OG4-K3Sesam 800 Radio Remote Control

946415-000-A0 OPERATING MANUAL SESAM 800 K3, RX DIN USA Table of Contents 1 Introduction ______________________________________3 2 Scope ___________________________________________3 2.1 Safety Considerations _____________________________________4 2.2 Warnings _______________________________________________6 3 Technical specifications ____________________________7 4 Description of the system __________________________8 4.1 Receiver ________________________________________________8 4.2 Transmitter ______________________________________________8 5 Description of Sesam 800 RX DIN receiver _____________9 6 Installation of the receiver __________________________10 6.1 Placement of the receiver __________________________________10 6.2 Connections on the receiver _______________________________11 7 Indicators on the receiver _________________________12 8 Configuration of the receiver _______________________12 8.1 Basic configuration _______________________________________12 8.2 Advanced configuration ___________________________________13 8.3 Erasing all transmitters in the receiver ________________________13 9 Description of Sesam 800 K3 transmitter _____________14 9.1 Indications on the transmitter _______________________________14 10 Using the system _________________________________15 11 Configuration of the transmitter _____________________15 11.1 Group ID _______________________________________________15 12 Replacing batteries in the transmitters _______________17 12.1 Replacing batteries in Sesam K3 ____________________________17 13 Error codes, Sesam 800 RX DIN _____________________18 14 Measure for Sesam 800 RX DIN _____________________19 Introduction 3 (16) Sesam 800 K3 RXDIN USA ManualDocument-ID: 946415-000 Version: A0Author: SH 1 Introduction This manual only covers the installation of the Sesam radio remote door opening system. The Sesam System is not a complete door opening system: it provides only the set of outputs that are driven according to the actions performed by the operator of the transmitter. The way the set of outputs is used for controlling the doors depends on the specific installation and is outside the scope of the Sesam. The approvals that the Sesam radio remote control system is only valid for the system itself. The complete remote control system, where the controlled object is one part, has to be tested and approved according to the standards/norms that are ap- plicable and specific to the controlled object. It is not the responsibility of Åkerströms Björbo. 2 Scope The following guide must be used when installing Åkerströms Sesam door opening system to ensure secure, safe operation. The installation must be car- ried out by a certified electrician. FCC Part 15 and Industry Canada RSS Notice This device complies with Part 15 of the FCC Rules and Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference that may cause undesired operation of the device RSS FCC Partie 15 et du Canada Avis à Industrie Cet appareil est conforme à la Partie 15 des règlements de la FCC et Industrie Canada exempts de licence standard RSS (s). Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne peut pas provoquer d'interférences et (2) cet appareil doit accepter toute interférence pouvant causer un mauvais fonctionnement du dispositif WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY ÅKERSTRÖMS BJÖRBO CORPORATION COULD VOID THE USER`S AUTHORITY TO OPERATE THE EQUIPMENT. Scope 4 (16) Sesam 800 K3 RXDIN USA ManualDocument-ID: 946415-000 Version: A0Author: SH 2.1 Safety Considerations 1. The safety guidelines in this manual are not intended to replace any rules or regulations or any applicable local, state, or federal governing laws. The following information is intended to be used in conjunction with other rules or regulations already in existence. It is important to read all safety information before operating any wireless radio remote control system. 2. Only properly trained persons designated by management should be permitted to operate wireless radio controlled equipment. Wireless radio controlled equipment should not be operated by any person who cannot read or understand signs, notices and operating instructions that pertain to the equipment. 3. Wireless radio controlled equipment should not be operated by any person with insufficient eyesight or hearing or by any person who may be suffer- ing from a disorder or illness or is taking any medication that may impair judgment or the ability to operate equipment. 4. Ensure transmitter batteries are in good condition and power for receiver is correct. Installation and maintenance should be done only while the con- trolled equipment main power and receiver’s power are off and locked out to prevent electrical shock. 5. Any person operating wireless radio controlled equipment should possess the following knowledge and/or skills: • Knowledge of hazards particular to the equipment being operated • Knowledge of safety rules for radio controlled equipment • Knowledge of the radio transmitter • Proper clearance of all moving parts on the radio controlled equipment • Proper storage space for radio control transmitter when not in use • Transferring radio control transmitter to another person • Reporting unsafe or unusual operating conditions • Remote controlled equipment capacity and limitations • Procedures for testing controlled equipment 6. The Sesam remote control system is recommended for the remote opera- tion of door opening equipment only. This unit is not intended for use on material handling, people moving or any other critical application. Scope 5 (16) Sesam 800 K3 RXDIN USA ManualDocument-ID: 946415-000 Version: A0Author: SH 7. Radio controlled operators should always position themselves for the best view of the equipment they are controlling. The equipment should n…

Text truncated - open the document above for the full version.

Class EXTERNAL Product/Project SESAM 800 Subject Document Id. Revision Label for 946416-000, S800K3 FCC 946429-000 B0 Approved by Category Date Page 2012-04-30 1 (2) ÅKERSTRÖMS BJÖRBO AB, SE-780 45 BJÖRBO, Sweden Phone +46 241 25 000, Fax +46 241 232 90 Vat No SE556153982501 Registrated office BJÖRBO www.akerstroms.se Specification of label: Durability according to SS-EN 60950. The label shall remain clear and easy-to-read during normal operation and usage. The label shall withstand normal cleaning with specified cleaning agent It shall be impossible to remove the label from the unit without permanently damaging the label. The adhesive on the label shall not affect plastic materials in a negative way. The label color shall be white. The text color shall be black. Content: Company logotype: Black: 100% black Grey scale: 30% black Text: Fonts: Arial Narrow Textsize: 1,7- 2.00 mm Power supply: 6V Type: S800K3 Freq: 926,5 MHz Åkerströms art.no: Art No: 946416-000 Web address: www.akerstroms.se IP-class IP65 FCC ID: FCC ID: OG4-K3 Country of origin: Made in China Class EXTERNAL Product/Project SESAM 800 Subject Document Id. Revision Label for 946416-000, S800K3 FCC 946429-000 B0 Approved by Category Date Page 2012-04-30 2 (2) ÅKERSTRÖMS BJÖRBO AB, SE-780 45 BJÖRBO, Sweden Phone +46 241 25 000, Fax +46 241 232 90 Vat No SE556153982501 Registrated office BJÖRBO www.akerstroms.se Example Size: Height: 25mm + 0-0,1mm Width: 20mm + 0-0,1mm Example in scale 1:1 (approx) Position Art.no: 946416-000 Type: S800K3 Power Supply: 6V Freq: 926,5 MHz FCC ID: OG4-K3 www.akerstroms.se Made in China IP65

Date Reference Page REPORT 2012-04-18 FX205878-F15C1 1 (7) FCC ID: OG4-K3 Appendix 8 SP Technical Research Institute of Sweden Photos The test set-up during all the radiated tests can be seen in the pictures below. EUT in X-axis, 30-1000 MHz: EUT in X-axis, 30-1000 MHz: Date Reference Page REPORT 2012-04-18 FX205878-F15C1 2 (7) FCC ID: OG4-K3 Appendix 8 SP Technical Research Institute of Sweden EUT in Y-axis, 30-1000 MHz: EUT in Y-axis, 30-1000 MHz: Date Reference Page REPORT 2012-04-18 FX205878-F15C1 3 (7) FCC ID: OG4-K3 Appendix 8 SP Technical Research Institute of Sweden EUT in Z-axis, 30-1000 MHz: EUT in Z-axis, 30-1000 MHz: Date Reference Page REPORT 2012-04-18 FX205878-F15C1 4 (7) FCC ID: OG4-K3 Appendix 8 SP Technical Research Institute of Sweden EUT in X-axis, 1-10 GHz: EUT in Z-axis, 1-10 GHz:
