OGJ-DA2800SPLIT-DECODED ACCESS CONTROLLER

SPLIT-DECODED CONTROLLER FOR DK-2800 SECURITY KEYP ADS DA -2800 & DA-2801 Installation & Operation Manual FOR ELECTRIC LOCK , INTER-LOCK AND SECURITY SYSTEM INSTALLATIONS VERSION: 10/2010 AEI PROTECT- ON SYSTEMS LIMITED www.apo-hk.com RoHS Compliance FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. TABLE OF CONTENTS INTRODUCTION FEATURES SPECIFICATIONS PACKAGE CONTENTS THE SPLIT-DECODED CONTROLLER UNIT (Figure 1) THE MAIN CIRCUIT BOARD OF THE CONTROLLER --- (Figure 2) INSTALLATION Precautions Split-Decoded Mode -- (For DA-2800 & DA-2801) The Necessary Connections For Split-Decoded The Function Mode Jumper Setting For Split-Decoded -- (DA-2800 Only) The Link-Up Jumper & Link-Up Code Acquisition The Function Mode Jumper -- (Available On DA-2800 Only) CONNECTION TERMINALS The Audible & Visible Signals The Alarm Outputs & Warnings RF Remote Controller -- (DA-2800 Only) Stand Alone Mode -- (DA-2800 Only) APPLICATION EXAMPLES Basic Wirings of A Split-Decoded Door Lock Basic Wirings of An Inter-Lock System Using Two Split-Decoded Keypads APPLICATION HINTS FOR THE AUXILIARY TERMINALS PROGRAMMING FOR FULL FEATURES --- (Supplementary Information) Set System in Programming Mode with The Master Code Direct Access to Programming Mode with The “DAP” Code – 8 0 8 0 Refresh The System with The “Refreshing Code” --- 9 9 9 9 The Default Values of The Keypad FEATURE PROGRAMMING -- KEY IN AND STORE THE DESIRED VALUES Programming Criteria for Codes Record A Master Code Record A Super User PIN Operation And Functions of The Super User PIN Record The Common User PINs for Output 1, 2 & 3 Record-Delete PINs or Cards for Output 1, 2, & 3 Examples – Programming And Operation Visitor Codes (For Output 1 Only) Duress Codes (For Outputs 1, 2 & 3) The Operation And Function of The Duress Code Configuration of The Output Modes for Output 1, 2 And 3 Personal Safety And System Lock-Out 2 .......................................................................................... 4 .............................................................................................. 4 .......................................................................................... 5 ..................................................................................... 5 ............................................................ 6 .................................................6 ............................................................................................ 7 ............................................................................................ 7 ............................................................. 7 ............................................................... 8 .........................................8 .............................................................8 ....................................................9 ................................................................................. 10 ............................................................................ 14 .......................................................................... 14 ................................................................... 15 ..................................................................... 15 ................................................................................. 16 ................................................................ 16 ....................................... 17 ....................................................... 18 ......................................... 21 .................................................... 21 ........................................... 22 .................................................. 23 ....................................................................... 23 ........................................ 24 .......................................................................... 24 .................................................................................. 25 ............................................................................... 25 ............................................................. 26 ......................................................... 26 ............................................................ 27 ............................................................... 28 ........................................................................ 30 .................................................................... 31 ......................................................... 32 .................................................... 33 ................................................................... 33 41 8 0 Door Forced Open Warning & Time FUNCTION MODE / TIME: 0---OFF 1-999 Seconds 80 FUNCTION / TIME # Mode = 0, Door Forced Open Warning OFF 8 1 Propped-up Warning & Time 81 FUNCTION / TIME # Mode = 0, Propped-up Warning OFF 9 0 Egress Delay Warning & Alarm CODE 1 - FUNCTION MODE: 1---Momentary, No warning 2---Momentary, with warning 3---Momentary, with warning + Alarm 4---Hold Contact, No warning 5---Hold Contact, with warning 6---Hold Contact, with warning + Alarm CODE 2 - DELAY TIME: 0---No Delay 1-99 Seconds 90 CODE 1 CODE 2 # Mode = 1 Momentary, No warning TIME = 0 No Delay 9 1 Door Opening Alarm & TIMER ALARM TIME: 0---No Alarm 1-999 Seconds 91 ALARM TIME # Time = 0, No Alarm 9 4 Operation Mode & Wiegand Output MODES OF WIEGAND OUTPUT 0---Stand Alone Keypad -Valid Codes & Cards Only 1---Reader -All Codes & Cards 2---Master Keypad -Valid Codes & Cards only 3---Slave Keypad -Valid Codes & Cards only 94 WIEGAND O/P MODE # Mode = 0 Keyp…

Text truncated - open the document above for the full version.

