O2K-106050PENDANT TRANSMITTER

SYDNEY – Head Office BRISBANE MELBOURNE PERTH 4/167 Prospect Highway 3/471 Lytton Road 24 Terracotta Drive Unit 1, 567 Newcastle Street Seven Hills NSW 2147 Australia Morningside QLD 4170 Australia Blackburn VIC 3130 Perth WA 6000 Telephone 02 8825 9222 Telephone 07 3399 4910 Telephone 03 9875 6400 Telephone 08 9328 2511 Fax 02 9674 2520 Fax 07 3217 9711 Fax 03 9875 6422 Fax 08 9227 7073 [email protected] [email protected] [email protected] [email protected] ABN 28 069 984 372 REQUEST FOR CONFIDENTIALITY Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: O2K-106050 Request for Confidentiality Dear Sirs: With regard to the referenced application, Ness Security Systems, is requesting confidentiality of certain sections of the accompanying documents. The documents for which Ness Security Systems is requesting confidentiality are: Schematic Diagram Schematic.jpg Block Diagram BlkDiagram.pdf Operational Descriptions OperDesc.pdf This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. The material for which confidentiality is requested falls within the scope of Section 552(b)(4) as trade secrets and includes material covered by Section 0.459 of the Commission’s Rules. Sincerely, David Steele Engineering Director U.S. Distribution Agent

FCC TEST REPORT PART 15.231 APPLICANT NESS SECURITY PRODUCTS PTY LTD. ADDRESS 4/167 PROSPECT HIGHWAY SYDNEY AUSTRALIA FCC ID O2K-106050 PRODUCT DESCRIPTION PENDENT TRANSMITTER DATE SAMPLE RECEIVED 6/18/2007 DATE TESTED 7/9/2007 TESTED BY Richard Block APPROVED BY Richard Block TIMCO REPORT NO. N\NESS_O2K\2320UT7\2320UT7TestReport.doc TEST RESULTS PASS FAIL TOTAL PAGES 13 THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM APPLICANT: NESS SECURITY PRODUCTS PTY LTD. FCC ID: O2K-106050 REPORT: N\NESS_O2K\2320UT7\2320UT7TestReport.doc Page 2 of 15 TABLE OF CONTENTS GENERAL INFORMATION ......................................................... 3 COMPLIANCE WITH PART 15.231(a)........................................... 2 EMC EQUIPMENT LIST.......................................................... 3 TEST PROCEDURE............................................................ 4 RADIATION INTERFERENCE................................................... 5 CALCULATION OF DUTY CYCLE................................................ 7 OCCUPIED BANDWIDTH....................................................... 11 APPLICANT: NESS SECURITY PRODUCTS PTY LTD. FCC ID: O2K-106050 REPORT: N\NESS_O2K\2320UT7\2320UT7TestReport.doc Page 3 of 15 GENERAL INFORMATION EUT Specification The test results relate only to the items tested. FCC ID O2K-106050 Product Description PENDANT TRANSMITTER Operating Frequency 303.818 MHz Max. output power 0.001777 mW Primary Power 3VDC EUT Power Secondary Power N/A Prototype Pre-Production Test Item Production Fixed Mobile Type of Equipment Portable Test standards FCC Part 15, Subparts C ANSI C63.4 – 2003 Modification to the DUT None Test exercise The EUT was set in continuous transmit mode of operation. Test Facility Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669. APPLICANT: NESS SECURITY PRODUCTS PTY LTD. FCC ID: O2K-106050 REPORT #: N\NESS\_O2K\2320UT7\2320UT7TestReport.doc Page 2 of 13 COMPLIANCE WITH PART 15.231(a) Part 15.231(a): • Continuous operation: Yes No • Control signal only: Yes No • Data transmission with a control signal Yes No N/A Description of control signal: _______________(notes: indicate whether such info is included in supporting exhibit such as operation description page xx) Part 15.231(a)(1): • Manually operated device: Yes No • Does it meet the 5s deactivation requirement after the switch is being released: Yes No Description: _______________(notes: a plot showing the pulse train does not necessarily constitute an objective evidence of compliance with the deactivation requirement. A plot should be accompanied by an explanation and/or statement of compliance, if not otherwise clearly stated in supporting documentation e.g. operation description page xx) Part 15.231(a)(2): • Automatically operated device: Yes No • Does it meet the 5s deactivation requirement after being activated: Yes No Description: _______________(notes: a plot showing the pulse train does not necessarily constitute an objective evidence of compliance with the deactivation requirement. A plot should be accompanied by an explanation and/or statement of compliance, if not otherwise clearly stated in supporting documentation e.g. operation description page xx) Part 15.231(a)(3): • Periodic transmission at regular predetermined intervals: Yes No N/A Description: ________________ • Polling or supervision transmissions, including data, to check system integrity check requires a total transmission time not exceeding 2s per hour: Yes No N/A Part 15.231(a)(4): Operation involving fire, security, or safety of life, when activated to signal an alarm, may operate during the pendency of the alarm condition. Does the transmitter meet the condition? Yes No N/A APPLICANT: NESS SECURITY PRODUCTS PTY LTD. FCC ID: O2K-106050 REPORT #: N\NESS\_O2K\2320UT7\2320UT7TestReport.doc Page 3 of 13 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter OATS TEI N/A N/A Listed 1/11/06 1/10/09 3/10-Meter OATS TEI N/A N/A Listed 3/20/07 3/19/10 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 5/11/07 5/10/10 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 12/7/05 12/7/07 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 12/7/05 12/7/07 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 12/8/05 12/8/07 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 12/8/05 12/8/07 Analyzer Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 5/17/07 5/17/09 Analyzer Blue Tower RF Preselector HP 85685A 2926A00983 CAL 5/17/07 5/17/09 Analyzer Blue Tower Quasi- Peak Adapter HP 85650A 2811A01279 CAL 5/17/07 5/17/09 Analyzer Silver Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/30/06 10/30/08 Analyzer Silver Tower RF Preselector HP 85685A 2620A00294 CAL 3/6/07 3/6/09 Analyzer Silver Tower Quasi- Peak Adapter HP 85650A 3303A01844 CAL 10/30/06 10/30/08 Analyzer Open- Frame Tower Preamplifier HP 8449B 3008A01075 CAL 8/8/05 8/8/07 Antenna: Biconnical Eaton 94455-1 1096 CAL 10/11/06 10/11/08 Antenna: Biconnical Eaton 94455-1 1057 CAL 12/12/05 12/12/07 Antenna: Log- Periodic Electro-Metrics LPA-25 1122 CAL 12/1/06 12/1/08 APPLICANT: NESS SECURITY PRODUCTS PTY LTD. FCC ID: O2K-106050 REPORT #: N\NESS\_O2K\2320UT7\2320UT7TestReport.doc Page 4 of 13 TEST PROCEDURE RADIATION INTERFERENCE: The test procedure used was ANSI standard C63.4-2003 using a spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was 300 kHz. The ambient temperature of the UUT was 98.3ºF with a humidity of 40%. FORMULA…
