USER MANUAL ITEM NO.: 0890 / 0895 The Future of Prehistoric 1 INTRODUCTION P. 2 BATTERY INFORMATION P.3 - 4 MIPOSAUR™ OVERVIEW P.5 - 6 GETTING STARTED P. 7 PERSONALITY & MOODS P. 8 CURIOUS MOOD P. 8 EXCITED MOOD P. 9 ANNOYED MOOD P.10 TRACKBALL P.11 TRACKBALL AND APP P.12 Q & A P.13 WARRANTY P14 CONTENTS 2 • 1 x Trackball INTRODUCTION • 1 x Quick Start Guide • 1 x User Manual • 1 x Miposaur™ Thank you for purchasing Miposaur™ by WowWee™! Meet Miposaur™, your new gesture tracking, self-balancing robotic creature! Out of the box, this intelligent robotic creature has an impressive blend of character and technology. Miposaur™ has an incredible evolving intelligence and personailty, and an ability to sense its own surroundings and environment. Interact with Miposaur™ and it will respond in a unique and lifelike way! Take control, interact, and play with Miposaur™ in many ways; through Gesture Sense™ technology, use Beacon Sense™ via the Trackball, or a Bluetooth ® Smart-Ready™ enabled mobile device. Take a few minutes to look through this user manual and get Miposaur™ ready to go. Please note the following when operating Miposaur™: • Do not immerse Miposaur™ or any parts in water or any other form of liquid. • Do not drop, throw, or kick Miposaur™ as this may damage mechanical functions. • Do not allow the robot to roam freely or leave unattended near edges from which Miposaur™ could fall. • Miposaur™ is intended for indoor use only. 3 BATTERY INFORMATION Installing or changing batteries in Miposaur™: 1. To change the batteries, carefully lay Miposaur™ on its side. Miposaur™ requires 4 x “AA” size alkaline batteries (not included). 2. Using a Phillips screwdriver (not included) remove the screws on the battery compartment cover located on the bottom of the robot. 3. Insert the batteries according to the diagram. Ensure that the positive and negative polarities match the illustrations inside the battery compartment. 4. Replace the battery compartment cover and tighten screws using the screwdriver. Do not over-tighten. Installing or changing batteries in the Trackball: 1. Lay the Trackball so that the battery compartment faces upwards. The Trackball requires 4 x “AAA” size alkaline batteries (not included). 2. Using a Phillips screwdriver (not included) remove the screws on the battery compartment cover located on the back of the ball. 3. Insert the batteries according to the diagram. Ensure that the positive and negative polarities match the illustrations inside the battery compartment. 4. Replace the battery compartment cover and tighten screws using the screwdriver. Do not over-tighten. Trackball Battery Diagram/Installation 4 x “AAA” Size Alkaline Batteries Miposaur™ Battery Diagram/Installation 4 x “AA” Size Alkaline Batteries

4 LOW BATTERY INDICATORS: When the batteries grow weak, Miposaur™ will move very slowly and easily fall down while moving or turning. When this occurs, power OFF and replace all batteries. When the batteries for the Trackball are low, the LED Power Indicator will not light up. When this occurs, power OFF and replace all batteries. NOTE: You will know when Miposaur™’s batteries are nearly depleted because it will make a low battery indication sound and then power off. You can also see current battery levels via the Miposaur™ App. IMPORTANT BATTERY INFORMATION: • Use only fresh batteries of the required size and recommended type. • Do not mix old and new batteries, different types of batteries [standard (Carbon-Zinc), Alkaline or rechargeable] or rechargeable batteries of different capacities. • Remove rechargeable batteries from the toy before recharging them. • Rechargeable batteries are only to be charged under adult supervision. • Please respect the correct polarity, (+) and (-). • Do not try to recharge non-rechargeable batteries. • Do not dispose of batteries into fire. • Replace all batteries of the same type/brand at the same time. • The supply terminals are not to be short-circuited. • Remove exhausted batteries from the toy. • Batteries should be replaced by adults. • Remove batteries if the toy is not going to be played with for some time. 5 1. Microphone 2. LED Eyes 3. LED Mood Indicator 4. IR Sensors 5. Arms 6. Speaker 7. ON/OFF Switch 8. Battery Compartment 9. Wheels 10. Heel 11. Tail MIPOSAUR ™ MIPOSAUR ™ OVERVIEW 1 2 3 4 4 5 6 8 7 9 10

