OHKFMT-301
South Pacific Electronics Ltd.
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Sep 06, 1999
- Application Purpose
- Original Equipment
- Date of Application
- May 03, 1999
- Frequency Range
- 27.14500000 - 27.14500000
- Country
- Fiji
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Block Diagram
1 28 2 27 3 26 4 25 5 24 6 23 7 22 8 21 9 20 10 19 11 18 12 17 13 16 14 15 ERIC 47K 470W 220K 1K 10K 9V Battery (6-16V) FMT-301 Circuit Diagram 1Hm 22pF 3pF 33pF33pF 15pF 56pF 50mm DILEC antenna 270pF Buzzer MA73 22pF 15pF Crystal 27.145MHz 33pF 15pF 12 Way Code Switch 220W Push Button LS4148 BC817 BZT55-C6V2 100nF 1nF 12 270pF 1nF
Contact Information
Applicant
Richard Eigner(Managing Director)
Technical Contact
CKC Laboratories IncTracy Phillips
[email protected]209 966-5240
5473A Clouds Rest · Mariposa, California · United States
Non-Technical Contact
CKC Laboratories IncJoyce Walker
[email protected]209 966-5240
Test Firm
CKC Laboratories, Inc.Steve Behm
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Tolerance |
|---|---|---|---|---|
| 1 | 15C | 27.145 MHz - 27.145 MHz | - | % |
