July 14, 1999 Professional installation of No Wires Needed 1100 series products to meet FCC 15.203 requirements. Product /Model connector description The No Wires Needed (NWN) 1100 products are in two hardware forms. One is the PC card, which is a PCMCIA type II card (OGD10330209). It has an integrated antenna and an external antenna connector utilizing a unique MMX connector. This unique coupling meets the FCC 15.203 requirements and therefore does not need professional installation. The second hardware form is used for the indoor access point and station adapter, and the outdoor wireless bridges (OGD10310308). This device uses a custom made SMA type connector which meets the FCC 15.203 requirements for unique coupling. The antennas used for the indoor models use this special connector. The antennas used for the outdoor models include a special; SMA to standard N type adapter cable. These antenna kits are not available to the general public. The users guide for the product explicitly states that professional installation is required for these antennas and that only the antenna certified with the products can be used. The statement below is provided in the user guide for all the NWN 1100 products, except for the PCMCIA adapter. Professional Installer Statement from the users guide, section 2 “Warning: It is the responsibility of the professional installer to ensure that when using the outdoor antenna kits in the United States (or where FCC rules apply), only these antennas shown in the table above are used. The use of any antenna other than those listed is expressly forbidden in accordance with the FCC rules CFR47 part 15.204. Note: Detached antennas, whether installed indoors or out, should be installed ONLY by experienced antenna installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void the No Wires Needed Product Warranty and may expose the end user to legal and financial liabilities. No Wires Needed and its resellers or distributors are not liable for injury, damage or violation of government regulations associated with the installation of detached antennas.”

Declaration of Conformity (DoC) October 5, 1999 No Wires Needed declares that its Swallow product identified under the FCC Certification number OGD10330209 has been tested as a Class B device, to comply with FCC standards for Home and Office use. Due to the small size of the device the following statement will be inserted into the user manual: “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” Peter Murray General Manager No Wires Needed USA Inc. PO Box 2368 Westfield, New Jersey 07091-2368 Telephone: 908-232-9054

November 3, 1999 No Wires Needed BV 3 – 5a Jan Steenlaan 3723 BS Bilthoven The Netherlands Reference:FCC Pending Application EA94818 OGD10330209 PCMCIA Swallow 1100 Gentlemen: No Wires Needed BV wish to change the RF power originally stated as 18 dBm to match current production with measured RF output of 15 mW. Please amend the Grant documents accordingly. Regards Peter Murray General Manager No Wires Needed USA Inc. Tel: 908-232-9054 E-Mail: [email protected]

No Wires Needed 3 – 5 Jan Steenlaan 3723 BS, Bilthoven The Netherlands 14 July, 1999 FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Reference: Request for Confidentiality for Exhibits Submitted with an Application for Certification. Applicant: No Wires Needed BV FCC ID OGD10330209. To whom it may concern: No Wires Needed BV, respectfully requests that the following documents be with-held from public inspection, under the provisions of §0.457 of the FCC rules: Schematics, Block Diagrams, and Technical description This document has been physically separated from the rest of the application. The information contained in the schematics, block diagrams and technical description is required as part of the certification process. Disclosure of this information to the general public would reveal trade secrets and design concepts that are proprietary to No Wires Needed BV. For this reason, we respectfully request a Grant of Confidentiality be issued for the items listed above. If you have any questions, or require further information, please contact the applicant. Sincerely, Peter Murray Tel: 908-232-9054 e-mail: [email protected]
