OKUBS2909Key Finder

EN . . . . . .Page 2 FR . . . . . .Page XXXX ES . . . . .Página XXXX Final size: 75 x 120 mm (2 .95 x 4 .72 in .) User Manual Key Finder, Wallet, Pet, Item Locator - Smart Tracker 100 ft (30 m) Range, 60dB (1M) Guide de l’utilisateur FR Key Finder, Wallet, Pet, Item Locator - FR Key Finder, Wallet, Pet, Item Locator - Smart Tracker 100 ft (30 m) Range, 60dB (1M)Smart Tracker 100 ft (30 m) Range, 60dB (1M) Manual del usuario SP Key Finder, Wallet, Pet, Item Locator - SP Key Finder, Wallet, Pet, Item Locator - Smart Tracker 100 ft (30 m) Range, 60dB (1M)Smart Tracker 100 ft (30 m) Range, 60dB (1M) B0CDLQ7ZL4 Note: template size updated Safety Instructions .....................................3 Package Contents .......................................8 Parts Overview ............................................8 Setting Up the Finder ..............................10 Using the Finder........................................12 Troubleshooting ........................................13 Specifications ............................................14 Legal Notices .............................................15 Feedback and Help ...................................18 Contents Safety Instructions WARNING KEEP OUT OF REACH OF CHILDREN Swallowing can lead to chemical burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion. Seek medical attention immediately. AVERTISSEMENT MAINTENEZ CE PRODUIT HORS DE LA PORTÉE DES ENFANTS Toute ingestion peut entraîner des brûlures chimiques, la perforation des tissus mous, voire la mort. Des brûlures graves peuvent se produire dans les deux heures suivant l'ingestion. Consultez immédiatement un médecin. 4 EN CAUTION Keep the product away from moisture and heat. WARNING INGESTION HAZARD: this product contains a button or coin battery / RISQUE D’INGESTION: Ce produit contient une pile bouton. DEATH or serious injury can occur if ingested/ Des blessures graves, voire la MORT, risquent de survenir en cas d’ingestion. A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours / Une pile bouton avalée peut provoquer des Brûlures Chimiques Internes en moins de 2 heures. KEEP new and used batteries OUT OF REACH OF CHILDREN / Il convient de TENIR piles neuves et usagées HORS DE PORTÉE DES ENFANTS. Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any parts of the body / Consultez immédiatement un médecin en cas de soupçon d’ingestion d’une pile ou d’introduction de celle-ci dans une quelconque partie du corps. 5 EN Button Cell Battery Warnings CAUTION Risk of explosion! »Do not leave the battery in an extremely high temperature environment as this can result in an explosion of the battery. »Disposal of the product into fire or a hot oven, or mechanically crushing or cutting of a battery can result in an explosion of the battery. »Do not subject the battery to extremely low air pressure as this can result in an explosion of the battery. »Before disposal, the battery must be removed from the device. »If the product appears to be bulging or is otherwise malfunctioning (such as excess noise), stop using the product immediately. »If the battery leaks, avoid contact with skin and eyes. Rinse affected areas immediately with plenty of clean water, then consult a doctor. 6 EN »Keep away from children. Seek immediate help if swallowed. CAUTION Contains a coin battery. Hazardous if swallowed. CAUTION A coin battery can cause serious internal chemical burns if swallowed. CAUTION Dispose of used batteries immediately. Keep new and used batteries away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. If the battery compartment does not close securely, stop using the product and keep it away from children. NO OBVIOUS SYMPTOMS: Unfortunately, it is not obvious when a button or coin battery is stuck in a child’s oesophagus (food pipe). There are no specific symptoms associated with this. The child might: »Cough, gag or drool a lot; 7 EN »Appear to have an upset stomach or virus; »Be sick; »Point to their abdomen or throat; »Be tired or lethargic; »Be quieter or more clingy than usual or otherwise “not themselves”; »Lose their appetite or have reduced appetite; and »Not want to eat solid food/ be unable to eat solid food. These sorts of symptoms vary or fluctuate, with the pain increasing and then subsiding. Another possible symptom of button and coin battery ingestion is vomiting fresh (bright red) blood. If the child does this seek immediate medical help. The lack of clear symptoms is why it is important to be vigilant with ”flat” or spare button or coin batteries in the home and the products that contain them. 8 EN Package Contents »Receivers with batteries (x6) »Remote control with battery »Stand for remote control »SIM eject tool »User Manual Parts Overview Receiver Lanyard hole LED indicator Battery eject hole Speaker Battery compartment 9 EN Remote Control with Stand Battery cover LED indicator Receiver buttons Stand Lanyard hole 10 EN Setting Up the Finder Attaching the Receivers Use the receivers' lanyard holes to attach the receivers to your keys, wallet, purse, or other items you don't want to lose. Keep track of which color receiver is with each item. NOTICE For items without a hole or loop, use double-sided tape to attach the receiver. The receiver is not shockproof or waterproof. Replacing a Receiver Battery 1. To open the battery compartment, push a SIM-eject tool or paper clip into the battery eject hole. Battery eject hole SIM-eject tool 11 EN 2. Install a new CR2032 battery. Make sure the polarity symbols on the battery match the symbols in the compartment. 3. Push the battery compartment back into the receiver. NOTICE Batteries in the receivers and remote should be changed every six months for the best performance. If the battery strength is low, signal strength may dec…

