NZI711923GPS Receiver with Bluetooth

English MobileMapper CE Getting Started Guide MM CE GS Guide.book Page 1 Monday, June 20, 2005 11:04 AM English Copyright Notice Copyright 2005 Thales Navigation. All rights reserved. No part of this publication or the computer programs described in it may be reproduced, translated, stored in a retrieval system, or transmitted in any form or by any means, elec- tronic, mechanical photocopying, recording, or otherwise, without prior written permission of Thales Navigation. Your rights with regard to this publication and the computer pro- grams are subject to the restrictions and limitations imposed by the copyright laws and/or the jurisdiction in which you are located Tra dem ar ks All product and brand names mentioned in this publication are trademarks of their respec- tive holders. FCC Notice This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in ac- cordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to cor- rect the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Thales Navigation could void the us- er's authority to operate this equipment. CAUTION: To comply with FCC RF exposure compliance requirements, a separation dis- tance of at least 20 cm must be maintained between the antenna of this device and all per- sons. In the presence of RF field, the receiver's satellite signal strength may degrade. When re- moved from the RF field, the signal strength should return to normal. This device has been found compliant with the Canadian RSS-210 specification, issue 5, November 2001 which stipulates that operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CopyrightTrademarkNotices.fm Page i Thursday, July 7, 2005 2:14 PM English Table of Contents Introduction ................................................................................................ 1 Key Features ........................................................................................ 1 Software Provided as Standard ............................................................ 2 About Windows CE .NET ................................................................... 2 Receiver Description .................................................................................. 3 Front Panel ........................................................................................... 3 Back Panel ........................................................................................... 3 Side Panel ............................................................................................ 4 I/O Module........................................................................................... 4 Resetting MobileMapper CE handheld ............................................... 4 Preparing for First-Time Use .................................................................... 5 Charging the battery ............................................................................ 5 Turning the Receiver On ..................................................................... 6 Calibrating the Screen.......................................................................... 7 Automatic System Time Update.......................................................... 7 Adjusting the Backlight ....................................................................... 7 Regional Settings ................................................................................. 8 Establishing a Connection with your PC ............................................. 9 Installing Software ............................................................................... 9 Initializing GPS ................................................................................. 10 Setting Up GPS .................................................................................. 11 Viewing Current GPS Status ............................................................. 13 Signal Quality/Navigation Window (Sig/Nav) ............................ 13 Azimuth and Elevation Graph (Azmth/Elvn) .............................. 13 Panel Window (Panel) ................................................................. 14 Statistics Window (Stats) ............................................................. 14 Working in Windows CE .NET Environment ....................................... 15 User Interface For Text Input ............................................................ 15 Using the integrated alphanumeric keypad........................................ 15 Using the Stylus ................................................................................. 16 Power Management.................................................................................. 17 Memory Management .............................................................................. 19 Using GPS ................................................................................................. 20 GPS initialization ...…

Text truncated - open the document above for the full version.

