jammed 21 Green Amber Slow Blinking: Unlocked Blinking: Low Battery Slow Blinking: Locked Red Interior Status LED Indicators 22 To remove the lock from your Hubspace account or reset lock settings back to default, follow the below steps: Remove Device/Reset Lock Settings 1. Open the Hubspace app 2. Select the desired lock 3. Tap the Settings Icon 4. Tap "Remove from Account" Your lock is now ready to be set up and added to the Hubspace app. 23 Wi-Fi Smart Lock at a Glance ExteriorInterior (cover removed) Lock Icon Troubleshooting If you have any issues, …

Text truncated - open the document above for the full version.

Rev 1/26/2023 Public Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/23/2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: NUL-9490 [Spectrum Brands, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Spectrum Brands, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a).  Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) Thuan Nguyen Rev 1/26/2023 Public Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 7/23/2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: NUL-9490 [Spectrum Brands, Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) Thuan Nguyen

Rev 1/26/2023 Public Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026/07/09 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: (NUL-9490) [Spectrum Brands, Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, [Spectrum Brands, Inc.] is the designated U.S. agent for service of process for the above referenced FCC ID. [ Spectrum Brands, Inc.] agree to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [Spectrum Brands, Inc.] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Spectrum Brands, Inc. Address: 19701 Da Vinci Foothill Ranch California 92610 USA. Contact Person: Thuan Nguyen Tel.: 1-949-672-4452 Email : [email protected] FRN: 0037031481 Sincerely, For Spectrum Brands, Inc. (as Applicant and Designated U.S. Agent) Signature Printed Name: Thuan Nguyen Title: Assoc. Principal Engineer, RF Electronics

MS-0044715 Page 1 of 1 Revision 1 Public Date: 2026/7/23 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for FCC ID: NUL-9490 Pursuant to FCC 47 CFR 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Permanent Permanent Test Setup*** Permanent Permanent User’s Manual*** Short Term Permanent Part List Spectrum Brands, Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: Thuan Nguyen / Assoc. Principal Engineer, RF Electronics (Signature) (Print name/Title) Tel: 9496724452 Email: [email protected]

Public Authority to Act as Agent Date: 2026/7/23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA To Whom It May Concern: I appoint TUV Taiwan / Jason Chang to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with Spectrum Brands, Inc. / 19701 DaVinci Foothill Ranch California 92610 United States. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: 2026/7/23 Agreement is valid for 12 months from the above date. By: Thuan Nguyen (Signature) (Print name) Assoc. Principal Engineer, RF Electronics 9496724452 (Title) (Telephone) Spectrum Brands, Inc. (Company Name)

Appendix EP Photographs of EUT Page 1 of 13 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 2 of 13 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 3 of 13 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490

Public FCC & IC sticker places Label location as illustration (Interior chassis backside) Dimension illustration:

Appendix EP Photographs of EUT Page 4 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 5 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 6 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 7 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 8 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 9 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 10 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 11 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 12 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Antenna Appendix EP Photographs of EUT Page 13 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Appendix EP Photographs of EUT Page 14 of 14 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490

Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN262OA4 001 Auftrags-Nr.: Order no.: 48305377 Seite 1 von 11 Page 1 of 11 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2026-05-14 Auftraggeber: Client: Spectrum Brands, Inc. 19701 Da Vinci Foothill Ranch California 92610 USA. Prü fgegenstand: Test item: WI-FI SMART LOCK Bezeichnung / Typ-Nr.: Identification / Type no.: 9490 Auftrags-Inhalt: Order content: FCC Certification Prü fgrundlage: Test specification: IEEE Std C95.1 47 CFR §2.1091 47 CFR §1.1310 KDB 447498 D04 Wareneingangsdatum: Date of sample receipt: 2026-05-28 Prü fmuster-Nr.: Test sample no: A004292288-001 A004292288-002 Prü fzeitraum: Testing period: 2026-06-12 - 2026-06-29 Ort der Prü fung: Place of testing: TÜ V Rheinland Taiwan Ltd. New Taipei Branch Prü flaboratorium: Testing laboratory: TÜ V Rheinland Taiwan Ltd. Taipei Testing Laboratories Prü fergebnis*: Test result*: Pass zusammengestellt von: compiled by: Anderson Chiu genehmigt von: authorized by: Zeus Chen Datum: Date: 2026-07-03 Ausstellungsdatum: Issue date: 2026-07-03 Stellung / Position: Senior Project Manager Stellung / Position: Laboratory Manager Sonstiges / Other: Zustand des Prü fgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prü fbericht bezieht sich nur auf das o.g. Prü fmuster und darf ohne Genehmigung der Prü fstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prü fzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland Taiwan Ltd. 11F., No. 758, Sec. 4, Bade Rd., Taipei 105, Taiwan, R.O.C. Mail: [email protected] ∙ Web: www.tuv.com V101023GCNSR Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN262OA4 001 Seite 2 von 11 Page 2 of 11 Anmerkungen Remarks 1 Alle eingesetzten Prüfmittel waren zum angegebenen Prüfzeitraum gemäß eines festgelegten Kalibrierungsprogramms unseres Prüfhauses kalibriert. Sie entsprechen den in den Prüfprogrammen hinterlegten Anforderungen. Die Rückverfolgbarkeit der eingesetzten Prüfmittel ist durch die Einhaltung der Regelungen unseres Managementsystems gegeben. Detaillierte Informationen bezüglich Prüfkonditionen, Prüfequipment und Messunsicherheiten sind im Prüflabor vorhanden und können auf Wunsch bereitgestellt werden. The equipment used during the specified testing period was calibrated according to our test laboratory calibration program. The equipment fulfils the requirements included in the relevant standards. The traceability of the test equipment used is ensured by compliance with the regulations of our management system. Detailed information regarding test conditions, equipment and measurement uncertainty is available in the test laboratory and could be provided on request. 2 Wie vertraglich vereinbart, wurde dieses Dokument nur digital unterzeichnet. Der TÜ V Rheinland hat nicht überprüft, welche rechtlichen oder sonstigen diesbezüglichen Anforderungen für dieses Dokument gelten. Diese Ü berprüfung liegt in der Verantwortung des Benutzers dieses Dokuments. Auf Verlangen des Kunden kann der TÜ V Rheinland die Gültigkeit der digitalen Signatur durch ein gesondertes Dokument bestätigen. Diese Anfrage ist an unseren Vertrieb zu richten. Eine Umweltgebühr für einen solchen zusätzlichen Service wird erhoben. Informationen zur Verifizierung der Authentizität unserer Dokumente erhalten Sie auf folgender Webseite: go.tuv.com/digital-signature As contractually agreed, this document has been signed digitally only. TUV Rheinland has not verified and unable to verify which legal or other pertaining requirements are applicable for this document. Such verification is within the responsibility of the user of this document. Upon request by its client, TUV Rheinland can confirm the validity of the digital signature by a separate document. Such request shall be addressed to our Sales department. An environmental fee for such additional service will be charged. For information on verifying the authenticity of our documents, please visit the following website: go.tuv.com/digital-signature 3 Prüfklausel mit der Note * wurden an qualifizierte Unterauftragnehmer vergeben und sind unter der jeweiligen Prüfklausel des Berichts beschrieben. Abweichungen von Prüfspezifikation(en) oder Kundenanforderungen sind in der jeweiligen Prüfklausel im Bericht aufgeführt. Test clauses with remark of * are subcontracted to qualified subcontractors and descripted under the respective test clause in the report. Deviations of testing specification(s) or customer requirements are listed in specific test clause in the report. 4 Die Entscheidungsregel für Konformitätserklärungen basierend auf numerischen Messergebnisen in diesem Prüfbericht basiert auf der "Null-Grenzwert-Regel" und der "Einfachen Akzeptanz" gemäß ILAC G8:2019 und IEC Guide 115:2023, es sei denn, in der auf Seite 1 dieses Berichts genannten angewandten Norm ist etwas anderes festgelegt oder vom Kunden gewünscht. Dies bedeutet, dass die Messunsicherheit nicht berücksichtigt wird und daher auch nicht im Prüfbericht angegeben wird. Zu weiteren Informationen bezueglich des Risikos durch diese Entscheidungsregel siehe ILAC G8:2019. The decision rule for statements of conformity, based on numerical measurement results, i…

Text truncated - open the document above for the full version.

Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN26W3OX 001 Auftrags-Nr.: Order no.: 48305377 Seite 1 von 26 Page 1 of 26 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2026-05-14 Auftraggeber: Client: Spectrum Brands, Inc. 19701 Da Vinci Foothill Ranch California 92610 USA. Prü fgegenstand: Test item: WI-FI SMART LOCK Bezeichnung / Typ-Nr.: Identification / Type no.: 9490 Auftrags-Inhalt: Order content: FCC Part 15C Test report (BLE) Prü fgrundlage: Test specification: FCC 47CFR Part 15: Subpart C Section 15.247 Wareneingangsdatum: Date of sample receipt: 2026-05-28 Prü fmuster-Nr.: Test sample no: A004292288-001 A004292288-002 Prü fzeitraum: Testing period: 2026-06-12 - 2026-06-29 Ort der Prü fung: Place of testing: TÜ V Rheinland Taiwan Ltd. New Taipei Branch Prü flaboratorium: Testing laboratory: TÜ V Rheinland Taiwan Ltd. Taipei Testing Laboratories Prü fergebnis*: Test result*: Pass zusammengestellt von: compiled by: Anderson Chiu genehmigt von: authorized by: Zeus Chen Datum: Date: 2026-07-03 Ausstellungsdatum: Issue date: 2026-07-03 Stellung / Position: Senior Project Manager Stellung / Position: Laboratory Manager Sonstiges / Other: Zustand des Prü fgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prü fbericht bezieht sich nur auf das o.g. Prü fmuster und darf ohne Genehmigung der Prü fstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prü fzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland Taiwan Ltd. 11F., No. 758, Sec. 4, Bade Rd., Taipei 105, Taiwan, R.O.C. Mail: [email protected] ∙ Web: www.tuv.com V101023GCNSR Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN26W3OX 001 Seite 2 von 26 Page 2 of 26 Anmerkungen Remarks 1 Alle eingesetzten Prüfmittel waren zum angegebenen Prüfzeitraum gemäß eines festgelegten Kalibrierungsprogramms unseres Prüfhauses kalibriert. Sie entsprechen den in den Prüfprogrammen hinterlegten Anforderungen. Die Rückverfolgbarkeit der eingesetzten Prüfmittel ist durch die Einhaltung der Regelungen unseres Managementsystems gegeben. Detaillierte Informationen bezüglich Prüfkonditionen, Prüfequipment und Messunsicherheiten sind im Prüflabor vorhanden und können auf Wunsch bereitgestellt werden. The equipment used during the specified testing period was calibrated according to our test laboratory calibration program. The equipment fulfils the requirements included in the relevant standards. The traceability of the test equipment used is ensured by compliance with the regulations of our management system. Detailed information regarding test conditions, equipment and measurement uncertainty is available in the test laboratory and could be provided on request. 2 Wie vertraglich vereinbart, wurde dieses Dokument nur digital unterzeichnet. Der TÜ V Rheinland hat nicht überprüft, welche rechtlichen oder sonstigen diesbezüglichen Anforderungen für dieses Dokument gelten. Diese Ü berprüfung liegt in der Verantwortung des Benutzers dieses Dokuments. Auf Verlangen des Kunden kann der TÜ V Rheinland die Gültigkeit der digitalen Signatur durch ein gesondertes Dokument bestätigen. Diese Anfrage ist an unseren Vertrieb zu richten. Eine Umweltgebühr für einen solchen zusätzlichen Service wird erhoben. Informationen zur Verifizierung der Authentizität unserer Dokumente erhalten Sie auf folgender Webseite: go.tuv.com/digital-signature As contractually agreed, this document has been signed digitally only. TUV Rheinland has not verified and unable to verify which legal or other pertaining requirements are applicable for this document. Such verification is within the responsibility of the user of this document. Upon request by its client, TUV Rheinland can confirm the validity of the digital signature by a separate document. Such request shall be addressed to our Sales department. An environmental fee for such additional service will be charged. For information on verifying the authenticity of our documents, please visit the following website: go.tuv.com/digital-signature 3 Prüfklausel mit der Note * wurden an qualifizierte Unterauftragnehmer vergeben und sind unter der jeweiligen Prüfklausel des Berichts beschrieben. Abweichungen von Prüfspezifikation(en) oder Kundenanforderungen sind in der jeweiligen Prüfklausel im Bericht aufgeführt. Test clauses with remark of * are subcontracted to qualified subcontractors and descripted under the respective test clause in the report. Deviations of testing specification(s) or customer requirements are listed in specific test clause in the report. 4 Die Entscheidungsregel für Konformitätserklärungen basierend auf numerischen Messergebnisen in diesem Prüfbericht basiert auf der "Null-Grenzwert-Regel" und der "Einfachen Akzeptanz" gemäß ILAC G8:2019 und IEC Guide 115:2023, es sei denn, in der auf Seite 1 dieses Berichts genannten angewandten Norm ist etwas anderes festgelegt oder vom Kunden gewünscht. Dies bedeutet, dass die Messunsicherheit nicht berücksichtigt wird und daher auch nicht im Prüfbericht angegeben wird. Zu weiteren Informationen bezueglich des Risikos durch diese Entscheidungsregel siehe ILAC G8:2019. The decision rule for statements of conformity, based on numerical measurement results, in t…

Text truncated - open the document above for the full version.

