O9EQ23X8001Dual-Band CDMA Wireless Module

WISMO Quik Q2338 series User’s Guide Reference: WM_PRJ_WM2C_UG_001 Level: 001B Date: 2nd December 2002 - Pre-production Draft - Copyright Copyright© 2002 Wavecom, Inc. All Rights Reserved. Trademarks All trademarks contained in this manual are the property of their respective owners. About This Manual This manual is furnished under license and may only be used or copied in accordance with the terms of such license. The information in this manual is for informational use only, is subject to change without notice, and should not be construed as a commitment by the manufacturer. The manufacturer assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Wavecom, Inc. Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: All other copyrights, trademarks and patents are the property of their owners. Document Number When ordering or referring to this publication, use the following number: Publication/PN WM_PRJ_WM2C_UG_001 WARNING! Read this information before using your phone FCC & Industry Canada Regulatory Compliance The Wismo Quik 2338 Series is approved for use with CDMA networks. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Your wireless hand-held portable Module is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless Modules. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your Module complies with the FCC guidelines and applicable standards. WARNING: Unauthorized antennas, modifications, or attachments could impair call quality, damage the Module, or result in violation of FCC regulations. Do not use the Module with a damaged antenna. Please contact your local authorized dealer for antenna replacement. WARNING: BODY-WORN OPERATION – This device was tested for typical body-worn operations using the optional belt- clip/holster to provide a separation distance of 0.8-inches/2.0 cm from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.8 inches/2.0 cm must be maintained between the user’s body and the belt-clip/holster, including the antenna, whether extended or retracted. Third party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with FCC RF exposure limits and should be avoided. FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Operating Requirements The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antennas or transmitters. Please maintain 20 cm separation distance from the antenna to meet FCC RF exposure compliance requirements. For more information about RF exposure, please visit the FCC website at www.fcc.gov NOTE: Read the “Safety” section prior to using your WISMO Quik Q2338 Series Module. Preface Your WISMO Quik Q2338 Series Module Congratulations! Your new WISMO Quik Q2338 Series Module is going to change the way you communicate. The WISMO QUIK Q2338 is a compact, lightweight, personal communications system with added features for the person on the go. More than just a mobile phone, the WISMO QUIK Q2338 allows you to: • Access your voice mail, and text messages • Review a list of your latest outgoing and incoming calls for reference or call back • Organize names and numbers • Go on-line through the Browser (service features depend upon your carrier service) to surf the web, get e-mails, stock quotes, etc. • Send and receive text messages via the Short Message Service (carrier service provider dependent) • Use your WISMO QUIK Q2338 as a wireless modem to send or receive faxes with your laptop computer. The WISMO QUIK Q2338 is a compact, simple, and affordable solution for your active life style. This Document is intended to provide the user complete instructions on the capabilities and use of the Wavecom Starter Kit. The Wavecom Starter Kit is designed to allow the customer to interface to the Wavecom Q2300 and Q2400 CDMA and GSM/GPRS Module families. Control of the Module is done via AT Commands issued from an external PC running a terminal emulator, such as HyperTerminal. The User should refer to the Wavecom CDMA AT Commands Interface Specification for more information on supported commands. [b1] Table Of Contents About This Manual ........................................................................…

Text truncated - open the document above for the full version.

WISMO Quik Q2338 series User’s Guide Reference: WM_PRJ_WM2C_UG_001 Level: 001B Date: 29th December 2002 - Pre-production Draft - Copyright Copyright© 2002 Wavecom, Inc. All Rights Reserved. Trademarks All trademarks contained in this manual are the property of their respective owners. About This Manual This manual is furnished under license and may only be used or copied in accordance with the terms of such license. The information in this manual is for informational use only, is subject to change without notice, and should not be construed as a commitment by the manufacturer. The manufacturer assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Wavecom, Inc. Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: All other copyrights, trademarks and patents are the property of their owners. Document Number When ordering or referring to this publication, use the following number: Publication/PN WM_PRJ_WM2C_UG_001 WARNING! Read this information before using your phone FCC & Industry Canada Regulatory Compliance The Wismo Quik 2338 Series is approved for use with CDMA networks. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Your wireless hand-held portable Module is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless Modules. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your Module complies with the FCC guidelines and applicable standards. WARNING: Unauthorized antennas, modifications, or attachments could impair call quality, damage the Module, or result in violation of FCC regulations. Do not use the Module with a damaged antenna. Please contact your local authorized dealer for antenna replacement. WARNING: BODY-WORN OPERATION – This device was tested for typical body-worn operations using the optional belt- clip/holster to provide a separation distance of 0.8-inches/2.0 cm from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.8 inches/2.0 cm must be maintained between the user’s body and the belt-clip/holster, including the antenna, whether extended or retracted. Third party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with FCC RF exposure limits and should be avoided. FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Operating Requirements The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antennas or transmitters. Please maintain 20 cm separation distance from the antenna to meet FCC RF exposure compliance requirements. For more information about RF exposure, please visit the FCC website at www.fcc.gov NOTE: Read the “Safety” section prior to using your WISMO Quik Q2338 Series Module. Preface Your WISMO Quik Q2338 Series Module Congratulations! Your new WISMO Quik Q2338 Series Module is going to change the way you communicate. The WISMO QUIK Q2338 is a compact, lightweight, personal communications system with added features for the person on the go. More than just a mobile phone, the WISMO QUIK Q2338 allows you to: • Access your voice mail, and text messages • Review a list of your latest outgoing and incoming calls for reference or call back • Organize names and numbers • Go on-line through the Browser (service features depend upon your carrier service) to surf the web, get e-mails, stock quotes, etc. • Send and receive text messages via the Short Message Service (carrier service provider dependent) • Use your WISMO QUIK Q2338 as a wireless modem to send or receive faxes with your laptop computer. The WISMO QUIK Q2338 is a compact, simple, and affordable solution for your active life style. This Document is intended to provide the user complete instructions on the capabilities and use of the Wavecom Starter Kit. The Wavecom Starter Kit is designed to allow the customer to interface to the Wavecom Q2300 and Q2400 CDMA and GSM/GPRS Module families. Control of the Module is done via AT Commands issued from an external PC running a terminal emulator, such as HyperTerminal. The User should refer to the Wavecom CDMA AT Commands Interface Specification for more information on supported commands. [b1] Table Of Contents About This Manual .......................................................................…

