O9Y-TIMONTimon

Spireon Inc. owered, Rechargeable Trailer and Asset Tracker HIGHLIGHT WDS is a door sensor, used for remote monitoring of door opening and closing IT’S RELIABLE WDS is an ultra-thin and durable high- performance monitoring device designed specifically for anti-theft applications in containers and parking lots. WDS has an integrated Bluetooth receiver for wireless data communication, can communicate with other monitoring devices such as cameras to form a more complete detection system. The external high-performance antenna is suitable for Bluetooth long-distance transmission, giving the product strong performance. IT’S SIMPLE No programming skills required; WDS comes with easy to configure application software and an extended AT command set. The report can be triggered regularly and can also respond to events such as opening or closing doors, severe acceleration and braking, and battery status violations. Can send notifications about the opening and closing status of vehicle doors and battery status IT’S FUNCTIONAL The WDS interface supports battery and UART input/output. There are two systems, with built-in reed switches and magnets that can detect the status of car doors. A 3-axis accelerometer can achieve motion detection and monitoring of car door behavior, and real-time data can be sent out through Bluetooth broadcasting. The built-in lithium-ion battery of the device can run continuously for up to 10 years. ▪ LED status indicators for activation and pairing status of devices ▪ Integrated accelerometer for monitoring vehicle status & driver behavior ▪ Reed switch used to sense the status of the car door ▪ Battery used for system power supply ▪ UART&USB ▪ Over the air configuration and firmware update ▪ Extended AT Command set for flexible and easy configuration ▪ Small size and easy installation ▪ OPTIONAL FEATURES WDS Car door status detection, car anti- theft Timon Maximize efficiency. Minimize risks. Manage assets. The application firmware is flexible and can be customized to be compatible with your existing server at special request. Spireon Inc BATTERY INFORMATION ▪ Type : Li-ION ▪ Capacity :3000mAh @ 3V ▪ Battery Life : In sleep mode, report once a day for a maximum of 7 to10 years. (Depending on Bluetooth signal strength a nd number of hourly reports per day) ENVIRONMENTAL ▪ Operation Temperature: -30°C to +75°C with Battery ▪ Storage Temperature: -40°C to +85°C ELECTRICAL ▪ Operating Voltage: 2.7V – 3V ▪ Power Consumption: ✓ Bluetooth pairing : ~ 8mA @ 3V ✓ Bluetooth broadcast package: ~ 6mA @ 3V ✓ Sleep mode : < 5uA @3V PHYSICAL ▪ Dimensions: 37.6 x 20.0 x 1.53 mm ▪ Internal Cellular and GPS Antennas ▪ Weight : ~11.5g APPROVALS ▪ FCC 47 ▪ PTCRB & Carrier Approved Specifications: Asiatelco Technologies Inc. (ATEL) Asiatelco is the leading provider of wireless terminal products to its value customers worldwide. Its innovative products and solutions are widely used for reliable broadband access, IoT/M2M applications and voice communication with 4G LTE, 3G & 2G wireless technologies. ATEL’s sales and marketing are globally positioned. It has become globally well-known company in the wireless industry due to its excellent products, solutions and services.. For more information, contact Asiatelco Technologies Inc. FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with FCC RF Exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for the transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co‐located or operating in conjunction with any other antenna or transmitter. ISED Warning statements This device complies with Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (l) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncont…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Spireon Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-20-2024 FCC ID: O9Y-TIMON Ref: Attestation Statements Part 2.911(d)(5)(i) Filing Spireon Inc certifies that the equipment for which authorization is sought is not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing Spireon Inc certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature ： Print name: Ky Vo

[Spireon Inc] [18881 Von Karman Ave.Suite #1500,Irvine, CA 92612, United States] [CA 92612] [United States] Date: [March 20, 2024] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: [O9Y-TIMON] US Agent – Attestation Statement / Part 2.911(d)(7) [Spireon Inc] certifies, that as of [March 20, 2024], we have designated Spireon Inc to accept service of process on our behalf for FCC ID: [O9Y-TIMON]. [Spireon Inc], accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Spireon Inc, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of [Spireon Inc] for FCC ID: [O9Y-TIMON]. Designated Agent Information: Company Name: Spireon Inc FRN: 0026634360 Address: 18881 Von Karman Ave.Suite #1500,Irvine, CA 92612, United States Contact Person: Ky Vo Telephone: (800)557-1449 x6135 Email: [email protected] Sincerely, Company: [Spireon Inc] Designated Agent: Spireon Inc Company Representative: [Ky Vo] Designated Agent Representative: Ky Vo Signature: Signature:

Spireon Inc POWER OF ATTORNEY DATE: 2024-3-20 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize Eurofins TA Technology (Shanghai) Co., Ltd /Yu Hongmei on our behalf, to apply to FCC on our equipment for FCC ID: O9Y-TIMON. Any and all acts carried out by Eurofins TA Technology (Shanghai) Co., Ltd / Yu Hongmei on our behalf shall have the same effect as acts of our own. Sincerely, Signature ： Print name: Ky Vo

Spireon Inc Request for Confidentiality Date: _2024-3-20_ Subject: Confidentiality Request for: _ FCC ID: O9Y-TIMON __ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Schematics Short Term Permanent Tune-Up Procedure Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _ Spireon Inc _ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Ky Vo (Signature/Title 2 ) (Print name)

EUT Appearance Report No.: R2401A0033 TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 1 of 3 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. EUT Appearance EUT Appearance Report No.: R2401A0033 TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 2 of 3 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. EUT Appearance Report No.: R2401A0033 TA Technology (Shanghai) Co., Ltd. TA-MB-01-032E Page 3 of 3 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Picture 1: Constituents of EUT

Internal photo FCC ID: O9Y-TIMON TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 1 of 4 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo Internal photo FCC ID: O9Y-TIMON TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 2 of 4 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: O9Y-TIMON TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 3 of 4 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: O9Y-TIMON TA Technology (Shanghai) Co., Ltd. TA-MB-01-033E Page 4 of 4 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd.

Prepared by: Liu Wei Approved by: Fan Guangchang TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 EMC TEST REPORT Applicant Spireon Inc FCC ID O9Y-TIMON Product Timon Model WDS Report No. R2401A0033-E1 Issue Date March 20, 2024 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC Code CFR47 Part15B (2023)/ ANSI C63.4-2014. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. EMC Test Report Report No.: R2401A0033-E1 TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 2 of 18 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ................................................................................................................................. 4 1.1 Notes of the Test Report ............................................................................................................ 4 1.2 Test Facility ................................................................................................................................ 4 1.3 Testing Location......................................................................................................................... 4 2 General Description of Equipment Under Test ................................................................................. 5 2.1 Applicant and Manufacturer Information ................................................................................... 5 2.2 General Information ................................................................................................................... 5 2.3 Applied Standards ..................................................................................................................... 6 2.4 Test Mode .................................................................................................................................. 7 3 Test Case Results ............................................................................................................................. 8 3.1 Radiated Emission ..................................................................................................................... 8 3.2 Conducted Emission ................................................................................................................ 13 4 Uncertainty Measurement ............................................................................................................... 15 5 Main Test Instruments ..................................................................................................................... 16 ANNEX A: The EUT Appearance ........................................................................................................... 17 ANNEX B: Test Setup Photos ................................................................................................................ 18 EMC Test Report Report No.: R2401A0033-E1 TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 3 of 18 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results Number Test Case Clause in FCC Rules Conclusion 1 Radiated Emission FCC Part15.109, ANSI C63.4-2014 PASS 2 Conducted Emission FCC Part15.107, ANSI C63.4-2014 NA Date of Testing: January 19, 2024~ January 24, 2024 Date of Sample Received: January 11, 2024 Note: 1. NA = Not Applicable. 2. All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. EMC Test Report Report No.: R2401A0033-E1 TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 4 of 18 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2 Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. A2LA (Certificate Number: 3857.01) TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform measurement. 1.3 Testing Location Company: TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Fan Guangchang Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: https://www.eurofins.com/electrical-and-electronics E-mail: [email protected] EMC Test Report Report No.: R2401A0033-E1 TA Technology (Shanghai) Co., Ltd. TA-MB-06-001E Page 5 of 18 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2 General Description of Equipment Under Test 2.1 Applicant and Manufacturer Information Applicant Spireon Inc Applicant address 18881 Von Karman Ave. Suite #1500, Irvine, California, USA Manufacturer Spireon Inc Manufacturer address 18881 Von Karman Ave. Suite #1500, Irvine, California, USA 2.2 General Information EUT De…

Text truncated - open the document above for the full version.

EMC Test Setup Report No.: R2401A0033 TA Technology (Shanghai) Co., Ltd. TA-MB-01-031E Page 1 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Part 15B Test Setup 30MHz-1GHz EMC Test Setup Report No.: R2401A0033 TA Technology (Shanghai) Co., Ltd. TA-MB-01-031E Page 2 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1GHz-18GHz Picture 1: Radiated Emission Test Setup
