OKUTSB14647Bluetooth Tower Stereo with USB Charging Port

IMPORTANT SAFETY INSTRUCTIONS 1.Read these instructions. 2.Keep these instructions. 3.Heed all warnings. 4.Follow all instructions. 5.Do not use this apparatus near water. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with the manufacture’s instructions. 8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10.Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11.Only use attachments/accessories specified by the manufacturer. 12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13.Unplug the apparatus during lightning storms or when unused for long periods of time. 14.Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. WARNING：To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. - This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. - Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. - The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. USB Output DC 5V,500mA Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Family models declaration letter. 2013-8-5 We SHENZHEN JUNLAN ELECTRONIC LTD Of District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China （address） Declare under our sole responsibility that the product FCC ID: OKUTSB14647 Product: Bluetooth Tower Stereo with USB Charging Port Model Number ：ITSB-250, TSB-14141, TSB-14142, TSB-14143, TSB-14145, TSB-14146, TSB-14147, TSB-14148, TSB-14149, TSB-14647, TSB-881K, TSB-881K9, TSP-9214, TSB-992Q, TSB-631NF, TSB-681NF, ITSB-209, TSB-9933, TSB-9933J, TSB-99337, TSB-9933K, TSB-9933L, TSB-981J, TSB-981J1, TSB-981J2, TSB-111H, TSI-1426, TSP-1417, TS9092, TS9092GB, TS9092MO, TS9092GBMO, BT950, BT910, BT910GB, BT910MO, BT910GBMO, TSB-121J1, TSB-121J, TSB-121JH, IP9050GBMO, SBP-8811, ITB133, ITB133B, BT5881, SBB-111H, , AR1003, TSB-881K6, TSB-14X47, TSB-121JX, TSB-981JX(“X” could be 1~9 and A~Z) All models have the same constructions, circuit diagram and PCB layout. Only model name, the color of appearance and trade name are different. Unless otherwise stated Thanks Sincerely, Signature Peng Xiao / safety engineer E-mail: [email protected] Phone: 0755-27309169 Fax: 0755-27309497 Address District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 SHENZHEN JUNLAN ELECTRONIC LTD 2013-8-5 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN JUNLAN ELECTRONIC LTD hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: OKUTSB14647 Bluetooth Tower Stereo with USB Charging Port, ITSB-250, TSB-14141, TSB-14142, TSB-14143, TSB-14145, TSB-14146, TSB-14147, TSB-14148, TSB-14149, TSB-14647, TSB-881K, TSB-881K9, TSP-9214, TSB-992Q, TSB-631NF, TSB-681NF, ITSB-209, TSB-9933, TSB-9933J, TSB-99337, TSB-9933K, TSB-9933L, TSB-981J, TSB-981J1, TSB-981J2, TSB-111H, TSI-1426, TSP-1417, TS9092, TS9092GB, TS9092MO, TS9092GBMO, BT950, BT910, BT910GB, BT910MO, BT910GBMO, TSB-121J1, TSB-121J, TSB-121JH, IP9050GBMO, SBP-8811, ITB133, ITB133B, BT5881, SBB- 111H, AR1003, TSB-881K6, TSB-14X47, TSB-121JX, TSB-981JX(“X” could be 1~9 and A~Z) We affirm that between SIEMIC and SHENZHEN JUNLAN ELECTRONIC LTD , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Peng Xiao / safety engineer E-mail: [email protected] Phone: 0755-27309169 Fax: 0755-27309497 Address District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China

RATING LABEL SIZE:122*80MM PRINTED IN WHITE ON BLACK BACKGROUND QTY=1PC 铭牌贴纸 尺寸：MM 黑底白字 用量:1PC 贴机器后板 122*80 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device might not cause harmful interference, and (2) this device must accept any interference received, including interference that might cause undesired operation. FCC LABEL SIZE:105*16MM PRINTED IN WHITE ON BLACK BACKGROUND QTY=1PC FCC 尺寸：*MM 黑底白字 用量:1PC 贴机器后板 贴纸 10516 WARNING: The power cord on this product contains lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. Warning LABEL FOR Power cord SIZE:70*14MM PRINTED IN WHITE ON BLACK BACKGROUND QTY=1PC 电源线警告 贴纸 尺寸：70*14MM 黑底白字 用量:1PC 贴机器后背电源线上方. 贴纸 IT 张富兴 ITSB-250 TSB-14647 JLE13384 0 ICES003 LABEL SIZE:35*12MM PRINTED IN WHITE ON BLACK BACKGROUND QTY=1PC ICES003 尺寸：3*MM 黑底白字 用量:1PC 贴机器后板 贴纸 512 13 MM 1 3 M M Bluetooth Tower Stereo with USB Charging Port MODEL: ITSB-250 POWER SUPPLY: AC 120V~ 60HZ POWER CONSUMPTION: 45W FM FREQUENCY RANGE:87.5-108MHZ FCC ID: OKUTSB14647 MADE IN CHINA 2013 Innovative Technology 1 Channel Drive Port Washington, NY 11050 www.ithomeproducts.com c MODEL: SERIAL NO: ITSB-250 WARNING TO PREVENT ELECTRIC SHOCK DO NOT REMOVE BACK COVER NO USER SERVICEABLE PARTS INSIDE CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR AVERTISSEMENT 1 . 5 M M 2 M M 3 M M Bluetooth Tower Stereo with USB Charging Port MODEL: ITSB-250 POWER SUPPLY: AC 120V~ 60HZ POWER CONSUMPTION: 45W FM FREQUENCY RANGE:87.5-108MHZ FCC ID: OKUTSB14647 MADE IN CHINA 2013 Innovative Technology 1 Channel Drive Port Washington, NY 11050 www.ithomeproducts.com c MODEL: SERIAL NO: ITSB-250 WARNING TO PREVENT ELECTRIC SHOCK DO NOT REMOVE BACK COVER NO USER SERVICEABLE PARTS INSIDE CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR AVERTISSEMENT 贴纸位置 LABEL POSITION MADE IN CHINA WARNING: The power cord on this product contains lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. 贴纸位置 LABEL POSITION 贴纸位置图 IT TSB-14647 JLE13384 张富兴 ITSB-250 XXXXXXXXX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device might not cause harmful interference, and (2) this device must accept any interference received, including interference that might cause undesired operation. Manufactured: 082013 贴纸 IT 张富兴 ITSB-250 TSB-14647 JLE13384 0 Manufactured: 082013 日期贴纸 尺寸：30*5mm 底字 用量:1PC 贴机器后板 贴纸 黑白 DATE LABEL SIZE:30*5MM PRINTED IN WHITE ON BLACK BACKGROUND QTY=1PC 130800001B130825400B TO 流水号贴纸 尺寸：30*5mm 白底黑字 用量:1PC 贴机器后板 SERIAL NO LABEL SIZE:30*5MM PRINTED IN BLACK ON WHITE BACKGROUND QTY=1PC JLE13494 122*95 MM 122*95 MM 13 MM 1 3 M M 1 . 5 M M 2 M M 3 M M

