OE5S874CSmartcard reader with keypad for access control systems 874 MKII

Mount the backplate using countersunk headed screws adjacent to the opening edge of the door. If fixing hole ’A’ is used then the breakout must be removed and the screw must not protrude. Feed the cable from the controller through the backplate. If the wall tamper function is to be used then the small hole in breakout ‘B’ may be used to mark the position of the wall screw before the breakout is removed. An appropriate wall screw should then be adjusted in height to protrude through the hole to activate the tamper lever. The front cover is secured to the backplate by UNSCREWING the securing screw ‘C’ via the small hole in the enclosure so that the screw head locates in the counterbored hole on the inside of the enclosure. The screw should not be removed from the backplate. 2 Mount the Backplate The S874-EX-KP V4 is a contactless smart-card reader, with LED’s and keypad. The reader can be set to use Wiegand or The S874-EX-KP V4 reader will read smartMAX encoded MIFARE cards and card serial numbers from most ISO 14443A smart cards which have a 4-byte UID (User Identification). The reader may be configured to read other card types by presenting a programming card to the reader during start up. For additional information regarding the installation, configuration and proper use of this product: SMS User Guide, P/N 9600-0429, M2150 Access Control Design Guide, P/N 9600-0420. Only DES-CARD and DES-CARD-W/MAG DESfire 32K bit smart cards have been evaluated for UL294. 20mA current loop communications. Installation and User Instructions for S874-EX-KP V4 Keypad Readers 1 Fit The Weather Proofing Kit When mounting outside, the gasket kit must be fitted: a)Remove the backplate from the reader after screwing the securing screw ‘C’ fully IN. b)Position the gasket between the back plate and the mounting surface. Note: For UL listed products, use only manufacturer provided gasket, P/N 87X-GASKET. You should find that the backplate has holes for connection to most standard electrical back boxes. C A B 3 Reader Connections Note: (For UL Listed Products) 1). Consult local AHJ (Authority Having Jurisdiction) when installing access control readers and locking mechanisms to any portal in an egress path. 2). The use of Fail Closed / secure configuration shall be determined by local building codes and the local AHJ. 3). Wiring methods shall be in accordance with NEC (National Electrical Code) ANSI/NFPA 70. 4). All Interconnected devices must be UL listed. 5 Reader Links Presentthe cardface-ontothereaderuntilyouhear a"bleep". Cardscan be presented in rapid succession; there is no need, for example, to wait for "GREEN LED’s" to disappear before presenting another. If the reader has been enabled for user-code mode at the controller, you can gain access by pressing the O key, entering your card number, then pressing the P key. When faulted, the reader can not accept a card read. Check wiring for faults or replace reader. The reader is now working correctly. 9600-0769. Installation and User Instructions for S874-EX V4 Keypad Readers, Issue 1.0 Copyright AMAG Technology, Inc. 2023. All rights reserved. FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any unauthorized modification to this device may void the authority of the user to operate it. All trademarks acknowledged. © LED Status Indicator GREEN – The lock is released and you may open the door. RED – You do not have access rights to gain entry, or the reader did not read your card properly (in this case, present it again). YELLOW – Enter your PIN. If you make a mistake, the RED LED’s are momentarily displayed, followed by YELLOW LED’s, to prompt you to try again. Specifications Input voltage: 10.6-12.7Vdc. (Voltage Source is Class 2 Power Limited) Input current: 200mA Max. Operating temperature: -40 to 158°F (-40 to 70°C) Operating humidity: 90%, non-condensing. Maximum read range: 4" (100mm). Approvals TBD 6 Using / Testing the Reader Set SW1 switch 2 (COM) to W for Wiegand communications, or C for 20mA current loop communications. Set SW1 switch 1 (USER F/B - audio feedback) to 1 for sound on, or 0 for sound off. 0V Green Data 0 Red Data 1 12V Controller 0V GRN 0 +V Wiegand RED 1 Reader TB1 Connect shield at controller end only. Note: Use SW1 switch 2 to select the communications mode (See Step 4). Multi conductor shielded Note: The FERRITE must be fitted! Slide the ferrite sleeve onto cable before wiring terminal block. Ferrite to be placed 50mm (2") up cable and held in place with cable ties. Maximum distance 75m 0V RX+ RX- TX+ TX- 12V Controller 0V TX+ TX- RX+ RX- +V Reader TB1 20mA current loop Connect shield at controller end only. Maximum distance 150m 4 Reader Connections contd. Twisted pairs shielded (use Belden 9504) cable or other shielded UL Listed style 2464 (DUZX) cable. Terminal TB1 is rated class 2

