OKUWE190810.1-inch Smart Digital Picture Frame

ENGLISH OPERATION MANUAL MODEL 10.1-inch Smart Digital Picture Frame WE-1908 Explanation of Graphical Symbols: an equilateral triangle, is int ended to alert the user to the presence of uninsulated “dangerous volt age” - cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is int ended to alert the user to the presence of important operating and maintenance (servicing) instructions in the lit erature accompanying the appliance . CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN For users in U.S. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. SPECIAL NOTES FOR YOUR RECORDS For your assistance in reporting this unit in case of loss or theft, please record below the model number and serial number which are located at the bottom of the unit. Please retain this information. Model number __________________ Serial number ___________________ Date of purchase ________________ Place of purchase _______________ To obtain service or product information, call 1-877-506-4900 FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation. 1.Read Instructions: All the safety and operating instructions should be read before the appliance is operated. 2.Retain Instructions: The safety and operating instructions should be well kept for future reference. 3.Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to. 4.Follow Instructions: All operating and use instructions should be followed. 5.Power Sources: The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. 6.Power-Cord Protection: Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point at which they exit from the appliance. 7.Overloading: Do not overload wall outlets and extension cords as this can result in a risk of f re or electric shock. 8.Grounding or Polarization: Precaution should be taken to insure that the grounding or polarization means of an appliance is not defeated. 9.Severe weather: In extreme weather such as lightning storm, hurricane, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the appliance due to unexpected power surges. 10.Water and Moisture: The appliance should not be used near water-for example, near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool, or a wet basement. 11.Heat: The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat. 12.Object/Liquid Entry: Care should be taken so that no object/liquid enter into the enclosure through openings. 13.Ventilation: The appliance should not be situated so that its location (on a bed, sofa, rug, or similar surface) or position (such as a bookcase or cabinet) interferes with its proper ventilation. 14.Mounting: The appliance should be mounted only as recommended by the manufacturer. 15.Cleaning: Only use a soft dry cloth to clean the appliance. 16.Servicing: The user should not attempt to service the appliance beyond that described in the user’s operating instructions. All other servicing should be referred to qualified personnel. 17.Replacement Parts: When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer. Unauthorized substitutions may result in fire, electric shock or other hazards. 18.Damage Requiring Service: The appliance should be serviced by qualified service personnel when: • The power-supply cord or plug has been damaged. • Objects have fallen into, or liquid has been spilled into the appliance enclosure. • The appliance has been exposed to rain. • The appliance has been dropped, or the enclosure damaged. • The appliance does not appear to op…

Text truncated - open the document above for the full version.

ShenzhenJunlanElectronicLtd [No.277PingKuiRoad,ShijingCommunity,PingshanStreet,PingshanNewDistrict,] [Shenzhen] [China] Date:03-27-2024 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 FCCID:OKUWE1908 FRN:0021880893 USAgent–AttestationStatement/Part2.911(d)(7) ShenzhenJunlanElectronicLtdcertifies,thatasof02-18-2024,wehavedesignatedFCCUSAgent, LLCtoacceptserviceofprocessonourbehalfforFCCID:OKUWE1908 ShenzhenJunlanElectronicLtd acceptstomaintainanagentofserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedallmarketing andimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofanyCommission- relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. FCCUSAgent,LLC,acceptsasofthedateofthefilingofthisapplication,theobligationofbeing thedesignatedagentforthepurposeofacceptingserviceofprocessonbehalfof ShenzhenJunlan ElectronicLtd forFCCID:OKUWE1908 DesignatedAgentInformation: CompanyName:FCCUSAgent,LLC FRN:0033402884 Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA ContactPerson:TimPayne Phone:708-571-3148 Email:[email protected] Sincerely, Company: ShenzhenJunlanElectronicLtd DesignatedAgent:FCCUSAgent,LLC CompanyRepresentative:pengxiaoDesignatedAgentRepresentative:TimPayne Signature:Signature:

Rev 1/26/2023 Shenzhen Junlan Electronic Ltd Federal Communications Commissi on Authorization and Evaluation Divisi on 7435 Oa kland Mills Road Columbia, MD 21046 US A Date: 2024-06-05 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID:OKUW E1908 Shenzhen Junlan Electronic Ltd(“the applicant”) certifies that the equipment for which authorization is so ughtis not “covered” equipment prohibited from receiving an equipment authorization pursu ant to se ction 2.903 of the FCC rules. Sincerely, (Applicant si gnature) peng xiao Rev 1/ 26/ 2023 Federal Communications Commissi on Authorization and Evaluation Divisi on 7435 Oa kland Mills Road Columbia, MD 21046 US A Date: 2024-06-05 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID:OKUW E1908 Shenzhen Junlan Electronic Ltd(“the applicant”) certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List as an entity producing “covered” equipment. The applicantis nota named entity or any of its su bsi diaries or affiliates. Sincerely, (Applicant si gnature) peng xiao Shenzhen Junlan Electronic Ltd

Appendix- WE-1908-Photos Page 3 of 10 2. Photographs –Constructional Details 2.1. EUT – External View Model WE-1908 FCC ID: OKUWE1908 Appendix- WE-1908-Photos Page 4 of 10 Appendix- WE-1908-Photos Page 5 of 10 Appendix- WE-1908-Photos Page 6 of 10 Appendix- WE-1908-Photos Page 7 of 10

流水号贴纸 尺寸: 30*5mm 材质: 不干胶贴纸 颜色: 白底黑字 用量: 1pc 位置: 贴产品塑胶壳后面 2024040001 2024040510 Serial No. label Size: 30*5mm Material:self-adhesive sticker Color: White background black character QTY: 1pc Position: back cabinet of unit 品号: 3020508351 Transparant round sticker Size: Φ33mm QTY: 1 pc Position: cover of giftbox 透明圆形贴纸 尺寸: Φ33mm 用量: 1pc 品号: 3227C330000101 主机铭牌贴纸 尺寸 材质: 强力不干胶贴纸 颜色 : 黑白印刷,表面过光胶 用量: 1pc 位置: 贴主机后壳 : 47*27mm Model NO.: WE-1908 10.1-inch Smart Digital Picture Frame Power Source: DC 5V 1.5A Made in China 2024040001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation. Model NO.: WE-1908 后板接口贴纸(客供) 尺寸: 73*5mm 材质: 消银龙 颜色: 黑底银字 用量: 1pc 位置: 贴主机后壳 由供应商提供 编号： ShenZhen JunLan Electronic LTD 深圳市君兰电子有限公司 材 质 制造尺寸装柜尺寸 本司机型 客户名称 客户型号 品 号 包装类别 设计 / 日期 单 号 用量 整机重量 版本 / 版次：A/0 单位：mm 1:1 JUNLAM 结构电子安规跟单标准化 确认签字 JLR240048A 贴纸 凌霄华 WE-1908 品号: 3020509721 品号: 3020509711 10.1-inch Smart Digital Picture Frame Power Source: DC 5V 1.5A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID:OKUWE1908 Made in China FCC ID:OKUWE1908

Appendix- WE-1908-Photos Page 8 of 10 2.2. EUT – Internal View Model WE-1908 FCC ID: OKUWE1908 ANT. Appendix- WE-1908-Photos Page 9 of 10 Appendix- WE-1908-Photos Page 10 of 10