Text truncated - open the document above for the full version.

2.911 (d)(5)(i) Equipment Type Attestation v1.2 Shenzhen Junlan Electronic Ltd Section 2.9 11(d)(5)(i) Certification – EquipmentType Company name: Shenzhen Junlan Electronic Ltd Address: No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Product Name: Key Finder FCC ID: OKUBS2909 Model(s): TTIF06A, BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) 2.911(d)(5)(i) EquipmentType We, [Shenzhen Junlan Electronic Ltd] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from rece ivi ng an equipment authoriza tion pursu ant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List ” NOT E 1 Yours si nce rely, Name: peng xiaoDate: 2023-11-14 Title and Company name:sa fety engineer /Shenzhen Ju nlan Elect ronic Ltd NOTE 1 “C overe d List”; is the List of Equipment and Serv ices Covere d By Section 2 of The Secure Network s Act, available at https://www.fcc.gov/supplychain/covere dlist Refere nces; 1) 986446 D01 Covere d Equipment v01 https://apps.fcc.gov/oetcf/kdb/form s/FTSSearc hResultPage.cfm?switch=P&id=325672 2) Federa l Register document 2022-2 8263 published on 02/06/23 https://www.federa lre gister.gov/documents/2023/02/06/2022-2 8263/protecting-a gainst-n ational-s ecuri ty-t hre ats-t o-t he-c om munications-s upply-c hain-t hro ugh-t he

2.911 (d)(5)(ii) Applicant Attestation v1.3 Shenzhen Junlan Electronic Ltd Section 2.9 11(d)(5)(ii) Certification – Applicant (Covered Lis t) Company name: Shenzhen Junlan Electronic Ltd Address: No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Product Name: Key Finder FCC ID: OKUBS2909 Model(s): TTIF06A, BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Junlan Electronic Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours si nce rely, Name: peng xiaoDate: 2023-11-14 Title and Company name:sa fety engineer /Shenzhen Ju nlan Elect ronic Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “C overe d List”; is the List of Equipment and Serv ices Covere d By Section 2 of The Secure Network s Act, available at https://www.fcc.gov/supplychain/covere dlist Refere nces; 1) 986446 D01 Covere d Equipment v01 https://apps.fcc.gov/oetcf/kdb/form s/FTSSearc hResultPage.cfm?switch=P&id=325672 2) Federa l Register document 2022-2 8263 published on 02/06/23 https://www.federa lre gister.gov/documents/2023/02/06/2022-2 8263/protecting-a gainst-n ational-s ecuri ty-t hre ats-t o-t he-c om munications-s upply-c hain-t hro ugh-t he

sought FCC ID: OKUBS2909 The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/15/2023 U.S. Agent Designation Shenzhen Junlan Electronic Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is Applicant FRN:0021880893 Name of U.S. agent: Tim Payne Company U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC serviceaccepttoobligationtheiracknowledgesbeonprocessofofhalf [Shenzhen Junlan Electronic Ltd]. Shenzhen Junlan Electronic Ltd with the FRN 0021880893] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature Peng Xiao safety engineer Shenzhen Junlan Electronic Ltd Signature Tim Payne Manager FCC US Agent, LLC 4 8_[model] US_Agent_2.911(d)(7) - U , V03 Shenzhen Junlan Electronic Ltd

ShenzhenJunlanElectronicLtd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023-11-14 Subject;RequestforLongTermConfidentiality FCCID:OKUBS2909 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:pengxiao Title:safetyengineer

Shenzhen Junlan Electronic Ltd No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Agent Authorization Company: Shenzhen Junlan Electronic Ltd Address: No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Product Name: Key Finder Model Number(s): TTIF06A, BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Product Description: Key Finder We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature:Date: 2023-11-14 Name:peng xiao Title:safety engineer Company: Shenzh en Junlan Electronic Ltd

Shenzhen Junlan Electronic Ltd No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Statement Product: Key Finder Model: TTIF06A Additional Model: BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Trademark : amazon basics We hereby state that TTIF06A is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of TTIF06A can represent the remaining models. Your assistance on this matter is highly appreciated. Yours sincere ly, Si gnature : Date: 2023/11/14 Name: peng xiao Company Name: Sh enzhen Junlan El ectro nic Ltd Ad dre ss: No.277 Pi ngKui Road, Sh ijing Community, Pi ngshan St re et, Pi ngshan New Distri ct, Sh enzhen, China Tel / Fax: 0755-2 7309169/0755-2 7309497 E-M ail: xp@jump-l an.com

Page 1 of 4 Appendix B: Photographs of EUT Product: Key Finder Model: TTIF06A External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: TTIF06A Label: Size: L*W=36*20mm Location

Page 1 of 3 Appendix B: Photographs of EUT Product: Key Finder Model: TTIF06A Internal Photos Antenna Page 2 of 3 Page 3 of 3

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : OKUBS2909 Test Report No. ............... : TCT231016E011 Date of issue ................... : Mar. 18, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Junlan Electronic Ltd Address ........................... : No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Manufacturer's name ... : Shenzhen Junlan Electronic Ltd Address ........................... : No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Standard(s) ..................... : KDB 447498 D01 General RF Exposure Guidance v06 Product Name ................. : Key Finder Trade Mark ...................... : amazon basics Model/Type reference..... : TTIF06A, BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Rating(s).......................... : DC 3V Date of receipt of test item ......................................... : Oct. 16, 2023 Date (s) of performance of test ................................... : Oct. 16, 2023 - Mar. 18, 2024 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT231016E011 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 4.1. Requirements ......................................................................................................... 6 4.2. Test Result ............................................................................................................. 6 Report No.: TCT231016E011 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Key Finder Model/Type reference........... : TTIF06A Sample Number....................: TCT231016E010-0101 Operation Frequency ........... : 433.92MHz Modulation Type ................... : FSK Antenna Type ........................ : FPC Antenna Antenna Gain ........................ : -4.06dBi Rating(s)................................ : DC 3V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 TTIF06A Other models BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Note: TTIF06A is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of TTIF06A can represent the remaining models. Report No.: TCT231016E011 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 3V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Transmitting mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT231016E011 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditation…

Text truncated - open the document above for the full version.

