O3YCU258-2Control Unit 258-2

Control unit 300 Series mounting + operating October 31, 2012 Page 2 of 10 1 Overview This control unit is designated to operate an electrically driven bed with optional comfort functions. • Power supply is provided via SMPS so the control box has protection class III. • The system is operated with an RF remote. The RF receiver is integrated into the control unit. Bed view from beneath Here for example you can see a control unit with two actuators and two massage motors connected Actuator 1 Actuator 2 Control unit Massage motor 1 2 Massage motor 2 October 31, 2012 Page 3 of 10 Control Unit 258-2 CU258-2 2 Mounting the control unit This mounting bracket is fixed on the flipside of the bed These two bolts fix the position of the control unit between the mounting bracket. The clip snaps in the holding fixtures of the control unit October 31, 2012 Page 4 of 10 October 31, 2012 Page 5 of 10 Performance data control unit Duty cycle 2/18 min. or 10 %, max, 5 switching cycles per minute Output voltage 29 V / 6A Further features Housing colour black RAL 9005 Housing material ABS + PC Ports drives: 2 actuators / 2 vibration motors power input 1 / multifunction output 1 Indicators + buttons Reset + pairing button / Pairing LED for RF Power LED Protection type IP20 Protection class III Relative humidity 30% - 75% Ambient temperature +50°F - +104°F Power supply external Integrated RF receiver 1 Key Function 1 Pairing enable Performance data RF receiver modulation GFSK Frequency Range 2.403~2.480GHz Transmitted Power 0 dBm Battery 30V supply voltage Working Current <60mA Standby Current <20mA Ambient Temperature -40—85Ԩ PCB Material & Size FR4 1.6mm 120*120mm October 31, 2012 Page 6 of 10 2.1 Power supply PD12 65444 Connecting cable73178 to control box Power supply cable 3.00.401.151.30 to mains power Performance data Output voltage 29 V DC constant voltage output Components Indicators LED operating status indication (green) Colour black RAL 9005 Further data Protection type IP20 Protection class II Relative humidity 30% - 75% Ambient temperature +50°F - +104°F Power supply wide input voltage range 100-240 V AC Safety NTC temperature sensor, primary fuse, overload protection, overcurrent switch-off, short-circuit-proof output October 31, 2012 Page 7 of 10 Remote Control 258B 2.2 RF258B Keys for fixed positions Choose between comfortable positions Manual adjustment keys Move head & foot rest up and down manually Massage keys X With the timer key you program duration and stop the massage function. X The LEDs signal the programmed duration, the key below starts the massage. With the Head & Foot keys you can select the massage zones. KeyFunction 1 Massage Head ON 2 Adjust Massage timer 3 Massage Foot ON 4 Move bed in TV position 5 Start both Massage (Head and Foot) 6 Move bed in Lounge position 7 Relay 1 on 8 Move bed in Flat position 9 Relay 3 on 10 Relay 2 on 11 Move bed in Zero G position 12 Relay 4 on Frontside 1 2 3 4 5 6 7 8 9 10 11 12 Pairing button & battery box (flipside) Insert 3x AAA 13 13 Pairing October 31, 2012 Page 8 of 10 Performance data remote (RF transmitter) Modulation GFSK Frequency Range 2.403~2.480GHz Battery AAA Working Current <40mA Standby Current <8uA Ambient Temperature -40—85Ԩ RC Dimension 145*50*14mm PCB Material & Size FR4 1.6mm 79*42mm Housing Material ABS+PC October 31, 2012 Page 9 of 10 3 Board Schematics (remote) 3.1 Remote 3.2 RX module Pls insert diagram _ October 31, 2012 Page 10 of 10 4 Functional Description Take cable 3.00.401.151.30 and connect it to mains supply. The system is delivered paired! You can test the functions of the system with the RF remote. Pairing instruction (in case of trouble) Pairing the remote with the control box. The distance between remote and control box for pairing should be less than 2 meters! 1. Remove the battery cover on the flipside of the remote. 2. Insert/check existing 3x AAA batteries. 3. Push the reset button on the control box twice with something spiky. The green pairing LED adjoining is lit. Now you have 10 s to pair remote and receiver. 4. On the flipside of the remote is a silicone push button positioned above the batteries (13). A blue LED starts blinking as the button is pressed. Keep it pressed until the blue LED is lit continuously, then pairing is completed, the blue LED light fades away. This device complies with Industry Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement." RSS-102 Statement: This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. Déclaration CNR-102: Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies pour…

Text truncated - open the document above for the full version.

DewertOkin GmbH Control Unit 258-2 FCC ID: O3YCU258-2 Model Number: CU258-2 Trademark: Made in China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location Proposed Label Location on EUT

Transmitter module Antenna

TRF No：FCC 15.249/A Page 1 of 28 Report No ES121108049E ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT T OF Control Unit 258-2 MODEL No.: CU258-2 BRAND NAME: FCC ID: O3YCU258-2 REPORT NO: ES121108049E ISSUE DATE: November 16, 2012 Prepared for DewertOkin GmbH Weststr. 1, 32278 Kirchlengern, Germany Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No：FCC 15.249/A Page 3 of 28 Report No ES121108049E Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1. PRODUCT DESCRIPTION........................................................................................................................... 5 1.2. RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3. TEST METHODOLOGY.............................................................................................................................. 5 1.4. SPECIAL ACCESSORIES............................................................................................................................ 5 1.5. EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6. MEASUREMENT UNCERTAINTY............................................................................................................... 6 1.7. TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1. EUT CONFIGURATION............................................................................................................................. 7 2.2. EUT EXERCISE........................................................................................................................................ 7 2.3. TEST PROCEDURE.................................................................................................................................... 7 2.4. DESCRIPTION OF TEST MODES................................................................................................................. 8 3. SUMMARY OF TEST RESULTS ....................................................................................... 10 3.1. CONFIGURATION OF TESTED SYSTEM ........................................................................................ 10 3.2. DESCRIPTION OF SUPPORT UNITS ................................................................................................ 10 4. CONDUCTED EMISSIONS TEST ..................................................................................... 11 4.1. MEASUREMENT PROCEDURE:................................................................................................................ 11 4.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 11 4.3. MEASUREMENT EQUIPMENT USED: ...................................................................................................... 11 4.4. CONDUCTED EMISSION LIMIT............................................................................................................... 11 4.5. MEASUREMENT RESULT:....................................................................................................................... 12 4.6. CONDUCTED MEASUREMENT PHOTOS: ................................................................................................. 13 5. RADIATED EMISSION TEST ............................................................................................ 14 5.1. MEASUREMENT PROCEDURE................................................................................................................. 14 5.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 15 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 16 5.4 RADIATED EMISSION LIMIT................................................................................................................... 16 5.5 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 17 5.6 MEASUREMENT RESULT........................................................................................................................ 18 5.7 RADIATED MEASUREMENT PHOTOS: .................................................................................................... 23 6. BANDWIDTH TEST ............................................................................................................. 25 6.1. MEASUREMENT PROCEDURE................................................................................................................. 25 6.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 25 6.3. MEASUREMENT EQUIPMENT USED: ...................................................................................................... 25 6.4. MEASUREMENT RESULTS:..................................................................................................................... 25 TRF No：FCC 15.249/A Page 4 of 28 Report No ES121108049E 6.4.1. 20DB BANDWIDTH TEST DATA CHART:.................................................................................................. 25 7. BAND EDGE TEST............................................................................................................... 28 7.1. MEASUREMENT PROCEDURE...........................................…

Text truncated - open the document above for the full version.

Radiated Measurement Photos: Conducted Measurement Photos:
