OKUJSBW650SCWALL MOUNTABLE 2.1-CHANNEL BLUETOOTH SOUNDBAR SPEAKER

WALL MOUNTABLE 2.1-CHANNEL BLUETOOTH SOUNDBAR SPEAKER WITH FM RADIO USER MANUAL JSBW-650 PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE. 1 DEAR JENSEN® CUSTOMER Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time your hearing "comfort level" adapts to higher volumes of sound. So what sounds "normal" can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level:  Start your volume control at a low setting.  Slowly increase the sound until you can hear it comfortably and clearly, and without distortion. Once you have established a comfortable sound level:  Set the dial and leave it there. Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime. We Want You Listening For a Lifetime Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association's Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise. Customer's Record: The serial number of this product is found on its bottom cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: JSBW-650 Serial Number: ____________________ 2 IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit. 1. Read these instructions – All the safety and operating instructions should be read before the appliance is operated. 2. Keep these instructions – The safety and operating instructions should be kept for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions – All operation and use instructions should be followed. 5. Do not use this apparatus near water – The appliance should not be used near water; for example, near a bath tub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. 6. Clean only with dry cloth – The appliance should be cleaned only as recommended by the manufacturer. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. AC adaptor is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the mains completely, the AC adaptor should be disconnected form the mains socket outlet completely. 10. Only use attachments / accessories specified by the manufacturer. 11. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 12. Unplug this apparatus during lightning storms or when unused for long periods of time. 13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14. This appliance shall not be exposed to dripping or splashing water and that no object filled with liquids such as vases shall be placed on the apparatus. 15. Power Sources – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. Do not overload wall outlet. 3 16. Battery shall not be exposed to excessive heat such as sunshine, fire or the like 17. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 18. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs, seek advice from your local qualified service technician or contact the distributor via the telephone number at the back of this instruction manual. 19. Caution marking and nameplate are located on bottom of product. IMPORTANT NOTE Avoid installing the unit in locations described below:  Places exposed to direct sunlight or close to heat radiating appliances such as electric heaters.  Places subject to constant vibration.  Dusty, humid or moist places.  Sources of electrical noise such as fluorescent lamps or motors.  In c…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company Shenzhen Junlan Electronic Ltd hereby declares: T he product model(s) SBB-040A1 is identical in the same PCB layout, interior structure and electrical circuits with the model JSBW-650 which tested in Global Un it Technology Co., Ltd., the only differences are the model name for commercial purpose.

FCC ID: OKUJSBW650SC According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation          [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,     !-" #$%  &  ! -g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, ---10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 96.49dBuV/m @3m Ant gain =2dBi, so Ant numeric gain= 1.58 So pt={ [10 (96.49) /10 6 x 3] 2 /30x1.58 }x1000 mW = 0.852mW So (0.852mW /5mm)x '48 = 0.267<3 Then SAR evaluation is not required Ant gain =0dBi, so Ant numeric gain= 1 1.346 So1.346mW/5mm)x 2.48 = 0.43<3

Global United Technology Services Co., Ltd. Report No.: GTSE15020020501 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Shenzhen Junlan Electronic Ltd Address of Applicant: No.277 PingKui Road, Shijing Community, Pingshan Street, Pingshan New District, Shenzhen, China. Equipment Under Test (EUT) Product Name: WALL MOUNTABLE 2.1-CHANNEL BLUETOOTH SOUNDBAR SPEAKER Model No.: SBB-040A1, JSBW-650 Trade Mark: JENSEN FCC ID: OKUJSBW650SC Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2013 Date of sample receipt: February 27, 2015 Date of Test: March 02-04, 2015 Date of report issued: March 05, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE15020020501 Global United Technology Services Co., Ltd. Project No.: GTSE150200205RF 2 Version Version No. Date Description 00March 05, 2015 Original Prepared By: Date: March 05, 2015 Project Engineer Check By: Date: March 05, 2015 Reviewer Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone,Xixiang Road, Baoan District, Shenzhen 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 32 Report No.: GTSE15020020501 Global United Technology Services Co., Ltd. Project No.: GTSE150200205RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone,Xixiang Road, Baoan District, Shenzhen 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 32 3 Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 .................................................................................................................................................. 2VERSION 3 .............................................................................................................................................. 3CONTENTS 4 ..................................................................................................................................... 4TEST SUMMARY 5 ...................................................................................................................... 5GENERAL INFORMATION 5.1 ......................................................................................................................... 5CLIENT INFORMATION 5.2......................................................................................................... 5GENERAL DESCRIPTION OF EUT 5.3 ........................................................................................................................................ 7TEST MODE 5.4....................................................................................................... 7DESCRIPTION OF SUPPORT UNITS 5.5.................................................................................................................................... 7TEST FACILITY 5.6................................................................................................................................. 7TEST LOCATION 5.7......................................................................... 7OTHER INFORMATION REQUESTED BY THE CUSTOMER 6..................................................................................................................... 8TEST INSTRUMENTS LIST 7 ...................................................................................... 9TEST RESULTS AND MEASUREMENT DATA 7.1 ..................................................................................................................... 9ANTENNA REQUIREMENT 7.2................................................................................................................... 10CONDUCTED EMISSIONS 7.3........................................................................................................... 13RADIATED EMISSION METHOD 7.3.1................................................................................ 15Field Strength of The Fundamental Signal 7.3.2 .................................................................................................................... 16Spurious emissions 7.3.3 .................................................................................................................. 20Bandedge emissions 7.4 .............................................................................................................. 2120DB OCCUPY BANDWIDTH 8............................................................................................................................ 23TEST SETUP PHOTO 9 ...................................................…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emissions
