 Make sure that you use the correct AC power adapter supplied with the terminal. Many adapters can appear similar and will plug into the terminal but will not work properly causing erratic behavior, poor charging or even damage to the unit . 2.4.2 Normal use:  1. After a full charge the Terminal in normal usage is expected to provide 50 or more transactions before the terminal has to be returned to the base for charging. Slow printing or a message <<-BAT->> on the display followed by beep usually indicates the battery is low 2. This terminal has a “reserve” capability in the event that more transactions are occasionally needed. As long as the print time is acceptable the Terminal will provide additional transactions beyond normal. The effect will be continued slowdown of the printer as well as a longer recharge cycle. 3. Do not use a “Fast Charging Base” if the terminal is returned to the base after each transaction. The batteries may be damage d and their life time reduced. A fast charging base should be used to charge battery pack ONLY when there is slow printing or a message <<-BAT->> displays otherwise use slow charging base. 3. Cleaning procedure: 1. Clean the outside of the terminal with a soft cloth moistened with a mild detergent solution. 2. Never spray cleaning so lution directly onto the terminal as drops may enter the unit. 3. Do not use Isopropyl Alcohol based cleaning products. 4. Technical specifications: 4.1 Terminal Features: • Magnetic card reader, ISO1 and ISO2 tracks decoding. • 18 key, backlit t actile feedback keyboard with audible tone and color coding. • Battery backed-up calendar and clock. • RS232 communications channel. • Logical and physical security. • Multi-application operating system allowing each application to be downloaded independently of all others. 4.2 Network: The terminal is equipped with an RF modem for exchanging data over one of the following networks: 1. Rogers Network. 2. CDPD 4.3 Power supply: The power adapter is mainly used for charging the internal NiMh battery. Power input voltage : 100-220V AC. Power input frequency : 50-60 Hz. Power output : 11V DC, 1.5A Figure 4: DC Plug 4.4 Operating environment Operating temperature : 5 to 40°C Humidity: 5% to 90% RH, with no condensation. 5. Thermal Paper Specification: The following specifications identify the thermal paper roll that must be used with Elite 790 Terminals: • Single ply thermal sensitive - POS or facsimile grade. • Basis Weight: (lb/rm 17 ins. X 22 ins. - 500) --- 14.5 +/- 5% (GSM) --- 55 +/- 5% • Caliper: 2.4 +/- 0.2 Mils or 60 +/- 5 Microns • Brightness: Min. 85% • Smoothness (Bekk Minimum): 300 s • Roll Width: 2.25 +/- 0.020 in (58 mm +/- 0.5 mm). • Roll Diameter: 2.0 in (51 mm) maximum. • Roll Core ID: 0.500 in (13 mm) nominal. • Roll Core OD: 0.625 in (16 mm) nominal. For best performance, Ingenico recommends The following sources/barnds: KANZAKI P300 APPLETON T1012A KOEHLER K55 5.1 Storage Recommendation for Thermal Paper: Thermal paper should NOT be exposed to vinyl, Plastics, adhesives, shrink-wraps, wet-toner copies or certain carbon papers, office light, UV light, high humidity and temperature (above 65%, 25C) for long periods of time. 7. If you experience problems : Call one of the customer service centers listed below: In Canada: In the USA: RBA Inc. Ingenico Inc. 3190 Orlando Drive TotalCARE Mississauga, Ontario 1335North Meadow L4V 1R5 Parkway, Suite 116 1-800-387-3938 Atlanta GA 30076 or (905) 672-1048 1-800 – 435-3014 US Federal Communicati ons Commission (FCC) Warnings: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are de signed to provide reasonable protection against harmful interference when this equipment is operated in a commercial envi ronment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Canadian Department of Communications (DOC) Warnings: This digital apparatus does not exceed the Class A limits for radio noise emissions from the digital apparatus as set out in the radio interference regulations of the Canadian Department of Communications. Ingenico Inc. 1003 Mansell Road, Atlanta, GA 30076 Tel: 770.594.6000 Fax 770.594.6003 www.ingenico-us.com Ingenico Canada Ltd. 79 Torbarrie Road, Toronto, Ontario – Canada M3L 1G5 Tel:416.245.6700 Fax: 416.245.6701 www.ingenico-ca.com Elite 790 Installation Guide 0130-00031-0100 1. Terminal description: 1.1 Introduction: The Elite 790 is a fully self-contained RF EFTPOS terminal with an integrated printer and the functionality to process all smart card, debit and credit purchases. The terminal communicates with the bank using the RF data network or using Fast Charging or Slow Charging Base through Telephone network. This RF network is similar to that used for mobile phones except that it is for data only. The terminal features a secure, multi-application operating system, which allows a number of different applications to run on the terminal independently, without jeopardizing software security. 1.2 The Terminal: The Elite 790 terminal has th e following peripherals: 1.2.1 Display: Standard 4 line x 16 character LCD graphic display, with back lighting. 1.2.2 Keypad: • 18 keys, with back light ing, with the following special function keys: • F1, F2, and F3 keys: Programmable keys which permit access to terminal level functions and the system menu. • Paper Feed key: Performs a 20mm paper feed. • ENTER key: is used to confirm the data entered or di…

Text truncated - open the document above for the full version.

March 2002/ version 1.6 Integra Version : 1.7 Date : March 2002 Reference : WM_Integra_UG_016 confidential © 1/60 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. March 2002/ version 1.6 Integra Level/ Indice Date/ Date History of the evolution / Historique des évolutions Writer / Rédacteur 0.3 June 2000 Creation and Correction P. Calvez, S. Dechicha F. Doherier, T. Lapousterle, M. Nau, D. Martinez, B. Zenou 1.2 Sept. 2000 Correction: figure 5 application note for serial link S. Dechicha 1.3 Sept 2000 Application note for external SIM 3V/5V interface S. Dechicha 1.4 January 2001 Minor formal modifications + addition of the mechanical specifications M. Nau 1.5 August 2001 SIM3/5V electric scheme added + modification flat cable reference S. Marion 1.6 March 2002 Modifications to include 2C-2 module version N. Subiger 1.7 March 2002 Add RF exposure and OEM instructions O. Clerc Name / Nom Function / Fonction Date/ Date Signature/ Signature Written by / Rédigé par B.Zenou Product Marketing June 2000 Validated by / Validé par D. MARTINEZ Modem Support Engineer June 2000 Approved by / Approuvé par P.Calvez Product Marketing Senior Manager June 2000 confidential © 2/60 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. March 2002/ version 1.6 Integra Integra User’s Guide Hardware Specifications confidential © 3/60 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. March 2002/ version 1.6 Integra Contents 1 Introduction to the Integra: outstanding assets........................................................................................................................7 1.1 Scope of the user’s guide............................................................................................................7 1.2 General characteristics................................................................................................................8 1.2.1 General.....................................................................................................................................8 1.2.2 Electrical...................................................................................................................................8 1.2.3 Physical....................................................................................................................................8 1.2.4 Basic Features..........................................................................................................................8 1.2.5 Interfaces..................................................................................................................................9 1.3 Mechanical Design Overview....................................................................................................10 2 Safety precautions..................................................................................................................................................................................13 2.1 RF safety....................................................................................................................................13 2.1.1 General...................................................................................................................................13 2.1.2 Exposure to RF energy...........................................................................................................13 2.1.3 Efficient modem operation......................................................................................................13 2.1.4 Antenna care and replacement..............................................................................................13 2.2 General safety...........................................................................................................................14 2.2.1 Driving.....................................................................................................................................14 2.2.2 Electronic devices...................................................................................................................14 2.2.3 Vehicle electronic equipment.................................................................................................14 2.2.4 Medical electronic equipment.................................................................................................14 2.2.5 Aircraft....................................................................................................................................14 2.2.6 Children..................................................................................................................................14 2.2.7 Blasting areas.........................................................................................................................14 2.2.8 Potentially explosive atmospheres.........................................................................................15 2.3 Safety standards........................................................................................................................15 3 Standard Compliance............................................................................................................................................................................15 3.1 GSM compliance.........................................................................................…

Text truncated - open the document above for the full version.

CONFIDENTIALITY FORM Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 February 13, 2002 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, WAVECOM INC requests confidentiality for the following products: FCC ID Number Product Title/Model O9EM2113 Integrated Modem/Integra M2113A For the product stated above, we request that the following information be held confidential: 1) Electrical Schematics of the Circuitry 2) Block Diagram 3) Operational description No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain WAVECOM S.A. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Olivier CLERC Integration Engineer WAVECOM Inc 610 West Ash, suite 1400 SAN DIEGO, California 92101 Tel: (619) 235 9702 ext 108 Fax: (619) 235 9844

