O9DAL3Wireless Access Point

Pebble™ Getting Started Guide 2 This Getting Started Guide covers the following information: 1. Pebble Display 2. Wearing the Pebble 3. Pebble Battery 4. Syncing Pebble Data 5. Using the ActiLink 6. Using the ActiScale 7. Using the ActiPressure 3 Pebble Display To show daily progress anytime 1. Device status 2. Activity status3. Sync status Quickly tap device 5 times 6 lights = 50% of daily goal achieved 1 light = minimal progress toward daily goal Shows daily progress, for example: Pulsing = at least 5 minutes of data stored Solid = recent successful data sync Sequence of lights = working properly 4 Wearing the Pebble All-day activity and walking Running, elliptical, and biking Good accuracy - clip on belt/waistband, pocket or bra Best accuracy - clip flat on top of shoes Note: Pebble must be secure 5 Pebble Battery Replacing the battery Pebble includes CR2032 battery An extra battery is included for convenience Turn clip counterclockwise Insert new battery under tab Replace battery door Turn clockwise Remove battery door Use tool or device clip to remove old battery Wait 60 seconds Red lights = less than 2 weeks of battery life remaining 1. 4. 2. 5. 3. CR 2032 + CR 2032 + CR 2032 + CR 2032 + CR 2032 + 6 Syncing Pebble Data The Pebble will sync data with your website when it is “awake” and near a wireless access point Tap device 5 times near an access point Walk near an access point OR Wght BP BP Wght BP BP To wake the Pebble and sync activity data 7 Wght BP BP Wght BP BP Using the ActiLink Insert ActiLink Download and install software ActiLink status Working properly No Internet connection No ActiLink detected 1. 3. 2. Wght BP BP 100% 8 Using the ActiScale Place on flat, hard surface up to 50 feet from ActiLink Stand on scale until weight is displayed Weight wirelessly sent to computer Tap the scale Wait for “0.0” 1. 3. 2. 4. Wght BP BP Wght BP BP 175 lbs. 9 120 80 60 Wght BP BP Wght BP BP Using the ActiPressure Place on flat surface up to 50 feet from ActiLink Follow ActiPressure instructions to take blood pressure Blood pressure wirelessly sent to computer 1. 2. S: 120 D: 80 P: 60 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operations. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the devices. Industry Canada Notice to users: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d‘Industrie Canada applicables aux appareils radio exempts de licence. L‘exploitation est autorisée aux deux conditions suivantes: (1) l‘appareil ne doit pas produire de brouillage, et (2) l‘utilisateur de l‘appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d‘en compromettre le fonctionnement. European Wireless EU Declaration of Conformity: This wireless device complies with the specifications EN 300 440-2, EN 301-489, and EN 60950 following the provisions of the R&TTE Directive. Patent information can be found at http://www.fitlinxx.net/patents.htm. Specifications subject to change without notice. Warning: Risk of explosion if battery is replaced by an incorrect type. Please dispose of used batteries in accordance with your local environmental laws and guidelines. © 2012 FitLinxx. All rights reserved. FitLinxx, the Fitlinxx logo, and Pebble are trademarks of FitLinxx, Inc. v1.9 For more information regarding use, care, or servicing, please contact: Use of this product is subject to the FitLinxx End User License Agreement (EULA): http://www.fitlinxx.net/terms.htm

Laser Etched Label Location:

Test Report No. R-5624N-2 Retlif Testing Laboratories R Certification and Signatures We certify that these Test Results are true results obtained from the tests of the equipment stated, and relates only to the equipment tested. We further certify that the measurements shown in this Test Results package were made in accordance with the procedures indicated and vouch for the qualifications of all Retlif Testing Laboratories personnel taking them. Scott Wentworth Branch Manager NVLAP Approved Signatory Todd Hannamann Laboratory Supervisor iNARTE Certified Technician ATL-0255-T Non-Warranty Provision The testing services have been performed, findings obtained and reports prepared in accordance with generally accepted laboratory principles and practices. This warranty is in lieu of all others, either expressed or implied. Non-Endorsement This test report contains only findings and results arrived at after employing the specific test procedures and standards listed herein. It is not intended to constitute a recommendation, endorsement or certification of the product or material tested. This test report may not be used by the client to claim product endorsement by NVLAP, NIST or any agency of the U.S. Government. Page 2 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Revision History Revisions to this document are listed below; the latest revised document supersedes all previous issues of this document. Revision Date Pages Affected - November 10, 2012 Original Release Page 3 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Program Summary Job Number: R-5624N-2 Applicant: FitLinxx, Inc. Address: 134 Flanders Road, Suite 200 Westborough, MA 01581 Test Sample: ActiLink 3.0 Wireless Access Point Brand Name: FitLinxx, Inc. Model: SyncPoint Antenna Port/Type: No Antenna Port Internal Antenna - PCB Trace Power Requirements: 5 VDC via USB Frequency Band of Operation: 2.40 GHz to 2.4835 GHz Frequency of Operation: 2.429 GHz FCC ID: O9DAL3 IC: 4068A-AL3 Test Specification: FCC Rules and Regulations Part 15, Subpart C, Paragraph 15.207 and 15.249 Radio Standards Specification, RSS-210, Issue 8, December 2010 and RSS-GEN, Issue 8, December 2010 Test Procedure: ANSI C63.4: 2003, American National Standard for Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Purpose: The purpose of this test program was to demonstrate compliance of the ActiLink 3.0 Wireless Access Point to the technical requirements of FCC Part 15.207 and 15.249 and RSS-210, Annex A2.9. Page 4 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Methods & Results: The following table depicts the test methods that were performed on the EUT and the corresponding test results: Table 1 – Test Methods Performed Testing Date(s) FCC Part 15, Subpart C Industry Canada RSS-210 Issue 8, December 2010 Industry Canada RSS-GEN Issue 3, December 2010 Test Method Test Results November 1, 2012 15.207(a) N/A 7.2.4 Conducted Emissions Complied September 25, 2012 15.249 (a) (e) A2.9 (a) N/A Field Strength of Fundamental & Harmonic Emissions Complied September 25, 2012 15.249 (d) A2.9 (b) N/A Field Strength of Out of Band/ Bandedge Emissions Complied September 25, 2012 N/A N/A 6.1 Field Strength of Receiver Spurious Emissions Complied September 25, 2012 N/A N/A 4.6.1 99% Bandwidth 3.86 MHz Test Sample Description: The ActiLink 3.0 is a personal wireless access point for individual users and families that automatically transfers activity and health data from ActiHealth-compatible devices over the Internet to the ActiHealth website. The ActiLink must be plugged into a USB port of a computer and uses a software application to transfer data to the ActiHealth website. This software application can be downloaded during the ActiHealth registration process or at any time from the “Devices” tab on the ActiHealth website. The ActiLink will collect data from ActiHealth-compatible devices at a range of up to 60 feet. Support Equipment: Table 2 – Support Equipment Description Manufacturer Part NumberModel Number Serial Number Laptop Dell N/A PP18L N/A AC Adapter Dell YT886 FA65NS0-00 CN-OYT886-73245- 93B-3389-A01 Keyboard Dell N/A RX7D50 CN-OJ4624-37172- 4AM-03PC Network Switch Linksys N/A EZXS55W R915OH443962 Page 5 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Sample/Test Results Summary:  The maximized fundamental field strength at 2429 MHz did not exceed 50 m V/M (94dBμV) at a test distance of 3 meters. The measured maximized average field strength was 77.65 dBμV/m.  The field strength of observed harmonic emissions did not exceed 500 μ V/M. The worst case harmonic emission measured was 40.59 dBuV/m at a frequency of 4858 MHz. No other harmonic emissions were observed within 10dB of the specified limit at 3 meter or 1 meter test distances.  The field strength of non-harmonic out of band/bandedge emissions were attenuated more than 50dB below the level of the fundamental or to the limits of 15.209 as applicable. No out of band spurious emissions were observed within 10dB of the specified limit at 3 meter or 1 meter test distances.  The maximized peak field strength of the emissions did not exceed the maximum permitted average field strength by more than 20 dB. The measured maximized peak field strength was 85.18 dBμV. General Test Requirements 1. The measurement procedures of ANSI C63.4:2003 were utilized as specified in FCC Part 15, Subpart C, Section 15.31(a)(3) and RSS-Gen, Section 4.1. 2. All radiated emissions measurements were performed on an Open Area Test Site (OATS), listed with the FCC and IC, in accordance with FCC Section 15.31(d) and RSS Gen, Section 4.2. 3. All measurements were performed at the specified 3 meter test distance. The EUT was rotated throughout 360 degrees for all radiated emissions measurements as specified in FCC Section 15.31(f)(5) and IC Section 4.3(h). 4. All readily accessible EUT cont…

Text truncated - open the document above for the full version.

Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photographs Page 10 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photograph(s) Radiated Emissions Horizontal Antenna Polarization Vertical Antenna Polarization Page 11 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photograph(s) Radiated Emissions Horizontal Antenna Polarization Vertical Antenna Polarization Page 12 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photograph(s) Radiated Emissions Horizontal Antenna Polarization Vertical Antenna Polarization Page 13 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photograph(s) 99% Bandwidth Test Setup Page 14 of 24 Test Report No. R-5624N-2 Retlif Testing Laboratories R Test Setup Photograph(s) Conducted Emissions Test Setup Page 15 of 24