14 6 12. Item Selection Wheel 13. Item Selection Window 14. Beacon Sense™ Array 15. ON/OFF Switch 16. LED Power Indicator 17. Battery Compartment TRACKBALL 11 12 17 13 15 16 12 7 BASIC COMMANDS On - Off Front Hold Swipe Left or RightBack Hold Dual HoldTail PullPush Forward Clap x2Clap x3 GETTING STARTED (1) With the batteries inserted, locate the power switch underneath the tail and activate Miposaur™ by toggling it to ON. (2) Place Miposaur™ upright on its wheels on a flat and smooth surface, away from edges and obstacles. On successful balancing, you should feel traction in its wheels. At this point, let go and Miposaur™ will stand on its own with slight movements to correct its balance. Miposaur™ can respond to various hand gestures and clapping and will react differently depending on its current mood (see pg 8-10). After Miposaur™ is balancing, you can use the actions below to interact with Miposaur™. Spin ClockwiseSpin Counter-Clockwise x3x2

8 CommandActionMood Standing Up Swipe Left/RightTurn Left or Right Spin ClockwiseSpin once clockwise Spin C-ClockwiseSpin once counter-clockwise Dual HoldMuffled bark Back HoldFall forwards Front HoldFall backwards Tail PullMake grumpy noises Push ForwardsMake grumpy noises Clap x2Sit backwards Clap x3Roam around Leaning Back Front HoldTrack hand and pant Back HoldPurr Clap x2Get back up Clap x3Get back up and roam around Leaning Forwards Front HoldTrack hand and pant Back HoldPurr Clap x2Get back up Clap x3Get back up and roam around MOODS Depending on how you play and interact with Miposaur™, its personality will develop and mood will change. Various commands will affect Miposaur™ in different ways depending on its current mood and whether Miposaur™ is standing up, leaning back, or leaning forward. Curious Mood (Default) When Miposaur™ is first activated, it will be in its default Curious Mood, indicated by the Blue color on the LED Mood Indicator. In this mood, Miposaur™ is neither annoyed nor excited. Below are the various commands that you can give to Miposaur™ to see its reaction. If you give Miposaur™ enough happy commands, it will start to get into an Excited Mood. However, if you give it too many unhappy commands, Miposaur™ will become upset and be in an Annoyed Mood. NOTE: After imputting a command, the LED Mood Indicator on Miposaur™ will blink. A BLUE blink indicates a command. An ORANGE colored blink indicates a command. A RED colored blink indicates a command. After inputting x5 of the same type of mood commands in a row, Miposaur™ will enter into the corresponding mood. After remaining idle for 30 seconds, Miposaur™ will revert back to its Curious Mood. PERSONALITY & MOODS Curious Mood 9 CommandActionMood Standing Up Swipe Left/RightTurn Left or Right Spin ClockwiseSpin once clockwise Spin C-ClockwiseSpin once counter-clockwise Dual HoldMuffled bark Back HoldFall forwards Front HoldFall backwards Tail PullMakes grumpy noise Push ForwardsMakes grumpy noise Clap x2Sit backwards Clap x3Roam around happily Leaning Back Front HoldTrack hand and bark Back HoldPurr Clap x2Get back up Clap x3Get back up and roam around Leaning Forwards Front HoldTrack hand and bark Back HoldPurr Clap x2Get back up Clap x3Get back up and roam around PERSONALITY & MOODS Excited Mood Excited Mood When Miposaur™ has performed enough positive actions, it will be in an Excited Mood, which is indicated by the Orange colour on the LED Mood Indicator. When Miposaur™ is in this mood, it will make more happy sounds and actions when you give it commands. 10 CommandActionMood Standing Up Swipe Left/RightTurn angrily left or right Spin ClockwiseTurn angrily left or right Spin C-ClockwiseTurn angrily left or right Dual HoldGrowl Back HoldSpin around and growl Front HoldMakes a grumpy noise and sits down Tail PullMakes a grumpy sound Push ForwardsSpin around and growl Clap x2Sit down Clap x3Roam around in an annoyed mood Leaning Back Front HoldTrack hand and growl Back HoldSpin around and growl Clap x2Get back up and growl Clap x3Get back up and roam around in an annoyed mood Swipe x3SPECIAL: Calm Miposaur™ Leaning Forwards Front HoldTrack hand and growl Back HoldSpin around and growl Clap x2Get back up and growl Clap x3Get back up and roam around in an annoyed mood SLEEP MODE After 20 minutes of inactivity, Miposaur™ will enter into Sleep Mode to conserve power. This is indicated by Miposaur™ falling either forwards or backwards, making a sound, and then powering down the LEDs. To exit Sleep Mode, simply flip the power switch on the bottom to the Off position, and then back to the On position. PERSONALITY & MOODS Annoyed Mood Annoyed Mood After receiving too many negative commands, Miposaur™ will start to make more unhappy sounds and actions. This means Miposaur™ is in an Annoyed Mood, and the LED Mood Indicator will become Red. x3 1 2 123 11 TRACKBALL Remember: Miposaur™ will react to whether the Trackball is close to it, whether the Trackball is far away, when you shake the Trackball, or when you clap your hands. Experiment with Miposaur™ to see what the various reactions are! NOTE: If Miposaur™ loses sight of the Trackball for more than a few seconds, or if the Trackball is turned off, it will change back to the Curious Mood. Also, after 5 minutes of inactivity, the Trackball will enter Sleep Mode. Shake the ball, turn the wheel, or power Off/On to awaken it. DANCE (Blue) Check out Miposaur™’s moves! Shake the ball to see Miposaur™ dance and play music! To stop dancing, shake the Trackball again. BALL (Green) Roll the Trackball along the ground and watch Miposaur™ chase and push the ball around! FOOD (Yellow) Use the ball to feed Miposaur™ tasty treats! LEASH (Purple) The Trackball becomes Miposaur™’s leash! Take it for a walk to lead Miposaur™ to new places to play and explore. TEDDY BEAR (Pink) The Trackball becomes Miposaur™’s favorite toy! BEAT BOX (White) When Miposaur™ gets close to the Trackball, it will start to beat box! TRACKBALL Miposaur™ comes with its favorite toy, the Trackball! By activating a different item on the Item Selection Wheel, you can activate different games and activities for you to play with Miposaur™. Miposaur™ even knows when the Trackball is close or far away, and it can even see when the Trackball is being shaken. Using the Trackball (1) With the batteries inserted, locate the power switch on the Trackball and turn it to the ON position. (2) Hold the Trackball as indicated and make sure not to cover the Beacon Sense™ sensors. (3) To activate different items, turn the Item Selection Wheel so that the desired toy icon is shown in the Item Selection Window. The LED Mood Indicator on Miposaur™’s back will change color, indicating a new item activation. See below for the various Items. 12 Trackball - Interaction You can interact with Miposaur™ via the Trackball in multiple ways: Roll Miposaur™ will follow the Trackball Shake (Standing) Miposaur™ will make a sound Shake (Sitting/Lean…