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 8 TEST REPORT Reference No. .................... : WTH24D04089814W003 FCC ID ................................ : OKUWE1908 Applicant ............................ : Shenzhen Junlan Electronic Ltd Address .............................. : No. 277, Pingkui Road, Shijing Community, Pingshan Office, Pingshan New District, Shenzhen, China Manufacturer .................... : Shenzhen Junlan Electronic Ltd Address ............................. : No. 277, Pingkui Road, Shijing Community, Pingshan Office, Pingshan New District, Shenzhen, China Product ............................... : 10.1-inch Smart Digital Picture Frame Model(s). ............................ : WE-1908, MX-PF101, MEMDPF101, WE-19XX, MX-CRXXX, WE- 1908XXX(XXX means unit color, it can be A to Z or N/A) Standards........................... : FCC 47CFR Part 2 Subpart J Section 2.1091 Date of Receipt sample .... : 2024-04-24 Date of Test ....................... : 2024-04-24 to 2024-06-04 Date of Issue ...................... : 2024-06-11 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTH24D04089814W003 Page 2 of 8 Waltek Testing Group Co., Ltd. http://www.w altek.com.cn 2. Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2.CONTENTS ............................................................................................................................................... 2 3.REVISION HISTORY ................................................................................................................................. 3 4.GENERAL INFORMATION ....................................................................................................................... 4 4.1. GENERAL DESCRIPTION OF E.U.T.................................................................................................... 4 4.2. DETAILS OF E.U.T. ......................................................................................................................... 4 4.3. TEST FACILITY ................................................................................................................................ 5 4.4. SUBCONTRACTED ........................................................................................................................... 5 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 5.TEST SUMMARY ...................................................................................................................................... 6 6.RF EXPOSURE ......................................................................................................................................... 7 6.1. REQUIREMENTS .............................................................................................................................. 7 6.2. THE PROCEDURES / LIMIT ................................................................................................................ 7 6.3. MPE CALCULATION METHOD........................................................................................................... 8 6.4. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ................................................................... 8 Reference No.: WTH24D04089814W003 Page 3 of 8 Waltek Testing Group Co., Ltd. http://www.wa ltek.com.cn 3. Revision History Test Report No. Date of Receipt Sample Date of Test Date of Issue Purpose Comment Approved WTH24D04089814W003 2024-04-24 2024-04-24 to 2024-06-04 2024-06-11 Original-Valid Reference No.: WTH24D04089814W003 Page 4 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4. General Information 4.1. General Description of E.U.T. Product: 10.1-inch Smart Digital Picture Frame Model(s): WE-1908, MX-PF101, MEMDPF101, WE-19XX, MX-CRXXX, WE- 1908XXX(XXX means unit color, it can be A to Z or N/A) Model Description: Only the model names are different. Model WE-1908 was tested in the report. Hardware Version: V01 Software Version: V03 4.2. Details of E.U.T. Operation Frequency: 802.11b/g/n HT20: 2412~2462MHz Max. RF output power: 18.73dBm Type of Modulation: DSSS, OFDM Antenna installation: FPC antenna Antenna Gain: 1.71dBi Note: #: The antenna gain is provided by the applicant, and the applicant should be responsible for its authenticity, WALTEK lab has not verified the authenticity of its information. Ratings: DC 5V 1.5A from adapter (Adapter Input: 100-240V~50/60Hz 0.5A) Adapter: Adapter name: SWITCHING POWER SUPPLY. Model No: GKYPS0150050UL1 Reference No.: WTH24D04089814W003 Page 5 of 8 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4.3. Test Facility The test facility has a test site registered with the following organizations: ISED CAB identifier: CN0013. Test Firm Registration No.: 7760A. Waltek Testing Group Co., Ltd. Has been registered and fully described in a report filed with the Industry Canada. The acceptance letter from the Industry Canada is maintained in our files. Registration number 7760A, October 15, 2016. FCC Designation No.: CN1201. Test Firm Registration No.: 523476. Waltek Testing Group Co., Ltd. EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the F…

Text truncated - open the document above for the full version.