Text truncated - open the document above for the full version.

WISMO Quik Q2338 series User’s Guide Reference: WM_PRJ_WM2C_UG_001 Level: 001B Date: 29th December 2002 - Pre-production Draft - Copyright Copyright© 2002 Wavecom, Inc. All Rights Reserved. Trademarks All trademarks contained in this manual are the property of their respective owners. About This Manual This manual is furnished under license and may only be used or copied in accordance with the terms of such license. The information in this manual is for informational use only, is subject to change without notice, and should not be construed as a commitment by the manufacturer. The manufacturer assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Wavecom, Inc. Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: All other copyrights, trademarks and patents are the property of their owners. Document Number When ordering or referring to this publication, use the following number: Publication/PN WM_PRJ_WM2C_UG_001 WARNING! Read this information before using your phone FCC & Industry Canada Regulatory Compliance The Wismo Quik 2338 Series is approved for use with CDMA networks. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Your mobile device is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for mobile device. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your Module complies with the FCC guidelines and applicable standards. WARNING: Unauthorized antennas, modifications, or attachments could impair call quality, damage the Module, or result in violation of FCC regulations. Do not use the Module with a damaged antenna. Please contact your local authorized dealer for antenna replacement. WARNING: BODY-WORN OPERATION – This device was tested for typical body-worn operations using the optional belt- clip/holster to provide a separation distance of 0.8-inches/2.0 cm from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.8 inches/2.0 cm must be maintained between the user’s body and the belt-clip/holster, including the antenna, whether extended or retracted. Third party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with FCC RF exposure limits and should be avoided. FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Operating Requirements The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antennas or transmitters. Please maintain 20 cm separation distance from the antenna to meet FCC RF exposure compliance requirements. For more information about RF exposure, please visit the FCC website at www.fcc.gov NOTE: Read the “Safety” section prior to using your WISMO Quik Q2338 Series Module. Preface Your WISMO Quik Q2338 Series Module Congratulations! Your new WISMO Quik Q2338 Series Module is going to change the way you communicate. The WISMO QUIK Q2338 is a compact, lightweight, personal communications system with added features for the person on the go. More than just a mobile phone, the WISMO QUIK Q2338 allows you to: • Access your voice mail, and text messages • Review a list of your latest outgoing and incoming calls for reference or call back • Organize names and numbers • Go on-line through the Browser (service features depend upon your carrier service) to surf the web, get e-mails, stock quotes, etc. • Send and receive text messages via the Short Message Service (carrier service provider dependent) • Use your WISMO QUIK Q2338 as a wireless modem to send or receive faxes with your laptop computer. The WISMO QUIK Q2338 is a compact, simple, and affordable solution for your active life style. This Document is intended to provide the user complete instructions on the capabilities and use of the Wavecom Starter Kit. The Wavecom Starter Kit is designed to allow the customer to interface to the Wavecom Q2300 and Q2400 CDMA and GSM/GPRS Module families. Control of the Module is done via AT Commands issued from an external PC running a terminal emulator, such as HyperTerminal. The User should refer to the Wavecom CDMA AT Commands Interface Specification for more information on supported commands. [b1] Table Of Contents About This Manual .........................................................................................................…

Text truncated - open the document above for the full version.

October 25, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: WAVECOM, INC. FCC ID: 09EQ23X8001 Part 22/24Certification Gentlemen: Attached herewith, on behalf of WAVECOM, INC. is an application for Part 22/24 Certification of the Dual-Band CDMA Wireless Module. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams (confidential), operational description, parts list (confidential), tune-up procedure and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: WAVECOM, INC.