Mount the backplate using countersunk headed screws adjacent to the opening edge of the door. If fixing hole ’A’ is used then the breakout must be removed and the screw must not protrude. Feed the cable from the controller through the backplate. If the wall tamper function is to be used then the small hole in breakout ‘B’ may be used to mark the position of the wall screw before the breakout is removed. An appropriate wall screw should then be adjusted in height to protrude through the hole to activate the tamper lever. The front cover is secured to the backplate by UNSCREWING the securing screw ‘C’ via the small hole in the enclosure so that the screw head locates in the counterbored hole on the inside of the enclosure. The screw should not be removed from the backplate. 2 Mount the Backplate The S874-KP V4 is a contactless smart-card reader, with LED’s and keypad. The reader can be set to use Wiegand or The S874-KP V4 reader will read smartMAX encoded MIFARE cards and card serial numbers from most ISO 14443A smart cards which have a 4-byte UID (User Identification). The reader is configured by presenting up to two different card formats, (or the same card format twice), after power up. For additional information regarding the installation, configuration and proper use of this product: SMS User Guide, P/N 9600-0429 M2150 Access Control Design Guide, P/N 9600-0420. Only DES-CARD and DES-CARD-W/MAG DESfire 32K bit smart cards have been evaluated for UL294. 20mA current loop communications. Installation and User Instructions for S874-KP V4 Keypad Readers 1 Fit The Weather Proofing Kit When mounting outside, the gasket kit must be fitted: a)Remove the backplate from the reader after screwing the securing screw ‘C’ fully IN. b)Position the gasket between the back plate and the mounting surface. Note: Reader suitable as indoor use only with UL listed products You should find that the backplate has holes for connection to most standard electrical back boxes. C A B 3 Reader Connections Note: (For UL Listed Products) 1). Consult local AHJ (Authority Having Jurisdiction) when installing access control readers and locking mechanisms to any portal in an egress path. 2). The use of Fail Closed / secure configuration shall be determined by local building codes and the local AHJ. 3). Wiring methods shall be in accordance with NEC (National Electrical Code) ANSI/NFPA 70. 4). All Interconnected devices must be UL listed. 5 Reader Links Presentthe cardface-ontothereaderuntilyouhear a"bleep". Cardscan be presented in rapid succession; there is no need, for example, to wait for "GREEN LED’s" to disappear before presenting another. If the reader has been enabled for user-code mode at the controller, you can gain access by pressing the O key, entering your card number, then pressing the P key. When faulted, the reader can not accept a card read. Check wiring for faults or replace reader. The reader is now working correctly. 9600-0770. Installation and User Instructions for S874-KP V4 Keypad Readers, Issue 1.0 . Copyright AMAG Technology, Inc. 2023. All rights reserved. FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any unauthorized modification to this device may void the authority of the user to operate it. All trademarks acknowledged. © LED Status Indicator GREEN – The lock is released and you may open the door. RED – You do not have access rights to gain entry, or the reader did not read your card properly (in this case, present it again). YELLOW – Enter your PIN. If you make a mistake, the RED LED’s are momentarily displayed, followed by YELLOW LED’s, to prompt you to try again. Specifications Input voltage: 10.6-12.7Vdc. (Voltage Source is Class 2 Power Limited) Input current: 250mA Max. Operating temperature: -13 to 158°F (-25 to 70°C) Operating humidity: 90%, non-condensing. Maximum read range: 4" (100mm). Approvals TBD 6 Using / Testing the Reader Set SW1 switch 2 (COM) to W for Wiegand communications, or C for 20mA current loop communications. Set SW1 switch 1 (USER F/B - audio feedback) to 1 for sound on, or 0 for sound off. 0V Green Data 0 Red Data 1 12V Controller 0V GRN 0 +V Wiegand RED 1 Reader TB1 Connect shield at controller end only. Note: Use SW1 switch 2 to select the communications mode (See Step 4). Multi conductor shielded Note: The FERRITE must be fitted! Slide the ferrite sleeve onto cable before wiring terminal block. Ferrite to be placed 50mm (2") up cable and held in place with cable ties. Maximum distance 75m 0V RX+ RX- TX+ TX- 12V Controller 0V TX+ TX- RX+ RX- +V Reader TB1 20mA current Connect shield at controller end only. Maximum distance 150m Twisted pairs shielded (use Belden 9504) cable or other shielded UL Listed style 2464 (DUZX) cable. Terminal TB1 is rated class 2 4 Reader Connections contd.

Mount the backplate using countersunk headed screws adjacent to the opening edge of the door. If fixing hole ’A’ is used then the breakout must be removed and the screw must not protrude. Feed the cable from the controller through the backplate. If the wall tamper function is to be used then the small hole in breakout ‘B’ may be used to mark the position of the wall screw before the breakout is removed. An appropriate wall screw should then be adjusted in height to protrude through the hole to activate the tamper lever. The front cover is secured to the backplate by UNSCREWING the securing screw ‘C’ via the small hole in the enclosure so that the screw head locates in the counterbored hole on the inside of the enclosure. The screw should not be removed from the backplate. 2 Mount the Backplate The S874 V4 is a contactless smart-card reader, with LED’s. The reader can be set to use Wiegand or The S874 V4 reader will read smartMAX encoded MIFARE cards and card serial numbers from most ISO 14443A smart cards which have a 4-byte UID (User Identification). The reader may be configured to read other card types by presenting a programming card to the reader during start up. For additional information regarding the installation, configuration and proper use of this product: SMS User Guide, P/N 9600-0429, M2150 Access Control Design Guide, P/N 9600-0420, 20mA current loop communications. Only DES-CARD and DES-CARD-W/MAG DESfire 32K bit smart cards have been evaluated for UL294. Installation and User Instructions for S874 V4 Readers 1 Fit The Weather Proofing Kit When mounting outside, the gasket kit must be fitted: a)Remove the backplate from the reader after screwing the securing screw ‘C’ fully IN. b)Position the gasket between the back plate and the mounting surface. Note: Reader suitable as indoor use only with UL listed products. You should find that the backplate has holes for connection to most standard electrical back boxes. C A B 3 Reader Connections Note: (For UL Listed Products) 1). Consult local AHJ (Authority Having Jurisdiction) when installing access control readers and locking mechanisms to any portal in an egress path. 2). The use of Fail Closed / secure configuration shall be determined by local building codes and the local AHJ. 3). Wiring methods shall be in accordance with NEC (National Electrical Code) ANSI/NFPA 70. 4). All Interconnected devices must be UL listed. 5 Reader Links Presentthe cardface-ontothereaderuntilyouhear a"bleep". Cardscan be presented in rapid succession; there is no need, for example, to wait for "GREEN LED’s" to disappear before presenting another. When faulted, the reader can not accept a card read. Check wiring for faults or replace reader. The reader is now working correctly. 9600-0771. Installation and User Instructions for S874 V4 Readers, Issue 1.0 AMAG Technology Inc, 2023 FCC Notice: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any unauthorized modification to this device may void the authority of the user to operate it. All trademarks acknowledged. © LED Status Indicator GREEN – The lock is released and you may open the door. RED – You do not have access rights to gain entry, or the reader did not read your card properly (in this case, present it again). Specifications Input voltage: 10.6 - 12.7Vdc. Input current: 200mA Max. Operating temperature: -13 to 158°F (-25 to 70°C) Operating humidity: 90%, non-condensing. Maximum read range: 4" (100mm). Approvals TBD 6 Using / Testing the Reader Set SW1 switch 2 (COM) to W for Wiegand communications, or C for 20mA current loop communications. Set SW1 switch 1 (USER F/B - audio feedback) to 1 for sound on, or 0 for sound off. 4 Reader Connections contd. 0V Green Data 0 Red Data 1 12V Controller 0V GRN 0 +V Wiegand RED 1 Reader TB1 Connect shield at controller end only. Note: Use SW1 switch 2 to select the communications mode (See Step 4). Multi conductor shielded . Note: The FERRITE must be fitted! Slide the ferrite sleeve onto cable before wiring terminal block. Ferrite to be placed 50mm (2") up cable and held in place with cable ties. Maximum distance 75m 0V RX+ RX- TX+ TX- 12V Controller 0V TX+ TX- RX+ RX- +V Reader TB1 20mA current loop Connect shield at controller end only. Maximum distance 150m Twisted pairs shielded (use Belden 9504) cable or other shielded UL Listed style 2464 (DUZX) cable. Terminal TB1 is rated class 2

RF914 9.0 Report on the Radio Testing For G4S Technology Ltd T/AS AMAG Technology on S874 Javelin Mifare Card Reader Report no. TRA-016463-47-02B 12 th December 2025 RF914 9.0 REPORT ON THE RADIO TESTING OF A G4S Technology Ltd T/AS AMAG Technology S874 Javelin Mifare Card Reader WITH RESPECT TO SPECIFICATION FCC 47CFR 15.225 TEST DATE: 23rd May 2023 to 09th June 2023 Tested by: Steven Garwell Radio Test Engineer Approved by: John Charters Department Manager - Radio Date: 12 th December 2025 Disclaimers: [1] THIS DOCUMENT MAY BE REPRODUCED ONLY IN ITS ENTIRETY AND WITHOUT CHANGE [2] THE RESULTS CONTAINED IN THIS DOCUMENT RELATE ONLY TO THE ITEM(S) TESTED Report Number: TRA-016463-47-02B Issue: B Report Number: TRA-016463-47-02B RF914 9.0 Page 3 of 41 1 Revision Record Issue Issue Date Revision History A 12 th September 2024 Original B 12 th December 2025 Update of ANSI C63.10 to 2020 version Report Number: TRA-016463-47-02B RF914 9.0 Page 4 of 41 2 Summary TEST REPORT NUMBER: TRA-016463-47-02B WORKS ORDER NUMBER: TRA-061463-00 PURPOSE OF TEST: USA: Testing of radio frequency equipment per the relevant authorization procedure of chapter 47 of CFR (code of federal regulations) Part 2, subpart J. TEST SPECIFICATION(S): 47CFR15.225 EQUIPMENT UNDER TEST (EUT): S874 Javelin Mifare Card Reader FCC IDENTIFIER: OE5S874C EUT SERIAL NUMBER: 2315001985 MANUFACTURER/AGENT: G4S Technology Ltd T/AS AMAG Technology ADDRESS: Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ United Kingdom CLIENT CONTACT: Ian Williams  01684 850977  [email protected] ORDER NUMBER: PUR102087 TEST DATE: 23rd May 2023 to 09th June 2023 TESTED BY: Steven Garwell Element Report Number: TRA-016463-47-02B RF914 9.0 Page 5 of 41 2.1 Test Summary Test Method and Description Requirement Clause 47CFR15 Applicable to this equipment Result / Note Radiated spurious emissions, below 30 MHz 15.225(d) PASS Radiated spurious emissions 15.209 PASS AC power line conducted emissions 15.207 PASS Occupied bandwidth 15.215(c) PASS Field strength of fundamental 15.225(a), (b) and (c) PASS Frequency stability 15.225(e) PASS Notes: The results contained in this report relate only to the items tested, in the condition at time of test, and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Any modifications made are identified in Section 8 of this report. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 5.2 of this test report (Deviations from Test Standards). General notes The decision rule for compliance is not inherent within this specification and compliance is based on the customer requesting a simple acceptance rule based on understanding and acceptance of Elements Measurement Uncertainty values. Report Number: TRA-016463-47-02B RF914 9.0 Page 6 of 41 3 Contents 1 Revision Record ......................................................................................................................................... 3 2 Summary .................................................................................................................................................... 4 2.1 Test Summary .................................................................................................................................... 5 3 Contents ..................................................................................................................................................... 6 4 Introduction ................................................................................................................................................. 8 5 Test Specifications ..................................................................................................................................... 9 5.1 Normative References ........................................................................................................................ 9 5.2 Deviations from Test Standards ......................................................................................................... 9 6 Glossary of Terms .................................................................................................................................... 10 7 Equipment under Test .............................................................................................................................. 11 7.1 EUT Identification ............................................................................................................................. 11 7.2 System Equipment ............................................................................................................................ 11 7.3 EUT Mode of Operation .................................................................................................................... 11 7.3.1 Transmission ............................................................................................................................ 11 7.4 EUT Radio Parameters ..................................................................................................................... 11 7.4.1 General ..................................................................................................................................... 11 7.5 EUT Description................................................................................................................................ 11 8 Modifications ............................................................................................................................................. 12 9 EUT Test Setup ...............................................................................................................................…

Text truncated - open the document above for the full version.

874 Antenna information A three-turn loop antenna is used, situated on layer 3 of the PCB. Antenna track width is 1mm. Antenna shield plains positioned on layers 2 and 4 of the PCB 1 oz copper used for the board construction. PCB layer 3 showing antenna dimensions (figure 1): 3 5 mm 60 mm PCB Layer 2, antenna top shield (figure 2): PCB layer 4, showing antenna bottom shield (figure 3):

RF EXPOSURE REPORT INFORMATION 2025-02-04 Element Job Number: Ple ase provide the requested support information by filling in the blanks. If an item does not apply, please fill in the section with ‘NA’. The following information is for Model (or System): The dimensions (XYZ) of the system: RF Exposure conditions: Minimum distance from user during intended product use mm cm What prevents a user from being closer than this? ex: distance from edge of enclosure, mounted to a wall, etc Location on/near body during use Head/Torso Limbs/Extremities Not Applicable Body-worn accessories None Rat ed Power: The rated power is the maximum RF output power your radio equipment is designed to transmit. List the rated power below along with units. If the value is radiated, please list EIRP or ERP as relevant. For the EU, the rated transmit power is listed in the user manual. Tune-up Tolerance: The tune-up tolerance is the variability in the RF output power than can be expected due to manufacturing variation, in (dB). The maximum permitted tolerance is 2 dB. An tenna Gain: If the antenna gain is specific to a frequency range or band, please list the information on a separate line. For loop antennas, no gain is required. List 'loop'. Min imum Distance: If the minimum distance from the antenna to the enclosure exceeds 5 mm (for portable use), please submit a photo with a ruler showing this measurement, or a CAD drawing with a dimension as a separate document. Radio Type Rated Power Tune-up Tolerance (dB) Antenna Gain (dBi) Minimum Distance from Antenna to Enclosure (mm) RF EXPOSURE REPORT INFORMATION 2022-04-01 Simultaneous Transmission: If the radio is capable of simultaneous transmission (when two different radios transmit at the same time) with another radio in the product or system, please include the details below. Otherwise, select ‘NA’. Case List of radios that can simultaneously transmit. 1 NA 2 NA 3 NA 4 NA O perational Duty Cycle: If the transmitters are designed to operate at a reduced duty cycle, please provide a separate document showing a derivation of the operational duty cycle. If the operational duty cycle is not inherent in the channel access mechanism, such as TDMA, this information will need to be documented in the report. See 2.4 GHz sample below which considers all modes when determining worst case duty cycle: Description Payload (bytes) Rate (bytes/sec) Duration (sec) Time between payloads (sec) Period Allowed (sec) Duty cycle (%) Status data 100 500 0.2 30 100 0.7% Streaming 175 500 0.35 0.01 100 97.2% Firmware (one time) 40000 500 80 N/A 100 80.0% So urce-Based Time Averaging (FCC KDB 447498) – A time average of instantaneous exposure over a period that is based on an inherent property or duty-cycle of a device to ensure compliance with the continuous exposure limits. The maximum observation period that can used for the duty cycle calculation is: <3 GHz: 100 seconds, 3-6 GHz: 60 seconds, 6-10 GHz: 30 seconds, 10-16 GHz: 14 seconds, 16-24 GHz: 8 seconds, 24-42 GHz: 4 seconds, 42 - 95 GHz: 2 seconds. (or 6 minutes for ISED). Select which applies: Assessment to be completed assuming 100% duty cycle All Radios Only the following radios: Duty cycle analysis will be provided as a separate document for each of the following radios: Reduced duty cycle radios: C ompleted by (name): Title: Company: Date: Email: S ubmit completed form to [email protected].

