O2E-ILR-IQ8Ci-Q8C ILR Tag

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 26 of 38 APPENDIX H: MANUAL Please see the following pages. ___________________________________________________________________________ i-Q8C ILR Tag User’s Manual IDENTEC SOLUTIONS, Inc. Suite 102, 1860 Dayton Street Kelowna, British Columbia Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541 www.identecsolutions.com Document # 9000-020, Rev. A - 2 – Disclaimer and Limitation of Liability IDENTEC SOLUTIONS, Inc. and its affiliates, subsidiaries, officers, directors, employees and agents provide the information contained in this Manual on an “as-is” basis and do not make any express or implied warranties or representations with respect to such information including, without limitation, warranties as to non- infringement, reliability, fitness for a particular purpose, usefulness, completeness, accuracy or currentness. IDENTEC SOLUTIONS, Inc. shall not in any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages. Trademarks “IDENTEC SOLUTIONS”, “Intelligent Long Range”, “ILR” and the stylized “i” are registered trademarks and “i-Q”, “i-D”, “i-CARD”, “i-PORT”, “i-LINKS”, “Solutions. It’s in our name.” are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC SOLUTIONS AG. Copyright Notice Copyright © 2003 IDENTEC SOLUTIONS, Inc. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, photographic, electronic, mechanical or otherwise, or used in any information storage and retrieval system, without the prior written permission of IDENTEC SOLUTIONS, Inc. Document # 9000-020, Rev. A - 3 – Radio Frequency Compliance Statement IDENTEC SOLUTIONS, Inc. is the responsible party for the compliance of the following device: MODEL: i-Q8C FCC ID: O2E-ILR-IQ8C CANADA: 3538B-IQ8C The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS, Inc. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, Inc., or unauthorized changes to approved products, may void the compliance of these products and may result in the loss of the user(s) authority to operate the equipment. Operation is subject to the following conditions: (1) these devices may not cause harmful interference, and (2) these devices must accept any interference, including interference that may cause undesired operation of the device. FCC Compliance This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communication. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Compliance This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Document # 9000-020, Rev. A - 4 – Table of Contents 1.0 INTRODUCTION........................................................................................................................................................5 1.1 FUNDAMENTALS...........................................................................................................................................................5 1.2 SYSTEM OVERVIEW......................................................................................................................................................5 1.3 OPERATIONAL DESCRIPTION......................................................................................................................................5 2.0 CONFIGURATION.....................................................................................................................................................6 3.0 MOUNTING THE TAG.............................................................................................................................................6 4.0 TECHNICAL SPECIFICATIONS..........................................................................................................................7 5.0 TECHNICAL CONTACTS.......................................................................................................................................7 Document # 9000-020, Rev. A - 5 – 1.0 Introduction 1.1 Fundamentals IDENTEC SOLUTIONS’ ILR ® (Intelligent Long Range ® ) technology is the next generation of long range RFID (Radio Frequency Identification). The objective is wireless and automated data collection over large distances. 1.2 System Overview IDENTEC SOLUTIONS’ ILR-System consists of four main components: • Active tags (also called transponders) with internal power supply, which are used to identify goods or to store data and histories • Interrogator (i-PORT; fixed-mounted) and handheld devices (mobile), which exchange information with the tags and host computer systems • Antennas f…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 19 of 38 APPENDIX C: CONFIDENTIALITY REQUEST Please see the following page. www.identecsolutions.com 13 June 2003 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 SUBJECT: Request For Confidentiality Reference A: O2E-ILR-IQ8C To Whom It May Concern: Further to the device approval identified at Reference A, IDENTEC SOLUTIONS hereby requests confidentiality pursuant to Section 0.459 of the Commission’s rules (CFR 47). IDENTEC SOLUTIONS requests that the following documents be withheld from public inspection: 1. Block Diagram 2. Theory of Operation 3. Schematics These exhibits contain IDENTEC SOLUTIONS’ proprietary information, trade secrets, or other confidential information that IDENTEC SOLUTIONS does not release to the public and which is otherwise not available to the general public. Since this design is a basis from which future technological products will evolve, IDENTEC SOLUTIONS considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. IDENTEC SOLUTIONS protects all of its proprietary, intellectual property rights and confidential information by requiring all of its employees and all other recipients of such information to sign confidentiality and non-disclosure agreements prior to receiving such information. If you have any questions or concerns, please do not hesitate to contact me at (250) 860-6567. Yours truly, IDENTEC SOLUTIONS, INC. Marty Brooks Product Engineer Email: [email protected] IDENTEC SOLUTIONS, INC. Suite 102, 1860 Dayton Street Kelowna, British Columbia Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 18 of 38 APPENDIX B: AGENCY AUTHORIZATION Please see the following page. www.identecsolutions.com 13 June 2003 American TCB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 SUBJECT: Agent Authorization Reference: FCC ID: O2E-ILR-IQ8C To Whom It May Concern: Please consider this letter as our authorization for Rhein Tech Laboratories, Inc. (RTL), 360 Herndon Parkway, Suite 1400, Herndon, VA 20170 to act as our agent in all matters relating to the Reference FCC applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. If you have any questions or concerns, please do not hesitate to contact me at (250) 860-6567. Yours truly, IDENTEC SOLUTIONS, INC. Marty Brooks Product Engineer Email: [email protected] IDENTEC SOLUTIONS, INC. Suite 102, 1860 Dayton Street Kelowna, British Columbia Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 2, 2003 RE: FCC ID: O2E-ILR-IQ8C_ATCB000553 Attention: Kathy Grzovic / Desmond Fraser I have a few comments on this Application. 1. Please note that the OBW measurements in the test report were done incorrectly. Please note that the Resolution bandwidth can either be set to 5% greater than the bandwidth requirements or it can be set to that specified in ANSI C63.4 (section 13.1.7). Your plot used an inappropriate RBW of 300Hz. Please retest the bandwidth using the proper Res and vid band width setting for Part 15 devices according to ANSI C63.4. Also, please note that the OBW of ANCI C63.4 for Part 15 devices is the 26dB bandwidth, not the 20dB bandwidth. 2. Please note that in table 3 of your report you have a number of AV and Pk limits reversed. Please compare the measured reading to the proper peak and average limits. 3. Please verify that the antenna is an integral antenna. The schematic appears to show a printed integral antenna, but parts of the technical description indicate that the device uses an external antenna. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 2, 2003 RE: FCC ID: O2E-ILR-IQ8C_ATCB000553 Attention: Kathy Grzovic / Desmond Fraser I have a few comments on this Application. 1. Please note that the OBW measurements in the test report were done incorrectly. Please note that the Resolution bandwidth can either be set to 5% greater than the bandwidth requirements or it can be set to that specified in ANSI C63.4 (section 13.1.7). Your plot used an inappropriate RBW of 300Hz. Please retest the bandwidth using the proper Res and vid band width setting for Part 15 devices according to ANSI C63.4. Also, please note that the OBW of ANCI C63.4 for Part 15 devices is the 26dB bandwidth, not the 20dB bandwidth. Response : Please refer to the revised test report uploaded with this response. 2. Please note that in table 3 of your report you have a number of AV and Pk limits reversed. Please compare the measured reading to the proper peak and average limits. Response : Please refer to the revised test report uploaded with this response. 3. Please verify that the antenna is an integral antenna. The schematic appears to show a printed integral antenna, but parts of the technical description indicate that the device uses an external antenna. Response : The antenna is an integral antenna, as evidenced by the antenna trace shown in photograph #12 in the Internal Photograph exhibit uploaded with the original application. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 29 of 38 APPENDIX J: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 4: TOP OF i-Q8C TAG Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 30 of 38 PHOTOGRAPH 5: BOTTOM OF i-Q8C TAG Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 31 of 38 PHOTOGRAPH 6: SIDE OF i-Q8C Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 32 of 38 PHOTOGRAPH 7: i-Q8C BACK SIDE WITH CONNECTOR Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 33 of 38 PHOTOGRAPH 8: i-Q8C CONNECTOR