Public 天線規格書 – Only radiated measurements are used to show compliance with FCC limits for fundamental and spurious emissions. 天線資訊 產品名稱 PCB antenna 產品廠牌 L eedarson 產品型號 LA02306 天線廠牌 L eedarson 天線型號 BLE antenna 天線型式 P CB antenna 天線增益值≦1.7 dBi 天線尺寸 7 * 16 mm 主頻頻率 2400M Hz www.leedarson.com ▏Better Life with Better IoT Innovation Rev. 1.0 Antenna Specification Antenna picture Antenna Type PCB Antenna Antenna Peak Gain 1.70 dBi Operating Band 2400-2483.5 MHz Test laboratory name and Address IoT Antenna Test Laboratory, 3 / A,LEEDARSON LIGHTING CO., LTD. Xingtai Industrial Park, Changtai Economic Development Zone, Zhangzhou, 363900, China Antenna Manufacturer LEEDARSON LIGHTING CO., LTD. Model name LA02306 DUT photo Test Date 2025-05-29 Test Conductor Fenghuijuan ANT Antenna Information www.leedarson.com ▏Better Life with Better IoT Innovation 1 OTA measurement Test System The SY-16 OTA system and RayZone2800 OTA system are anechoic chambers, which can measures antenna passive data such as antenna efficiency, antenna gain, and 2D&3D pattern. The systems are shown as follow: Figure 1 SY-16 OTA system Figure 2 RayZone2800 OTA system Antenna Information www.leedarson.com ▏Better Life with Better IoT Innovation 2 Equipment List Table 1 Equipment List Used Equipment Manufacturer Model No. Serial No. Last Cal. Due Date ☒ Network Analyzer Keysight E5071C MY46527808 2025/1/9 2026/1/8 ☐ Network Analyzer Keysight E5071C MY46108051 2025/4/19 2026/4/18 ☒ Anechoic Chamber Sunyield SY-16 SI1727 2025/4/28 2026/4/27 ☐ Anechoic Chamber General Test System RayZone2800 CT10121244 B5079 2025/5/10 2026/5/9 Test Method Table 2 Test Method Name Antenna Performance Parameter Radiation Efficiency Test Method IEEE Standard Test Procedures for Antennas Standard No. ANSI/IEEE Std 149-2021 Test Software PMS-V2.8.5 ☒ MaxSign-V1.4.3 ☐ Test Result Efficiency and Gain Table 3 Antenna Efficiency and Gain Frequency (MHz) Gain (dBi) Efficiency (dB) Efficiency (%) 2400 0.66 -2.74 53.24 2410 0.57 -2.80 52.53 2420 0.83 -2.52 55.97 2430 0.97 -2.43 57.12 2440 1.11 -2.34 58.32 2450 1.27 -2.26 59.45 2460 1.50 -2.14 61.14 2470 1.70 -2.09 61.77 2480 1.39 -2.06 62.28 2490 1.40 -2.15 60.97 2500 1.44 -2.21 60.18 Antenna Information www.leedarson.com ▏Better Life with Better IoT Innovation 3 Radiation Pattern Table 4 Product coordinates Product Coordinates Table 5 3D radiation pattern 3D Radiation Pattern at 2450MHz Antenna Information www.leedarson.com ▏Better Life with Better IoT Innovation 4 Table 6 Radiation pattern in XY Plane 2D Radiation Pattern ( θ = 90°, XY Plane) Table 7 Radiation pattern in XZ Plane 2D Radiation Pattern ( φ = 0°, XZ Plane) Antenna Information www.leedarson.com ▏Better Life with Better IoT Innovation 5 Table 8 Radiation pattern in YZ Plane 2D Radiation Pattern ( φ = 90°, YZ Plane)

Appendix SP Photographs of Test Setup Page 1 of 3 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Photograph 1: Test Setup for Spurious Emissions (Front View 1) Photograph 2: Test Setup for Spurious Emissions (Front View 2) Appendix SP Photographs of Test Setup Page 2 of 3 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK Type Identification: 9490 Photograph 3: Test Setup for Spurious Emissions (Back View 1) Photograph 4: Test Setup for Spurious Emissions (Back View 2) Appendix SP Photographs of Test Setup Page 3 of 3 CN26W3OX 001 CN262OA4 001 Product: WI-FI SMART LOCK T…