AEI PROTECT-ON SYSTEMS LTD. September 2, 2012 To: SIEMIC, INC. 775 Montague Expressway Milpitas , CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ AEI Protect-On Systems Limited ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: SPLIT-DECODED ACCESS CONTROLLER Model name: DA-2800, DA-2801 FCC ID: OGJ-DA2800 We affirm that between SIEMIC and __ AEI Protect-On Systems Limited ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: CHIU KWOK HO / GENERAL MANAGER Contact information / address: Flat B, 4/F., Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, N.T., Hong Kong

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 2.0 AEI PROTECT-ON SYSTEMS LTD. August 22, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: OGJ-DA2800 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s signature: Client’s name / title: CHIU KWOK HO / GENERAL MANAGER Contact information / address: Flat B, 4/F., Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, N.T., Hong Kong

FCC Certification label Sample FCC ID: OGJ-DA2800 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC Certification Label Location Sample Label location

Receiver Antenna

Page 1 of 22 FCC ID: OGJ-DA2800 ACCURATE TECHNOLOGY CO. LTD Report No. ATE20120839 APPLICATION CERTIFICATION FCC Part 15B On Behalf of AEI Protect-On Systems Limited SPLIT-DECODED ACCESS CONTROLLER Model No.: DA-2800, DA-2801 FCC ID: OGJ-DA2800 Prepared for : AEI Protect-On Systems Limited Address : Flat B, 4/F., Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, N.T., Hong Kong Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20120839 Date of Test : August 15-26, 2012 Date of Report : August 27, 2012 Page 2 of 22 FCC ID: OGJ-DA2800 ACCURATE TECHNOLOGY CO. LTD Report No. ATE20120839 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Accessory and Auxiliary Equipment ........................................................................................................4 1.3. Description of Test Facility ......................................................................................................................5 1.4. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. OPERATION OF EUT DURING TESTING ................................................................................. 7 3.1. Operating Mode ........................................................................................................................................7 3.2. Configuration and peripherals ..................................................................................................................7 4. TEST PROCEDURES AND RESULTS ......................................................................................... 8 5. CONDUCTED EMISSION FOR FCC PART 15 SECTION 15.107(A) ...................................... 9 5.1. Block Diagram of Test Setup....................................................................................................................9 5.2. The Emission Limit ..................................................................................................................................9 5.3. Configuration of EUT on Measurement .................................................................................................10 5.4. Operating Condition of EUT ..................................................................................................................10 5.5. Test Procedure ........................................................................................................................................10 5.6. Power Line Conducted Emission Measurement Results ........................................................................11 6. RADIATED EMISSION FOR FCC PART 15 SECTION 15.109(A)......................................... 14 6.1. Block Diagram of Test Setup..................................................................................................................14 6.2. The Emission Limit For Section 15.109 (a) ...........................................................................................15 6.3. EUT Configuration on Measurement .....................................................................................................15 6.4. Operating Condition of EUT ..................................................................................................................15 6.5. Test Procedure ........................................................................................................................................16 6.6. The Emission Measurement Result ........................................................................................................17 Page 3 of 22 FCC ID: OGJ-DA2800 ACCURATE TECHNOLOGY CO. LTD Report No. ATE20120839 Test Report Certification Applicant : AEI Protect-On Systems Limited Manufacturer : AEI Protect-On Systems Limited EUT Description : SPLIT-DECODED ACCESS CONTROLLER (A) MODEL NO.: DA-2800, DA-2801 (B) SERIAL NO.: N/A (C) POWER SUPPLY: DC 12-24V Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B ANSI C63.4: 2009 The device described above is tested by ACCURATE TECHNOLOGY CO. LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B limits. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO. LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of ACCURATE TECHNOLOGY CO. LTD. Date of Test : August 15-26, 2012 Prepared by : (Apple Lv, Engineer) Approved & Authorized Signer : (Sean Liu, Manager) Page 4 of 22 FCC ID: OGJ-DA2800 ACCURATE TECHNOLOGY CO. LTD Report No. ATE20120839 1. GENERAL INFORMATION 1.1. Description of Device (EUT) EUT : SPLIT-DECODED ACCESS CONTROLLER Model Number : DA-2800, DA-2801 (Note: These samples are identical, except the appearance is difference. Therefore only model DA-2800 is tested for EMC tests.) Power Supply : DC 12-24V Receiver Frequency : 433.92MHz Applicant : AEI Protect-On Systems Limited Address : Flat B, 4/F., Effort Industrial Building, 2-8 Kung Yip Street, Kwai Chung, N.T., Hong Kong Manufacturer : AEI Protect-On Systems Limited Address : Flat B, …

Text truncated - open the document above for the full version.

Conducted emissions test Radiated emissions test 30MHz- 1GHz Radiated emissions test > 1GHz