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 50 TEST REPORT Referen ce No. .................... : WTH24D04089814W002 FCC ID ................................ : OKUWE1908 Applicant ............................ : Shenzhen Junlan Electronic Ltd Address .............................. : No. 277, Pingkui Road, Shijing Community, Pingshan Office, Pingshan New District, Shenzhen, China Manufacturer .................... : Shenzhen Junlan Electronic Ltd Address ............................. : No. 277, Pingkui Road, Shijing Community, Pingshan Office, Pingshan New District, Shenzhen, China Product ............................... : 10.1-inch Smart Digital Picture Frame Model(s). ............................ : WE-1908, MX-PF101, MEMDPF101, WE-19XX, MX-CRXXX, WE- 1908XXX(XXX means unit color, it can be A to Z or N/A) Standards........................... : FCC 47CFR Part 15.247 Date of Receipt sample .... : 2024-04-24 Date of Test ....................... : 2024-04-24 to 2024-06-04 Date of Issue ...................... : 2024-06-11 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTH24D04089814W002 Page 2 of 50 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 4 4 GENERAL INFORMATION ....................................................................................................................... 5 4.1 G ENERAL DESCRIPTION OF E.U.T. ....................................................................................................... 5 4.2 D ETAILS OF E.U.T. .............................................................................................................................. 5 4.3 C HANNEL LIST ..................................................................................................................................... 5 4.4 T EST FACILITY .................................................................................................................................... 6 4.5 S UBCONTRACTED ................................................................................................................................ 6 4.6 A BNORMALITIES FROM STANDARD CONDITIONS .................................................................................... 6 4.7 T EST MODE ........................................................................................................................................ 7 5 TEST SUMMARY ...................................................................................................................................... 8 6 EQUIPMENT USED DURING TEST ......................................................................................................... 9 6.1 E QUIPMENTS LIST ............................................................................................................................... 9 6.2 M EASUREMENT UNCERTAINTY ........................................................................................................... 10 7 DUTY CYCLE .......................................................................................................................................... 11 8 CONDUCTED EMISSION ....................................................................................................................... 13 8.1 E.U.T. OPERATION ............................................................................................................................ 13 8.2 EUT SETUP ...................................................................................................................................... 13 8.3 M EASUREMENT DESCRIPTION ............................................................................................................ 13 8.4 C ONDUCTED EMISSION TEST RESULT ................................................................................................ 14 9 RADIATED EMISSIONS ......................................................................................................................... 16 9.1 EUT OPERATION ............................................................................................................................... 16 9.2 T EST SETUP ..................................................................................................................................... 17 9.3 S PECTRUM ANALYZER SETUP ............................................................................................................ 18 9.4 T EST PROCEDURE ............................................................................................................................. 19 9.5 C ORRECTED AMPLITUDE & MARGIN CALCULATION .............................................................................. 19 9.6 S UMMARY OF TEST RESULTS ............................................................................................................. 20 10 CONDUCTED SPURIOUS EMISSIONS ..........................................................................…

Text truncated - open the document above for the full version.

version01 Shenzhen Junlan Electronic Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: WE-1908, MX-PF101,MEMDPF101，WE-19XXX, MX-CRXXX, WE-1908XXX(XXX means unit color, it can be A to Z or N/A) FCC ID:OKUWE1908 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for FPC antenna type(s) described below: Model No. of antenna:WE-1908 Type of antenna:FPC antenna Gain of the antenna: 1.71 dBi Frequency range: 2400-2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name:Shenzhen Junlan Electronic Ltd Address: No.277 PingKui Road, Shijing Community, Pingshan Office, Pingshan City:Shenzhen ZIP / Postal code: Country:China Contact Name:peng xiaoDate:2024-06-05 Signature:

Antena Test Report Frequency ：WIFI2.4G Production date: 2023-3-2 Contents 1： Antenna Overview & Dimension 2： The test project 2.1 Antenna Matching Network 2.2 VSWR 2.3 Gain & Efficiency 2.4 3D Date 2.5 The Free Space 3D Date/The Free Space 2D Date 3 : Ground processing Series N/A Antenna PA Shunt 01 N/A Shunt 02 N/A LocationDescription Shunt 01 N/A SeriesN/A Shunt 02N/A 5 2.4G 802.11b，(2.4G)11M ChannelCH1CH6CH1 1 TRP15.3415.5715.46 TIS -84-84-84 Conducting data Gain & Efficiency WIFIFrequency (MHz)Efficiency (%)Peak GAIN (dBi) 2400 45.751.68 2450 46.541.71 2500 45.691.62 7 2.4G 802.11b，(2.4G)11M ChannelCH1CH6CH1 1 TRP12.0712.4512.38 TIS -76.39-76.53-76.77 WIFI OTA Data Environmental treatment The screen cable in the red box is shielded with conductive cloth Antenna Assembly & environmental processing WIFI

Appendix- WE-1908-Photos Page 1 of 10 1. Test Setup photos Model WE-1908 FCC ID: OKUWE1908 1.1 Photograph – Conducted Emission Test Setup For Conducted Emission Test Site 1# 1.2 Photograph – Radiated Emissions For 9kHz-30MHz Test Site 2# Appendix- WE-1908-Photos Page 2 of 10 For 30MHz-1000MHz Test Site 2# For Above 1GHz Test Site 1#