Subj:
Cellular Modems and Bluetooth
Date:
3/5/01 11:32:18 AM Pacific Standard Time
From: [email protected] (Frank Coperich) To: [email protected] CC: [email protected] (Joe Dichoso), [email protected] (Rich Fabina)
In response to your question(s) below: 3.) The Bluetooth approval procedures are listed below: BLUETOOTH APPROVALS For all devices, the following items, 1-12, are common to all Bluetooth devices and will not vary from one device to another. The list can be copied and pasted into the filing. 1 Output power and channel separation of a Bluetooth device in the different operating modes: The different operating modes (data-mode, acquisition-mode) of a Bluetooth device don*t influence the output power and the channel spacing. There is only one transmitter which is driven by identical input parameters concerning these two parameters. Only a different hopping sequence will be used. For this reason the check of these RF parameters in one op-mode is sufficient. 2 Frequency range of a Bluetooth device: Hereby we declare that the maximum frequency of this device is: 2402 * 2480 MHZ. This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for devices which will be operated in the USA. This was checked during the Bluetooth Qualification tests (Test Case: TRM/CA/04-E). Other frequency ranges ( e.g. for Spain, France, Japan) which are allowed according the Core Specification are not supported by this device. 3 Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters: Bluetooth units which want to communicate with other units must be organized in a structure called piconet. This piconet consist of max. 8 Bluetooth units. One unit is the master the other seven are the slaves. The master co-ordinates frequency occupation in this piconet for all units. As the master hop sequence is derived from it*s BD address which is unique for every Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. 4 Example of a hopping sequence in data mode: Example of a 79 hopping sequence in data mode: 40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68, 02, 70, 06, 01, 51, 03, 55, 05, 04 5 Equally average use of frequencies in data mode and behavior for short transmissions: The generation of the hopping sequence in connection mode depends essentially on two input values: 1. LAP/UAP of the master of the connection 2. Internal master clock The LAP (lower address part) are the 24 LSB*s of the 48 BD_ADDRESS. The BD_ADDRESS is an unambiguous number of every Bluetooth unit. The UAP (upper address part) are the 24 MSB*s of the 48 BD_ADDRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronization with other units only offset are used. It has no relation to the time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30). In most case it is implemented as 28 bit counter. For the deriving of the hopping sequence the entire LAP (24 bits), 4 LSB*s (4 bits) (Input 1) and the 27 MSB*s of the clock (Input 2) are used. With this input values different mathematical procedures (permutations, additions, XOR-operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions the Bluetooth system has the following behavior: The first connection between the two devices is established, a hopping sequence was generated. For transmitting the wanted data the complete hopping sequence was not used. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the period between the two transmission is longer (and it cannot be shorter) than the minimum resolution of the clock (312.5 μs). The hopping sequence will always differ from the first one. 6 Receiver input bandwidth and behavior for repeated single or multiple packets: The input bandwidth of the receiver is 1 MHZ. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see chapter 5). The slave follows this sequence. Both devices shift between RX and TX time slot according to the clock of the master. Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and its TX/RX timing according to the packet type of the connection. Also the slave of the connection will use these settings. Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case. That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence 7 Dwell time in data mode The dwell time of 0.3797s within a 30 second period in data mode is independent from the packet type (packet length). The calculation for a 30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels *30s Example for a DH1 packet (with a maximum length of one time slot) Dwell time = 625 μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced according to the length of the packet. Example for a DH5 packet (with a maximum length of five time slots) Dwell time = 5 * 625 μs * 1600 * 1/5 *1/s / 79 * 30s = 0.3797s (in a 30s period) This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for all Bluetooth devices. Therefore all Bluetooth devices comply with the FCC dwell time require…

Text truncated - open the document above for the full version.

AW204841 AW, LABEL, FCC, ERIKSSON DRAWING NO.REV. A 960 Overland Court, San Dimas, CA 91773 SHEET 1 of 1 DRAWN CHECK QA APPR. ENGR. APPR. Tolerance: SIZECODE ID. NO. A0H9N4 REV.EDM NO.DESCRIPTIONDRN.APPR. J. Millette 6/2/2005 .xx ±0.01 .xxx ±0.005 Fractions 1/64" Angles ±0.50? Unless otherwise specified, dimensions are in inches. APRODUCTION RELEASEJMM Canada 210 FCC ID: N Z I 7 1 1 9 2 3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Sticker Location