874-V4-0 874-V4-DPD 874-V4-S 874-KP-V4-0 874-KP-V4-DPD 874-KP-V4-S 874-KP-V4-SW 874-KP-V4-TV 874-EX-KP-V4-S 874-EX-KP-V4-SW

AMAG Technology Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ UK Telephone: +44 (0) 1684 850977 www.amag.com Registered Office: AMAG Technology is a trade name of G4S Technology Ltd Challenge House, International Drive Tewkesbury, Glos, GL20 SUQ Registered Number: 02382338 England. A member of the British Security Industry Association 1151/7.17 For the attention of: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA 29 th October 2024 Submission of FCC ID OE5S874C for Equipment Authorisation G4S Technology Limited (trading as AMAG Technology) submits the following equipment for equipment authorisation: FCC ID OE5S874C Product Numbers 874-V4, 874-V4-0, 874-V4-S, 874-V4-DPD, 874-KP-V4, 874-KP-V4-0, 874-KP-V4-S, 874-KP-V4-DPD, 874-KP-V4-SW, 874-KP-V4-TV, 874-EX-KP-V4, 874-EX-KP-V4-S, 874-EX-KP-V4-SW Description Smartcard reader with keypad for access control systems Radio type Inductive loop (near field magnetic field) short range device (SRD) for radio frequency identification (RFID). Frequency 13.56 MHz Nominal field strength 6.66 dBμA/m at 10m (120μV/m at 30m) Band 13.110 to 14.010 MHz Channel spacing Not channelised Wide/narrow band Wideband Modulation Amplitude Shift Keying Antenna Integrated loop antenna Applicant G4S Technology Limited Applicant type Manufacturer Authorisation sort Original certification Applicable rule parts CFR Title 47, Chapter I, Subchapter A, Part 15, Subpart C, § 15.225 Operation within the band 13.110-14.010 MHz (47 CFR 15.225) G4S Technology Limited certifies that all statements it makes in this request for equipment authorisation are true and correct to the best of its knowledge. G4S Technology Limited certifies that neither it nor any party to the application is subject to a denial of Federal benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. Signed on behalf of G4S Technology Limited, Mr Ian Williams Hardware Team Lead Tel: +44 7734362323 Email: [email protected]

AMAG Technology Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ UK Telephone: +44 (0) 1684 850977 www.amag.com AMAG Technology is a trade name of G4S Technology Ltd Registered Office: Challenge House, International Drive, Tewkesbury, Glos, GL20 8UQ Registered Number: 02382338 England. A member of the British Security Industry Association 1151/7.17 For the attention of: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA 16 th October 2025 DECLARATION OF SIMILARITY G4S Technology Limited, trading as AMAG Technology, declares that the following products: 874-V4 874-KP-V4-0 874-EX-KP-V4 874-V4-0 874-KP-V4-S 874-EX-KP-V4-S 874-V4-S 874-KP-V4-SW 874-EX-KP-V4-SW 874-V4-DPD 874-KP-V4-TV 874-KP-V4-DPD are identical with regards to radio performance and electromagnetic compatibility performance as product number: 874-KP-V4 that was tested and assessed by Element Material Technology Warwick Limited. All of the above products will be identified by the FCC ID: OE5S874C. All of the above products share the same circuit board and firmware. The differences are as follows: Product Difference Beginning 874-V4... No keypad membrane or waterproof keypad is fitted. Beginning 874-KP... A rubber keypad membrane is fitted. It is not waterproof. Beginning 874-EX-KP... A waterproof keypad is fitted. The circuit board is conformally coated. Ending ...-0,-S,-SW, -TV,-DPD These denote cosmetic differences for some customers, or regional markets where the label is different for regulatory purposes. Signed on behalf of G4S Technology Limited, Mr Ian Williams Hardware Team Lead Tel: +44 7734362323 Email: [email protected]

AMAG Technology Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ Telephone: 01684-850977 www.Amag.com REQUEST FOR CONFIDENTIALITY IN ACCORDANCE WITH FCC RULE 0.459 12 th June 2024 Element Materials Technology Warwick Ltd 100 Frobisher Business Park Leigh Sinton Road Malvern Worcestershire WR14 1BX UK RE: Certification Application FCC ID: OE5S874C To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of AMAG Technology Limited.  Schematics  Parts Lists  Block Diagram  Operational Description The application contains technical information, which AMAG Technology Limited deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully AMAG Technology Limited Challenge House International Drive Tewkesbury Gloucestershire GL20 8UQ Issued by:- Date:- 12/06/2024 Ian Williams (Hardware Team Lead)
