Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 40 of 72 APPENDIX C: CONFIDENTIALITY REQUEST Please see the following page. www.identecsolutions.com 14 April 2004 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 SUBJECT: Request For Confidentiality Reference A: O2E-ILR-ICARDIII To Whom It May Concern: Further to the device approval identified at Reference A, IDENTEC SOLUTIONS hereby requests confidentiality pursuant to Section 0.459 of the Commission’s rules (CFR 47). IDENTEC SOLUTIONS requests that the following documents be withheld from public inspection: 1. Block Diagram 2. Theory of Operation 3. Schematics These exhibits contain IDENTEC SOLUTIONS’ proprietary information, trade secrets, or other confidential information that IDENTEC SOLUTIONS does not release to the public and which is otherwise not available to the general public. Since this design is a basis from which future technological products will evolve, IDENTEC SOLUTIONS considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. IDENTEC SOLUTIONS protects all of its proprietary, intellectual property rights and confidential information by requiring all of its employees and all other recipients of such information to sign confidentiality and non-disclosure agreements prior to receiving such information. If you have any questions or concerns, please do not hesitate to contact me at (250) 860-6567. Yours truly, IDENTEC SOLUTIONS, INC. Marty Brooks Product Engineer Email: [email protected] IDENTEC SOLUTIONS, INC. Suite 102, 1860 Dayton Stree t Kelowna, British Columbia Canada V1Y 7W6 Tel : (250) 860-6567 Fax: (250) 860-6541

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 39 of 72 APPENDIX B: AGENCY AUTHORIZATION Please see the following page. www.identecsolutions.com 14 April 2004 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 SUBJECT: Agent Authorization Reference: FCC ID: O2E-ILR-ICARDIII To Whom It May Concern: Please consider this letter as our authorization for Rhein Tech Laboratories, Inc. (RTL), 360 Herndon Parkway, Suite 1400, Herndon, VA 20170 to act as our agent in all matters relating to the Reference FCC applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. If you have any questions or concerns, please do not hesitate to contact me at (250) 860-6567. Yours truly, IDENTEC SOLUTIONS, INC. Marty Brooks Product Engineer Email: [email protected] IDENTEC SOLUTIONS, INC. Suite 102, 1860 Dayton Stree t Kelowna, British Columbia Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 26, 2004 RE: FCC ID: O2E-ILR-ICARDIII Attention: Kathy Grzovic / Desmond Fraser I have a few comments on this Application. 1. On the second to last photo in the internal photo exhibit, in the upper left corner, there is an undetermined component/shielded area. Please explain and or remove the shielding and show the board underneath. 2. Please note that the manual states that maximum output for this device used in North America is 24dBm. This is about 250mW. Please note that 15.245 limits are in field strength (dBuV/m). For 902-928MHz this correlates to 113.98dBuV/m or 6.98dBm at 3 meters (assuming a 50 Ohm system). Please also note that as the limit is a field strength limit, this maximum level would include any gain of any antenna used. It is not stated as to how the power listed in the manual and the measured values relate. Please verify that the information in the manual is accurate and representative for this device and is in line with actual allowed and measured values. 3. Please note that section 1.1 (page 5 of the test report) states that you modified the power settings of the device in order to test the YAGI antenna. Please note that as this is not a professionally installed device, this user power adjustable configuration is not allowed (see 15.15b - “An intentional or unintentional radiator must be constructed such that the adjustments of any control that is readily accessible by or intended to be accessible to the user will not cause operation of the device in violation of the regulations.”) This means the user cannot have access to any controls, firmware or software that would allow the device to exceed its maximum output or frequency range. This also means that the maximum output at the time the YAGI was used is the maximum output for the device under all configurations and antenna(s). Please explain how the manufacturer intends on limiting the device output so it does not exceed this level. Also, please test the other antenna configurations using the same maximum allowed output as used with the YAGI antenna. Alternately, please explain how this device is professionally installed so as the various power levels and antennae configurations do not violate the maximum filed strength levels for all antenna configurations. 4. Please note that the technical specification / operating description states that there are 4 antenna types used with this device (monopole, dipole, patch and YAGI). Please verify if the 1.4wave data in the report is meant to be for the monopole antenna stated in the operational description. If this is not the monopole, please test the monopole antenna specified. 5. Please provide the email between Jon Hughes and Tim Harrington of the FCC mentioned in the rf exposure exhibit if available. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 26, 2004 RE: FCC ID: O2E-ILR-ICARDIII Attention: Kathy Grzovic / Desmond Fraser I have a few comments on this Application. 1. On the second to last photo in the internal photo exhibit, in the upper left corner, there is an undetermined component/shielded area. Please explain and or remove the shielding and show the board underneath. Response : The area of the board in question is the frequency synthesizer. It is a single component and does not have an external shield that can be removed. 