OGK300116620013D-iD Asset Locating Tag

RF Technologies Inc
3D-iD Asset Locating Tag - FCC ID OGK30011662001 - RF Technologies Inc
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Apr 03, 2000
Application Purpose
Original Equipment
Date of Application
Mar 21, 2000
Equipment Note
3D-iD Asset Locating Tag
Frequency Range
5800.00000000 - 5800.00000000
Company
RF Technologies Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC Application for PinPoint – Tag Manual • •• • FCC ID: OGK30011662001 • •• • Report No. EA0440-1 22-Mar-00 P age 1 of 6 ______________________________________________________________________ 7.0Tag Manual: © Copyright 2000, PinPoint Corporation. All rights reserved. 3D-iD Hardware Installation and Maintenance Manual PinPoint Local Positioning Systems. Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means without the express written permission of the PinPoint Corporation. © Copyright 2000, PinPoint Corporation. All rights reserved. #3000-11602-001 Printed in the United States PinPoint and L 3 RF are trademarks of PinPoint Corporation. 3D-iD is registered. All other trademarks are the properties of their respective owners. The devices discussed in this manual comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes and modifications not expressly approved by PinPoint Corporation could void the user’s authority to operate the equipment. 2 PinPoint Local Positioning Systems Part #: 3000-11602-001 TABLE OF CONTENTS About 3D-iD 5 Antenna Installation and Maintenance 7 Warnings 8 Included in the Antenna Package 9 Antenna Placement Tips 10 Mounting the Antenna 11 Positioning the Antenna 12 Technical Specification 13 Cell Controller Installation and Maintenance 15 Warnings 16 Included in the Cell Controller package 16 Cell Controller Placement 17 Mounting the Cell Controller 18 Installing the Cell Controller 19 Maintaining the Cell Controller 21 Technical Specifications 22 Coaxial Cable Installation 23 Warnings 24 Included in the Coaxial Cable package 24 Installing Coaxial Cables 25 Technical Specifications 26 Tag Installation and Maintenance 27 Warnings 28 Included in the Tag Package 29 Mounting Tags - Asset Mount 30 Mounting to a flat surface 30 Mounting to a curved surface 31 Mounting Tags - Personnel Mount 33 Maintaining the Tag 34 Technical Specifications 36 3.Symbols used in this manual This is a warning symbol. This highlights text that concerns safety and other major issues. This is a note symbol. This highlights text that contains information that might not be obvious and deserves attention. This is the warranty symbol. It highlights actions that will void your warranty. FCC Application for PinPoint – Tag Manual • •• • FCC ID: OGK30011662001 • •• • Report No. EA0440-1 22-Mar-00 P age 2 of 6 ______________________________________________________________________ 4 PinPoint Local Positioning Systems About 3D-iD 3D-iD is the world's first Local Positioning System (LPS). The system allows end-users the ability to locate, track, and secure their inventory or valuable assets. The hardware system uses Cell Controllers to continually track PinPoint's tags in real-time. Using high-frequency radio signals, 3D-iD can read Tags at long distances (no line of sight is required) and track their movement within a facility or around its perimeter. For example, a warehouse manager can maximize the efficiency of his fork lift moves by instantly knowing the location of the closest fork lift to the inventory that needs to be moved. The hardware system is based on three components. These are the Tags, the Antennas, and the Cell Controllers. Tags: The 3D-iD Tags are attached to valuable assets, inventory, or personnel. The Tag receives 2.4GHz spread spectrum radio signals from the system's Antennas and responds with a 5.8GHz signal that includes Tag identification data, known as the Tag Serial Number. The Tags are designed around PinPoint's proprietary L 3 RF (Long-Range, Long Life, Low Cost Radio Frequency) technology. As a result, 3D-iD Tags can be read at long ranges compared to conventional RFID (Radio Frequency Identification) systems while exhibiting a long battery life at a reasonable cost. 5.Antennas: The 3D-iD Antennas are mounted components that transmit and receive the radio signals generated by the Cell Controller and the Tags, respectively. They connect to the Cell Controller via special low-loss Coaxial Cables. Cell Controllers: The 3D-iD Cell Controllers coordinate the exchange of radio signals between the Antennas and the Tags. The Cell Controllers generate and send the 2.4GHz to the Tags via the Antennas. As stated above, the Tags receive the signal and transmit it back at 5.8GHz. The Cell Controller receives the retransmitted signal and calculates the time-delay between when the initial (2.4GHz) signal was sent and when the return signal (5.8GHz) was received. Using this information, the exact distance from the Antenna to the Tag can be calculated. 6 PinPoint Local Positioning Systems Antenna Installation and Maintenance 7.Warnings This 3D-iD Antenna is intended for indoor use only. Use of the Antenna outdoors can cause damage to its internal components. Contact your PinPoint sales representative for details regarding outdoor use of the 3D-iD system. Do not mount the Antenna in places that are excessively humid or where it is likely to get wet. When placing your antenna, keep in mind that metallic objects, dense walls, microwave ovens and other obstacles can alter radio signals and limit the Antenna's effectiveness. Contact your certified 3D-iD system integrator for proper Antenna placement. The Antenna must be installed so that there is at least a 6-inch gap between it and any possible contact with people. Failure to install it in this fashion may invalidate the user’s license to operate this product. Changes and modifications not expressly approved by PinPoint Corporation could void the user’s authority to operate the equipment. 8 PinPoint Local Positioning Systems Included in the Antenna Package 1-4 Antenna(s) 1-4 Antenna mount(s), each including: 1 base plate 1 mount post 1 mounting…
