ÅKERSTRÖMS BJÖRBO AB, S-78045 BJÖRBO, SwedenPhone +46 241 25000Fax +46 241 23290 Fax service dept +46 241 25090Vat No SE556153982501Säte/Registered office BJÖRBO Basic requirements for the owners Warning Do not make changes on the devices. Violation will invalidate interference emission certification (FCC, RSS, CE), and the manufacturer’s warranty. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer Sesam 500 – Door opening system SESAM 500 has been developed to meet the markets requirements for an attractively priced, easily operated and powerful door opening system. SESAM 500 is flexible and simple in operation, and it is based on modern digital radio technology. The transmitter is available in four versions. SESAM 501 is a small hand-held transmitter with one function. SESAM 503 is technically identical to SESAM 501, but has three functions. SESAM 512 is a hand-held or vehicle-mounted transmitter with facilities for communication with up to twelwe receivers. SESAM 599 has the same facilities as SESAM 512, but can communicate with up to 999 receivers. The SESAM 599 is also provided with a display. The system includes receivers with one or three output relays. Sesam 501 Sesam 503 Sesam 512 Sesam 599 Receiver Receiver Plug-in model TECHNICAL DESCRIPTION SESAM 500 Type of equipment: Transmitters Sesam 501, Sesam 503, Sesam 512, Sesam 599. Receivers Sesam R1 - R5 Characteristics of the equipment Frequency band: ISM-band class 1, 433,92 MHz Type of modulation: ASK, 1K20A1D Output power: 74.0 dBμV/m@ 3m test distance Operating temperature range: -25ºC – +55ºC Sesam 501 Number of functions: 1 Power source: 9V battery Current: 25 mA Size: 100 x 60 x 25 mm Sesam 503 Number of functions: 3 Power source: 9V battery Current: 25 mA Size: 100 x 60 x 25 mm Sesam 512 Number of functions: 3 Number of codes: 12 Power source: 9V battery or external source Current: 25 mA Size: 142 x 68 x 26 mm Sesam 599 Number of functions: 3 Number of codes: 12 Power source: 9V battery or external source Current: 25 mA Size: 142 x 68 x 26 mm Sesam R1 – R5 Number of functions: 1 or 3 Sensitivity: better than –95 dBm Relay load: max 400 VAC, 6 A, 1500 W, resistive load Power source: 230 VAC, or 24 VAC or 12 – 24 VDC Size: 152 x 102 x 42 mm or plug-in model 80 x 72 x 35 mm ÅKERSTRÖMS BJÖRBO AB Tel +46 (0)241 - 25000. Telefax +46 (0)241 - 23290 780 45 Björbo www-service: htt p:// www.akerstroms.se Sweden e-mail: [email protected] We reserve the ri ght to alter t echnical data without notice

FCC-ID: OG4S500LT EMV-PrüfzentrumEMI/EMC-Testcenter Top of unit - Sesam 599 FCC-ID: OG4S500LT EMV-PrüfzentrumEMI/EMC-Testcenter Rear of unit - Sesam 599

FCC-ID: OG4S500LT EMV-PrüfzentrumEMI/EMC-Testcenter Label or identifying mark - Sesam 599

FCC-ID: OG4S500LT EMV-PrüfzentrumEMI/EMC-Testcenter Top view - printed board - Sesam 599 FCC-ID: OG4S500LT EMV-PrüfzentrumEMI/EMC-Testcenter Bottom view - printed board - Sesam 599
