DRIVING INSTRUCTION REMOTUS BC7400 USA Variant 1 (variant 2, see page 4) MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 1 (11) TRANSMITTER ON Pull out the stop button and the transmitter is switched on. The operation indicator lamp (STATUS) starts blinking and the transmitter is on. MAIN CONTACTOR ON Then the transmitter is on press the Å . This activates the Main Contactor in the receiver (the Main Contactor of the telpher) and the telpher is ready for operation. NORMAL RUN The transmitter is designed with two pushbuttons for UP/DOWN and two for FORWARD/BACKWARD. Each button is divided into 2 steps (a perceptible resistance), which facilitates the running at a certain speed. The first speed is obtained when the pushbutton is half compressed and the second speed is obtained when the pushbutton is totally compressed. All the motions can be run simultaneously and the motions stop when the pushbutton is released, otherwise make an QUICK STOP. MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 2 (11) MICRO RUN Push in the button for MICRO and the diode lamp for micro lights. The micro-run movements are only at lowest speed in micro-run mode irrespective of the compression of the pushbuttons. The buttons are looped so that only one movement can be operated at a time. The other functions are work as in ordinary runs. PUSHBUTTON 1 AND 2 The diode lamps indicate which function that has been chosen. The pushbutton function can be momentary (the function will be active as long as the pushbutton is activated) or maintain (the function is active when the diode lamp lights). See the installation guide how to choose the function of the pushbuttons. SIGNAL A signal can be emitted at any time during the run and is obtained as long as the push button switch is depressed. Continue page 6 MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 3 (11) Variant 2 MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 4 (11) TRANSMITTER ON Pull out the stop button and the transmitter is switched on. The operation indicator lamp (STATUS) starts blinking and the transmitter is on. MAIN CONTACTOR ON Then the transmitter is on press Å, button 7. This activates the Main Contactor in the receiver and it is ready for operation. NB! The Main Contactor On will be activated without a press on Å, button 7, if such choice of program is made in the receiver. NORMAL RUN The transmitter is designed with pushbuttons for function 1-8. All the motions can be run simultaneously and the motions stop when the pushbutton is released, otherwise make an QUICK STOP. MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 5 (11) QUICK STOP Depress the STOP button for QUICK STOP. AUTOMATIC SWITCH OFF FUNCTION The indicator lamp for operation goes out and the Main Contactor is de-energized. For renewed activation of the Main contactor restart is required, press the stop button, pull it out again and press Å. It is not necessary to press button Å if such choice of program is made in the receiver. When the battery voltage is to low, that also causes automatic switch-off. TRANSMITTER OFF MAIN CONTACTOR OFF Depress the STOP button, which switches off the transmitter. At the same time the Main Contactor is deactivated (the Main Contactor of the telpher cuts out). The operation indicator lamp goes out. MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 6 (11) RUN DOWN BATTERY The transmitter is equipped with an indicator lamp for battery status (STATUS). The lamp blinks slowly when the battery voltage is normal, but starts to blink rapidly when it falls. When the indicator lamp has started blinking rapidly the transmitter can be operated for approx. 10 min. before the voltage is so low that the transmitter switches off automatically. CHARGING INSTRUCTIONS • The transmitter should be set on charge as often as possible. • The battery has got power for 10 hours continuous operation. • Charging time 3 hours (quick-charge) there upon automatically changes to maintenance charging which does not need supervising. • The transmitter has an indicator lamp (CHARGE) which lights when the battery is charging. When the charging is ready, the lamp goes out. • A WELL MAINTAINED BATTERY IS NECESSARY FOR FAULTLESS OPERATION. • WATCH THE ACCUMULATED CHARGE AND CHARGING CAREFULLY. • THE BATTERY DID NOT BE CHARGED IF ITS TEMPERATURE IS LOWER THAN ±0°C OR HIGHER THAN +45°C. MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 7 (11) DISCHARGED BATTERY. A Li-Ion battery is environment conformed, but as usually, all batteries shall be handed back for recycling. When the battery will be changed, the used Li-Ion-battery shall be returned to the distributor, where a new battery is to be bought. Just to make sure that a proper battery will be required. An alternative is to directly dispose of the battery for recycling. Old batteries shall be returned for recycling. MANUAL BC7400 No. 926137-000 USA Version: A0 Approved by: HH Page 8 (11) ! INSTRUCTIONS FOR CRANE OPERATORS These instructions have to be followed. Marked 1. Check that the radio transmitter operates on the crane, which you are going to drive (ex. give a signal). Check the function of the radio transmitter. 2. Check that no unauthorized person is on or at the crane when you start to drive it. The blocking device at entry of the crane should be closed. 3. Check the position of the symbols for driving direction (crane-trolley travel). 4. At the beginning of each shift the crane operator is to test brake, limit-switches and emergency stop function. 5. The crane operator is when driving the crane to walk or stand at a suitable distance from the crane hoist in order to have adequate overview of the operation. 6. It is prohibited to move the crane load over oneself or other people. Signal in order to warn others. 7. Avoid driving into end stops since equipment and goods can be damaged. 8. Check your own free passageway in or…