79 Torbarrie Road, Toronto, Ontario, M3L 1G5 Tel (416) 245 6700 Fax (416) 245 6701 March 13 th , 2003 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Authority to Act as an Agent to FCC Applicant: Ingenico Canada Ltd. Product: Elite 790 GPRS Model: Elite 790 GPRS FCC ID: O34-E790GPRS Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application to F.C.C. for authorization of equipment under F.C.C. Rules. I also certify that the information provided, properly described the device or system for which authorization is required. Yours truly, Geoff Bowen Executive Vice President & General Manager 79 Torbarrie Road, Toronto, Ontario, Canada, M3L 1G5 (416) 245-6700

April 3, 2003 AmericanTCB, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 Subject: Type Acceptance Application under FCC 47CFR, Parts 2 and 24 (Subpart E) - Personal Communications Services in the Frequency Band 1850.2 – 1909.8 MHz, Boadband PCS Applicant: Ingenico Canada Ltd. Product: Elite 790 GPRS Model: ELITE 790 GPRS FCC ID: O34-E790GPRS Dear Sir/Madam, As appointed agent for Ingenico Canada Ltd., we would like to submit the application to the Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to your website for detailed information. The ELITE 790 GPRS is a handheld Point of Sale, which incorporates the Wavecom radio modem module (FCC ID: O9EM2113). The incorporated radio is identical in design and construction to the original. Thus, in this application, Ultratech will provide test reports for SAR, Power and Spurious Emissions. As for the other required tests, please refer to the original application for Wavecom, which are also uploaded to AmericanTCB eletronic filing site. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-747-6381 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. UltraTech Group of La bs 31040/SIT A96/TH/0093 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 18, 2003 RE: FCC ID: O34-E790GPRS Attention: Tri M. Luu I have a few comments on this Application. 1. Please note that you have placed “This device contains a WAVECOM RF Modem Model No. INTEGRA M2113A which was approved by FCC (FCC ID: O9EM2113)” on the FCC ID label. By placing this statement on the label, this indicates that you have accepted and agree to the use permit associated with that grant. Please note that the OEM installation manual for the FCC ID:O9EM2113 specifically states that portable use is prohibited. Your SAR report tests the device for Body SAR indicating that an intent of your product is portable use. Your test report classifies the device as :Portable.” The SAR report does not provide any information on any accessory that would allow the device to be used in a portable configuration (i.e. no information on shoulder straps, belt clips etc). Also, your manual has no indication of portable use. Please thoroughly explain why the grant conditions on the rf modem internal to your device has been violated and please explain how this device is used in a portable configuration (i.e. what straps, belt clips etc are used). If this is a portable device, please remove the “Contains TX” statement so as not to violate the grant conditions associated with the internal rf modem. If this device is not for use in a portable configuration, please clearly state this and correct all documentation. If this device is not used in a portable configuration then an MPE report not a SAR report is needed. Please clarify, identify and correct all documentation to match the correct classification of this device. 2. Please note that your manual contains no RF exposure information as required. Please note that the end user is required to be informed about rf hazards for either portable or mobile devices. If portable, then the rf statement in the user manual must clearly state compliance to SAR requirements; if mobile the user manual must clearly state 20cm separation requirements. Also please note that the OEM installation manual does not appear to be the document provided to the end user and as such the rf statement in that manual is not valid to meet the rf notification requirements to the user. Please provide a proper rf exposure statement in the end user manual that is associated with the proper and defined use of this device. 3. Please provide proper probe calibration data. The information provided appears to be more of a calibration method than calibration data. Probes must show calibration data within 100MHz of the target frequencies. Please provide the appropriate calibration certificate and data for the probe. 4. No apparent dipole calibration data was provided. Please provide the dipole calibration data. 5. Please clarify the crest factor on the data sheets/plots for the device under test. Perhaps I have overlooked or missed this item. 6. Please note that the device is classified as a base station (PCB). As such, the power listed on the grant must be conducted power. Your report states that the ‘specification’ is 712mw, and it says the 712mW was measured, but you have provided no evidence of this measurement in the report (i.e. you have not defined how you tested conducted power nor the test method used to measure conducted power). Please provide objective evidence of the antenna conducted power measurements and methods for this base station (PCB) transmitter. 7. Please note that this device operates at 1850.2 and 1909.8MHz. However, your report shows that the lowest and highest frequencies were not tested. Thus you have not shown compliance to band and block edges. It is therefore not known if this device complies with band edge requirements. Please provide plots/data showing compliance with the band edges as required in 24.238(a) and (b). 8. z Page 2 April 18, 2003 Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