Bluetooth Module Antenna

FCC ID : OKUTSB14647 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Operation Frequency: Bluetooth: 2402-2480MHz, Power density limited: 1mW/ cm 2 Antenna GAIN: 0dBi Output Peak power (dBm) max Output Peak power (mW) Antenna Gain (dBi) Numeric Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 1.47 1.403 1 0.0003 1

TRF No：FCC 15.247/A Page 1 of 45 Report No: ES130620161E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPARTC REQUIREMENT OF Bluetooth Tower Stereo with USB Charging Port MODEL No.: ITSB-250, TSB-14141, TSB-14142, TSB-14143, TSB-14145, TSB-14146, TSB-14147, TSB-14148, TSB-14149, TSB-14647, TSB-881K, TSB-881K9, TSP-9214, TSB-992Q, TSB-631NF, TSB-681NF, ITSB-209, TSB-9933, TSB-9933J, TSB-99337, TSB-9933K, TSB-9933L, TSB-981J, TSB-981J1, TSB-981J2, TSB-111H, TSI-1426, TSP-1417, TS9092, TS9092GB, TS9092MO, TS9092GBMO, BT950, BT910, BT910GB, BT910MO, BT910GBMO, TSB-121J1, TSB-121J, TSB-121JH, IP9050GBMO, SBP-8811, ITB133, ITB133B, BT5881, SBB-111H, AR1003, TSB-881K6, TSB-14X47, TSB-121JX, TSB-981JX(“X” could be 1~9 and A~Z) FCC ID: OKUTSB14647 Trademark: N/A REPORT NO: ES130620161E ISSUE DATE: August 2, 2013 Prepared for Shenzhen Junlan Electronic Ltd. District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No：FCC 15.247/A Page 2 of 45 Report No: ES130620161E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World VERIFICATION OF COMPLIANCE Applicant: Shenzhen Junlan Electronic Ltd. District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China Manufacturer: Shenzhen Junlan Electronic Ltd. District 2 type A plant in the second layer 1-4, NO.2 Industrial Fuyuan Tangwei Fuyong Baoan Shenzhen China Product Description: Tower Speaker Model Number: ITSB-250, TSB-14141, TSB-14142, TSB-14143, TSB-14145, TSB-14146, TSB-14147, TSB-14148, TSB-14149, TSB-14647, TSB-881K, TSB-881K9, TSP-9214, TSB-992Q, TSB-631NF, TSB-681NF, ITSB-209, TSB-9933, TSB-9933J, TSB-99337, TSB-9933K, TSB-9933L, TSB-981J, TSB-981J1, TSB-981J2, TSB-111H, TSI-1426, TSP-1417, TS9092, TS9092GB, TS9092MO, TS9092GBMO, BT950, BT910, BT910GB, BT910MO, BT910GBMO, TSB-121J1, TSB-121J, TSB-121JH, IP9050GBMO, SBP-8811, ITB133, ITB133B, BT5881, SBB-111H, TSB-14X47, TSB-121JX, TSB-981JX(“X” could be 1~9 and A~Z) (Note: These models are identical in circuitry and electrical, mechanical and physical construction; the only differences are the color of appearance, trademark and model no. for trading purpose. We prepare TSB-14647 for test. File Number: ES130620161E We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Date of Test : July 20, 2013 to July 28, 2013 Prepared by : Joe Xia/Editor Reviewer : June Xie/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No：FCC 15.247/A Page 3 of 45 Report No: ES130620161E Shenzhen EMTEK Co.,Ltd. Building 69, Majialong Industry Zone, Nanshan District, Shenzhen,Guangdong,China www.emtek.com.cn Tel: +86-755-2695 4280 Fax: +86-755-2695 4282 Access to the World Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 10 2.6 EQUIPMENT USED IN TESTED SYSTEM.................................................................................................. 10 2.7 DESCRIPTION OF TEST MODES............................................................................................................... 11 3. SUMMARY OF TEST RESULTS ....................................................................................... 12 4. CONDUCTED EM…
