NW71022iON Air Pro 3 WiFi / Air Pro 3 WiFi / Gen 3 WiFi / iON Air Pro 3 Value Pack/ HD Sports Video Camera

Quick Start Guide Thank you for purchasing the iON Air Pro 3 HD sports video camera. This QSG contains the common functions and features of Air Pro 3 and Air Pro 3 Wi-Fi. For additional features and functions of Air Pro 3 Wi-Fi, please refer to the back part of the manual. The iON Air Pro 3 can be mounted with the Bike & Helmet Kit or the Board Kit for the ultimate adventure HD recording experience. EN-1 Getting to know your camera Common features: 9iON Air Pro 3 is a Professional, High Quality Digital Video Recorder that records Full HD videos with the flip of an easy slide switch 9It has the latest 12 Mega Pixel Sensor for you to take great digital photographs 9A 180 degree high quality lens provides a super wide angle field of view 9Your camera supports a MicroSD card up to 64GB, allowing you to take videos in 1080p with 30 frames per second for approximately 4 Hours. 9Equipped with the microphone jack for connection with an external microphone.* 9The Waterproof Housing enables you to operate the camera up to 10 meters under water. 9iON Air Pro 3 is about 4.51 ounces or 128g. * When an external microphone (not included) is connected, audio cannot be recorded through the built-in microphone. 1. Package Contents of Air Pro 3 Carefully unpack the package and ensure that you have the following items: EN-2 1 USB Cable 1. Connect the camera to a computer for data transfer or camera setup. 2. Charge your camera. 2 Universal Power Adapter Attach the correct international wall plug to the adapter block and connect to the camera with the USB cable 3 Double Faced Adhesive - Helmet Adhere to the helmet mount and/or helmet. 4 Helmet Mount with removable ball join nut Enables you to mount the camera on different types of helmets by tightening and loosening the ball joint nut 5 CamLOCK Mount or remove the camera quickly from the CamLOCK socket. 6 Quick User Guide Provides quick information for easy camera operation 7 Warranty Card Please retain for manufacturers warranty period which is limited to 1 year. 8 Mi-media Card Provides guidance on how to sign up for your free iON cloud storage. 9 Package - Plastic Display Tinbox and Paper Sleeve 10 ION Logo Label 11 WiFi Podz EN-3 2. Functional Parts of Air Pro 3 1Power 1. Turns the camera on or off 2. Takes a single photograph 2LED Indicator Shows the camera status 3 Recording Slide Switch Slide to start or stop video recording 4LensHigh quality lens 5MicroSD Card Slot MicroSD card storage location. 6Mini HDMI Jack To enable you to connect the camera to an HDTV with an HDMI cable (not included) 7USB Port 1. Connect to your computer for data transfer or camera setup 2. Charge your camera 8 Video Resolution Switch Select video resolution: FHD (Full HD) or HD. 9Mic Jack To enable you to connect to an external microphone (not included) 10Reset Button Reset the camera 11PODZ Socket Connect the PODZ to the camera to perform additional functions EN-4 3. Using Your Camera 3.1 Charging up Your Camera Charge your camera with either the USB cable or AC/DC adapter. The red LED will light up to indicate the camera is charging and it will turn off once the camera has been fully charged. It takes about 3 hours to fully charge the camera. 3.2 Inserting a Memory Card Insert a MicroSD card up to 64GB (not included) before using your camera. Ensure that the camera power is turned OFF before inserting the card into the slot. Notes: 1.There is only one correct direction to insert the MicroSD card into the slot. Do not force the card into the card slot as it may damage both the camera and the MicroSD card. 2.A new MicroSD card should be formatted before using. For more information, please see section 4.2. 3.We recommend a class 10 SDHC card. 3.3 Setting up Date and Time Connect your camera to a computer and run the iON software from the MicroSD card folder. You can set the date and time on the camera via the settings page. Please see section 4.1 to open iON software 3.4 Installing the PODZ 1.Attach the PODZ to the back of the camera and rotate clockwise until the two dots are aligned. 2.Slide the latch on the PODZ to lock it. WARNING: The latch must be locked in place to ensure the waterproof is activated – failure to do so may cause water leakage. seal 3.5 Recording Videos Before starting to record, select the video resolution using the Video Resolution Switch. There are two methods for starting the video recording function. When the camera starts recording, there will be a short vibration indicating recording has started. The LED indicator illuminates GREEN throughout recording. 1.Whether the camera power is ON or OFF, simply slide the Recording Slide Switch from STOP to REC to start recording. EN-5 2.When your camera is OFF and the Recording Slide Switchis at REC location, it will start recording. To stop Recording, move the Recording Slide Switch from REC to STOP. The camera will then enter the Standby mode. An additional option is to hold the Powerbutton to stop the recording and turn the camera off. Notes: 1.An additional 432x240 (w/ 1080p/720p) video file will be created simultaneously with the recording of an HD/FHD video file. The smaller video file size allows for more efficient uploading of content to social media platforms and email. 2.Changing video resolution is disabled during video recording. 3.There will be around 1-2 seconds delay before the camera starts recording. 4.The various video resolution options for HD and FHD can be changed under the “Settings” selection in the iON software. (see 4.1) 3.6 Taking Photos 1.Turn on the camera by pressing the Power button. 2.After the camera power has been turned on, press the Power button very briefly to take a photo. A short vibration and a flash of the green LED indicates that the action was successful. Note:Change photo resolutions and shooting mode (Single Shot, Burst Mode and Time Lapse) through the “Settings” section on the iON software. 4. Mounting Your Camera 4.1 Secure Strap 1.Loop one end of the secur…

Text truncated - open the document above for the full version.

World Wide Licenses Ltd. Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong TEL No: 852 - 95527113 Attestation for FCC Declaration of Conformity FCC lD: NW71022 Data: Aug.07, 2013 Please be notified that we, the undersigned, World Wide Licenses Ltd. declares that the product which bears the above FCC lD is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 137478R-RFUSP37V02 Testing in regards to this report was done by QuieTek Corporation, located at 2F, No.345, Xinhu 2nd Rd., Neihu District,, Taipei Taiwan, which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KD8349827. Sincerely, For and on behalf of WORLD WIDE LICENSES LIMITED Mandy Wong / Operation Manage World Wide Licenses Ltd. Tel: 852 -95527113 Email : mandy@wwlhk. com

World Wide Licenses Ltd. FCC ID.: NW71022 Federal Communications Commisston Authorization and Evaluation Division Aug.07 ,2013 ATTESTATION FCC ID:NW71022 Product:iONAirPro3WiFi/AirPro3WiFi/Gen3WiFi/iONAirPro3ValuePack/HDSportsVideoCamera We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. r For and on behalf of Jlncerely' WORLD WIDE LICENSES LIlv{iTrD Mandy Wong / Operation Manage World Wide Licenses Ltd. Suite D,l6lF.,On Hing Building,No I On Hing Terrace, Central, Hong Kong Tel : 852 - 95527113

World Wide Licenses Ltd. FCC ID.: NW71022 Federal Communications Commission Authorization and Evaluation Division Aug. 07,2013 Confidential Statement We have understood that the following request for confidential documents has been and viewable since the date of grant, since it has been granted. Confi dentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics : (1022) Schem Block Diagram: (1022) BlkDia Operational Description: (1 022) OPDes Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The prUtit disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission's policy, in order to comply with the marketing regulations in 47 DFR $2.803 and the importation rules in 47 CFR 52.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized divices. We are requesting the commission to grant short-thrm confidentialify request for 90 days on the following attachments: External Photos: (1022) Expho Internal Photos: (1022) Inpho Test Setup Photos: (1022) Tsup User Manual: (1022) UserMan It is our understanding that all measurement test reports, FCC ID label format and corespondent during certification review process cannot be granted as confidential documents and those information will be available for publicreview once the grant of equipment authsrization is issued. sincerelv, il?biii"ri,B'ftiii*urs Lil\{rrED Mandy Wong / Operation Manage World Wide Licenses Ltd. Suite D,l6lF.,On Hing Building,No I On Hing Terrace, Central, Hong Kong Tel : 852 - 95527113

World Wide Licenses Ltd. Declaration of Authorization World Wide Licenses Ltd. Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Hong Kong China Gene Chang(1) QuieTek Corp. F|.2, No.345, Xin-hu 2nd Rd., Nei-hu District Taipei Taiwan R-F_l60,Issue 02 We Name: Address: City: Country: Declare that: Name Representative of agent: Agent Company name: Address: City: Country FCC ID: Date: City: Name: Function: Signature: ......2013t08t07 ...... Hong Kong . ...... Mandy Wong ...... Operation Manage ...... For and on behalf of WORLD WIDE LICENSES LIMITED is authorized to apply for Certification of the following product(s): Productdescription: iON Air Pro 3WiFi/AirPro 3WiFi/Gen 3WFi/ iON Air Pro 3Value Pack/ HD Sports Video Camera N\At71022 Trademark: iON on our behalf. (1): Required for FCC application (2): For FCC it must be the Grantee Code "ownel' or the authorized agent

Report No：137478R-HPUSP09V01 Page: 4 of 18 EUT Photographs

World Wide Licenses Ltd. FCC ID.: NW71022 Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Tel : 852 - 9552 7113 FCC ID Label

World Wide Licenses Ltd. FCC ID.: NW71022 Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Tel : 852 - 9552 7113 The FCC ID and Doc Label will be placed on the equipment as shown in the photograph below.

Report No.: 137478R-RFUSP42V01 Page : 2 of 18 (3) EUT Photo (4) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 3 of 18 (5) EUT Photo (6) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 4 of 18 (7) EUT Photo (8) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 5 of 18 (9) EUT Photo (Antenna) (10) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 6 of 18 (11) EUT Photo (WiFi Module) (12) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 7 of 18 (13) EUT Photo (14) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 8 of 18 (15) EUT Photo (16) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 9 of 18 (17) EUT Photo (18) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 10 of 18 (19) EUT Photo (20) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 11 of 18 (21) EUT Photo (22) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 12 of 18 (23) EUT Photo (24) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 13 of 18 (25) EUT Photo (26) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 14 of 18 (27) EUT Photo (28) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 15 of 18 (29) EUT Photo (30) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 16 of 18 (31) EUT Photo (32) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 17 of 18 (33) EUT Photo (34) EUT Photo Report No.: 137478R-RFUSP42V01 Page : 18 of 18 (35) EUT Photo (36) EUT Photo

Report No：137478R-HPUSP09V01 Page: 1 of 24 FCC SAR Test Report Product Name ： iON Air Pro 3 WiFi / Air Pro 3 WiFi / Gen 3 WiFi / iON Air Pro 3 Value Pack/ HD Sports Video Camera Model No. ： 1022, 1031, 1032, 1033, 1034, 1035, 1036, 1037, 1038, 1039 Applicant ： World Wide Licenses Ltd. Address ： Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Date of Receipt ：2013/07/24 Issued Date ：2013/08/02 Report No. ：137478R-HPUSP09V01 Report Version ：V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Report No：137478R-HPUSP09V01 Page: 2 of 24 Test Report Certification Issued Date: 2013/08/02 Report No.:137478R-HPUSP09V01 Product Name ： iON Air Pro 3 WiFi / Air Pro 3 WiFi / Gen 3 WiFi / iON Air Pro 3 Value Pack/ HD Sports Video Camera Applicant ： World Wide Licenses Ltd. Address ： Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Manufacturer ： ABILITY ENTERPRISE CO., LTD. Model No. ： 1022, 1031, 1032, 1033, 1034, 1035, 1036, 1037, 1038, 1039 Trade Name ： iON FCC ID ： NW71022 Applicable Standard ： FCC Oet65 Supplement C June 2001 IEEE Std. 1528-2003 47CFR § 2.1093 Measurement procedures ： KDB 447498 , KDB 248227 , KDB 865664 Test Result ： Max. SAR Measurement (1g) 0.980 W/kg Application Type ： Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Documented By ： (Adm. Specialist / April Chen) Tested By ： (Engineer / Wen Lee) Approved By ： (Manager / Vincent Lin) Report No：137478R-HPUSP09V01 Page: 3 of 24 TABLE OF CONTENTS Description Page 1. General Information .............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Antenna List ................................................................................................................... 7 1.3 Maximum output power and tolerance allowed for production units ............................ 7 1.4 Test Environment ...........................................................................................................7 2. SAR Measurement System ................................................................... 8 2.1 DASY5 System Description .......................................................................................... 8 2.1.1 Applications ................................................................................................................ 9 2.1.2 Area Scans................................................................................................................... 9 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 9 2.1.4 Uncertainty of Inter-/Extrapolation and Averaging .................................................... 9 2.2 DASY5 E-Field Probe ................................................................................................. 10 2.2.1 Isotropic E-Field Probe Specification ....................................................................... 10 2.3 Boundary Detection Unit and Probe Mounting Device ............................................... 11 2.4 DATA Acquisition Electronics (DAE) and Measurement Server ............................... 11 2.5 Robot.. .......................................................................................................................... 12 2.6 Light Beam Unit........................................................................................................... 12 2.7 Device Holder ..............................................................................................................13 2.8 SAM Twin Phantom .................................................................................................... 13 3. Tissue Simulating Liquid .................................................................... 14 3.1 The composition of the tissue simulating liquid .......................................................... 14 3.2 Tissue Calibration Result ............................................................................................. 14 3.3 Tissue Dielectric Parameters for Head and Body Phantoms........................................ 15 4. SAR Measurement Procedure ............................................................ 16 4.1 SAR System Check ...................................................................................................... 16 4.1.1 Dipoles ...................................................................................................................... 16 4.1.2 System Check Result ................................................................................................ 16 4.2 SAR Measurement Procedure ...................................................................................... 17 5. SAR Exposure Limits .......................................................................... 18 6. Test Equipment List ............................................................................ 19 7. Measurement Uncertainty................................................................... 20 8. Conducted Power Measurement ........................................................ 21 9. Test Results.......................................................................................... 22 9.1 SAR Test Results Summary ......................................................................................... 22 10. SAR measurement variability............................................................. 23 Report No：137478R-HPUSP09V01 Page: 4 of 24 Appendix ...........................................................................................24 Appendix A. SAR System Check Data Appendix B. SAR measurement Data Appendix …

Text truncated - open the document above for the full version.

Report No.: 137478R-RFUSP42V01 Page : 1 of 114 FCC Test Report Product Name iON Air Pro 3 WiFi / Air Pro 3 WiFi / Gen 3 WiFi / iON Air Pro 3 Value Pack/ HD Sports Video Camera Model No 1022, 1031, 1032, 1033, 1034, 1035, 1036, 1037, 1038, 1039 FCC ID. NW71022 Applicant World Wide Licenses Ltd. Address Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Date of Receipt July 24, 2013 Issue Date Aug. 06, 2013 Report No. 137478R-RFUSP42V01 Report Version V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government. Report No.: 137478R-RFUSP42V01 Page : 2 of 114 Test Report Certification Issue Date: Aug. 06, 2013 Report No.: 137478R-RFUSP42V01 Product Name iON Air Pro 3 WiFi / Air Pro 3 WiFi / Gen 3 WiFi / iON Air Pro 3 Value Pack/ HD Sports Video Camera Applicant World Wide Licenses Ltd. Address Suite D,16/F.,On Hing Building,No 1 On Hing Terrace, Central, Hong Kong Manufacturer ABILITY ENTERPRISE CO., LTD. Model No. 1022, 1031, 1032, 1033, 1034, 1035, 1036, 1037, 1038, 1039 FCC ID. NW71022 EUT Rated Voltage DC 3.7V (Power by Battery) EUT Test Voltage AC 120V/60Hz, DC 3.7V (Power by Battery) Trade Name iON Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2003, ANSI C63.10: 2009 Test Result Complied The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government. Documented By : ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Andy Lin ) Approved By : ( Manager / Vincent Lin ) Report No.: 137478R-RFUSP42V01 Page : 3 of 114 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ..............................................................................................................10 1.3. Tested System Details..................................................................................................................11 1.4. Configuration of Tested System ..................................................................................................11 1.5. EUT Exercise Software ...............................................................................................................13 1.6. Test Facility .................................................................................................................................14 2. Conducted Emission..................................................................................................................15 2.1. Test Equipment............................................................................................................................15 2.2. Test Setup ....................................................................................................................................15 2.3. Limits ..........................................................................................................................................16 2.4. Test Procedure .............................................................................................................................16 2.5. Uncertainty ..................................................................................................................................16 2.6. Test Result of Conducted Emission.............................................................................................17 3. Peak Power Output ...................................................................................................................19 3.1. Test Equipment............................................................................................................................19 3.2. Test Setup ....................................................................................................................................19 3.3. Limits ..........................................................................................................................................19 3.4. Test Procedure .............................................................................................................................19 3.5. Uncertainty ..................................................................................................................................19 3.6. Test Result of Peak Power Output...............................................................................................20 4. Radiated Emission .....................................................................................................................23 4.1. Test Equipment............................................................................................................................23 4.2. Test Setup ....................................................................................................................................24 4.3. Limits ..........................................................................................................................................25 4.4. Test Procedure .............................................................................................................................26 4.5. Uncertainty ..................................................................................................................................26 4.6. Test Result of Radiated Emission................................................................................................27 5. RF …

Text truncated - open the document above for the full version.

Report No.: 137478R-RFUSP42V01 Page : 1 of 4 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test – Mode 4 Back View of Conducted Test – Mode 4 Report No.: 137478R-RFUSP42V01 Page : 2 of 4 Front View of Radiated Test – Mode 1, Mode 2, Mode 3 Back View of Radiated Test – Mode 1, Mode 2, Mode 3 Report No.: 137478R-RFUSP42V01 Page : 3 of 4 Front View of Radiated Test – Mode 4 Back View of Radiated Test – Mode 4 Report No.: 137478R-RFUSP42V01 Page : 4 of 4 Front View of Radiated Test (Horn) – Mode 1, Mode 2, Mode 3 Back View of Radiated Test (Horn) – Mode 1, Mode 2, Mode 3

Report No：137478R-HPUSP09V01 Page: 1 of 18 Appendix C. Test Setup Photographs & EUT Photographs Test Setup Photographs EUT Bottom EUT Front Touch Touch Report No：137478R-HPUSP09V01 Page: 2 of 18 EUT Back EUT L-Side Touch Touch Report No：137478R-HPUSP09V01 Page: 3 of 18 EUT R-Side Depth of the liquid in the phantom-Zoom In Note: The positions used in the measurements were according to IEEE 1528-2003. Touch
