OJYKAG11RBS1130 CDMA Cellular Base Station

6455 Lusk Boulevard, San Diego, CA 92121-2779 (619) 587-1121 6210 Spine Rd. Boulder, CO 80301 Federal Communication Commission February 10, 2003 Reference: FCC ID: OJYKAG11 Request for Confidentiality Pursuant to the Sections 0.457 and 0.459 of the Commission’s Rules, Ericsson Wireless Communications Inc. hereby requests confidentiality of certain aspects of the information accompanying this Application for Type Acceptance as specifically identified below: 1. Technical Description 2. System Block Diagram 3. Schematics 4. Pictures 5. Parts List 6. Tune-up Procedure All items contain trade secrets and other proprietary information not customarily released to the general public. Public disclosure of this information would be harmful to Ericsson Wireless Communications Inc. at this time, and would provide unjustified benefits to our competitors. These materials contain proprietary intellectual property, and Ericsson is on the process of filling for patent protection on many of these items. The request for confidentiality on the Installation Manuel at this time is due to licensee testing which will be conducted after the grant is issued but before the product is released to the general public. Release of the installation instructions before formal release to the general public would expose proprietary information concerning advanced operation functions. Once the product is released to the general public the FCC will be informed the confidentiality treatment of the Installation Manuel may be removed. Ericsson understands that pursuant to Rule 0.457 disclosure of any information contained in this application will not be made before the date of grant. Regards, Keith A. Goshia Senior Regulatory Engineering Manager

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 21, 2003 RE: FCC ID: OJY KAG11 Attention: Keith Goshia I have a few comments on this Application. 1. Your MPE calculations do not appear correct. A 20 watt device with a 16dBi antenna would give a separation distance of 250cm (2.5 meters) not 600cm. Please correct the calculations in the MPE report. xxx 2. Please provide photos of the circuitry under the shields on all boards and board sides. xxx 3. Your internal photos (exhibit 5) state confidential in the file name. However, you have not asked for nor provided evidence that the photos can be held confidential. Unless the confidentiality request included these photos and unless it can be shown why these photos should be confidential, they will not be held confidential. xxx 4. This is a licensed device, please explain why the FCC DoC logo for home use has been applied. xxx 5. Please note that while you have provided a short tuneup procedure, you have not provided the theory of operation or an operational description for the device. Please provide an adequate operational description of the system. xxx 6. Please note, you have not provided a test report for the device. Please provide the necessary test report. Once this is provided, review can resume. xxx Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

1 dward From: [email protected] Sent: Sunday, March 09, 2003 7:22 PM To: [email protected] Cc: [email protected] Subject: MESSAGE attached to OJYKAG11_ATCB000224 by Keith Goshia From: Keith Goshia (Keith Goshia) Hey Dennis, Sorry about the delay I was Out of the Office Friday and half the day today and half the day tomorrow. 1. New Test Report with lab name @ ATCB page. 2. Yes TNB. 3. I will get on the tech. pub guys to strip off the appropiate pages, just like last time. 4. New Confindentiality request @ ATCB page. Goshia

73.66 ±0.13 2.900 ±.005 57.15 ±0.13 2.250 ±.005 ERICSSON WIRELESS COMMUNICATIONS INC. 190 89-SVB 154 405/1, REV A ARTWORK (MEDIA N/D), LABEL, RBS 1130, REGULATORY NOTE: DIE-LINES SHOWN IN BLUE. DIE LINES DO NOT PRINT

