O6RAMP331PSports Data Collection Unit

Dynastream’s AMP 331 Instructions for Users D00000381 Rev 0.E Dynastream Innovations Inc. 228 River Avenue Cochrane Alberta T4C 2C1 www.dynastream.com p 403.932.9292 f 403.932.6521 June 12, 2003 Contact: Anne Gildenhuys Product Manager [email protected] AMP 331 Instructions for Users Dynastream Innovations Inc. DOCUMENT NO: D00000381 Rev. 0.E SHEET: 2 of 2 Restricted Proprietary Information This information disclosed herein is the exclusive property of Dynastream Innovations Inc. and is not to be disclosed without the written consent of Dynastream Innovations Inc. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, reproduction, execution or transmission without the prior written consent of Dynastream Innovations Inc. The recipient of this document by its retention and use agrees to respect the security status of the information contained herein. This document is Confidential. The information contained in this document is subject to change without notice and should not be construed as a commitment by Dynastream Innovations Inc. unless such commitment is expressly given in a covering document. © Copyright 2003 Dynastream Innovations Inc. All Rights Reserved AMP 331 Instructions for Users Dynastream Innovations Inc. DOCUMENT NO: D00000381 Rev. 0.E SHEET: 3 of 3 TABLE OF CONTENTS TABLE OF CONTENTS....................................................................................................3 1 TECHNICAL INFORMATION.............................................................................4 2 COMPONENTS OF AMP 331.............................................................................5 3 AMP POD.............................................................................................................6 3.1 POD USER-INTERFACE..................................................................................................6 3.2 POD POWER SUPPLY....................................................................................................7 4 AMP ANKLE SLEEVE........................................................................................8 4.1 STARTING DATA COLLECTION......................................................................................8 4.2 INSTRUCTIONS FOR TEST SUBJECTS.............................................................................9 4.3 CARE..............................................................................................................................9 5 AMP LINK..........................................................................................................10 6 AMP WARE.......................................................................................................11 6.1 INSTALLING AMP WARE...........................................................................................11 6.2 MS® EXCEL SETTINGS...............................................................................................11 6.3 USING AMP WARE.....................................................................................................11 7 FREQUENTLY ASKED QUESTIONS..............................................................14 AMP 331 Instructions for Users Dynastream Innovations Inc. DOCUMENT NO: D00000381 Rev. 0.E SHEET: 4 of 4 1 TECHNICAL INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The abbreviation, IC, before the registration number signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada has approved the equipment. Caution: Changes or modifications to this device not expressly approved by Dynastream Innovations Inc. could void your authority to use the equipment. AMP 331 Instructions for Users Dynastream Innovations Inc. DOCUMENT NO: D00000381 Rev. 0.E SHEET: 5 of 5 2 COMPONENTS OF AMP 331 AMP Pod At the heart of the AMP 331 system is the pod which contains the inertial sensors and the imbedded software used to monitor activity. AMP Ankle Sleeve The ankle sleeve, attached to the lower leg just above the ankle, holds the pod in the correct position and orientation to enable accurate activity monitoring. AMP Link The Link connects to the USB port of a PC enabling wireless downloading of data from the AMP Pod. AMP Ware AMP Ware is a PC application that enables the user to enter subject and trial information, and then download the activity data from the pod. The subject and trial information is presented along with the activity data in MS® Excel. AMP 331 Instructions for Users Dynastream Innovations Inc. DOCUMENT NO: D00000381 Rev. 0.E SHEET: 6 of 6 3 AMP POD 3.1 Pod User-Interface 1. To start the AMP Pod, press and hold the right button until the LCD displays “on”. 2. The pod will display one of the following: a. If there is data in the pod memory, the pod will display “DATA”. Go to Step 5. b. If the pod is ready to start data collection it will display “CLR” to indicate that there is no data in the memory, then it will display the date and time, then the words “PUSH START ”. Go to Step 4 for instructions on data collection. c. If the date and time need to be set, the pod will display “CLR”, then “DATE”, then the year with the third digit flashing and the word “ SET ” at the bottom. For instructions on setting the date and time go to Step 3. 3. Setting the date and time. a. When the pod displays the year with the third digit flashing and the word “ SET ” at the bottom the date and time must be set. This always occurs after changing the battery. The procedure for setting the date and time are as follows: i. Use the right button to scroll through the digits of the year, the months of…

Text truncated - open the document above for the full version.

228 river ave, cochrane, alberta, canada T4C2C1 p 403.932.9292 f 403.932.6521 www.dynastream.com July 9, 2003 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Curtis-Straus LLC TCB 527 Great Rd Littleton, MA 02702 Re: Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457(d)(2) pertaining to confidential material. Dynastream Innovations Inc requests that the following documents regarding this submission for FCC ID 06RAMP331-P be kept confidential: 1. Schematics 2. Block Diagram 3. Circuit/Technical Description The material above contains technical data, which would customarily be guarded from competitors. Sincerely, Victor Beda Designer Dynastream Innovations Inc.

REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: External Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 1 of 2 REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: External Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 2 of 2 Note: See the Label exhibit for the correct label information

REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: Internal Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 1 of 4 REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: Internal Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 2 of 4 REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: Internal Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 3 of 4 REPORT: ED0552-1 FCC ID: O6RAMP331P EXHIBIT: Internal Photos MODEL: AMP331-P01 _____________________________________________________________ _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 4 of 4

Test Report Report No ED0552-1 Client Dynastream Innovations, Inc. 228 River Avenue Cochrane, Alberta T4C 2C1 Phone (403)-932-9292 Fax (403)-932-6521 FRN 0008033557 Model AMP331-P01 FCC ID O6RAMP331P Equipment Type Low Power Communication Device Transmitter Equipment Code DXX Results As detailed within this report Prepared by _____________________ Evan Gould – Test Engineer Authorized by __________________________ Michael Buchholz – EMC Manager Issue Date 7/30/03 Conditions of issue This Test Report is issued subject to the conditions stated in ‘terms and conditions’ section of this report. Curtis-Straus LLC is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 REPORT: ED0552-1 FCC ID: O6RAMP331P _____________________________________________________________ Table Of Contents Summary ............................................................................................................3 Test Methodology .............................................................................................3 Statement of Conformity .................................................................................4 Fundamental Frequency Measurement ......................................................5 Band Edge Measurements ............................................................................6 Harmonic Frequency Measurements ..........................................................7 Test Equipment Used ......................................................................................8 Terms And Conditions .....................................................................................9 A2LA Accreditation ........................................................................................11 _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 2 of 13 REPORT: ED0552-1 FCC ID: O6RAMP331P _____________________________________________________________ Summary This report is an application for Certification of a Transmitter operating pursuant to 47 CFR 15.249. The product covered by this report is the AMP331 Activity Monitoring Pod (Model AMP331-P01). This report is designed to demonstrate the compliance of this device with the requirements outlined in 47 CFR Part 15 using the methods outlined in 47 CFR Part 2. Test Methodology Radiated emissions testing is performed according to the procedures specified in ANSI C63.4 (2000). Frequency range investigated: 30MHz –10GHz Measurement distance: 3 Meters (30MHz - ~7GHz) 1 Meter (~7GHz – 10GHz) EUT power source: Fresh AAA battery Emission Maximization: EUT rotated around three orthogonal axes Antenna height and polarization varied _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 3 of 13 REPORT: ED0552-1 FCC ID: O6RAMP331P _____________________________________________________________ Statement of Conformity The Dynastream AMP331-P01 has been found to conform with the following parts of 47 CFR as detailed below: Part 2 Part 15 Comments 15.15(b) The product contains no user accessible controls that increase transmission power above allowable levels. 2.925 15.19 The label is shown in the label exhibit. 15.21 Information to the user is shown in the instruction manual exhibit. 15.27 No special accessories are required for compliance. 15.203 The antenna is soldered to the transmitter board, which is not user accessible, and there is no external antenna connection. 15.205 15.209 The fundamental is not in a Restricted band and the spurious and harmonic emissions in the Restricted bands comply with the general emission limits of 15.209. 15.249 The unit complies with the field strength limits of 15.249. _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 4 of 13 REPORT: ED0552-1 FCC ID: O6RAMP331P _____________________________________________________________ Fundamental Frequency Measurement LIMIT Quasi-Peak: 50mV/m = 93.9dBμV/m @ 3m [15.249(a)] Note: If Peak measurements meet Quasi-Peak limits, then Quasi-Peak measurements are not required. MEASUREMENT Radiated Emissions Table Curtis-Straus LLC Date: 17-Jul-03 Company: Dynastream Table: 1 Engineer: Evan Gould EUT Desc: AMP331 Work Order: D0552 Frequency Range: 916.7MHz Measurement Distance: 3 m Notes: continuous transmission; unmodulated AntennaPreampAntennaCableAdjusted 47 CFR 15.249(a) PolarizationFrequencyReadingFactorFactorFactorReadingLimitMarginResult (H / V)(MHz)(dBμV)(dB)(dB/m)(dB)(dBμV/m)(dBμV/m)(dB)(Pass/Fail) Vpk 916.764.819.721.44.170.693.9-23.3Pass Test Site: "F" Pre-Amp: Green Cable: 65 ft RG8A/U Analyzer: Orange Antenna: Grn-Blk ANALYZER PLOT _____________________________________________________________ Curtis-Straus LLC • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 Page 5 of 13 REPORT: ED0552-1 FCC ID: O6RAMP331P _____________________________________________________________ Band Edge Measurements LIMITS Quasi-Peak: 50dB below level of Fundamental OR General radiated emission limits of 15.209 “...whichever is the lesser attenuation.” [15.249(c)] Note: If Peak measurements meet Quasi-Peak limits, then Quasi-Peak measurements are not required. MEASUREMENTS Radiated Emissions Table Curtis-Straus LLC Date:17-Jul-03Company:DynastreamTable:2 Engineer: Evan Gould EUT Desc: AMP331 Work Order: D0552 Frequency Range: 900-928.4MHz Measurement Distance: 3 m Notes: AntennaPreampAntennaCableAdjusted FCC Class B PolarizationFrequency…