English 1 Introduction Thank you for purchasing a MobileMapper CE from Thales Navigation. This Getting Started guide will give you useful information about your Windows CE GPS handheld com- puter. It will also guide you in your first steps using the sys- tem. MobileMapper CE is a handheld device that integrates sub- meter GPS with Microsoft Windows CE .NET in a rugged design suitable for mobile mapping applications. Being an open-platform Windows CE device, MobileMap- per CE allows you to choose the GIS software that is right for you. Key Features - Integrated GPS with real-time, sub-meter accuracy using WAAS/EGNOS or external real-time RTCM differential corrections - Integrated Bluetooth wireless technology - Ready for RTCM real-time corrections - Full color, daylight readable, transflective TFT display with 320 x 240 resolution and touch screen - Integrated Secure Digital memory card slot - Rugged and waterproof design - Built-in alphanumeric keyboard - Built-in speaker and microphone - Advanced power management - All-day rechargeable, removable Li-ion battery - Embedded Microsoft Windows CE .NET operating sys- tem - Off-the-shelf industry standard Mobile GIS software applications support English 2 Software Provided as Standard - GPS utilities - provide initialization and setup, current GPS status view, mission planning and configuration of optional beacon differential receiver - Bluetooth Manager - full-featured Bluetooth connectiv- ity configuration utility - Microsoft WordPad, Internet Explorer®, Windows Explorer, Terminal, ActiveSync®, Windows Media Player and Inbox - Microsoft File Viewers: Excel, Word and Image Viewers - EZ Recorder - sound record and playback program - Software Development Kit (SDK) and GPS Application Programming Interface (API), not delivered but available from our web site: www.thalesnavigation.com About Windows CE .NET Windows CE is a version of the Windows operating system designed for small devices such as personal digital assistants (PDAs) or handheld PCs. The Windows CE graphical user interface (GUI) is very similar to desktop Windows operat- ing systems. MobileMapper CE is embedded with the latest version: Windows CE .NET 4.2 Professional version. Like most Windows CE devices, the MobileMapper CE handheld has a touch screen. To interact with the MobileMapper CE, use the stylus to tap on the touch screen.

English 23 Using Bluetooth The MobileMapper CE is equipped with built-in Bluetooth technology that allows short-range connections to other Bluetooth-enabled devices such as cellular phones, personal digital assistants (PDA), and desktop or notebook comput- ers, and provides fast, reliable, and secure wireless commu- nication. Working with Bluetooth Manager Use the Bluetooth Manager to find, configure and establish connections to other Bluetooth devices. To start the Blue- tooth Manager: -Tap >Settings>Control Panel and double-tap BTManager. The icon now appears in the system tray. Turning On/Off Bluetooth -Tap the ON button on Bluetooth Manager. The MobileMapper CE starts to search for other available Bluetooth devices that are within range. The detected devices are then listed. - To preserve battery power, we recommend that you enable (turn on) Bluetooth only when using it: Tap the OFF button on Bluetooth Manager to disable Bluetooth. Supported Services The functions that Bluetooth supports are called services. MobileMapper CE can communicate with Bluetooth devices that support the following services: - Serial Port: A direct wireless connection to RS232 com- patible devices. English 24 - Dial-up Networking: Enables dial-up network to a cellu- lar phone or modem via a Bluetooth-enabled modem. - File Transfer: Supports the OBEX communication proto- col which allows the MobileMapper CE to send and receive files from other connected Bluetooth devices. To see a list of services offered by the detected device, click the box next to the device name. If a check mark appears over the service icon, the service has been activated (see fig- ure opposite). Configuring Services - Tap and hold the service that you want to connect to, and then tap Configure (see figure opposite) -Tap Save settings to save the service configuration set- tings. Transferring Files You can exchange files with a connected device. You can use the File Transfer service to: • Browse through the directories • View files and folders • Transfer files to / from a remote device. Follow the instructions below: - Tap and hold a File Transfer service, then tap Configure. - To authenticate the client, check the Authenticate check box and type in a password (see figure opposite). When the other device connects to this service, it must enter a passkey to establish the connection. Secured connection is an encrypted connection, which requires an authentica- tion. This step is optional. - Tap and hold File Transfer service, then tap Connect. A check mark now appears over the service icon. - Tap and hold File Transfer service, then tap Browse.

Designed for the most extreme field conditions, MobileMapper(tm) CE is a lightweight, rugged and powerful handheld GPS receiver for GIS. The Microsoft(r) Windows(r) CE operating system supports off-the-shelf Windows CE GIS software and many other mobile applications. Valuable features include real-time, sub-meter GPS positioning, Bluetooth(r) wireless technology, SD memory card expandability, touch-screen technology, field replaceable all-day runtime battery, built-in alphanumeric keypad and more. MobileMapper CE is optimized to overcome the challenges of urban canyons and dense foliage with advanced multipath mitigation. Simple, rugged and affordable, MobileMapper CE ensures your success with uncompromised performance and affordability.