Text truncated - open the document above for the full version.

Request for Confidentiality 06 April 2004 PHOENIX TEST-LAB GmbH Königswinkel 10 D32825 Blomberg Germany RE: Certification Application FCC ID: OG4BC7418 Please be advised that the following information is to be held confidential on behalf of Akerstroms Bjorbo AB: • Schematics • Parts Lists • Block Diagram The application contains technical information which Akerstroms Bjorbo AB deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

FCC ID: OG4BC7418 EUT FCC ID: OG4BC7418 EUT side view FCC ID: OG4BC7418 EUT top view FCC ID: OG4BC7418 EUT bottom view FCC ID: OG4BC7418 EUT side view

FCC ID: OG4BC7418 EUT disassambled FCC ID: OG4BC7418 PCB bottom view FCC ID: OG4BC7418 PCB top view FCC ID: OG4BC7418 RF module disassembled FCC ID: OG4BC7418 PCB RF module bottom view FCC ID: OG4BC7418 PCB RF module top view

780 45 Björbo • Tel 0241-250 00 • Fax 0241-232 90 • www.akerstroms.com • Email [email protected] The RemotusThe Remotus The RemotusThe Remotus The Remotus Mini systemMini system Mini systemMini system Mini system The Mini system is preprogrammed to enable short delivery times. Mini is userfriendly and is aimed as a control- ler for telphers and small machinerys. The system consists of a small pushbutton transmitter, a receiver and a charger. Key FeaturesKey Features Key FeaturesKey Features Key Features TransmitterTransmitter TransmitterTransmitter Transmitter Small and rugged handy transmitter with 4 doubleaction and 4 singleaction pushbuttons. LED indications for Battery, status and selected functions. An accompained attach- ment-clips may be mounted on the transmitter. Inbuilt self- diagnostic continously checks important functions. Dimensions 142x68x26 mm ReceiverReceiver ReceiverReceiver Receiver 8 output relays with changeover contacts. Different pre- programmed functions may be selected by a rotary switch. Frequency synthesized radio with selectable frequencies in the 433 MHz band. Dual channel approach (two separate microprocessors) enables high safety. An antenna is mounted directly on the receiver. IP 65 Output data250VAC; 6A resistive load Power supply Max 12 VA Voltage supply 24/48/115/230 +15 –20% VAC alt. 15-35 VDC Dimensions250x150x80 mm Battery/ChargerBattery/Charger Battery/ChargerBattery/Charger Battery/Charger The transmitter has an inbuilt Li-Ion-battery which gives approx. 10 hours of continous operation. The battery is charged via an inbuilt charger. An AC-adapter is included for battery-charging. OtherOther OtherOther Other Two signs, ”Radio-controlled crane” and ”When working on the crane...” are included in each system delivery. Installation- instructions and usermanual are included to enable a flexible assembly and easily understood handling. As options an inbuilt siren or a relayboard for an external siren, is available. A cassette for the transmitter is also available. The transmitter built in battery may be charged when the transmitter is put in the cassette.

EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 1 of 26 Pages Straubing, 30 March 2004 T E S T - R E P O R T No. 56502-40186 for Remotus BC 7418 UHF Handheld Transmitter Applicant: Akerströms Björbo AB Test Specification: FCC Code of Federal Regulations, Part 15 Subpart C, Section 15.231 Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 2 of 26 Pages Table of Contents 1. Administrative Data....................................................................................3 2. Identification of Test Laboratory.................................................................4 3. Operation Mode of EUT.............................................................................6 4. Configuration..............................................................................................7 5. Measuring Methods...................................................................................8 5.1. Conducted powerline emissions..........................................................9 5.2. Field Strength of Emissions, Prescans in a fully-anechoic Room.................................................................................................10 5.3. Radiated Emission Measurement at Open Area Test Site................12 6. Photographs Taken During Testing.........................................................13 7. List of Measurements...............................................................................20 8. Referenced Regulations..........................................................................25 Charts taken during testing...............................................................................26 EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 3 of 26 Pages 1. Administrative Data Test item (EUT) Type designation Remotus BC 7418 Serial number(s): 92 6116-0864 Type of equipment: UHF Handheld Transmitter Parts/accessories: FCC-ID: OG4BC7418 Technical data Frequency range 433.050 MHz - 434.790 MHz Operational frequency 434.650 MHz Type of modulation 10K0F1D Pulse frequency N/A Pulse width N/A Antenna Integrated Power supply Battery 3.7 V Applicant: (full address) Akerströms Björbo AB S-780 45 Björbo Contract identification: --- Contact person: Mr. Bernt Eriksson Manufacturer: Akerströms Björbo AB Application details Receipt of EUT: 22.March 2004 Date of test: 22. - 26 March 2004 Note: Responsible for testing: Thomas Eberl Responsible for test report: Thomas Eberl EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 4 of 26 Pages 2. Identification of Test Laboratory DETAILS OF THE TEST LABORATORY COMPANY NAME: Senton GmbH EMI/EMC Test Center ADDRESS: Aeussere Fruehlingsstrasse 45 D-94315 Straubing Germany LABORATORY ACCREDITATION: DAR-Registration No. TTI-P-G 062/94-01 FCC TEST SITE LISTING 90926 INDUSTRY CANADA TEST SITE REGISTRATION IC 3050 NAME FOR CONTACT PURPOSES: Mr. Johann Roidt TELEPHONE: (+49) (0)9421 5522-0 FAX: (+49) (0)9421 5522-99 PERSONNEL INVOLVED IN THIS TEST REPORT LABORATORY MANAGER: Mr. Johann Roidt RESPONSIBLE FOR TESTING: Mr. Thomas Eberl RESPONSIBLE FOR TEST REPORT: Mr. Thomas Eberl EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 5 of 26 Pages SUMMARY OF TEST RESULTS The tested sample complies with the requirements set forth in the FCC Code of Federal Regulations Part 15, Subpart C, Section 15.231 EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 6 of 26 Pages 3. Operation Mode of EUT While one button is pressed, the transmitter continuously sends the corresponding datagram. When the button is released, the transmitter stops working instantly. EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 7 of 26 Pages 4. Configuration Configuration of the EUT Not applicable Cables connected to the EUT Not applicable Peripheral devices connected to the EUT Not applicable EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 8 of 26 Pages 5. Measuring Methods EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 9 of 26 Pages 5.1. Conducted powerline emissions Rules and Specifications: Sections 15.107 & 15.207 Guide: CISPR 22 Measurement Procedure: In general conducted emission tests in the frequency range 0.15 - 30 MHz are required to be performed with quasi-peak and average detector. To simplify testing the following procedure is used: First the whole spectrum of emission caused by equipment under test (EUT) is recorded with detector set to peak. After that all emission levels having less margin than 20 dB to or exceeding the appropriate limit (in general average limit is 10 dB lower than quasi-peak limit) are retested with detector set to quasi-peak. If average limit is kept no additional scan with average detector is necessary. In cases of emission levels between quasi-peak and average limit an additional scan with detector set to average has to be recorded. Shielded Room LISN EUT Wooden Table EMI-Receiver Test instruments used: No. Type Model Serial Number Manufacturer 01 EMI Receiver ESHS 10 860043/016 Rohde & Schwarz 02 LISN ESH3-Z5 862770/021 Rohde & Schwarz 03 LISN ESH-3-Z5 830952/025 Rohde & Schwarz 04 Shielded Room No. 4 --- 3FD-100 544 Euroshield EMV-PrüfzentrumEMI/EMC-Testcenter Report Form for Testing to FCC Part 15 Test Report No.: 56502-40186 Page 10 of 26 Pages 5.2. Field Strength of Emissions, Prescans in a fully-anechoic room (30 MHz – 1 G…
