OG4400T5Remote Control Transmitter Module

Request for Confidentiality 19 April 2005 EMCCert DR. RAŠEK - Certification Institute - Boelwiese 5 D-91320 Ebermannstadt RE: Certification Application FCC ID: OG4400T5 Please be advised that the following information is to be held confidential on behalf of Akerstroms Bjorbo AB: • Schematics • Parts List • Block Diagram • Technical Description The application contains technical information which Akerstroms Bjorbo AB deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

FCC ID OG4400T5 FCC ID OG4400T5 FCC ID OG4400T5

FCC ID OG4400T5 FCC ID OG4400T5 FCC ID OG4400T5

EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 1 of 46 Pages Straubing, April 11, 2005 T E S T - R E P O R T No. 56502-050025 for 400T5 Remote Control Transmitter Module Applicant: Akerstrˆms Bjˆrbo AB Purpose of testing: To show compliance with FCC Code of Federal Regulations, CFR 47, Part 90, Section 90.217 FCC Code of Federal Regulations, CFR 47, Part 2, Subpart J Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 2 of 46 Pages Table of Contents 1. Administrative Data ..............................................................................................3 2. Identification of Test Laboratory ...........................................................................4 3. Summary of Test Results.....................................................................................5 4. Operation Mode of EUT .......................................................................................6 5. Configuration of EUT and Peripheral Devices ......................................................7 6. Measuring Methods..............................................................................................8 6.1. Maximum Transmitter Power (CFR47 ß90.217, ß2.1046 ).............................8 6.2. Frequency tolerance (CFR47 ß90.217, ß2.1055 ) .......................................10 6.3. Occupied Bandwidth (CFR47 ß90.217, ß2.1049) ........................................12 6.4. Unwanted Emission (CFR47 ß90.217, ß2.1051)..........................................13 7. Photographs of Test Setups...............................................................................15 8. Equipment List ...................................................................................................18 9. Referenced Regulations.....................................................................................20 10. List of Measurements.........................................................................................21 11. Test Results .......................................................................................................22 12. Additional Information supplementary to the Test Report ...................................45 12.1. Calculation of the necessary bandwidth (Section 2.202b) ...........................45 12.2. Additional Information..................................................................................46 EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 3 of 46 Pages 1. Administrative Data Equipment Under Test (EUT): 400T5 Serial number(s): --- Type of equipment: Remote Control Transmitter Module Type of emission: 9K80F1D Parts/accessories: --- FCC-ID: OG4400T5 Applicant: (full address) Akerstrˆms Bjˆrbo AB 78045 Bjˆrbo, SWEDEN Contract identification: --- Contact person: Mr. Bernt Eriksson Manufacturer: Akerstrˆms Bjˆrbo AB Receipt of EUT: February 2005 Dates of test: February 2005 Note: --- Responsible for testing: Thomas Eberl Responsible for test report: Thomas Eberl EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 4 of 46 Pages 2. Identification of Test Laboratory Test Laboratory: Senton GmbH EMI/EMC Test Center (full address): Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Contact person: Mr. Johann Roidt Communication: Telephone (+49) 0 94 21 / 55 22-0 Fax (+49) 0 94 21 / 55 22-99 eMail: [email protected] FCC registration number: 90926 EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 5 of 46 Pages 3. Summary of Test Results The tested sample complies with the requirements set forth in the The Code of Federal Regulations 47, Part 90, Section 90.217 and The Code of Federal Regulations 47 Part 2, Subpart J. of the Federal Communication Commission (FCC) Johann Roidt Thomas Eberl Laboratory Manager Test Engineer EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 6 of 46 Pages 4. Operation Mode of EUT • transmitting continuously 1 • with battery supply nominal 7.5 V DC 2 • operating with f = 406 MHz - 469 MHz Tested positions of EUT: P1: EUT in vertical position - antenna right up 1 Modulation as indicated on appropriate test record 2 For conducted measurements replaced by external DC supply EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 7 of 46 Pages 5. Configuration of EUT and Peripheral Devices EUT is configured as stand-alone device Configuration of cables of EUT Not applicable Configuration of peripheral devices connected to EUT Not applicable EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 8 of 46 Pages 6. Measuring Methods 6.1. Maximum Transmitter Power (CFR47 ß90.217, ß2.1046 ) The maximum transmitter power was measured radiated and, if applicable, conducted at antenna connector. EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 9 of 46 Pages 6.1.1. Radiated Maximum Transmitter Power Radiated Maximum Transmitter Power was measured with detector-function of the spectrum analyzer set to positive peak and trace mode max hold: RBW = 100 kHz, VBW = 100 kHz, span = 1 MHz, sweep = 15 s For measurement setup and procedure see section "Unwanted Emission " on Page 13. EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 10 of 46 Pages 6.2. Frequency tolerance (CFR47 ß90.217, ß2.1055 ) 6.2.1. Frequency stability vs. temperature The frequency stability vs. temperature was measured with a spectrum analyzer connected to the antenna connector (conducted measurement) while EUT was operating in transmit mode using the assigned frequency. The trace mode of the spectrum analyzer was s…

Text truncated - open the document above for the full version.

EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 16 of 46 Pages Test setup for radiated unwanted radiation 30 MHz - 5 GHz EMV-Pr ̧fzentrum EMI/EMC-Testcenter FCC-ID: OG4400T5 Test Report No. 56502-050025 Page 17 of 46 Pages Test setup for radiated unwanted radiation 30 MHz - 5 GHz