In reply to your recent questions: A1. This is a portable device. Therefore, SAR report was required. Please find the revised ID Label uploaded to AmericanTCB.com website per your request. A2. This product has been tested for SAR and found to meet the requirements with no distance stipulation (EUT in contact with body tissue). Since the product inherently meets the RF exposure requirements, no users notice warning of exposure hazard is required. A3. Probe calibration data Brain Tissue Calibration General Information Type ETR "ETR" for E-field triangular, "EI" for E-field I-Beam M/N ETR-UT S/N 0200-1 Sensor Size 2.0 [mm] Sensor Offset 2.00 [mm] Sensor Factor to Power density in the air,  Pd 10.8 [mV/(mW/cm2)] Sensor Factor to |E| 2 in the air,  E2 0.002865 [mV/(V/m)2] Freespace calibration Calibration Date: September 23, 2002 Uniform Field Generating Method Waveguide "TEM cell", "Waveguide" or "Horn Antenna" Frequency, f 1900 [MHz] Power Density, Pd 5 [mW/cm2] Probe Insertion Depth 60 [mm] Probe Incident Angle to E-Field 90 [°] Max. Probe Output for Channel 1, POmax1 3888 Amplifier Setting 1, AS1 0.00925112 Max. Probe Output for Channel 2, POmax2 4248 Amplifier Setting 2, AS2 0.00846713 Max. Probe Output for Channel 3, POmax3 3227 Amplifier Setting 3, AS3 0.01114607 Calibration with calculable field in waveguide Calibration Date: March 7, 2003 Frequency, f 1900 [MHz] Conductivity, σ' 1.43 [S/m] Dielectric Constant, ε 40.9 Penetration Depth from Tissue calibration, δ' 0.024104 [m] Mass Density, ρ 992 [Kg/m3] Specific Heat Capacity, c 3602 [J/Kg/°C] Width of cross-section of Waveguide, a 0.109000 [m] Height of cross-section of Waveguide, b 0.054700 [m] Tissue Temperature in the lossy waveguide 21.0 [°C] Input Power Measurement, Pfw - Pbw 0.222 [W] Return Loss, better than -33.1 [dB] Probe Output [mV] at 5mm, PO(5) 46.2 [mV] Probe Output [mV] at 10mm, PO(10) 29.5 [mV] Probe Output [mV] at 15mm, PO(15) 19.1 [mV] Probe Output [mV] at 20mm, PO(20) 12.0 [mV] Probe Output [mV] at 25mm, PO(25) 7.5 [mV] Probe Output [mV] at 30mm, PO(30) 4.6 [mV] Conversion Factor,  5.372 Conversion Factor, CF (Obsolete) 1.001 [W/Kg/(mW/cm2)] Muscle Tissue Calibration General Information Type ETR "ETR" for E-field triangular, "EI" for E-field I-Beam M/N ETR-UT S/N 0200-1 Sensor Size 2.0 [mm] Sensor Offset 2.00 [mm] Sensor Factor to Power density in the air,  Pd 10.8 [mV/(mW/cm2)] Sensor Factor to |E| 2 in the air,  E2 0.002865 [mV/(V/m)2] Freespace calibration Calibration Date: September 23, 2002 Uniform Field Generating Method Waveguide "TEM cell", "Waveguide" or "Horn Antenna" Frequency, f 1900 [MHz] Power Density, Pd 5 [mW/cm2] Probe Insertion Depth 60 [mm] Probe Incident Angle to E-Field 90 [°] Max. Probe Output for Channel 1, POmax1 3888 Amplifier Setting 1, AS1 0.00925112 Max. Probe Output for Channel 2, POmax2 4248 Amplifier Setting 2, AS2 0.00846713 Max. Probe Output for Channel 3, POmax3 3227 Amplifier Setting 3, AS3 0.01114607 Calibration with calculable field in waveguide Calibration Date: March 8, 2003 Frequency, f 1900 [MHz] Conductivity, σ' 1.59 [S/m] Dielectric Constant, ε 53.5 Penetration Depth from Tissue calibration, δ' 0.024689 [m] Mass Density, ρ 992 [Kg/m3] Specific Heat Capacity, c 3602 [J/Kg/°C] Width of cross-section of Waveguide, a 0.109000 [m] Height of cross-section of Waveguide, b 0.054700 [m] Tissue Temperature in the lossy waveguide 21.0 [°C] Input Power Measurement, Pfw - Pbw 0.178 [W] Return Loss, better than -31.3 [dB] Probe Output [mV] at 5mm, PO(5) 28.1 [mV] Probe Output [mV] at 10mm, PO(10) 17.3 [mV] Probe Output [mV] at 15mm, PO(15) 10.9 [mV] Probe Output [mV] at 20mm, PO(20) 6.6 [mV] Probe Output [mV] at 25mm, PO(25) 3.8 [mV] Probe Output [mV] at 30mm, PO(30) 2.2 [mV] Conversion Factor,  4.378 Conversion Factor, CF (Obsolete) 1.368 [W/Kg/(mW/cm2)] A4. Calculable waveguide calibration procedure specified in IEEE 1528 standards was employed to calibrate the specific probe in the solution at 1.9 GHz. Thermal transfer calibration procedure using dipole is only applied to the application below 1 GHz. For the calculable waveguide calibration result, please refer to page 68 in SAR report and Answer3 above. The reference verification dipole specification (dimension and return loss at target frequency) is listed at page 69 in SAR report as well. A5. The Crest Factor is a parameter which describes the SAR systems ability to measure signals that have various peak to RMS ratios while still remaining within the system specifications. The crest factor is not provided for the 3D-EMC system and a verification test was carried out to determine that the SAR system is responding to the duty cycle waveform as an averaging system. A uniform field within a TEM cell is used to compare the output of the SAR system of a CW signal at the frequency of interest, with a pulse modulated carrier using the same pulse width and repetition rate as the EUT previously tested at 12.5%. An HP 437A Peak power meter is used to set the same peak power in both test conditions. The 3D-EMC system allows for a real-time monitoring of all amplifier channels. The summed output of the three amplifier channels from the probe is directly proportional to the |E| 2 which is also directly proportional to SAR according to the equation: ρ σ 2 E SAR ⋅ = The measured results from the monitor are: SAR System Output for CW = 39.094 SAR System Output for 12.5% = 4.788 The ratio of the CW to Duty Cycle Field = 4.788/39.094*100% = 12.3% A ttenuati on V s D epth y = 48. 067e -101.43x R 2 = 0. 9989 0.0 10.0 20.0 30.0 40.0 50.0 60.0 0.0000.0100.0200.0300.0400.0500.0600.070 Distance [m m ] P r obe Output [m V ] The above test verifies that the SAR system is correctly averaging the pulsed carrier and that the measured SAR values are time based average values. Figure 1. Amplifier channel real-time output monitor of SAR system for a CW signal Figure 2. Amplifier channel real-time output monitor of SAR system for a 12.5% Pulse modulated Sign…

