ODMACTOP11 AC Wide Range Ceiling Mount PoE Access Point

AC.TOP 11 AC Wide Range Ceiling Mount PoE Access Point User’s Manual Copyright and Disclaimer Copyright & Disclaimer No part of this publication may be reproduced in any form or by any means, whether electronic, mechanical, photocopying, or recording without the written consent of OvisLink Corp. OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice All Trademarks are properties of their respective holders. This product contains some codes from GPL. In compliance with GPL agreement, AirLive will publish the GPL codes on our website. Please go to www.airlive.com and go to the "Support → GPL" menu to download source code. i AirLive AC.TOP User’s Manual Copyright and Disclaimer FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. IMPORTANT NOTE FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. AirLive AC.TOP User’s Manual ii Table of Contents Table of Contents 1. Introduction .............................................................................................. 1 1.1 Overview............................................................................................ 1 1.2 Firmware Upgrade and Tech Support ................................................ 1 1.3 Features ............................................................................................ 2 1.4 Wireless Operation Modes ................................................................. 2 1.4.1 Access Point Mode .................................................................. 2 1.4.2 WDS Repeater Mode ............................................................... 3 2. Installing the AC.TOP .............................................................................. 4 2.1 Package Content ............................................................................... 4 2.2 Knowing your AC.TOP ....................................................................... 4 2.3 Hardware Installation ......................................................................... 5 2.3.1 Ceiling Mount ........................................................................... 5 2.3.2 Install in T-Rail Mount ............................................................... 6 2.3.3 Power up the AC.TOP .............................................................. 8 2.4 LED Indicators ................................................................................... 9 3. Configuring the AC.TOP ........................................................................ 10 3.1 Important Information ....................................................................... 10 3.2 Prepare your PC .............................................................................. 10 3.3 Introduction to IP Finder .................................................................... 11 3.4 Introduction to Web Management .................................................... 12 3.4.1 Getting into Web Management ................................................12 3.4.2 Main Menu ..............................................................................13 3.5 Configuring with Setup Wizard ......................................................... 14 3.6 Initial Configurations ........................................................................ 16 3.6.1 Change the Device’s IP Address ..........................................16 iii AirLive AC.TOP User’s Manual Table of Contents 3.6.2 Set the Time and Date ..........................................................17 3.6.3 Change Password ................................................................18 4. Wireless Settings ................................................................................... 19 4.1 About Wireless Modes ..................................................................... 19 4.2 Basic Wireless Functions ................................................…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B1 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT Flash :8M FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B2 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B13 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Flash :16M FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B14 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B26 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B27 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973

FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B2 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Flash :8M FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B3 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B4 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B5 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B6 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B7 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B8 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B9 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B10 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B11 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B12 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B14 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Flash :16M FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B15 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B16 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B17 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B18 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B19 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B20 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B21 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B22 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B23 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Report No. : FR530676 SPORTON International Inc. Page Number : B24 of B27 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973

FCC EMF Test Report Report No. : FA530676 SPORTON INTERNATIONAL INC. Page No. : 1 of 6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Human Exposure Assessment 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f 2 )* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 FCC EMF Test Report Report No. : FA530676 SPORTON INTERNATIONAL INC. Page No. : 2 of 6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   FCC EMF Test Report Report No. : FA530676 SPORTON INTERNATIONAL INC. Page No. : 3 of 6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.3 Result of Maximum Permissible Exposure (2.4G) Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location b 1 1 Correlated 25.38 Yes g 1 1 Correlated 24.90 Yes n (HT20) 2 1 Uncorrelated 25.57 Yes n (HT40) 2 1 Uncorrelated 23.95 Yes Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 1 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 Sum Chain Gain (dBi) EIRP Power PD (S) (mW/cm²) b 1 25.38 - 25.38 2.82 28.20 0.13144 g 1 24.90 - 24.90 2.82 27.72 0.11769 n (HT20) 2 23.94 20.54 25.57 2.64 28.22 0.13200 n (HT40) 2 22.68 18.00 23.95 2.64 26.60 0.09085 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains FCC EMF Test Report Report No. : FA530676 SPORTON INTERNATIONAL INC. Page No. : 4 of 6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.4 Result of Maximum Permissible Exposure (5.8G) Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location a 1 1 Correlated 22.35 Yes n(HT20) 2 1 Uncorrelated 26.45 Yes n(HT40) 2 1 Uncorrelated 25.05 Yes ac(VHT20) 2 1 Uncorrelated 24.86 Yes ac(VHT40) 2 1 Uncorrelated 25.01 Yes ac(VHT80) 2 1 Uncorrelated 22.55 Yes Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz and 5GHz.) Note 2: RF output power specifies that Maximum Conducted (Average) Output Power. Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Power Level 1 RF Output Power (dBm) Modulation Mode N TX Chain- Port 1 Chain- Port 2 Sum Chain Gain (dBi) PD (S) (mW/cm²) a 1 22.35 - 22.35 4.00 0.08585 n(HT20) 2 22.17 24.42 26.45 3.73 0.20751 n(HT40) 2 22.83 21.08 25.05 3.73 0.15045 ac(VHT20) 2 22.82 20.61 24.86 3.73 0.14406 ac(VHT40) 2 22.79 21.04 25.01 3.73 0.14907 ac(VHT80) 2 20.51 18.29 22.55 3.73 0.08456 Maximum Permissible Exposure Limit (mW/cm²) 1 Note 1: N TX = Number of Transmit Chains FCC EMF Test Report Report No. : FA530676 SPORTON INTERNATIONAL INC. Page No. : 5 of 6 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.5 Result of Maximum Permissible Exposure(5.2G) Transmitter Chains & Receiver Chains Information IEEE Std. 802.11 Protocol Number of Transmit Chains (N TX ) Number of Receive Chains (N RX ) Correlation Signals with Multiple N TX RF Output Power (dBm) Co-location a 1 1 Correlated 19.95 Yes n(HT20) 2 1 Uncorrelated 21.71 Yes n(HT40) 2 1 Uncorrelated 21.31 Yes ac(VHT20) 2 1 Uncorrelated 20.52 Yes ac(VHT40) 2 1 Uncorrelated 20.69 Yes ac(VHT80) 2 1 Uncorrelated 19.89 Yes Note 1: Co-location, Co-location is generally defined as simultaneously transmitting (co-transmitting) antennas within 20 cm of each other. (i.e., EUT has simultaneously co-transmitting that operating 2.4GHz a…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR530676AN SPORTON INTERNATIONAL INC. Page No. : 1 of 99 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Equipment : 11 AC Wide Range Ceiling Mount PoE Access Point Brand Name : Air Live Model No. : AC.TOP / AC.TOP Series FCC ID : ODMACTOP Standard : 47 CFR FCC Part 15.407 Operating Band : 5150 MHz – 5250 MHz 5725 MHz – 5850 MHz FCC Classification : NII Applicant Manufacturer : OvisLink Corp. 5F, No.6, Lane 130, Min-Chuan Rd., Hsin-Tien Dist., New Taipei City 231, Taiwan Function : Outdoor AP; Indoor AP; Fixed P2P AP Portable Client The product sample received on Jul. 15, 2014 and completely tested on Oct. 31, 2014. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2013 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Vic Hsiao / Supervisor FCC Test Report Report No. : FR530676AN SPORTON INTERNATIONAL INC. Page No. : 2 of 99 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Product Details ....................................................................................................................................... 8 1.3 Accessories and Support Equipment ..................................................................................................... 8 1.4 Testing Applied Standards ..................................................................................................................... 8 1.5 Testing Location Information .................................................................................................................. 9 1.6 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION OF EUT ....................................................................................................... 10 2.1 The Worst Case Modulation Configuration .......................................................................................... 10 2.2 The Worst Case Power Setting Parameter .......................................................................................... 10 2.3 The Worst Case Measurement Configuration ...................................................................................... 11 2.4 Test Setup Diagram ............................................................................................................................. 13 3 TRANSMITTER TEST RESULT .......................................................................................................... 15 3.1 AC Power-line Conducted Emissions .................................................................................................. 15 3.2 Emission Bandwidth ............................................................................................................................. 18 3.3 RF Output Power .................................................................................................................................. 22 3.4 Peak Power Spectral Density ............................................................................................................... 27 3.5 Transmitter Bandedge Emissions ........................................................................................................ 31 3.6 Transmitter Unwanted Emissions ......................................................................................................... 35 3.7 Frequency Stability ............................................................................................................................... 96 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 98 A PPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR530676AN SPORTON INTERNATIONAL INC. Page No. : 3 of 99 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Result 1.1.2 15.203 Antenna Requirement Complied 3.1 15.207 AC Power-line Conducted Emissions Complied 3.2 15.407(a) Emission Bandwidth Complied 3.3 15.407(a) RF Output Power (Maximum Conducted Output Power) Complied 3.4 15.407(a) Peak Power Spectral Density Complied 3.5 15.407(b) Transmitter Bandedge Emissions Complied 3.6 15.407(b) Transmitter Unwanted Emissions Complied 3.7 15.407(g) Frequency Stability Complied FCC Test Report Report No. : FR530676AN SPORTON INTERNATIONAL INC. Page No. : 4 of 99 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR530676AN Rev. 03 Initial issue of report Apr. 10, 2015 FCC Test Report Report No. : FR530676AN SPORTON INTERNATIONAL INC. Page No. : 5 of 99 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) RF Output Power (dBm) Co-location 5150-5250 a 5180-5240 36-48 [4] 1 19.95 Yes 5725-5850 5745-5825 149-165 [5] 1 22.35 Yes 5150-5250 n (HT20) 5180-5240 36-48 [4] 2 / 2 21.71 / 20.52 Yes 5725-5850 ac (VHT20) 5745-5825 149-165 [5] 2 / 2 26.45 / 24.86 Yes 5150-5250 n (HT40) 5190-5230 38-46 [2] 2 / 2 21.31 / 20.69 Yes 5725-5850 ac (VHT40) 5755…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR530676 SPORTON INTERNATIONAL INC. Page No. : 1 of 8 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 CO-LOCATION 1.1 Transmitter Radiated Unwanted Emissions 1.1.1 Transmitter Radiated Unwanted Emissions Limit Restricted Band Emissions Limit Frequency Range (MHz) Field Strength (uV/m) Field Strength (dBuV/m) Measure Distance (m) 0.009~0.490 2400/F(kHz) 48.5 - 13.8 300 0.490~1.705 24000/F(kHz) 33.8 - 23 30 1.705~30.0 30 29 30 30~88 100 40 3 88~216 150 43.5 3 216~960 200 46 3 Above 960 500 54 3 Note 1: Test distance for frequencies at or above 30 MHz, measurements may be performed at a distance other than the limit distance provided they are not performed in the near field and the emissions to be measured can be detected by the measurement equipment. When performing measurements at a distance other than that specified, the results shall be extrapolated to the specified distance using an extrapolation factor of 20 dB/decade (inverse of linear distance for