Supervised By: Thomas J. Funk RD:kg Sub-part 2.1033 (c): Equipment Identification FCC ID: OJYKAG11 Date of Report Thursday, February 06, 2003 OJYKAG11 The applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27 (a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. OJYKAG11 Table of Contents Rule Description 2.1033 List of General Information Required 2.1046 R.F. Power Output 2.1049 Occupied Bandwidth 22.917 Emission Requirements 2.1051 Spurious Emissions at Antenna Terminals 22.917 (e) 2.1053 Field Strength of Spurious Radiation 2.1055 Frequency Stability - Temperature & Voltage Variation 2.202 (g) Necessary Bandwidth and Emission Bandwidth 2.906 Testimonial & Statement of Certification Radio Frequency Radiation Exposure Limits Exhibits: Appendix: Page OJYKAG11 List of General Information Required for Type Acceptance In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to Part 22 sub-part H Sub-part 2.1033 (c)(1) Name and Address of Applicant: Ericsson Wireless Communications 6210 Spine Rd. Boulder, CO 80301 Vendor: Applicant 2.1033(c)(2): FCC ID: OJYKAG11 2.924 Model No RBS11130 Technical Description: 2.1033(c)(4): Type of Emission: 1M25F9W 2.1033(c)(5) Frequency Range, MHz: 870 MHz 880 MHz 2.1033(c)(6) Power Rating, Watts: 1, 20 Switchable Adjustable x N/A 2.1033(c)(7) Maximum Power Rating, Watts: 20 2.1033(c)(8) Voltages & Currents in all Elements in Final R.F. Stage, Including Final Transistor or Solid State Device: Collector Current, A = per manual Collector Voltage, Vdc = per manual Supply Voltage, Vac = N/A Page OJYKAG11 Exhibits 2.1033 Block Diagram: Please see Attached Exhibit 1 2.1033 Circuit Diagram: Please see Attached Exhibit 2 2.1033 Parts List: Please see Attached Exhibit 3 2.1033 Manual: Please see Attached Exhibit 4 2.1033 Photographs: Please see Attached Exhibits 5 2.1033 Tune-Up Procedure/Alignment Procedure: Please see Attached Exhibit 6 2.1033 Label Information: Please see Attached Exhibit 7 2.1033(c)(14) Test Report: Test Report Follows Page OJYKAG11 Sub-part 2.1033 (c) : Test and Measurement Data All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Volume II; Part 2, Sub-part J, Sections 2.1046, 2.1049, 2.1051, 2.1053, 2.1055 and the following individual Parts: 21 Domestic Public Radio Services 24 Personal Communications Services 22E Broadband PCS __ 22.901 (d) Special Provisions for Alternative Cellular Technologies and and Auxiliary Services X 23 International Fixed Public Radio Communications Service 74 Experimental, Auxiliary & Special Broadcast and Other Program Distribution Services 74H Low Power Auxiliary Stations 80 Stations in the Maritime Service 80.209 (5)(I) Transmitter Frequency Tolerances, 156–162 MHz, Coast Stations 80K Private Coast Stations & Marine Utility Stations 80S Compulsory R/T Installations for Small Passenger Boats 80T Radio Telegraph Installation Required for Vessels on the Great Lakes 80U Radio Telegraph Installation Required by the Bridge–to–Bridge Act 87 Aviation Services 90 Private Land Mobile Radio Services 94 Private Operational–Fixed microwave Services 95 General Mobile Radio Service Page OJYKAG11 General Information 1. Spurious radiation was measured at three (3) meters. 2. The normal modes of modulation are: (a) Voice (b) Wideband Data (c) SAT (d) ST (e) SAT + Voice (f) SAT + DTMF (g) 64-Ary Orthogonal CDMA X (h) Pi/4 DQPSK (i) NAMPS Voice (j) NAMPS DSAT (k) NAMPS ST Page OJYKAG11 Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: Room Temperature = 25 ± 5° C Room Humidity = 20–50% D.C. Supply Voltage, Vdc = - 48VDC Prior to testing, the E.U.T. was tuned up in accordance with the manufacturer’s alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst case measurements. Page OJYKAG11 Supervised By: Thomas J. Funk Name of Test: R.F. Power Output & Occupied Bandwidth Paragraph: 47 CFR 2.1046 & 2.1049 Guide: EIA Standard RS 152B, Paragraph 3.3 Test Condition: Standard Temperature & Humidity Test Equipment: As per Attached Appendix J Measurement Procedures 1. The E.U.T. was connected to a directional coupler and a resistive coaxial attenuator of normal load impedance, and the modulated output pow…
