O871185UHF Pocket Paging Transmitter

11-85 UHF POCKET PAGING TRANSMITTER OPERATOR’S MANUAL Sea Air and Land Communications Ltd, PO Box 22-621, 120 St Asaph Street, Christchurch, New Zealand 11-85 UHF POCSAG TRANSMITTER OPERATOR’S MANUALIssue 1185UA 0104 Sea Air and Land Communications LtdPage 1 11-85 UHF POCKET PAGING TRANSMITTER 1.0DESCRIPTION The 11-85 is a UHF low power POCSAG paging transmitter with an in-built encoder. The buttons initiate transmissions to provide numeric, alpha-numeric and tone-only POCSAG paging, enabling a user to call a pager (approximately 2,000,000 codes), append a priority level (1 of 4), and add a numeric or alpha-numeric message. In addition to the front panel buttons, four discrete inputs are supported with unique pre-programmed messages on low input transition. Provision to transmit a message more than once is catered for and the time between transmissions is programmable. ‘Beep’ Indicator: Audible ‘beeps’ accompany each key-push and all successful transmissions. There are different beeps for an ‘out of lock’ transmission failure and a distinctive beep for low battery accompanies each transmission. Aerial: The 11-85 has an fixed external quarter wave helical aerial. 2.0WARRANTY Our Products are warranted for a period of 12 months from date of purchase against faulty materials and workmanship. Should any fault occur the unit should be returned to the vendor, freight pre-paid. Please include a description of the fault to assist with prompt return. Any unauthorized alterations or repairs will invalidate the warranty. 3.0DISCLAIMER All information provided in this document is carefully prepared and offered in good faith as a guide in the installation, use and servicing of our products. Installers must ensure that the final installation operates satisfactorily within the relevant regulatory requirements. We accept no responsibility for incorrect installation. We reserve the right to change products, specifications, and installation data at any time, without notice. Note: The 1185 should not be used for the control of industrial machinery where a fail-safe mode of operation is necessary for the purposes of safety. Please contact Salcom for advice where this is a requirement. 11-85 UHF POCSAG TRANSMITTER OPERATOR’S MANUALIssue 1185UA 010411-85 UHF POCSAG TRANSMITTER OPERATOR’S MANUALIssue 1185UA 0104 Sea Air and Land Communications LtdPage 2Sea Air and Land Communications LtdPage 3 4.0INSTALLATION Numeric transmissions The unit can be attached to a wall or carried in a pocket. It is advisable to mount the unit away from sources of heat, damp or vibration The power supply can be an internal 9volt battery, or an external power source. The supply input is protected against reversed connection damage. Wire connections can be made to the internal connectors, and the wires can pass through the battery access hole, or provision for a hole can be made in the side of the case. 5.0OPERATION To operate the unit press the front panel button until the LED indicates transmitter operation. The LED will flash rapidly if a low supply is detected. A number of factors can influence the range of the unit. The range can be optimised by applying the following recommendations: 1.Ensure the path between 11-85 and receiver is as clear from obstructions as possible. 2. Replace batteries when the flashing LED indicates low battery. 3. If handheld, hold the unit in the open with one hand as far from the body as possible. 4. Do not fix the unit to metal surfaces so that it screens the radio signals. The aerial must be clear of metal obstruction. 5.Some pager receivers do not respond as well as fixed receivers with external aerials 6.0OPERATING MODES Sleep mode. This is the quiescent mode. In this state the unit consumes zero power except for any residual current flowing in the discrete inputs. The unit will stay in this mode until a button is pressed or a discrete input goes low. Transmit mode. If an input is activated, the unit will enter the transmit mode to transmit the message(s). The unit will return to the sleep mode after the message has been sent. 7.0TYPES OF PAGING MESSAGE The 11-85 can transmit two types of POCSAG message, with any one of four function levels: Alphanumeric transmissions Messages can contain any alphanumeric character . The 11-85 will accept the standard ASCII 7 bit character set. Messages can contain numeric characters and some symbols. These can convey a telephone number, or other numerically coded information. The transmitted message is shorter, and therefore there is a smaller chance of errors received by the pager. The numeric character set is as follows: 0 1 2 3 4 5 6 7 8 9 [ ] - E U <space> Note. The E may be displayed as P or * on different pagers 8.0INITIATING TRANSMISSIONS There are two ways of initiating a paging message transmission: Button press: The 11-85 will remain in a sleep mode, with zero supply current, until a button is pressed. This action will initiate a transmission as per the configuration. Note that on single button units, only button 2 is used. External Discrete Inputs: A transmission can be initiated from one of the four external inputs with an input transition to LOW (connection to GND). The 11-85 will remain in a sleep mode with zero supply current until a discrete input is activated. A low transition on any discrete input will wake the unit for approx one second. Once the unit is activated, a message related to the particular input is sent and the unit goes back to sleep. 9.0BATTERY MAINTENANCE A 9 volt alkaline battery should have capacity for 5 hours of transmission, or about 5000 messages of 3 seconds each. If the battery voltage drops below 7 volts, the LED will flash rapidly when operated. No battery monitoring takes place in the sleep mode. The internal 9 volt battery can be accessed by sliding back the battery cover on the rear of the unit. RECOMMENDED BATTERY PP3, MN1604, 6F229 Volt Alkaline 11-85 UHF POCSAG TRANSMITTER OPERATOR’S MANUALIssue 1185UA 010411-85 UHF…