2. Please note that the manual states that maximum output for this device used in North America is 24dBm. This is about 250mW. Please note that 15.245 limits are in field strength (dBuV/m). For 902-928MHz this correlates to 113.98dBuV/m or 6.98dBm at 3 meters (assuming a 50 Ohm system). Please also note that as the limit is a field strength limit, this maximum level would include any gain of any antenna used. It is not stated as to how the power listed in the manual and the measured values relate. Please verify that the information in the manual is accurate and representative for this device and is in line with actual allowed and measured values. Response : Although the device’s maximum peak power is 24dBm, the 15.245 limit of 7dBm is a time average value. This limit is met due to the duty cycle of the device being less than 5%. 3. Please note that section 1.1 (page 5 of the test report) states that you modified the power settings of the device in order to test the YAGI antenna. Please note that as this is not a professionally installed device, this user power adjustable configuration is not allowed (see 15.15b - “An intentional or unintentional radiator must be constructed such that the adjustments of any control that is readily accessible by or intended to be accessible to the user will not cause operation of the device in violation of the regulations.”) This means the user cannot have access to any controls, firmware or software that would allow the device to exceed its maximum output or frequency range. This also means that the maximum output at the time the YAGI was used is the maximum output for the device under all configurations and antenna(s). Please explain how the manufacturer intends on limiting the device output so it does not exceed this level. Also, please test the other antenna configurations using the same maximum allowed output as used with the YAGI antenna. Alternately, please explain how this device is professionally installed so as the various power levels and antennae configurations do not violate the maximum filed strength levels for all antenna configurations. American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 Response : The YAGI antenna is used specifically when the device is installed by IDENTEC SOLUTIONS or by our Authorized System Integrators (who are considered professional installers). The device is typically shipped direct to end-users with the standard ¼ wave monopole antenna. The higher gain antenna (specifically the YAGI) is used in specialized applications and is available for integration only to those companies that are considered professional installers. Therefore, any installation of the YAGI will only be completed by trainer installers who are competent in the device configuration to maintain compliance with all field strength levels. 4. Please note that the technical specification / operating description states that there are 4 antenna types used with this device (monopole, dipole, patch and YAGI). Please verify if the 1.4wave data in the report is meant to be for the monopole antenna stated in the operational description. If this is not the monopole, please test the monopole antenna specified. Response : Yes, the 1/4 wave antenna data in the report is for the monopole antenna. 5. Please provide the email between Jon Hughes and Tim Harrington of the FCC mentioned in the rf exposure exhibit if available. Response : Please see the cover letter exhibit uploaded with this response. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 63 of 72 APPENDIX K: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 17: ½ WAVE WHIP ANTENNA Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 64 of 72 PHOTOGRAPH 18: 1/4 WAVE WHIP ANTENNA Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 65 of 72 PHOTOGRAPH 19: YAGI ANTENNA TOP VIEW Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 66 of 72 PHOTOGRAPH 20: YAGI ANTENNA BOTTOM VIEW Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 67 of 72 PHOTOGRAPH 21: PATCH ANTENNA FRONT VIEW Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 68 of 72 PHOTOGRAPH 22: PATCH ANTENNA BACK VIEW PCMCIA Card Front View PCMCIA Card Rear View PCMCIA Card End View PCMCIA Card End View

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 42 of 72 APPENDIX E: LABEL AND LOCATION Please see the following pages for a sample label and a photograph of the label location.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 69 of 72 APPENDIX L: INTERNAL PHOTOGRAPHS PHOTOGRAPH 23: PCB MOUNTED WITHOUT PCMCIA CARD Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 70 of 72 PHOTOGRAPH 24: PCB MOUNTED WITH PCMCIA CARD Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 71 of 72 PHOTOGRAPH 25: TOP OF PCB Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 72 of 72 PHOTOGRAPH 26: BOTTOM OF PCB PCMCIA Card with Shields - Top View PCMCIA Card Without Shields - Top View P CMCIA Card - Bottom View

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 FCC CERTIFICATION APPLICATION FOR UNLICENSED TRANSMITTER MODEL: i-Card III/NA FCC ID: O2E-ILR-ICARDIII Identec Solutions, Inc. #102 – 1860 Dayton Street Kelowna, BC Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541 March 15, 2004 STANDARDS REFERENCED FOR THIS REPORT PART 2: 2003 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 2003 RADIO FREQUENCY DEVICES ANSI C63.4-2001 STANDARD FORMAT MEASUREMENT/TECHNICAL REPORT PERSONAL COMPUTER AND PERIPHERALS RSS-210; 2001 LOW POWER LICENSE-EXEMPT RADIO COMMUNICATION DEVICES (ALL FREQUENCY BANDS) FCC Rule Frequency Range (MHz) Output Power (W) Frequency Tolerance Emission Designator 15.245 905-918 0.070 N/A 356KG1D REPORT PREPARED BY: Rhein Tech Laboratories, Inc. Test Engineer: Daniel Baltzell Administrative Writer: Daniel Baltzell Document Number: 2004032 This report may not be reproduced,except in full, without the written approval of Rhein Tech Laboratories, Inc. Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 2 of 72 TABLE OF CONTENTS 1 GENERAL INFORMATION.......................................................................................................................................... 5 1.1 MODIFICATIONS............................................................................................................................................................................ 5 1.2 RELATED SUBMITTAL(S)/GRANT(S).................................................................................................................................... 5 1.3 TEST METHODOLOGY............................................................................................................................................................... 5 1.4 TEST FACILITY............................................................................................................................................................................... 5 2 CONFORMANCE STATEMENT................................................................................................................................6 3 SYSTEM TEST CONFIGURATION........................................................................................................................... 7 3.1 JUSTIFICATION.............................................................................................................................................................................. 7 3.2 EXERCISING THE EUT............................................................................................................................................................... 7 3.3 TEST SYSTEM DETAILS............................................................................................................................................................. 7 3.4 CONFIGURATION OF TESTED SYSTEM............................................................................................................................ 8 4 OCCUPIED BANDWIDTH - §2.1049; NECESSARY BANDWIDTH §2.202 (OCCUPIED BANDWIDTH) –IC RSS-210 §5.9.1................................................................................................................................... 9 4.1 MODULATED BANDWIDTH TEST PROCEDURE............................................................................................................. 9 4.2 TEST EQUIPMENT USED FOR TESTING............................................................................................................................ 9 4.3 MODULATED BANDWIDTH TEST DATA.............................................................................................................................. 9 4.4 MODULATED BANDWIDTH PLOTS..................................................................................................................................... 10 5 RADIATED EMISSIONS............................................................................................................................................. 13 5.1 TEST METHODOLOGY FOR RADIATED EMISSIONS MEASUREMENTS........................................................... 13 5.2 RADIATED EMISSIONS DATA................................................................................................................................................ 14 5.3 FUNDAMENTAL RADIATED EMISSIONS: FCC §15.245; IC RSS-210 §6.2.2 (N) ......................................................................... 14 6 RADIATED SPURIOUS AND HARMONIC EMISSIONS - §2.1053............................................................. 16 6.1 HARMONIC RADIATED EMISSIONS: FCC §15.245 ........................................................................................................................ 16 7 CONDUCTED LIMITS - §15.207; IC RSS-210 §9.............................................................................................. 24 7.1 TEST METHODOLOGY FOR CONDUCTED LINE EMISSIONS MEASUREMENTS.......................................... 24 7.2 CONDUCTED LINE EMISSION TEST.................................................................................................................................. 24 7.3 CONDUCTED LINE EMISSIONS TEST EQUIPMENT.................................................................................................... 24 7.4 CONDUCTED LINE EMISSIONS TEST DATA.................................................................................................................. 25 8 CONCLUSION................................................................................................................................................................ 37 Rhein Tech Laborator…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 47 of 72 APPENDIX J: TEST CONFIGURATION PICTURES PHOTOGRAPH 1: RADIATED TEST CONFIGURATION (¼ WAVE WHIP ANTENNA FRONT VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 48 of 72 PHOTOGRAPH 2: RADIATED TEST CONFIGURATION (¼ WAVE WHIP ANTENNA REAR VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 49 of 72 PHOTOGRAPH 3: RADIATED TEST CONFIGURATION (½ WAVE WHIP ANTENNA FRONT VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 50 of 72 PHOTOGRAPH 4: RADIATED TEST CONFIGURATION (½ WAVE WHIP ANTENNA REAR VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 51 of 72 PHOTOGRAPH 5: RADIATED TEST CONFIGURATION (PATCH ANTENNA FRONT VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 52 of 72 PHOTOGRAPH 6: RADIATED TEST CONFIGURATION (PATCH ANTENNA REAR VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 53 of 72 PHOTOGRAPH 7: RADIATED TEST CONFIGURATION (YAGI ANTENNA FRONT VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-CARD III/NA Suite 1400 FCC ID: O2E-ILR-ICARDIII Herndon, VA 20170 Standards: FCC 15.245/IC RSS-210 http://www.rheintech.com Date: March 15, 2004 Page 54 of 72 PHOTOGRAPH 8: RADIATED TEST C…