Text truncated - open the document above for the full version.

WowWee Group Limited Suite 301 A-C, Energy Plaza, 92 Granville Road, T.S.T. East, Kowloon, Hong Kong. Tel: (852)2739 5288 Fax: (852)2724 6931 Email: [email protected] Letter of Agency I, an officer of (WowWee Group Limited) do hereby authorize Intertek Testing Services (Terry Chan / Koo Wai IP / Kenneth Wong) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,862. Dated this 18 day December of 2014 By Dennis Tsoi Signature Printed Title Quality Assurance Manager

WowWee Group Limited Suite 301A-C, Energy Plaza, 92 Granville Road, T.S.T. East, Kowloon, Hong Kong. Tel: (852)2739 5288 Fax: (852)2724 6931 Email: [email protected] Re: Request for confidentiality Applicant: WowWee Group Limited FCC ID: [FCC ID: OKP0890] To whom it may concern, Request is hereby submitted by WowWee Group Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: WowWee Group Limited has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [For FCC certification; delete for TCB certification: The fee for confidentiality has been submitted along with the fee for certification.] If you have questions or need further information, please contact the undersigned. Sincerely, __________________________ Dennis Tsoi Quality Assurance Manager WowWee Group Limited Date: May 04, 2015

Grantee Name : WowWee Group Limited FCC ID:OKP0890 Equipment Class : Part 15 Low Power Communication Device Rules Part : 15C, Frequency Range : 2402-2480MHz Date : July 14, 2015 ____________________________________________________________________ To Whom it may concern, It is writing to request to update the test report for FCC ID : OKP0890 granted on 05/04/2015, is now superseded by the test firm - Intertek Testing Services Hong Kong Limited. The following has been changed: Pages Exhibit Description Cause 1 Test report Revised battery type of EUT, from "AAA" to "AA" size Typo 1 Descri Revised battery type of EUT, from "AAA" to "AA" size Typo 1 Analysis report Revised battery type of EUT, from "AAA" to "AA" size Typo Thank you for your attention. ________________________ Koo Wai Ip Assistant Supervisor To : WowWee Group Limited Ref. : ERA-TLW2768 Attn. : Dennis Tsoi Date : July 13, 2015 ____________________________________________________________________ RE. : Report & Verification Revision Notification Intertek Testing Services FCC 15V & ICES-003 Report & Verification No. 15030169HKG-002 & 15030169HKG-003 dated April 17, 2015. Please be informed that all the content recorded in the above captioned report & Verification will be voided. These captioned report & Verification are now superseded by revised Intertek Testing Services report & Verification number 15030169HKG-002R1 & 15030169HKG-003R1 dated July 13, 2015. In Verification & Report No. 15030169HKG-002R1 & 15030169HKG-003R1, The following has been changed: Pages Description All Added trackball information & photo. Thank you for your attention. ________________________ Koo Wai Ip Assistant Supervisor

INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (External)