www.kontec.com.cn 1 PRODUCT SPECIFICATION Customer: Customer’s part number: Product description:FPC-433 Antenna Uni Link’s part number:433-FPC-CT-4301-JL-TX-V1.0 Issue Date:2024-01-16 Note:423-443MHz Customer Use Customer's authorized signature Remarks Full approved Conditional approved Rejected 一、（ PRODUCT TECHNICALSPECIFICATION ） Electrical Specifications Frequency Range (MHz) 422-443 V.S.W.R ≤3.0 Mechanical Specifications Antenna Length (mm)29.4*7.3±0.5mm Cable (mm)/ Connect Type/ MountingPaste type ColorofCableBlack -30 °C～ +75 （ Operating Temperature ）°C Working humidity（%）0%-95% -35 °C～ +80 （ Storing Temperature ）°C Storage humidity（ % ） 0%-95% 二、Installation position diagram : 二、Test data： 1. Standing wave measuremen: Test data： Standing wave： Return loss： 2 ． OTA T E S T ： Test equipment：24 probe spherical microwave dark test chamber Testing instrument： 5071B ， CMW500 ， E4438C Test data： Gain&Efficiency&PhaseCenter frequency (MHz) gain (dBi) efficiency (dB) efficiency (%) 423-2.19-5.9125.63 424-1.87-5.5527.88 425-1.93-5.5527.88 426-2.07-5.6227.4 427-2.41-5.8925.75 428-2.89-6.2823.53 429-3.39-6.7221.29 430-3.84-7.119.51 431-4.17-7.3618.38 432-4.31-7.4617.94 433-4.27-7.418.21 434-4.06-7.1419.3 435-3.68-6.7321.24 436-3.21-6.2223.88 437-2.77-5.7426.68 438-2.47-5.4328.66 439-2.41-5.3729.02 440-2.64-5.6127.49 441-3.1-6.0824.65 442-3.73-6.7121.32 443-4.47-7.4118.14 3D:

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : OKUBS2909 Test Report No. ............... : TCT231016E010 Date of issue ................... : Mar. 18, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen Junlan Electronic Ltd Address ........................... : No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Manufacturer's name ... : Shenzhen Junlan Electronic Ltd Address ........................... : No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.231 Product Name ................. : Key Finder Trade Mark ...................... : amazon basics Model/Type reference..... : TTIF06A, BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Rating(s).......................... : DC 3V Date of receipt of test item ......................................... : Oct. 16, 2023 Date (s) of performance of test ................................... : Oct. 16, 2023 - Mar. 18, 2024 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT231016E010 Page 2 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test Environment and Mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 6 4. Facilities and Accreditations .................................................................. 7 4.1. Facilities ................................................................................................................. 7 4.2. Location ................................................................................................................. 7 4.3. Measurement Uncertainty ..................................................................................... 7 5. Test Results and Measurement Data ..................................................... 8 5.1. Antenna Requirement ........................................................................................... 8 5.2. Conducted Emission ............................................................................................. 9 5.3. Radiated Emission Measurement ...................................................................... 10 5.4. Manually Activated Transmitter ......................................................................... 20 5.5. Occupied Bandwidth ........................................................................................... 22 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT231016E010 Page 3 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Key Finder Model/Type reference........... : TTIF06A Sample Number....................: TCT231016E010-0101 Operation Frequency ........... : 433.92MHz Modulation Technology ....... : FSK Antenna Type ........................ : FPC Antenna Antenna Gain ........................ : -4.06dBi Rating(s)................................ : DC 3V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 TTIF06A Other models BS-2909, B0CDLQ7ZL4, TTIF06XX, BS-2909XX (XX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank.) Note: TTIF06A is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of TTIF06A can represent the remaining models. Report No.: TCT231016E010 Page 4 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS Conduction Emission, 0.15MHz to 30MHz §15.207 N/A Manually Activated Transmitter §15.231(a) PASS Radiation Emission §15.231(b), §15.205, §15.209, §15.35 PASS Occupied Bandwidth §15.231(c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT231016E010 Page 5 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. General Information 3.1. Test Environment and Mode Operating Environm…

Text truncated - open the document above for the full version.

Page 1 of 1 Appendix A: Photographs of Test Setup Product: Key Finder Model: TTIF06A Radiated Emission
