O9DABluetooth Activity Sensor

Pebble Display To show your daily progress anytime Quickly tap the Pebble 5 times with the pads of your fingers Sequence of lights Activity StatusSync Status 50% of your goal achieved Minimal progress toward your goal Pulsing = at least 5 minutes of data stored Solid = recent successful data sync Wearing Your Pebble Running, indoor biking and elliptical Note: Pebble must be secure Syncing Pebble Data The Pebble will sync data when it is “awake” and near a wireless SyncPoint To wake the Pebble and sync activity data Walk near a SyncPoint Quickly tap the Pebble 5 times with the pads of your fingers near a SyncPoint OR Replacing Your Battery 1. 4. 3. 5. 2. CR 2032 + CR 2032 + CR 2032 + CR 2032 + Turn the clip counterclockwise Remove the battery door Use tool or device clip to remove the old battery Wait 60 seconds Insert the new battery under tab Replace the battery door Turn clockwise For more information regarding use, care, or servicing, please contact: FitLinxx, Inc. 3 Enterprise Drive Suite 401 Shelton, CT 06484 United States of America Email: [email protected] Use of this product is subject to the FitLinxx End User License Agreement (EULA): http://www.fitlinxx.net/terms.htm This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operations. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the devices. Patent information can be found at http://www.fitlinxx.net/patents.htm. European Wireless EU Declaration of Conformity: This wireless device complies with the specifications EN 300 440-2, EN 301-489, and EN 60950 following the provisions of the R&TTE Directive. Warning: Risk of explosion if battery is replaced by an incorrect type. Please dispose of used batteries in accordance with your local environmental laws and guidelines. Specifications subject to change without notice. © 2013 FitLinxx. All rights reserved. FitLinxx, the Fitlinxx logo, and Pebble are trademarks of FitLinxx, Inc. Pebble and FitLinxx Quick Reference Guide Working properly Not working properly 100% Step 1: Install FitLinxx Connect • Go to www.fitlinxx.com/start to download the FitLinxx Connect installer • Follow the on-screen instructions to set up FitLinxx Connect and add your devices • Validate the SyncPoint connection status in the system tray or Mac Dock Step 2: Clip your Pebble on and go! • Clip the Pebble on your shoe for best accuracy, or your waistband, belt, pocket or bra for good accuracy • Walk within range of a working Personal SyncPoint to sync your data • Tap the Pebble quickly 5 times to activate the display Scan to see Pebble videos: Before you begin: You must set up a FitLinxx account at your fitness facility AND register on the FitLinxx member website before installing FitLinxx Connect. Please see your facility staff for more information on getting set up on FitLinxx. Here is what you will need to continue: A Pebble® activity tracker A Personal SyncPoint Your FitLinxx online username and password

8 10 16 18 9 7 FONT CALIBRI 55 6 PT FONT CALIBRI 55 8 PT REVISIONS ZONEREV.DESCRIPTIONDATEAPPROVED 01INITIAL RELEASE08/05/2013DPG 02MODIFIED LOGO POSITION12/11/2013DPG m P EXCEPT AS NOTED, ALL DIMS ARE MM DIMENSIONS IN [ ] ARE INCHES This document contains confidential or proprietary information of FitLinxx. Neither this document nor the information therein is to be reproduced, distributed, used or disclosed either in whole or in part, except as specifically authorized by FitLinxx. 214-00098-01 MARKING LASER RCM PEBBLE+ SHEET 1 OF 1 - Drawn by SolidWorks LASER PRINT (WHITE) REV SCALE:2:1 DSN'D PAPER SIZE DRAWING NUMBER MAT'L DRAWN CHK'D DATE 542 Westport Avenue 2nd Floor Norwalk, CT 06851 Phone: (203) 316-5151 e-mail: [email protected] DPG DRAWN DSN'D A DATE CHK'D SURFACE FINISH: 3.2 ASME Y14.5M-1994 APPLIES 0 PLACE DECIMAL ANGULAR TOL'S 1 PLACE DECIMAL ± 0.25 mm ± 1.0 mm ± 1.0 2 PLACE DECIMAL ± 0.1 mm DPG JM - 0/5/2013 02 ®

