NZI111256Zmax Communication Unit

GETTING STARTED GUIDE Z-Max ® .Net www.thalesgroup.com/navigation English Copyright Notice Copyright 2003-2006 Thales Navigation. All rights reserved. Tr ad e m a r k s All product and brand names mentioned in this publication are trademarks of their respective holders. FCC Notice Z-Max.Net Receiver complies with the limits for a Class B dig- ital device, pursuant to the Part 15 of the FCC rules when it is used in Portable Mode. See Note below related to Class B de- vice. Class B digital devices NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interfer- ence by one or more of the following measures: - Reorient or locate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. When Z-Max.Net is used with an external power supply or con- nected to an external device using the USB port, it complies with the limits for a Class A digital device, pursuant to the Part 15 of the FCC rules. See Note below related to Class A device. Class A digital devices NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the in- struction manual, may cause harmful interference to radio com- munications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Remark: Any changes or modifications not expressly approved by Thales Navigation, could void the right for user to operate the equipment. RF Safety Exposure To Radio Frequency Energy (SAR) Radio transmitting devices radiate Radio Frequency (RF) ener- gy during its operation. RF energy can be absorbed into the hu- man body and potentially can cause adverse health effects if excessive levels are absorbed. The unit of measurement for hu- man exposure to RF energy is "Specific Absorption Rate" (SAR). The Federal Communications Commission (FCC), Industrie Canada (IC), and other agencies around the world have estab- lished limits that incorporate a substantial safety margin de- signed to assure the safety of all persons using this equipment. In order to certify this unit for sale in the US, Canada and Eu- rope this unit has been tested for RF exposure compliance at a qualified test laboratory and found to comply with the regula- tions regarding exposure to RF Energy.SAR was measured with the unit (GSM Module) transmitting at its maximum certified RF power. Often, however, during normal operation the unit (GSM Module) will transmit much less than maximum power. Transmit power is controlled automatically and, in general is re- duced as you get closer to a cellular base station. This reduction in transmit power will result in a lower RF energy exposure and resulting SAR value. SAR: ANSI/IEEE C95.1 1992 FCC OET Bulletin 65 Supplement C 1999/519/CE The highest SAR value for this wireless survey system when worn on the body, as described in this user guide, is 1.44 W/kg. No separation from the body is required when the wireless sur- vey system is in operation as the SAR measurements were taken with the unit "touching" the surface of the body. The device main intent use is for handheld operations only. FCC and CE UHF Safety Statement The different versions of the UHF Transmitters are FCC and CE compliant. In order to comply with FCC and CE RF exposure safety guide- lines as body-worn, normal use of unit, the following must be followed: A distance of AT LEAST 10 feet (3 m) of separation between the users body and the unit (UHF Transmitter). This distance has been defined taken into account the FCC and CE Require- ments and the worst output power configuration. Do NOT use the device in a manner such that it is in direct con- tact with the body (e.g. on the lap). Such use will likely exceed FCC RF safety exposure limits. See www.fcc.gov/oet/rfsafety/ for more information on RF exposure safety. Antenna Care/Unauthorized Modifications Use only the supplied integral antenna. Unauthorized antenna modifications or attachments could damage the unit and may vi- olate FCC and CE regulations. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Replacing the Thales U-Link Transmitter Power Fuse The Thales U-Link transmitter is protected by a 4-A fuse inserted in the data/power cable. This Y-shaped cable is used to connect the U-Link transmitter to the Z-Max.Net receiver via a 7-pin connector, and to the power battery. Should you have to replace this fuse, please get a spare fuse, 4 A, fast acting, ATO type, and then do the following: - Unplug the battery end of the data/power cable - Open the fuse holder located along the data/power cable - Extract the damaged fuse - Insert the new fuse and then push the holder lid back into place - Co…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA FCC ID: IHDT56BD1 May 8, 2003 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56BD1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment is an OEM module (similar to FCC ID: IHDT6AC1 & IHDT56CW1), and can transfer data or voice over cellular and PCS networks. It has the capability to operate in 850 MHz & 1900 MHz GSM bands. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DB2 SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission The transceiver of type IHDT56DB2 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. Menashe Cohen Engineering HW Manager OEM embedded modules Design Center Eli Zakuto Engineering Manager OEM embedded modules Design Center Exhibit 2A APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DB2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duty certified. SIGNATURE: (signed) Menashe Cohen NAME: Menashe Cohen DATE: June 8 th , 2005 POSITION: Engineering HW Manager I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: SIGNATURE: (signed) Eli Zakuto NAME: Eli Zakuto DATE: June 8 th , 2005 POSITION: Engineering Manager Exhibit 2B

FCC ID Label Location

800964-16B.doc DÉSIGNATION/TITLE Label COM MODULE + GSM NA PLAN N° / DRAWING No. FOLIO SHEET __________ 1/1 C.D N° M A 800964-16 B Ce document est la propriété inaliénable de Magellan Navigation, Inc / Reproduction & diffusion interdites This drawing is the exclusive property of Magellan Navigation, Inc / Reproduction and unauthorized use are forbidden Magellan ÉTABLI PAR/DRAWN BY TESSIER Philippe DATE DE CREATION Oct 09,2003 VÉRIFIÉ PAR/CHECKED BY: Gérard JUTON INDICE INDEX ECO ou/or M DATE B 06616 DEFINITION DE L'ETIQUETTE Type : Etiquette adhésive infalsifiable en polyester argenté munie d'un adhésif acrylique de type permanent. Moyen de protection : Damier de colle restant sur le support au décollage Température d'utilisation : Le marquage et l'adhésif doivent résister à des températures comprises entre –45°C et +135°C Environnement : Extérieur, à l'humidité et sous la pluie Dimensions : 78 x 38mm coins arrondis Couleurs : Ecriture noire sur fond argenté Caractères : ARIAL ; Magellan : Trade Gotic ou Arial Marquage : Voir plan échelle 1 ci-dessous Codification du numéro de série sur étiquette S/N : YYYYWWNNN YYYY : année (2006) WW : Semaine de fabrication (47) NNN : numéro dans la semaine compris entre 001 et 999 Code barres Code 128 Tested to Comply With FCC Standards TYPE : ASSY COM MOD,GSM NA P/N : 800964-16 S/N : 200647019 Made in France Magellan X Indice de la BOM Code barres avec S/N Code barres avec P/N Sans l’indice de la BOM FCC ID : NZI111256 This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

2867 Progress Place, Suite 4D • Escondido, CA 92029 • U.S.A. TEL (760) 737-3131 • FAX (760) 737-9131 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Thales Navigation Dates of Test: June 20 - 21, 2006 471 El Camino Real Test Report Number: SAR.20060603 Santa Clara, CA 95050 Revision B FCC ID: IHDT56DB1 IC Certificate: 1090-DB1 Model(s): 800963 Test Sample: Pre-Production Unit same as Production Serial No.: 200512021 Equipment Type: Wireless Survey System Classification: Portable Transmitter Next to Body TX Frequency Range: 824.2 – 848.8 (GSM), 1850.2 – 1909.8 (PCS) Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 32.07 dBm (GSM), 29.07 dBm (PCS) Peak Conducted Signal Modulation: GMSK Antenna Type (Length): External – (54mm x 8mm) Nearson PN D321AM-AMPS/PCS Battery: P/N 800965 – 02/A Battery Pack Application Type: Certification FCC Rule Parts: Part 22H, Part 24E This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1999 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, OET Bulletin 65 Supp. C, RSS-102 and Safety Code 6 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 © 2006 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. FCC ID: IHDT56DB1 © 2006 RF Exposure Lab, LLC Page 2 of 102 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction........................................................................................................................... 3 SAR Definition [5]...................................................................................................................... 3 2. SAR Measurement Setup..................................................................................................... 4 Robotic System ......................................................................................................................... 4 System Hardware..................................................................................................................... 4 System Description................................................................................................................... 4 E-Field Probe ALS-E-020......................................................................................................... 5 3. Robot Specifications............................................................................................................. 7 4. Probe and Dipole Calibration................................................................................................ 8 5. Phantom & Simulating Tissue Specifications........................................................................ 9 SAM Phantom........................................................................................................................... 9 Brain & Muscle Simulating Mixture Characterization................................................................ 9 Device Holder........................................................................................................................... 9 6. Definition of Reference Points............................................................................................. 10 Ear Reference Point................................................................................................................ 10 Device Reference Points ........................................................................................................ 10 7. Test Configuration Positions............................................................................................... 11 Positioning for Cheek/Touch [5].............................................................................................. 11 Positioning for Ear / 15 ̊ Tilt [5]................................................................................................ 12 Body Worn Configurations...................................................................................................... 13 8. ANSI/IEEE C95.1 – 1999 RF Exposure Limits [2]............................................................... 14 Uncontrolled Environment....................................................................................................... 14 Controlled Environment.......................................................................................................... 14 9. Measurement Uncertainty................................................................................................... 15 10. System Validation........................................................................................................... 16 Tissue Verification................................................................................................................... 16 Test System Verification......................................................................................................... 16 11. SAR Test Data Summary................................................................................................ 17 Procedures Used To Establish Test Signal............................................................................. 17 Device Test Condition.........................................................…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DB2 SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission The transceiver of type IHDT56DB2 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. Menashe Cohen Engineering HW Manager OEM embedded modules Design Center Eli Zakuto Engineering Manager OEM embedded modules Design Center Exhibit 2A APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DB2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duty certified. SIGNATURE: (signed) Menashe Cohen NAME: Menashe Cohen DATE: June 8 th , 2005 POSITION: Engineering HW Manager I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: SIGNATURE: (signed) Eli Zakuto NAME: Eli Zakuto DATE: June 8 th , 2005 POSITION: Engineering Manager Exhibit 2B

APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 10361-1 Report Date – April 14, 2003 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Mark Kien_____ Title: Electrical Engineer Date : _ 04/14/03____ This report must not be reproduced, except in full, without written approval from this laboratory. EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Table of Contents Description Page Test Report Details 3 Applicable Standards 4 Summary of Testing 5 General and Special Conditions 5 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 6 Measurement Procedures and Data RF Power Output 7 Occupied Bandwidth 8 GSM 850 Reference Plot 9 GSM 850 Mid Band Plot 9 GSM 850 Lower Band Edge 10 GSM 850 Upper Band Edge 10 GSM 1900 Reference Plot 11 GSM 1900 Mid Band Plot 11 GSM 1900 Lower Band Edge 12 GSM 1900 Upper Band Edge 12 Spurious Emissions at Antenna Terminals 13 GSM 850 Tabular and Graphical Data 14 GSM 850 Cellular Base Station Frequency Range Plot 15 GSM 1900 Tabular and Graphical Data 16 Field Strength of Spurious Emissions 17 GSM 850 Tabular and Graphical Data 18 GSM 850 Tabular and Graphical Data 19 Frequency Stability 20 GSM 850 Tabular and Graphical Data 21 GSM 1900 Tabular and Graphical Data 22 Field Strength of Spurious Emissions From Unintentional Radiators 23 GSM 850 Tabular and Graphical Data 24 GSM 1900 Tabular and Graphical Data 25 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 26 Figure A.2 – Substitution Measurement 26 Test Report Number: 10361-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Test Report Details Field Strength Tests Performed By: Underwriters Laboratory Inc. 333 Pfingsten Road Northbrook, IL 60062-2096 PH (847) 272-8800 Fax (847) 272-8129 FCC Registration Number: 91044 Industry Canada Number: IC2180 All Other Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-3642 Fax (847) 523-8274 FCC Registration Number: 100000 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Data Module Signaling Capability: GSM 850, GSM 1900 Model Number: G20 Serial Numbers: PGE00070, PGE00022, PGE00033 PGE00032 Received Date: 3/31/2003 Testing Start Date: 3/31/2003 Testing Complete Date: 4/9/2003 Test Report Number: 10361-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 98-C, ANSI 63.4 2000, RSS-132, RSS-133 Test Report Number: 10361-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 Occupied Bandwidth Pass 3 Spurious Emissions at Antenna Terminal Pass 4 Field Strength of Spurious Emissions Pass 5 Frequency Stability Pass 6 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 Occupied Bandwidth See Plots 3 Spurious Emissions at Antenna Terminal 16.7 dB 4 Field Strength of Spurious Emissions 13.4 dB 5 Frequency Stability 62.2 Hz 6 Field Strength of Spurious Emissions 4.4 dB from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Equipment and Cable Configurations The EUT was tested with a development interface used to simulate the user interface to the EUT. This configuration is representative of typical use. Test Report Number: 10361-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Measuring Equipment and Calibration Information Manufacturer Name Item Name Description Model # Serial Number Calibration Due Date Agilent EMC Analyzer E7405A US53944019 11/6/03 Hewlett Packard QP Adapter 85650A 2811A01069 1/15/04 Hewlett Packard S/A Display 8566B 2542A12974 1/15/04 Hewlett Packard S/A 8566B 2637A03376 1/15/04 Hewlett Packard RF Preselector 85685A 2810A00692 1/15/04 Rohde & Schwarz S/A FSEK20 DE2525315 1/14/04 EMCO Horn Antenna 1-18GHz 3115 8812-3032 5/23/03 EMCO Horn Antenna 1-18GHz 3115 2638 7/20/03 EMCO Horn Antenna 18-26.5GHz 3160-09 9904-1165 N/A* Chase Bi-Con Antenna 30-300MHz VBA6106A 1246 6/18/03 Chase Log-Periodic Antenna UPA6108 1120 6/20/03 Weinschel Attenuator Kit – 10, 6 dB AS6 6675 10/9/03 Thermotron Environmental Chamber S-4 31580 12/19/03 Hewlett Packard System DC Power Supply 66311B US38447252 10/18/03 Agilent Wireless Communication Test Set 8960 Series 10 GB42360906 9/10/03 Giga-tronics Universal Power Meter 8651A 8650508 7/2/2003 Giga-tronics Power Sensor 80701A 1834031 7/2/2003 * Per ANSI C63.5-1998 (Revision of ANSI C63.5-1988) pg. 6, under 5.1 General “It is unnecessary to calibra…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56DB1 Test Report Number: 10361-1 EXHIBIT 6 26 Appendix A – Radiated Emissions Test Setup Photos Note: Photos are representative of the test house setup used. A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report
