OKUAEW150033-Speed Vintage Bluetooth Turntable

Model:ITVS-550BT 9V 1A 12 W LINE IN JACK Once the tone arm is back to rest position,Unit will immediately back to Bluetooth mode. 7. The system is preset at Bluetooth mode,a beep sound from speaker will inform user to prepare connecting the equipment. Bluetooth connection will be automatcally disconnected if the Turntable tone Arm is picked up and Turntable started to operate. Unit will make a beep sound when connection has been achieved. "This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body."

Shenzhen Junlan Electronic Ltd Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2015-06-19 SUBJECT: FCC Application for OKUAEW15003 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at SHENZHEN EMTEK CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SHENZHEN EMTEK CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Shenzhen Junlan Electronic Ltd Peng Xiao/ safety engineer 2015-06-19

Declaration on model difference 产品差异声明 Page 1 of 1 page We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; the only differences are the appearance, trade name and model no. for trading purpose. 我们在下面签名并据此确认:以下产品型号之间的差异仅为外观，商标和型号不同，其它设计完全相同。 „ FCC ID: OKUAEW15003 Production name 产品名称 Trade name 商标 Model no. 型号 3-Speed Vintage Bluetooth Turntable Innovative Technology AEW-15003-BT, AEW-15003BT, ITVS-550BT ** (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) AEW-1500*BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.), AEW-1*003-BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) Confirmed by . Authorized Signature: 授权人签字 Date: 2015-06-19 日期

Rev 11/20/07 Shenzhen Junlan Electronic Ltd Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: OKUAEW15003 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematic Diagram Circuit Description BlcokDiagram.pdf SchematicDiagram.pdf CircuitDescription.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Shenzhen Junlan Electronic Ltd (signature) Peng Xiao/ safety engineer 2015-06-19

External Photos

12 DC 9V 1000mA FCC ID:OKUAEW15003 M ODE L : I T V S- 500 BT BR M ADE I N C H I N A 2015 I nnovative Technology 1 C hannel D rive Por t W ashington, NY 11050 www.itho m eproducts.co m c M ODE L I T V S- 500 BT BR SERIAL NO: : 注:机身颜色图片供参考 LINE OUT R L 082015 Screen 警告贴纸 WA RN I N G ST ICKE R la b el FCC la b el FCC 贴纸位置 LINE OUT R L DC-9V 1000mA DC-9V 1000mA 后名片贴纸 Rating la b el 丝印颜色：Screen color : Pantone 877C 银色 Pantone 877C Siliver O N OFF L I N E I N PH O N E 45 RPM ADA PT E R 45 转贴纸 45 RPM ADA PT E R 50mm 20mm L OGO S IZE : 51 * 27mm 丝印颜色： Pantone 877C 银色 Screen color : Pantone 877C Siliver 丝印颜色： Screen color : Pantone 877C 银色 Pantone 877C Siliver 3-Speed Vintage Bluetooth Turntable 丝印颜色：Screen color : Pantone 877C 银色 Pantone 877C Siliver 外框印 Pantone 28 6 C Blue 蓝色 流水号贴纸 5mm 51mm 19 . 7 6 mm 19 . 7 6 mm 1 6. 3mm 32.3 mm 6.6 mm 9mm 6. 8mm 4mm Buc k le " N " in Shiny C hro m e f inish 机前上下盖开关门扣用N款光亮电镀银色 E 款注塑黑色提手 Handle "E" in Blac k 机背合页用T款光亮电镀色Hinge " T " in Shiny C hro m e f inish 黑色PVC皮,红色绒布Blac k with Red F elt 内框印 Pantone 877C 银色 150800001

Internal Photos Bluetooth Module Antenna

FCC ID : OKUAEW15003 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the followi ng table shall be used to evaluat e the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission form ula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result BT DSS Channel Freq. (MHz) modulation conducted power (mW) conducted power (dBm) Tune-up power (dBm) Max tune- up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2402 GFSK 0.64 -1.962 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2441 GFSK 0.54 -2.649 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2480 GFSK 0.50 -3.003 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2402 π /4 - DQPSK 0.63 -2.019 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2441 π /4- DQPSK 0.54 -2.691 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2480 π /4- DQPSK 0.50 -3.030 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2402 8DPSK 0.63 -2.016 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2441 8DPSK 0.54 -2.690 -3.5dBm to -1.5dBm -1.5 1 0.00014 1 2480 8DPSK 0.50 -3.017 -3.5dBm to -1.5dBm -1.5 1 0.00014 1

TRF No.:FCC 15.247/A Page 1 of 65 Report No.: ES150522252E Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For 3-Speed Vintage Bluetooth Turntable MODEL No.: AEW-15003-BT, AEW-15003BT, ITVS-550BT ** (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) AEW-1500*BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.), AEW-1*003-BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) FCC ID: OKUAEW15003 Trademark: Innovative Technology REPORT NO.: ES150522252E ISSUE DATE: June 10, 2015 Prepared for Shenzhen Junlan Electronic Ltd No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 65 Report No.: ES150522252E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION............................................................................................................ 4 3 SUMMARY OF TEST RESULT ................................................................................................................ 5 4 TEST METHODOLOGY ........................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ................................................................................................ 7 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 FACILITIES .................................................................................................................................... 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 8 6 TEST SYSTEM UNCERTAINTY .............................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 10 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 10 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................... 11 7.4 SUPPORT EQUIPMENT ............................................................................................................. 12 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ......................................................................... 13 8.1 STANDARD APPLICABLE ........................................................................................................... 13 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................... 13 8.3 EQUAL HOPPING FREQUENCY USE ....................................................................................... 14 8.4 FREQUENCY HOPPING SYSTEM ............................................................................................. 14 9 TEST REQUIREMENTS ........................................................................................................................ 15 9.1 20DB BANDWIDTH ..................................................................................................................... 15 9.2 CARRIER FREQUENCY SEPARATION ..................................................................................... 21 9.3 NUMBER OF HOPPING FREQUENCIES ................................................................................... 27 9.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) ................................................................... 29 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER .................................................................. 32 9.6 CONDUCTED SUPRIOUS EMISSION ....................................................................................... 33 9.7 RADIATED SPURIOUS EMISSION ............................................................................................ 40 9.8 CONDUCTED EMISSION TEST ................................................................................................. 60 9.9 ANTENNA APPLICATION ............................................................................................................ 65 TRF No.:FCC 15.247/A Page 3 of 65 Report No.: ES150522252E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: Shenzhen Junlan Electronic Ltd No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Manufacturer: Shenzhen Junlan Electronic Ltd No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Product Description: 3-Speed Vintage Bluetooth Turntable Model Number: AEW-15003-BT, AEW-15003BT, ITVS-550BT ** (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) AEW-1500*BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.), AEW-1*003-BT (* can be A to Z or 1 to 9 or blank and means unit color or pattern.) (Note: These models are identical in circuitry and electrical, mechanical and physical construction; the only differences are the appearance, trade name and model no. for trading purpose. We prepare AEW-15003-BT for test, and the worst result recorded in the report.) File Number: ES150522252E Date of Test: M…

Text truncated - open the document above for the full version.

Setup photos LINE CONDUCTED EMISSION TEST RADIATED EMISSION TEST