Curtis-Straus LLC is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 1 of 19 Test Report Curtis-Straus LLC, a wholly owned subsidiary of BV CPS Report No EN3397-1 Client Fitlinxx Technologies John MacLean Address 3 Enterprise Drive Suite 401 Shelton, CT 06484 Phone (978) 357-8086 Items tested Pebble+ FCC ID IC ID O9DA 4068A-A FRN 0004307153 Equipment Type Low Power Communication Device Transmitter Equipment Code DXX Standards 47CFR 15.249,RSS 210 Issue 8, RSS GEN Issue 3 Test Dates April 1 – 3, 14 and 15, 2014 Results As detailed within this report Prepared by Tuyen Truong A. – Test Engineer Authorized by Christopher Reynolds – EMC Supervisor Issue Date 6/23/2014 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 18 of this report. Test Report for Fitlinxx Technologies  Report No. EN3397-1 June 23, 2014 ______________________________________________________________________ ____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 2 of 19 Contents Contents .................................................................................................................................. 2 Product Tested - Configuration Documentation ....................................................................... 3 Summary ................................................................................................................................. 4 Test Methodology ................................................................................................................ 4 Compliance Statement ............................................................................................................ 5 Test Results ............................................................................................................................ 6 Fundamental Measurements................................................................................................ 6 Radiated Spurious Emissions ............................................................................................ 10 Occupied Bandwidth .............................................................................................................. 14 Measurement Uncertainty...................................................................................................... 17 Conditions Of Testing ............................................................................................................ 18 Form Final Report REV 2-16-07 (DW) Test Report for Fitlinxx Technologies  Report No. EN3397-1 June 23, 2014 ______________________________________________________________________ Issue No. Reason for change Date Issued 1 Original Release June 23, 2014 _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 3 of 19 Product Tested - Configuration Documentation EUT Configuration Work Order: N3397 Company: Fitlinxx Technologies Company Address: 134 Flanders Road Westborough, MA 01581 Contact: Dave Goodall Person Present: Dave Goodall MN SN EUT: Body LAN Configuration Pebble+ HGEN-00512-12297 Bluetooth Configuration Pebble+ HGWT-00512-12235 Sleep Mode Config Pebble+ HGVH-00512-10156 EUT Description: Pebble+ EUT Max Frequency: 16 MHz EUT TX Frequency: 2402 - 2480MHz Support Equipment: MN SN None EUT Ports: Port Label Port Type No. of ports No. Populated Cable Type Shielded Ferrites Length Max Length In/Out NEBS Type Unpopulated Reason None Software / Operating Mode Description: 2) For Bluetooth configuration: EUT is set to transmit at 2402MHz, 2426MHz and 2480MHz simultaneously. 3) For Body LAN / Bluetooth configuration tested in Sleep mode: EUT is set to transmit for 8ms, then go into silent mode until it detects movement again. 1) For Body LAN configuration: EUT is set to transmit at 2429MHz, Test Report for Fitlinxx Technologies  Report No. EN3397-1 June 23, 2014 ______________________________________________________________________ Issue No. Reason for change Date Issued 1 Original Release June 23, 2014 _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1  Littleton, MA  TEL (978) 486-8880  FAX (978) 486-8828 page 4 of 19 Summary This test report supports an application for certification of a transmitter operating pursuant to 47 CFR 15.249. The product is Pebble+. It is a transmitter that operates on a single channel 2429MHz for Body LAN configuration and operates in the range 2402 - 2480MHz for Bluetooth configuration. We found that the product met the above requirements. The test samples were received in good condition. Test Methodology Radiated emission testing was performed according to the procedures specified in ANSI C63.4 (2003) and RSS-GEN. Radiated Emissions were maximized by rotating the device around three orthogonal axes as well as varying the test antenna’s height and polarity. The device antenna cannot be maximized separately. AC Main conducted emission was not done because the EUT is battery powered. The product was tested with modulation on and peak readings were compared against the average limit presented in section CFR 15.249. The EUT operating voltage is 3VDC. (Fresh batteries were used during testing.) The following bandwidths were used during…

Text truncated - open the document above for the full version.

Fundamental Readings EMI Radiated – Fundamental Frequencies EMI Radiated – X -orientation EMI Radiated – Y -orientation EMI Radiated – Z –orientation Radiated Spurious Emission EMI Radiated – 25-1000MHz EMI Radiated – 1-6GHz EMI Radiated – 6-18GHz EMI Radiated – 18-26.5GHz