December 30, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Wavecom, Inc. FCC ID: O9EQ23X8001 731 Confirmation No.: EA307003 Request for Tech. Info.: 12/10/2002 Correspondence Reference No.: 24509 Dear Stan: Transmitted herewith, on behalf of Wavecom, Inc., is an amendment provided in response to the request for technical information dated December 10, 2002. 1. Please find attached the revised User’s Manual clearly stating that the device is not for portable use. 2. Please find attached the MPE report showing the analysis for both frequency bands. 3. Please find attached the revised User’s Manual stating that the device is authorized for mobile use only. 4. Please find attached the MPE report to show the maximum antenna gain that can be used with this device. 5. Please find attached the antenna installation information included in the User’s Manual. If you have any further questions, please do not hesitate to contact us. cc: Wavecom, Inc.

January 13, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Wavecom, Inc. FCC ID: O9EQ23X8001 731 Confirmation No.: EA307003 Request for Tech. Info.: 01/6/2003 Correspondence Reference No.: 24642 Dear Stan: Transmitted herewith, on behalf of Wavecom, Inc., is an amendment provided in response to the request for technical information dated January 6, 2003. 1. Please find attached the revised User’s Manual. 2. Please find attached the revised MPE report recalculated at 20 cm. If you have any further questions, please do not hesitate to contact us. cc: Wavecom, Inc.

January 15, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Wavecom, Inc. FCC ID: O9EQ23X8001 731 Confirmation No.: EA307003 Request for Tech. Info.: 01/15/2003 Correspondence Reference No.: 24705 Dear Stan: Transmitted herewith, on behalf of Wavecom, Inc., is an amendment provided in response to the request for technical information dated January 15, 2003. 1. This is to confirm that Wavecom is requesting confidentiality on Block Diagram, Schematics, and Parts List only. 2. Please find attached the new replacement confidentiality letter. If you have any further questions, please do not hesitate to contact us. cc: Wavecom, Inc.

© 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module © 2002 PCTEST Lab WAVECOM FCC ID: 09EQ23X8001 Dual-Band CDMA Wireless Module

WISMO-CDMA Dual-Band Embedded Module Hardware Specification PRELIMINARY Reference: WM_Dpt_Projet_Type_N° ordre Level : 1.5 Date: 17 May 2002 confidential © Page : 1 / 34 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. WM_Dpt_Projet_Type_N° ordre - 5/28/2002 Document Information Level Date History of the evolution Writer Rev 1 12/17/01 CNowak Rev 2 03/07/02 CNowak Name Function Date Signature Written by CNowak Checked by Approved by Distribution List • confidential © Page : 2 / 34 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. WM_Dpt_Projet_Type_N° ordre - 5/28/2002 Contents 1 WISMOCDMA Introduction.....................................................................................................................................................................8 1.1 Scope.......................................................................................................................................8 1.2 Applicable Standards...............................................................................................................8 1.3 Safety and Governmental Agency Approval............................................................................8 2 Product Features........................................................................................................................................................................................9 2.1 General Specifications WISMOCDMA module:.......................................................................9 2.2 RF Features..............................................................................................................................9 2.3 Baseband Features..................................................................................................................9 3 Detailed Description...............................................................................................................................................................................11 3.1 RF...........................................................................................................................................11 3.1.1 Transmitter...................................................................................................................11 3.1.1.1 RFT3100-1............................................................................................................11 3.1.1.2 Transmitter Specification......................................................................................12 3.1.2 Receiver 12 3.1.2.1 RFR3100..............................................................................................................12 3.1.2.2 IFR3000................................................................................................................12 3.1.2.3 Receiver Specification..........................................................................................13 3.1.3 Synthesizer...................................................................................................................13 3.2 Baseband...............................................................................................................................13 3.2.1 Power ...................................................................................................................... 14 3.2.1.1 ON-OFF................................................................................................................14 3.2.1.1.1 Mode One..........................................................................................................14 3.2.1.1.2 Mode Two..........................................................................................................15 3.2.1.1.3 Mode Three........................................................................................................15 3.2.1.2 Vcc_Out................................................................................................................15 3.2.1.3 Charging...............................................................................................................15 3.2.2 Digital ...................................................................................................................... 15 3.2.2.1 MSM5101.............................................................................................................15 3.2.2.2 Memory.................................................................................................................15 3.2.3 System Connector........................................................................................................16 3.2.3.1 System Connector Description.............................................................................16 3.2.3.2 I/O Description Parameters..................................................................................16 3.2.3.3 System Connector Names and Pinouts................................................................ 17 3.2.3.4 GPx_INT...............................................................................................................19 3.2.3.5 Keypad..................................................................................................................20 3.2.3.6 I/O Interfaces........................................................................................................21 3.2.3.6.1 UART – 1...........................................................................................................21 3.2.3.6.2 UART – 2.............................................................................…

Text truncated - open the document above for the full version.

PCTEST MPE REPORT FCC CERTIFICATION REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 22/24.220925529a.09E TEST DATES: Sept. 25-26, 2002 EUT TYPE: DUAL-BAND CDMA WIRELESS MODULE FCC ID: 09EQ23X8001 PAGE 1 OF 2 © 2002 PCTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of this product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1210 is followed. The Gain of the antenna used in this product is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (Pout*G) /…

Text truncated - open the document above for the full version.