field-strength measurements, inverse of linear distance-squared for power-density measurements). Note 2: Test distance for frequencies at below 30 MHz, measurements may be performed at a distance closer than the EUT limit distance; however, an attempt should be made to avoid making measurements in the near field. When performing measurements below 30 MHz at a closer distance than the limit distance, the results shall be extrapolated to the specified distance by either making measurements at a minimum of two or more distances on at least one radial to determine the proper extrapolation factor or by using the square of an inverse linear distance extrapolation factor (40 dB/decade). The test report shall specify the extrapolation method used to determine compliance of the EUT. Un-restricted Band Emissions Limit RF output power procedure Limit (dB) Peak output power procedure 20 Average output power procedure 30 Note 1: If the peak output power procedure is used to measure the fundamental emission power to demonstrate compliance to requirements, then the peak conducted output power measured within any 100 kHz outside the authorized frequency band shall be attenuated by at least 20 dB relative to the maximum measured in-band peak PSD level. Note 2: If the average output power procedure is used to measure the fundamental emission power to demonstrate compliance to requirements, then the power in any 100 kHz outside of the authorized frequency band shall be attenuated by at least 30 dB relative to the maximum measured in-band average PSD level. 1.1.2 Measuring Instruments Refer a test equipment and calibration data table in this test report. FCC Test Report Report No. : FR530676 SPORTON INTERNATIONAL INC. Page No. : 2 of 8 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.3 Test Procedures Test Method Measurements may be performed at a distance other than the limit distance provided they are not performed in the near field and the emissions to be measured can be detected by the measurement equipment. When performing measurements at a distance other than that specified, the results shall be extrapolated to the specified distance using an extrapolation factor of 20 dB/decade (inverse of linear distance for field-strength measurements, inverse of linear distance-squared for power-density measurements). The average emission levels shall be measured in [duty cycle ≥ 98 or duty factor]. For the transmitter unwanted emissions shall be measured using following options below: Refer as FCC KDB 558074, clause 10.1 for unwanted emissions into non-restricted bands. Refer as FCC KDB 558074, clause 10.2 for unwanted emissions into restricted bands. Refer as FCC KDB 558074, clause 10.2.3.3 and 8.2.1 Option 1 (spectral trace averaging) Refer as FCC KDB 558074, clause 10.2.3.3 and 8.2.1 Option 2 (slow sweep speed). Refer as ANSI C63.10, clause 4.2.3.2.3 (Reduced VBW). VBW ≥ 1/T, where T is pulse time. Refer as ANSI C63.10, clause 4.2.3.2.4 average value of pulsed emissions. Refer as FCC KDB 558074, clause 10.2.3.2 and 8.1.1 measurement procedure peak limit. Refer as FCC KDB 558074, clause 10.2.3.1 measurement procedure Quasi-Peak limit. For radiated measurement, refer as FCC KDB 558074, clause 10.2.1. Refer as ANSI C63.10, clause 6.4 for radiated emissions from below 30 MHz. Test distance is 3m. Refer as ANSI C63.10, clause 6.5 for radiated emissions from 30 MHz to 1000 MHz. Test distance is 3m. Refer as ANSI C63.10, clause 6.6 for radiated emissions from above 1 GHz. Test distance is 3m. For conducted and cabinet radiation measurement, refer as FCC KDB 558074, clause 10.2.2. For conducted unwanted emissions into non-restricted bands (relative emission limits). Devices with multiple transmit chains: Refer as FCC KDB 662911, when testing out-of-band and spurious emissions against relative emission limits, tests may be performed on each output individually without summing or adding 10 log(N) if the measurements are made relative to the in-band emissions on the individual outputs. For conducted unwanted emissions into restricted bands (absolute emission limits). Devices with multiple transmit chains using options given below: (1) Measure and sum the spectra across the outputs or (2) Measure and add 10 log(N) dB FCC KDB 558074 FCC Test Report Report No. : FR530676 SPORTON INTERNATIONAL INC. Page No. : 3 of 8 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.4 Test Setup Transmitter Radiated Unwanted Emissions Below 1GHz Magnetic field tests shall be performed in the frequency range of 9 kHz to 30 MHz using a calibrated loop antenna. Electric field tests shall be performed in the frequency range of 30 MHz to 1000 MHz using a calibrated bi-log antenna. Transmitter Radiated Unwanted Emissions Above 1GHz Electric field tests shall be performed in the frequency range of 1 GHz to 10th harmonic of highest fundamental frequency or 40 GHz using a calibrated horn antenna. 1.1.5 Transmitt…