FCC ID: OKP0890 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. LABEL SIZE: 35mm x 13mm

INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal) INTERTEK TESTING SERVICE Report No.: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Equipment Photographs Model: 0890 (Internal)

Analysis Report Report No.: 15030169HKG-001 The Equipment Under Test (EUT) is a 2.4GHz Bluetooth 4.0 transceiver (Dinosaur), which is operating at 2402MHz to 2480MHz (40 channels with 2MHz channel spacing). The EUT is powered by 6VDC (4 X 1.5V “AA ” batteries). The EUT has a power ON/OFF switch and a LED. When the EUT is switched ON, the LED will be on. Press the correct icon in the App of the Smartphone, the EUT will pair with the relating Smartphone. After pairing, the EUT can be controlled to move forward, backward, left and right by the corresponding Bluetooth device. There is a ball with IR function also. The EUT will chase for the ball when choosing the “Ball Mode” in the App. Antenna Type: Internal integral antenna Antenna Gain: 0dBi Nominal rated field strength: 93.1dBμV/m at 3m Maximum allowed field strength of production tolerance: +3dB / - 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 96.1dBμV/m at 3m in frequency 2.4GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 1.222mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 1.222mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Report No.: 15030169HKG-001R1 i FCC ID: OKP0890 IC: 7091A-0890 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Grantee: WowWee Group Limited Grantee Address: Energy Plaza, Suite 301A-C, 92 Granville Road, T.S.T. East, Kowloon, Hong Kong. Contact Person: Dennis Tsoi Tel: (852) 2739 5288 Fax: (852) 2724 6931 e-mail: [email protected] Manufacturer: WowWee Group Limited Manufacturer Address: Energy Plaza, Suite 301A-C, 92 Granville Road, T.S.T. East, Kowloon, Hong Kong. Brand Name: WowWee FCC Model: 0890 FCC Additional Model: 0891, 0895 IC Model: 0890 Type of EUT: Transceiver Description of EUT: Miposaur (0890) Girl Miposaur (0891) Miposaur w/ Rechargeable Kit (0895) Serial Number: N/A FCC ID / IC: OKP0890 / 7091A-0890 Date of Sample Submitted: March 05, 2015 Date of Test: March 05, 2015 to March 23, 2015 Report No.: 15030169HKG-001R1 Report Date: July 10, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Report No.: 15030169HKG-001R1 ii FCC ID: OKP0890 IC: 7091A-0890 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com SUMMARY OF TEST RESULT TEST SPECIFICATION REFERENCE RESULTS Radiated Emission Radiated Emission on the Bandedge 15.249, 15.209 / RSS-210 A2.9, RSS-210 2.5 Pass Radiated Emission in Restricted Bands 15.205 / RSS-210 2.2 Pass The equipment under test is found to be complying with the following standards: FCC Part 15, October 1, 2013 Edition RSS-210 Issue 8, December 2010 RSS-Gen Issue 4, December 2014 Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. Issuing Laboratory: Intertek Testing Services Hong Kong Limited HKAS has accredited this laboratory (HOKLAS 005 – TEST) under HOKLAS for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. Report No.: 15030169HKG-001R1 iii FCC ID: OKP0890 IC: 7091A-0890 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 General Description.............................................................................................. 1 1.1 Product Description ............................................................................................. 1 1.2 Related Submittal(s) Grants................................................................................. 1 1.3 Test Methodology ................................................................................................ 1 1.4 Test Facility ......................................................................................................... 1 2.0 System Test Configuration ................................................................................... 2 2.1 Justification.......................................................................................................... 2 2.2 EUT Exercising Software..................................................................................... 2 2.3 Special Accessories ............................................................................................ 2 2.4 Measurement Uncertainty.................................................................................... 2 2.5 Support Equipment List and Description.............................................................. 2 3.0 Emission Results .................................................................................................. 3 3.1 Field Strength Calculation.................................................................................... 3 3.2 Radiated Emission Configuration Photograph ..................................................... 4 3.3 Radiated Emission Data ...................................................................................... 4 4.0 Equipment Photographs ....................................................................................... 8 5.0 Product Labelling .................................................................................................. 8 6.0 Technical Specifications ...................................................................................... 8 7.0 Instruction Manual ................................................................................................ 8 8.0 Miscellaneous Information ................................................................................... 9 8.1 Radiated Emission on the Bandedge................................................................... 9 8.2 Discussion of Pulse Desensitization .................................................................. 12 8.3 Calculation of Average Factor............................................................................ 12 8.4 Emissions Test Procedures ......................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICE Report No: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: 0890 INTERTEK TESTING SERVICE Report No: 15030169HKG-001 FCC ID: OKP0890 IC: 7091A-0890 Configuration Photographs Worst-Case Radiated Emissions (Rear View) Model: 0890