Features: ƒ Small and lightweight ƒ Omnidirectional, azimuth plane ƒ Wide bandwidth, ultra-wide band capable ƒ Internal mounting ƒ Available in tape and reel packaging ƒ SMT compatible Specifications: Frequency Range 2.4 – 2.5 GHz, 5.15-5.875 GHz Polarization Linear Peak Gain > 2 dBi (2.4-2.5 GHz) > 3 dBi (5.15-5.875 GHz) Nominal Impedance 50 ohms VSWR (Min. Performance) <2.0:1 (2.4-2.5 GHz, 5.15-5.875 GHz) Temperature Range -40° to +85°C Vibration 6G RMS (9.04g2/Hz) for 15 minutes each in vertical and horizontal. No appearance or functional axis. Thermal Shock Change after 4 repeated cycles of 1 hr. at +85°C and 1 hr. at -40°C. Transfer time is 5 min. Radiating Element Size (L x W x H) 8 x 6 x 2.5 mm Physical Mass 0.21 grams Length w/ Solder Tabs 12mm BlueChip Part Number (P/N): CAF95901 Single Band Eval PCBA: CAF95943 UWB Eval PCBA : CAF94408 BlueChip 3 – 2/12/03 Azimuth 2450 MHz Free Space Elevation 2450MHz PHI=0 Free Space Parallel Patch on PCB connected directly to feed line for UWB 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 1800 2000 2200 2400 2600 2800 3000 3200 3400 3600 3800 4000 4200 4400 4600 4800 5000 5200 5400 5600 5800 6000 Frequency (MHz) VSWR Typical VSWR performance on evaluation PCB PCMCIA Design Elevation 5800 MHz PHI=0 Free Space Internal Wireless Device Antenna

MPE Calculations Systems operating under the provision of 47 CFR 1.1307(b)(1) shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the FCC guidelines. The EUT will only be used with a separation of 1 meter or greater between the antenna and the body of the user or nearby persons and can therefore be considered a mobile transmitter per 47 CFR 2.1091(b). The MPE calculation for this exposure is shown below. Power density at the specific separation: S = PG/(4R 2 π) S = (0.13156 x 1.58) / (4 x 1 2 x π ) S = 0.0165413552 mW/ cm 2 Where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW). G = Numeric power gain of the antenna – worst case R = Distance to the center of the radiation of the antenna (1 cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1mW/cm 2. The power density at 1 centimeter does not exceed the 1mW/ cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (antenna gain in dBi/10) G = Log -1 (2/10) G = 1.58

Report Number: B50430D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report GPS Receiver Model: MobileMapper CE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 24 FCC PART 15, SUBPART B and C TEST REPORT for GPS RECEIVER MODEL: MobileMapper CE Prepared for THALES NAVIGATION, INC. 960 OVERLAND COURT SAN DIMAS, CALIFORNIA 91773 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MAY 12, 2005 REPORT APPENDICES TOTAL BODY A B C D E PAGES 24 2 2 2 17 59 106 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50430D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report GPS Receiver Model: MobileMapper CE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 24 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment for Brea Facility – Part 1 12 5.3 EMI Test Equipment for Brea Facility – Part 2 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Channel Number and Frequencies 15 7.2 Antenna Gain 15 8. TEST PROCEDURES 16 8.1 RF Emissions 16 8.1.1 Conducted Emissions Test 16 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 17 8.2 20 dB Bandwidth 19 8.3 Peak Output Power 20 8.4 RF Antenna Conducted Test 20 8.5 RF Band Edges 21 8.6 Carrier Frequency Separation 21 8.7 Number of Hopping Frequencies 21 8.8 Average Time of Occupancy Test 22 8.9 Spectral Density Test 23 9. CONCLUSIONS 24 Report Number: B50430D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report GPS Receiver Model: MobileMapper CE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 24 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site Report Number: B50430D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report GPS Receiver Model: MobileMapper CE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 24 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: GPS Receiver Model: MobileMapper CE S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Manufacturer: Thales Navigation, Inc. 960 Overland Court San Dimas, California 91773 Test Dates: April 19, 21, and 22, 2005 Test Specifications : EMI requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 2003 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50430D1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report GPS Receiver Model: MobileMapper CE Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 24 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207 2 Spurious Radiated RF Emissions, 30 MHz – 1000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.209 3 Spurious Radiated RF Emissions, 10 kHz – 30 MHz and 1000 MHz – 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; an…