Text truncated - open the document above for the full version.

-----Original Message----- From: Tri Luu [mailto:[email protected]] Sent: Wednesday, May 28, 2003 6:22 AM To: [email protected] Cc: Hung Trinh; Ram Janarthanam; Dan Hyunh Subject: Re: Occupied BW & Band Edge Measurements for O34-E790GPRS Hi Dennis, Since the radio Module is already FCC Certified as a modular transceiver, and there is no changes on this radio operation. We only need to conducted the RF Output Power and Transmitter Spurious Emissions to ensure the continuing compliance. All other tests are referred to the original test report of the module that was submitted with this application. All our past submissions to FCC were done these way. Please submit my answer to FCC and see what they said. If they still insist the occupied bandwidth and Band-edge emissions to be done, we will conduct the test and re-submitted to you ASAP. Tri Luu, P.Eng. Ultrachic Engineering Labs Inc.

ANNEX 2 – EXTERNAL EUT PHOTOS Ingenico Elite 790 GPRS, Model ELITE 790 GPRS FCC ID: O34-E790GPRS A2 - 1 ANNEX 2 – EXTERNAL EUT PHOTOS Ingenico Elite 790 GPRS, Model ELITE 790 GPRS FCC ID: O34-E790GPRS A2 - 2

Ingenico Canada Ltd., 79 Torbarrie Road, Toronto, Ontario M3L 1G5 ♦ Tel: [416] 245-6700 ♦Fax: [416] 245-6701 The following diagrams show the format and location of the product label on Elite 790 GPRS Terminal. Model : Elite 790 GPRS Modele: Elite 790 GPRS Power: 11VDC/1500mA Alimentaiton: 11VDC / 1500mA This device complies with Part 15 of the FCC rules. Operation is subject to The following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference That may cause undesired operation. This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. FCC ID: O34-E790GPRS IC: 2586B-E790GPRS Made in E.U. Fabrique en U.E. 2416-00031-0100 Diagram 1: Format and text of Elite 790 Product Label Label Specifications: • Ingenico Part Number: 2416-00031-0100 • Size: 49mm x 47mm • Material: White vinyl • Text: Black Elite 790 product label Diagram 2: Position of Product label on Elite 790 GPRS unit. Printed Name: Ram Janarthanan Date: March 13 th , 2003 Signature: Engineering Technical Support