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 20 of 38 APPENDIX D: LABEL AND LOCATION Please see the following pages for a sample label and a photograph of the label location. Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 21 of 38 FIGURE 2: SAMPLE FCC ID LABEL Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 22 of 38 PHOTOGRAPH 1: LABEL LOCATION ON BACK OF EUT FCC ID LABEL LOCATION

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 34 of 38 APPENDIX K: INTERNAL PHOTOGRAPHS PHOTOGRAPH 9: i-Q8C PCB IN CASE Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 35 of 38 PHOTOGRAPH 10: i-Q8C INSIDE BACK CASE Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 36 of 38 PHOTOGRAPH 11: i-Q8C CIRCUIT CARD TOP Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 37 of 38 PHOTOGRAPH 12: i-Q8C CIRCUIT CARD BOTTOM Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 38 of 38 PHOTOGRAPH 13: i-Q8C CIRCUIT CARD BOTTOM WITHOUT BATTERY

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 APPLICATION FOR FCC CERTIFICATION UNLICENSED TRANSMITTER MODEL: i-Q8C FCC ID: O2E-ILR-IQ8C Identec Solutions, Inc. #102 – 1860 Dayton Street Kelowna, BC Canada V1Y 7W6 Tel: (250) 860-6567 Fax: (250) 860-6541 June 14, 2003 STANDARDS REFERENCED FOR THIS REPORT PART 2: 1999 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 1999 RADIO FREQUENCY DEVICES ANSI C63.4-1992 STANDARD FORMAT MEASUREMENT/TECHNICAL REPORT PERSONAL COMPUTER AND PERIPHERALS RSS-210 LOW POWER LICENSE-EXEMPT RADIO COMMUNICATION DEVICES (ALL FREQUENCY BANDS) FCC Rules Parts Frequency Range (MHz) Output Power (W) Frequency Tolerance Emission Designator 15.249 916.5 0.00070 N/A N/A REPORT PREPARED BY: Test Engineer: Daniel Baltzell Administrative Writer: Daniel Baltzell Rhein Tech Laboratories, Inc. Document Number: 2003095 No part of this report may be reproduced without the full written approval of Rhein Tech Laboratories, Inc. Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 2 of 38 TABLE OF CONTENTS 1 GENERAL INFORMATION ................................................................................................... 4 1.1 MODIFICATIONS ............................................................................................................................... 4 1.2 RELATED SUBMITTAL(S)/GRANT(S) .................................................................................................... 4 1.3 TEST METHODOLOGY ........................................................................................................................ 4 1.4 TEST FACILITY .................................................................................................................................. 4 2 CONFORMANCE STATEMENT.............................................................................................. 5 3 SYSTEM TEST CONFIGURATION ........................................................................................ 6 3.1 JUSTIFICATION ................................................................................................................................. 6 3.2 EXERCISING THE EUT ........................................................................................................................ 6 3.3 TEST SYSTEM DETAILS ...................................................................................................................... 6 3.4 CONFIGURATION OF TESTED SYSTEM ................................................................................................ 7 4 CONDUCTED EMISSIONS ................................................................................................... 8 5 RADIATED EMISSIONS ...................................................................................................... 9 5.1 TEST METHODOLOGY FOR RADIATED EMISSIONS MEASUREMENTS...................................................... 9 5.2 RADIATED EMISSION DATA...............................................................................................................10 6 MODULATED BANDWIDTH - §15.247(A)(2) .................................................................... 13 6.1 MODULATED BANDWIDTH TEST PROCEDURE.....................................................................................13 6.2 TEST EQUIPMENT USED FOR TESTING...............................................................................................13 6.3 MODULATED BANDWIDTH TEST DATA ...............................................................................................13 6.4 MODULATED BANDWIDTH PLOTS ......................................................................................................14 7 CONCLUSION ................................................................................................................... 15 Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 3 of 38 FIGURE INDEX FIGURE 1: TEST SYSTEM CONFIGURATION................................................................................................. 7 FIGURE 2: SAMPLE FCC ID LABEL..............................................................................................................21 TABLE INDEX TABLE 1: EQUIPMENT UNDER TEST (EUT).....................................................................................................6 TABLE 2: FUNDAMENTAL RADIATED EMISSIONS: FCC PART 15.249 ..............................................................10 TABLE 3: HARMONIC RADIATED EMISSIONS: FCC PART 15.249....................................................................10 TABLE 4: DIGITAL RADIATED EMISSIONS; FCC PART 15.209.........................................................................11 TABLE 5: EQUIPMENT USED FOR TESTING...................................................................................................12 TABLE 6: TEST EQUIPMENT USED FOR TESTING (MODULATED BANDWIDTH) ................................................13 TABLE 7: MODULATED 20 DB BANDWIDTH ..................................................................................................13 APPENDIX INDEX APPENDIX A: ADDITIONAL INFORMATION SUPPLEMENTARY TO THE TEST REPORT .........................................16 APPENDIX B: AGENCY AUTHORIZATION ........................................................................................................18 APPENDIX C: CONFIDENTIALITY REQUEST ....................................................................................................19 APPENDIX D:…

Text truncated - open the document above for the full version.

Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 27 of 38 APPENDIX I: TEST CONFIGURATION PICTURES PHOTOGRAPH 2: RADIATED TEST CONFIGURATION (FRONT VIEW) Rhein Tech Laboratories, Inc. Client: Identec Solutions, Inc. 360 Herndon Parkway Model: i-Q8C Suite 1400 Report No: 2003095 Herndon, VA 20170 Standards: FCC 15.249/IC RSS-210 http://www.rheintech.com Date: June 14, 2003 Page 28 of 38 PHOTOGRAPH 3: RADIATED TEST CONFIGURATION (REAR VIEW)