Text truncated - open the document above for the full version.

GROUND D1 KEYPAD P1, +9V P4, P5 DISCRETE INPUTS IC2 MICRO- CONTROLLER P8, SER. PROG. P7, FLASH PROGRAM SK1 BNC LOW PASS FILTER Q7, Q8, RF AMPLIFIERS IC6 BUFFER IC5 VCO Q5, Q6 VCO 5V VCO LOOP H.S. DATA Q3 PWR CNTRL +5VBIAS IC4 SYNTH. RF L.S. TCX1 9.6MHz OSC. PTT OOL IC1 +5V Reg. D24 MOD 11-85 UHF POCSAG TRANSMITTER

DESIGNERS AND MANUFACTURERS OF COMMUNICATIONS SYSTEMS Page 1 SEA AIR AND LAND COMMUNICATIONS LTD 120 ST ASAPH STREET, PO BOX 22-621, CHRISTCHURCH, NEW ZEALAND Phone: +64 3 379-2298 Fax: +64 3 365-1580 Email: [email protected] 26 April 2004 To whom it may concern CONFIDENTIALITY REQUEST Reference rule sections 0.457 (d) (ii) and pursuant to rule section 0.459 (a) confidentiality is requested as follows. Specific Information: Schematics diagrams, Layout diagrams, Bill of materials The Salcom 11-85 Pocsag Transmitter schematics, layout diagram and the bill of materials contain trade secret information which is not made routinely available to the public or to our competitors. Disclosure of this information could result in an unfair advantage to our competitors. It should be treated as confidential for the duration of the Grant Of Authorisation. Regards John Croft Engineering Manager Sea Air & Land Communications (Salcom) Ltd Christchurch New Zealand

Response to TCB Findings Please specify the label material. The label material is FUGI XEROX Self Adhesive, permanent adhesive, paper labels suitable for inkjet or laser printers.

EMC Technologies (NZ) Ltd Test Report No 00729.1 Report date: 1 July 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 0 of 1 EXTERNAL PHOTOGRAPH

SALCOM1185UHFPOCSAGTransmitter FCCID:O871185 SeaAir&LandCommunicationsLtd Christchurch,NewZealand SerialNo:00001 SALCOM1185UHFPOCSAGTransmitter FCCID:O871185 SeaAir&LandCommunicationsLtd Christchurch,NewZealand SerialNo:00001 Enlarged Actualsize

EMC Technologies (NZ) Ltd Test Report No 00729.1 Report date: 1 July 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 0 of 2 INTERNAL PHOTOGRAPHS EMC Technologies (NZ) Ltd Test Report No 40121.3 Report date: 20 January 04 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 1 of 12

EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 1 of 19 TEST REPORT Salcom 11-85 UHF Pocket Paging Transmitter tested for compliance with the Code of Federal Regulations (CFR) 47 Part 90 –Private Land Mobile Services for Sea Air and Land Communications Ltd Test Report issued by: ______________________________________ Andrew Cutler - General Manager Test Report prepared by: ______________________________________ Cecilia Lam – Office Administrator EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 2 of 19 Table of Contents 1. CLIENT INFORMATION 3 2. DESCRIPTION OF TEST SAMPLE 3 3. COMPLIANCE STATEMENT & SUMMARY OF TEST RESULTS 4 4. ARTICLES SUBMITTED 4 5. TEST SAMPLE DESCRIPTION 5 6. TEST CONDITIONS 6 7. ATTESTATION 7 8. TRANSMITTER TEST RESULTS 8 9. TEST EQUIPMENT USED 16 10. ACCREDITATIONS 16 11. PHOTOGRAPH(S) 17 EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 3 of 19 1. CLIENT INFORMATION Company Name Sea Air and Land Communications Ltd Address PO Box 22-621 City Christchurch Country New Zealand Contact John Croft 2. DESCRIPTION OF TEST SAMPLE Brand Name Salcom Model Number 11-85-0000 Product UHF Pocket Paging Transmitter Manufacturer Sea Air and Land Communications Ltd Country of Origin New Zealand Serial Number 00001, 00002 FCC ID O871185 NB: This report replaces the reports issued in the 40121 range to include a number of additional measurements required by the Telecommunications Certifications Body in order that certification for the product could be obtained. This report includes measurements to show compliance when the frequency deviation is increased to 4 kHz. EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 4 of 19 3. COMPLIANCE STATEMENT AND SUMMARY OF TEST RESULTS The Salcom 11-85 UHF Pocket Paging Transmitter complies with 47 CFR Part 90, section 90.217. Testing was carried out in accordance with the test methods defined in 47 CFR Part 2 and 90. Listed below are the relevant Part 2 test methods and the Part 90 limits. CLAUSE TEST PERFORMED RESULT 2.1041 Measurement procedures Noted 2.1046 RF power output Complies 2.1049 Occupied bandwidth Noted 2.1051 Spurious emissions at antenna terminals Complies 2.1053 Field strength of spurious radiation Complies 2.1055 Frequency stability Complies 2.1057 Frequency spectrum to be investigated Noted 90.217 Exemption from technical standards Complies 4. ARTICLES SUBMITTED 1 x Salcom 11-85 UHF Pocket Paging Transmitter. User manual. The transmitter has an integral antenna. The sample supplied for testing was fitted with an external antenna connection in order to make testing easier. EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 5 of 19 5. TEST SAMPLE DESCRIPTION The sample tested has the following specifications: Rated Transmitter Output Power 20 dBm +/- 1 dB (100 mW) Test frequencies 470.000 MHz Channel spacing 12.5 kHz and 25 kHz FCC Frequency Range 450.0 – 470.0 MHz Emission Type 512 Baud Pocsag with Carrier FSK and NRZ data Emission Designation 12K5F1D Deviation +/- 2.25 kHz and +/- 4.50 kHz Power Supply 9 Vdc from an internal DC battery External Controls This device has no external controls. Antenna Integral whip antenna. EMC Technologies (NZ) Ltd Test Report No 40628.1 Report date: 25 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 6 of 19 6. Test Conditions Standard Temperature and Humidity Temperature: +25°C ± 4° maintained. Relative Humidity: 60% ± 10% observed. Extreme Temperature High Temperature: + 50°C maintained. Low Temperature: - 30 °C maintained. Tests were carried out at these extremes of temperature in increments of 10 ° C. Extreme Power Supply This device is powered using an internal battery. The user manual recommends Alkaline batteries. Extreme power supply tests have been carried out at 85% and 115% of the nominal supply voltage. The user manual advises that the device can be operated with an external power supply that should not exceed 10 Vdc. Testing has also been carried out at: 85% = 7.6 Vdc 115% = 10.4 Vdc EMC Technologies (NZ) Ltd Test Report No 40…

Text truncated - open the document above for the full version.

EMC Technologies (NZ) Ltd Test Report No 40121a Report date: 10 th June 2004 EMC Technologies (NZ) Ltd Telephone: +64 9 360 0862 Fax: +64 9 360 0861 STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, New Zealand E-mail: [email protected] POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand Web Site: www.emctech.com.au This report may not be reproduced except in full Page 18 of 18 Radiated Emissions Test Set Up
