NUL450126VHCZ_Wave Plus Lock Version II

Regulatory Compliance This product complies with standards established by the following regulatory bodies: • Federal Communications Commission (FCC) • Industry Canada FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ( 1 ) this device may not cause harmful interference, and ( 2 ) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. IMPORTANT! Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Industry Canada This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: ( 1 ) This device may not cause interference, and ( 2 ) This device must accept any interference, including interference that may cause undesired operation of the device. Cumplimiento Normativo Este producto cumple con las normas establecidas por los siguientes organismos reguladores: • Comisión Federal de Comunicaciones (FCC) • Industry Canada FCC Este dispositivo cumple con la 15ª parte del reglamento de la FCC. Su funcionamiento está sujeto a las siguientes dos condiciones: ( 1 ) este dispositivo no deberá causar ninguna interferencia dañina, y ( 2 ) este dispositivo deberá aceptar cualquier interferencia recibida, incluyendo aquélla que podría causar un funcionamiento no deseado. Se realizaron pruebas a este equipo cuyos resultados revelaron que cumple con los límites establecidos para un dispositivo digital de la Clase B, conforme a la 15ª parte del reglamento de la FCC. Estos límites han sido impuestos para proporcionar protección razonable contra interferencias dañinas en una instalación residencial. Este equipo genera, utiliza y puede irradiar energía de radiofrecuencia y, si no se instala y utiliza según lo que indican las instrucciones, podría causar interferencia dañina en radiocomunicaciones. Sin embargo, no hay garantía de que la interferencia no ocurrirá en determinadas instalaciones. Si este equipo efectivamente causa interferencia en la recepción de radio o televisión, la cual puede determinarse encendiendo y apagando el equipo, sugerimos al usuario que intente corregir dicha interferencia tomando una o más de las siguientes medidas: • Volver a orientar o ubicar la antena receptora. • Incrementar la distancia entre el equipo y el recibidor. • Conectar el equipo a una toma de corriente en un circuito distinto del circuito en el cual esté conectado el recibidor. • Consultar con el distribuidor o un técnico de radio y TV con experiencia para obtener su ayuda. ¡IMPORTANTE! Todo cambio o modificación no aprobado expresamente por el fabricante podría desautorizar al usuario para operar el equipo. Industria de Canada Este dispositivo contiene transmisor (es) / receptor (es) exento (s) de licencia que cumple con los RSS (s) exentos de licencia de Innovación, Ciencia y Desarrollo Económico de Canadá. El funcionamiento está sujeto a las dos condiciones siguientes: (1) este dispositivo no puede causar interferencia, y (2) este dispositivo debe aceptar cualquier interferencia, incluida la interferencia que pueda causar un funcionamiento no deseado del dispositivo. Conformité règlementaire Ce produit est conforme aux normes établies par les organismes de règlementation suivants : • Federal Communications Commission (FCC) • Industrie Canada FCC Cet appareil est conforme aux limites prescrites dans la partie 15 des règlements de la Federal Communication Commission (FCC) des États-Unis. Son utilisation est subordonnée aux conditions suivantes : ( 1 ) l’appareil ne doit pas causer d’interférence nuisibles, et ( 2 ) il doit accepter toute interférence, y compris celles qui peuvent causer son mauvais fonctionnement. Lors des tests effectués, cet appareil s’est révélé conforme aux limites prescrites dans la partie 15 des règlements de la Federal Communications Commission (FCC) des États-Unis pour un appareil numérique de Classe B. Ces limites ont été fixées pour protéger raisonnablement les installations résidentielles contre les interférences nuisibles. L’appareil produit, utilise et peut émettre des radiofréquences. S’il n’est pas installé et utilisé de la façon prescrite, il peut brouiller les communications radio. Il n’est pas garanti qu’aucune interférence ne se produira. Si l’appareil brouille la réception d’une radio ou d’un téléviseur (pour savoir s’il est à l’origine du brouillage, il suffit de l’éteindre et de le rallumer), l’utilisateur est invité à tenter de corriger la situation en prenant une ou plusieurs des mesures suivantes : • réorienter ou déplacer l’antenne réceptrice; • éloigner davantage l’appareil émetteur du récepteur; • brancher l’appareil dans une prise reliée à un circuit différent de celui auquel le récepteur est…

Text truncated - open the document above for the full version.

Welcome to the Kwikset family! This guide will get you up and running with your new [NEED NAME] Lock. If you have any issues, please visit our support center: kwikset.com/[need-url] or call us at 1-800-327-5625. Parts in the box ................................................2 Required tools ..................................................3 Installation ...........................................................5 Smart home system setup.........................15 Reference guide .............................................17 Table of contents 1 Required tools Parts in the box Mounting plate Keys Exterior assembly Latch Strike Battery packInterior assembly Interior cover Batteries SmartKey™ tool Phillips head screwdriver 1 Step 2 Step 3 Step 4 Step 5 Step actual size 03809 46780 actual size actual size actual size actual size 68272 69316 68611 No electric drills 23 If drilling a new door, use the supplied template and instructions available at: kwikset.com/doorprep Remove your existing deadbolt ! Installation 5 C B A DOOR JAMB *Use the longer screws if the holes are worn out. You will have two extra screws. *Install the longer screws closest to the door jamb. 1" (25 mm) hole depth Extend the latch bolt. UP is on top. If the D-shaped hole is not centered in the door hole, rotate the latch face to extend the latch. 03809* (2X) 46780* (4X) If your door requires a drive-in latch, please contact Kwikset at 1-800-327-5625. 2 Install the strike 1 Install the latch [OUTSIDE] 67 A C B Install the exterior assembly 3 [OUTSIDE] [INSIDE] Cable goes under the latch. Route the cable through the center hole, then push into the bottom hole. Insert the key and test the latch. If the latch does not extend or retract smoothly, adjust the screws. Tighten the screws evenly. DO NOT over-tighten. 68272 (2X) 89 B A E D C Install the interior assembly 4 Remove the interior cover from the interior assembly. Secure the interior assembly onto the mounting plate. Make sure the turnpiece shaft is pointing up as shown below. Incorrect: If the turnpiece shaft is not pointing up, put the cover back on and rotate the turnpiece. 69316 (2X) Connect the cable. Ensure a tight cable connection. Lay cable flat inside the bottom of the interior housing. Ensure the spindle fully engages with the turnpiece shaft. [INSIDE] 1011 Perform the door handing process 5 Secure the interior cover onto the interior assembly. With the door open, install the battery pack to initiate auto-handing. Install 4 AA batteries into the battery pack. You may need to rotate the turnpiece to align with the turnpiece shaft. For additional security, you may choose to lock the window by installing the security screw. When the window is locked, you will need to remove the entire cover to access the battery pack and buttons. The latch will retract and extend to learn the orientation of the door. Then the status LED will indicate success or failure. 69316 (3X) 68611 (1X) GREEN:Successful. Proceed to the next step. RED:Unsuccessful. Make sure the lock interior and batteries are correctly installed. Perform step 5 again. If your second attempt is still unsuccessful, visit our support center: kwikset.com/need-url [INSIDE][INSIDE] 1213 Status LED AB CD Smart home system setup 15 Add the lock to your smart home system Initiate the process to add the lock to your system at your smart home controller. Refer to your smart home system instructions for more information. SmartStart Enabled Products SmartStart enabled products can be added into a Z-Wave network by scanning the Z-Wave QR Code present on the product with a controller providing SmartStart inclusion. No further action is required and the SmartStart product will be added automatically within 10 minutes of being switched on in the network vicinity. At this time, you may be prompted by your smart home system to enter the 5-digit pin found on the label of the interior assembly. If not, proceed to step D. When prompted by your smart home system to add the lock, press button “A” on the lock interior one time. The red LED will illuminate when the lock enters Add Mode. If successful, re-name the lock in your system (if applicable). If unsuccessful, follow your system’s instructions to remove the lock from the controller and any other network, then press button “A” on the lock one time. Perform steps A-C again. If still unsuccessful, consult the Programming and Troubleshooting Guide on the [NEED NAME] page at kwikset.com. Button “A” 5-digit pin QR code Reference Guide To lock your door, press the Kwikset button. To unlock your door, enter your access code. LockingUnlocking 17 NEED URL Network Information Z-Wave® System Notes Removing the lock from the network Follow your smart home system’s instructions to remove the lock from the network. When prompted by the system, press button “A” on the lock interior once. This product is a security enabled Z-Wave Plus product and must be used with a Security Enabled Z-Wave controller to be fully utilized. Z-Wave is a “Wireless mesh network,” and results may vary based on building construction and communication path. To assure interoperability, each Z-Wave product must pass a stringent conformance test to assure that it meets the Z-Wave standard for complete compliance with all other devices and controls. The Z-Wave identity mark assures consumers, integrators, dealers and manufacturers that their products will reliably perform with any other Z-Wave device. And, regardless of the vendor, always powered nodes may act as a repeater for Kwikset/ Weiser/Baldwin products. Z-Wave Configuration and Association Parameters are available on the [NEED NAME] page at www.kwikset.com. [NEED NAME] at a Glance ExteriorInterior (cover removed) SmartKey™ tool access Keypad Kwikset button Keyway Button “A” Status LED Program button Turnpiece shaft Battery pack Troubleshooting If you have any issues, please visit our support center: kwikset.com/need-url or call us at 1-800-327-5625. 1819 Button …

