Model:CHT940x Sound Bar with FM/Bluetooth Music Player Sound Bar with FM/Bluetooth Music Player R R WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Warnings FCC NOTICE: To assure continued compliance, follow the attached installation instructions and use only shielded cables when connecting to other devices. Modifications not authorized by the manufacturer may void user’s authority to operate this device. 2. Mounting the Speaker Bar onto a wall We recommend having this speaker professionally mounted. By using the included wall mounting accessories, the sound bar can be mounted onto a wall. Distance Between Two Brackets 1. Placing on the table When placing the Sound Bar on an entertainment center, bookshelf, or any type of enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat generated from the Sound Bar could produce a potential heat hazard. To the DC IN jack on the top of the unit. 25.9 inches To the wall outlet NOTE: If Long period of time will not use the unit, unplug the AC Cord from the wall outlet. 1. Insert the plug from the supplied AC/DC adaptor to the DC In Jack on the top of unit. 2. Insert the small plug from the supplied AC Power Cord to the AC In Jack on the AC/DC Adaptor. 3. Insert the AC Plug from the supplied to the wall outlet Having AC 100-240V~; 50/60Hz. To the AC In Jack 1. Mark the position of the mounting screws on the wall using a pencil. 2. Drill the supplied screws directly into the marks that you have made on the wall and leave approx. 0.3 inch length to hook the sound bar. 3. Put the sound bar onto the mounting screws. Make sure they are firm and stable. 4 You may use 2 pieces plastic inserts (Included) 2 pieces screws (Included) 1. Mark the position of the mounting screws on the wall using a pencil. 3. Insert the supplied plastic inserts into the holes by hammer . 5. Put the sound bar onto the mounting screws. Make sure they are firm and stable. (1) (2) 4. Secure the supplied screws into the plastic insert and leave approx. 0.3 inch 2 pieces screws (Included) 2.2 Mounting on the wooden wall: You may use 2.2 Mounting on the wall 2.1 Mounting on the wooden wall length to hook the sound bar. ( Not Supplied ) 2. Drill 2 x 7/32 inch diameter holes by a powerful electric drill ( Not Supplied ). 25.9 inches 25.9 inches 5 1.Indicator 3. Speakers 2. Remote Sensor 3. Speakers POWER/ SOURCE VOL- VOL+ PLAY/ PAUSE FM ANT AUX IN1 AUX IN2 L R DC IN DC 16V, 3A Front View POWER/ SOURCE VOL- VOL+ PLAY/ PAUSE FM ANT AUX IN1 AUX IN2 L R DC IN DC 16V, 3A 12345 6 7 8910 1. FM ANT ( FM Antenna ) 2. AUX IN 1 jack 3. AUX IN 2 jacks 4. DC IN jack 5. POWER/SOURCE button 6. VOL- ( Volume Down ) button 7. VOL+ ( Volume Up ) button 8. PLAY/PAUSE button 9. TUNE-/ ( Skip Backward ) button TUNE- TUNE+ 10. TUNE+/ ( Skip Forward ) button TUNE- TUNE+ Top View (FM receiver Antenna ) EQ SOURCE BASS - BASS+ VOL- VOL+ MO/ST TREBLE- TREBLE+ 6 1 2 3 4 5 6 7 8 9 10 11 TUNE- TUNE+ 2. TUNE-/ ( Skip Backward ) button 3. TUNE+/ ( Skip Forward ) button 1. Power ON/OFF button 4. MO/ST ( Mono/Stereo ) button 5. SOURCE button 6. BASS +/- buttons 7. ( Mute ) button 8. EQ ( Equalizer ) button 9. ( Play/Pause ) button 10. VOL ( Volume ) +/- buttons 11. TREBLE +/- buttons 7 BATTERY PRECAUTIONS Fig.1Fig.2 Fig.3 - First Time Use Remove and discard the insulation tab as figure on the right. 1. Push and slide out the battery holder as figure 1 below. 3. Close the battery holder. 2. Replace the battery with a new CR2025 button cell as the polarity markings on the rear of the Remote Control. ° Remote Sensor 30 ° 30 8. This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burn in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. - If the battery is consume, replace it as below: Folloe these precautions when using a battery in this device: 1. Use only the size and type of battery specified. 2. Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment. A reversed battery may cause damage to the device. 3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc ) or old batteries with fresh ones. 4. If the batteries in the device are consumed or device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage. 5. Do not try to recharge the battery not intended to …
Text truncated - open the document above for the full version.
3A CHT940x FCC ID:OKUCHT940X J U L 2 0 1 4 贴纸位置图 铭牌贴纸 订单号:JLE14257D CRAIG CHT940X 胡本林 版本/版次:A/0 SBB-25636 铭牌贴纸
Radiated Emission Conducted Emission
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |
