3. The Card Reader: Terminal is equipped with a bi-directional Magnetic Stripe Reader located immediately above the display. The Magnetic Stripe on the card should face down and to the rear of the terminal. The card should be swiped at uniform speed and pressure, ensuring that the card remains in contact with the bottom of the track throughout the entire swipe action. 4. Smart Card Reader: The terminal is equipped with Smart Card Reader slot at the front of the terminal for future use. 5. Cleaning procedure: 1. Clean the outside of the terminal with a soft cloth moistened with a mild detergent solution. 2. Never spray cleaning solution directly onto the terminal as drops may enter the unit. 3. Do not use Isopropyl Alcohol based cleaning products. 6. Technical specifications: 6.1 Terminal Features: • Magnetic card reader, ISO1 and ISO2 tracks decoding. • 18 key, backlit tactile feedback keyboard with audible tone and color coding. • Battery backed-up calendar and clock. • RS232 communications channel. • Multi-application operating system allowing each application to be downloaded independently of all others. • Logical and physical security. 6.2 Network: The terminal is equipped with an RF modem for exchanging data over one of the following networks: 1. MOBITEX. 2. CDPD 3. ARDIS (DataTac) – future option. 6.3 Power supply: The power adapter is mainly used for charging the internal NiCd battery. Power input voltage : 120V AC. Power input frequency : 60 Hz. Power output : 12V DC, 500mA. Figure 4: DC Plug 6.4 Operating environment Operating temperature : 5 to 40°C Humidity : 5% to 90% RH, with no condensation. 7. If you experience trouble : Call one of the customer service centers listed below: In Canada: In the USA: RBA Inc. IVI Checkmate Inc. 3190 Orlando Drive TotalCARE Mississauga, Ontario 1335 North Meadow L4V 1R5 Parkway, Suite 116 1-800-387-3938 Atlanta Ga 30076 or (905) 672-1048 1-800 - 435-3014 US Federal Communications Commission (FCC) Warnings: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Canadian Department of Communications (DOC) Warnings: This digital apparatus does not exceed the Class A limits for radio noise emissions from the digital apparatus as set out in the radio interference regulations of the Canadian Department of Communications. ™ Elite 780 RF Installation guide 0130-07056-0200 1. Terminal description: 1.1 Introduction: The Elite 780RF is a fully self-contained RF EFTPOS terminal with an integrated printer and the functionality to process all smart card, debit and credit purchases. The terminal communicates with the bank using the RF data network. This network is similar to that used for mobile phones except that it is for data only. The terminal features a secure, multi-application operating system, which allows a number of different applications to run on the terminal independently, without jeopardizing software security. Paper Feed Key Functions keys Magnetic Stripe Card Reader Printer Compartment CAN key CORR key ENTER key ADMIN key LCD Display Smart Card Reader 1.2 The Terminal: The Elite 780RF terminal has the following peripherals: 1.2.1 Display: Standard 4 line x 16 character LCD graphic display, with back lighting. 1.2.2 Keypad: • 18 keys, with back lighting, with the following special function keys: • F1, F2, and F3 keys: Programmable keys which permit access to terminal level functions and the system menu. • Paper Feed key: Performs a 20mm paper feed. • ENTER key: is used to confirm the data entered or displayed. • CAN key: is used to cancel the current function and return the terminal to the idle state. • CORR key: is used to correct any invalid data entry. • ADMIN key: is used to access the terminal administration function menu. 1.2.3 Magnetic Stripe Card Reader: This is a bi-directional reader capable of simultaneously reading Tracks 1&2, and is located just above the display. 1.2.4 Modem: The Modem facilitates data exchange over an RF network. 1.2.5 Printer: The built-in printer is a high-speed thermal printer (4 lines per second) and is graphics compatible. 1.2.6 Smart Card Reader: Complies with standard ISO 7816, Sync & Async. 1.3 Package contents are as follows: 1. The Elite 780RF terminal. 2. RF antenna. 3. Wall mount power adapter for charging the NiCd battery. 4. Thermal printer paper, one roll. 5. Installation guide. 2. Installation procedure: A Important Note: The battery must be charged for 24 hours before using the terminal for any purpose including key injection, program loading or customer use. (See Paragraph 2.3) 2.1 Paper loading (If required): 1. Open the paper compartment cover. 2. Move the paper load lever forward to disengage the friction roller. 3. Remove the empty paper roll by pressing the roll release lever on the right hand side. 4. Position the paper roll with the end of the roll protruding from UNDERNEATH the roll. 5. Feed the paper under the printer’s roller until it protrudes from the top of the printer. 6. Fit the paper roll to the spindle and move the paper load lever back to engage the friction roller. 7. Close the cover and test the operation of the printer by pressing Paper Feed key. Paper Load Lever Metal blade to tear off paper Roll Release Lever Printer Compartment cover 2.2 Connecting the RF antenna: 1. Place the RF antenna connector over the coaxial screw mount located on the back panel. Make sure the wire wit…

Text truncated - open the document above for the full version.

IVI CHECKMATE Inc., 79 Torbarrie Road, Toronto, Ontario M3L 1G5 ♦ Tel: [416] 245-6700 ♦Fax: [416] 245-6701 Thursday, July 27, 2000 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Authority to Act as an Agent Applicant: IVI Checkmate Inc. Product: Elite 780 CDPD Model: Elite 780 CDPD FCC ID: 034-Elite780CD Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application to F.C.C. for authourization of equipment under F.C.C. Rules. I also certify that the information provided, properly described the device or system for which authourization is required. Regards By: Ayman Sydhom Engineering Technical Support

Photo 1 of 4 Photo 2 of 4 Photo 3 of 4 Photo 4 of 4

IVI CHECKMATE Inc., 79 Torbarrie Road, Toronto, Ontario M3L 1G5 ♦ Tel: [416] 245-6700 ♦Fax: [416] 245-6701 The Following diagrams show the format and location of Elite 780 CDPD product label on the terminals. Model : ELITE 780-CDPD Modele: ELITE 780-CDPD Power: 12VDC / 500mA Alimentaiton: 12VDC / 500mA This device complies with Part 15 of the FCC rules. Operation is subject to The following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference That may cause undesired operation. This device contains a Novatel Wireless Technologies Ltd. Modem registered as Follows: TRADE NAME: EXPEDITE WIRELESS IP MODEM Model#: NRM-6832 FCC ID: 034-Elite780CD CANADA: Made in E.U. Fabrique en U.E Diagram 1: Format and text of Elite 780 CDPD Product Label Label Specifications: • IVI Part Number: 2416-00200-0100 • Size: 49mm x 47mm • Material: White vinyl • Text: Black Elite 780 CDPD product label Diagram 2: Position of Product label and Serial number barcoded label on Elite 780 CDPD unit. Printed Name: Ayman Sydhom Date: July 27, 2000 Signature: Engineering Technical Support

IVI CHECKMATE Inc., 79 Torbarrie Road, Toronto, Ontario M3L 1G5 ♦ Tel: [416] 245-6700 ♦Fax: [416] 245-6701 The Following diagrams show the format and location of Elite 780 CDPD product label on the terminals. Model : ELITE 780-CDPD Modele: ELITE 780-CDPD Power: 12VDC / 500mA Alimentaiton: 12VDC / 500mA This device complies with Part 15 of the FCC rules. Operation is subject to The following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference That may cause undesired operation. This device contains a Novatel Wireless Technologies Ltd. Modem registered as Follows: TRADE NAME: EXPEDITE WIRELESS IP MODEM Model#: NRM-6832 FCC ID: 034-ELITE780CD CANADA: Made in E.U. Fabrique en U.E Diagram 1: Format and text of Elite 780 CDPD Product Label Label Specifications: • IVI Part Number: 2416-00200-0100 • Size: 49mm x 47mm • Material: White vinyl • Text: Black Elite 780 CDPD product label Diagram 2: Position of Product label and Serial number barcoded label on Elite 780 CDPD unit. Printed Name: Ayman Sydhom Date: July 27, 2000 Signature: Engineering Technical Support

Photo 1 of 15 Photo 2 of 15 Photo 3 of 15 Photo 4 of 15 Photo 5 of 15 Photo 6 of 15 Photo 7 of 15 Photo 8 of 15 Photo 9 of 15 Photo 10 of 15 Photo 11 of 15 Photo 12 of 15 Photo 13 of 15 Photo 14 of 15 Photo 15 of 15

July 18, 2000 File No.: IVI78_SAR IVI Checkmate Inc. 79 Torbarrie Road Toronto, Ontario CanadaM3L 1G5 NOT TRANSFERABLE This Verification Certificate is hereby issued to the named GRANTEE and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below: GRANTEE'S NAME: IVI Checkmate Inc. PRODUCT UNDER TEST: Elite 780 CDPD Handheld MODEL NO.: Elite 780 CDPD FCC ID: NBZNRM-6832 APPLICABLE STANDARDS: SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C) and Industry Canada RSS-102(Issue 1) EQUIPMENT TYPE: Wireless Point of Sales (POS) Handheld Terminal ß Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia) ß Recognized/Listed by FCC (USA) & IC (Canada) ß All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Approved by: Tri M. Luu, P.Eng. V.P. – Engineering UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Elite 780 CDPD Handheld Model No.: Elite 780 CDPD Tested For IVI Checkmate Inc. 79 Torbarrie Road Toronto, Ontario CanadaM3L 1G5 In Accordance With SAR (Specific Absorption Rate) Requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C) and Industry Canada RSS-102(Issue 1) UltraTech's File No.: IVI78_SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: July 25, 2000 Report Prepared by: Mike Tom Tested by: Jaewook Choi, SAR Engineer Issued Date: July 18, 2000 Test Dates: July 15, 2000 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Specific Absorption Rate Page 1 Elite 780 CDPD Handheld Elite 780 CDPD ULTRATECH GROUP OF LABS File #: IVI78_SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 18, 2000 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION....................................................................................................................................2 1.1. SCOPE....................................................................................................................................................................2 1.2. REFERENCES.......................................................................................................................................................2 EXHIBIT 2. STATEMENT OF CERTIFICATION...................................................................................................3 EXHIBIT 3. PERFORMANCE ASSESSMENT.........................................................................................................4 3.1. CLIENT AND MANUFACTURER INFORMATION..........................................................................................4 3.2. DEVICE UNDER TEST (DUT) DESCRIPTION..................................................................................................4 3.3. LIST OF DUT’S ACCESSORIES:.........................................................................................................................4 3.4. SPECIAL CHANGES ON THE DUT’S HARDWARE/SOFTWARE FOR TESTING PURPOSES...................5 3.5. ANCILLARY EQUIPMENT..................................................................................................................................5 3.6. GENERAL TEST CONFIGURATIONS................................................................................................................5 3.6.1. Equipment Configuration...............................................................................................................................5 3.6.2. Exercising Equipment....................................................................................................................................5 3.7. SPECIFIC OPERATING CONDITIONS...........................................................................................................................5 3.8. BLOCK DIAGRAM OF TEST SETUP.................................................................................................................6 EXHIBIT 4. SUMMARY OF TEST RESULTS..........................................................................................................7 4.1. LOCATION OF TESTS.........................................................................................................................................7 4.2. APPLICABILITY & SUMMARY OF SAR RESULTS.........................................................................................7 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA....................................................................8 5.1. TEST SETUP.........................................................................................................................................................8 5.2. PHOTOGRAPHS OF DUT POSITION.................................................................................................................9 5.3. TEST DATA...................................................................................................................................................…