Text truncated - open the document above for the full version.

Thuan Nguyen Sr. Electronic Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 6/30/2020 Attention: Application Examiner RE: Request for Confidentiality Applicant: Spectrum Brands, Inc. FCC ID: NUL450126VHC To Whom It May Concern: Request is hereby submitted by Spectrum Brands, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block Diagrams  Detailed Operational/Functional Description Short‐term Confidentiality [Complete this section if short‐term confidentiality is requested] Request is hereby submitted by Spectrum Brands, Inc. to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 180 days from the date of Authorization:  Internal photos  User manual Rationale for request for confidentiality: Thuan Nguyen Sr. Electronic Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Spectrum Brands, Inc. has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short‐term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Thuan Nguyen Sr. Electrical Engineer Spectrum Brands, Inc.

Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Exterior Photos - Traditional Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Exterior Photos - Contemporary

SHEET SCALE REV DWG NO SIZE TITLE DRAFTER CHECKED ENGINEER APPROVED DATE DATE DATE DATE A B C D A B C D 4 3 2 1 4 3 1 RELEASE STATE ITER NOTES: UNLESS OTHERWISE SPECIFIED THIS DOCUMENT IS THE PROPERTY OF SPECTRUM BRANDS, INC AND/OR ITS AFFILIATES. THE CONTENTS OF THIS DOCUMENT ARE CONFIDENTIAL AND CONSTITUTE TRADE SECRETS PROPRIETARY TO SPECTRUM BRANDS. NEITHER THIS DOCUMENT NOR ITS CONTENTS SHALL BE DISCLOSED TO ANY UNAUTHORIZED PERSON, COPIED, OR PUBLISHED WITHOUT SPECTRUM BRANDS' PRIOR WRITTEN CONSENT. 1.38 .20 PDM REFD: B.0+M: B.0+ 4/11 OF 1 SPECTRUM BRANDS, INC HARDWARE AND HOME IMPROVEMENT 19701 DA VINCI, LAKE FOREST, CA 92610 LABEL, FCC, 10BV B DO NOT SCALE DRAWING 5069302 PreliminaryB 0 C. SONG03/04/20 C. SONG03/04/20 C. SONG03/04/20 JA. LIN03/04/20 THIRD ANGLE PROJECTION KWIKSET REVDESCRIPTIONDATEDRAFTERENGINEERAPPROVED A PRELIMINARY DESIGN03/04/20C. SONGT. NGUYENJA. LIN 1. FCC ID LABEL FOR THE SBD 10-BUTTON VHC LOCK A. IC: 3022A-450126VHC WHERE IC --- INDUSTRY CANADA WHERE 3022A-450126VHC --- INDUSTRY CANADA NUMBER B. FCC ID: NUL450126VHC WHERE NUL --- FIRST THREE CHARACTERS OF GRANTEE CODE WHERE --- REMAINING NUMBERS/CHARACTERS FCC ID C. MODEL: 450126VHC WHERE 450126VHC --- INTERNAL HHI FCC MODEL NUMBER. D. LABEL COLOR: BLACK. E. LABEL MATERIAL: REFER TO 695-00006-001 FOR LABEL SPECIFICATION. F. FONT: FIT ON LABEL, WHITE. G. LABEL LOCATION: REFER TO DRAWING 5069303. H. ALL DIMENSIONS ARE IN INCHES.

Thuan Nguyen Sr. Electronic Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 NUL450126VHC FCC ID Label Location

Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 9/10/2020 Interior Photos: Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Location of ISED certification number and PMN on product. Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Exterior/Interior Connection: Name: Thuan Nguyen Title: Sr. Elect Engineer II 19701 DaVinci Lake Forest, CA 92610 (T) 949.672.4452 Exterior PCBA:

RF Exposure FCC ID: NUL450126VHC IC: 3022A-450126VHC RF Exposure Page 1 of 1 FCC §1.1310 Performance Criterion (Limits): f MHz /1500 mW/cm 2 At 908.4 MHz, the limit is 0.6056 mW/cm 2 At 916 MHz, the limit is 0.6107 mW/cm 2 Evaluation Results: Complies Details: The maximum permissible exposure (MPE) is predicted by using the following equation: S = EIRP/4πR 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) EIRP = (Exd) 2 /30 transmitter output power in watts E = electric field strength in V/m d = measurement distance in m R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) For: E = 92.76 dBuV/m (from Intertek test report 104271913LAX-001) = 43451 uV/m = 0.04345 V/m, d = 3 m, EIRP = (0.04345 x 3) 2 /30 = 0.0005664 W = 0.5664 mW For: EIRP = 0.5664 mW and R = 20 cm S = 0.5664 / (4 x π x 20 2 ) = 0.0001 mW/cm 2 ISED RSS-102 Issue 5 §2.5.2 Performance Criterion (Exemption Limits): 1.31x10 -2 f -0.6834 W (300 MHz ≤ f < 6 GHz), f is in MHz. At 908.4 MHz, 1.31x10 -2 f -0.6834 W = 1.37 W At 916 MHz, 1.31x10 -2 f -0.6834 W = 1.39 W Evaluation Results: Complies Details: Since the worst-case e.i.r.p. (at 916 MHz) is 0.0005664 W, which is much lower than the exemption limit of 1.39 W, RF exposure evaluation is exempted.

Spectrum Brands, Inc. TEST REPORT SCOPE OF WORK FCC 15.249 AND ISED RSS-210 TESTING – 450126VHC REPORT NUMBER 104271913LAX-001 ISSUE DATE REVISED DATE 2-June-2020 18-September-2020 PAGES 31 DOCUMENT CONTROL NUMBER Non-Specific Radio Report Shell Rev. December 2017 © 2017 INTERTEK Non-Specific Radio Report Shell Rev. December 2017 Page 2 of 31 Spectrum Brands, Inc., Model: 450126VHC EMC TEST REPORT (FULL COMPLIANCE) Report Number: 104271913LAX-001 Project Number: G104271913 Report Issue Date: June 2, 2020 Report Revised Date: September 18, 2020 Model(s) Tested: 450126VHC Standards: FCC CFR47 Part 15 Subpart C, January 2020 Intentional Radiator §15.249 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725- 5875 MHZ, and 24.0-24.25 GHz ISED RSS-210 Issue 10, December 2019 Licence-Exempt Radio Apparatus: Category I Equipment ISED RSS-Gen Issue 5, March 2019, Amendment 1 General Requirements for Compliance of Radio Apparatus Tested by: Client: Intertek 25791 Commercentre Drive Lake Forest, CA 92630 USA Spectrum Brands, Inc. 19701 DaVinci Foothill Ranch, CA 92610 USA Report prepared by Report reviewed by Grace Lin EMC Staff Engineer Uri Spector EMC Team Leader This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Report Number: 104271913LAX-001 Issued: June 2, 2020 Revised: September 18, 2020 Non-Specific Radio Report Shell Rev. December 2017 Page 3 of 31 Spectrum Brands, Inc., Model: 450126VHC Table of Contents Spectrum Brands, Inc. .................................................................................................................................................... 1 1 Introduction and Conclusion ........................................................................................................................... 4 2 Test Summary ................................................................................................................................................ 4 3 Client Information .......................................................................................................................................... 5 4 Description of Equipment Under Test and Variant Models ............................................................................. 5 5 System Setup and Method ............................................................................................................................. 7 6 Occupied Bandwidth ...................................................................................................................................... 8 7 Fundamental Field Strength ......................................................................................................................... 13 8 Radiated Spurious Emissions ........................................................................................................................ 16 9 AC Mains Conducted Emissions .................................................................................................................... 29 10 Revision History ........................................................................................................................................ 31 Intertek Report Number: 104271913LAX-001 Issued: June 2, 2020 Revised: September 18, 2020 Non-Specific Radio Report Shell Rev. December 2017 Page 4 of 31 Spectrum Brands, Inc., Model: 450126VHC 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the radiated spurious emissions requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 3 Client Information - 4 Description of Equipment Under Test and Variant Models - 5 System Setup and Method - 6 Occupied Bandwidths (FCC §15.215(c); ISED RSS-Gen Issue 5 §6.7) Compliant 7 Field Strength of Fundamental (FCC §15.249(a); ISED RSS-210 Issue 10 §B.10(a)) Compliant 8 Radiated Spurious Emissions (FCC §15.249(a); ISED RSS-210 Issue 10 §B.10(a)) Compliant 9 AC Mains Conducted Emissions (FCC §15.207, ISED RSS-Gen §8.8) Not Applicable* 10 Revision History - *: The EUT is battery powered Intertek Report Number: 104271913LAX-001 Issued: June 2, 2020 Revised: September 18, 2020 Non-Specific Radio Report Shell Rev. December 2017 Page 5 of 31 Spectrum Brands, Inc., Model: 450126VHC 3 Client Information This EUT was tested at the request of: Client: Spectrum Brands (formerly Kwikset Corp.) 19701 DaVinci Foothill Ranch, CA 92610 USA Contact: Thuan Nguyen Telephone: (949) 672-4452 E…

Text truncated - open the document above for the full version.

Test Setup Photos FCC ID: NUL450126VHC IC: 3022A-450126VHC Test Setup Photos Page 1 of 5 Test Setup Photos FCC ID: NUL450126VHC IC: 3022A-450126VHC Test Setup Photos Page 2 of 5 Test Setup Photos FCC ID: NUL450126VHC IC: 3022A-450126VHC Test Setup Photos Page 3 of 5 Test Setup Photos FCC ID: NUL450126VHC IC: 3022A-450126VHC Test Setup Photos Page 4 of 5 Test Setup Photos FCC ID: NUL450126VHC IC: 3022A-450126VHC Test Setup Photos Page 5 of 5
