ONYET2032CUSB TOUCH SCREEN CONTROLLER

TOUCH SCREEN CONTROLLER USER’S MANUAL ET2032C ET&T Technology Co., Ltd. 2F N0.2, Lane 57 Sec.1, Chien-Kuo N.Rd. Taipei,Taiwan,R.O.C. Tel: 886-2-2506-9472 Fax:886-2-2501-6877 E-Mail: [email protected] WARNING Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of FCC Rules. These Limits are designed to provide reasonable protection against harmful interferfnce in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver in connected. l Consult the dealer or an experienced radio/TV technician for help. Notice: Changes or modigications not expressly approved by the part responsible for Compliance could void the user’s authority operate equipment. This device complies with Part 15 of the FCC Rules operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Table of Contents 1. Hardware Installation. 2. Software Installation. 3. How To Use Appendix 1. Hardware Installation. 1.1 Hardware Requirement 1) A PC with COM Port. 2) Touch Screen Controller ( ET2032C ). 3) Touch Screen Panel. 1.2 Installation Note! Please turn off the power before following operation. 1) Fit in the Touch Screen accessories with monitor size. 2) To connect the controller and Touch Screen Panel. 3) Plug in Touch Screen COM controller to PC COM Port. 2. Software Installation 2.1 Preparation 1) Win98 operation system. 2) Win98 CD. 2.2 Installation 1) Boot up your system. 2) Insert driver diskette To A: 3) Place Win98 CD in CD Rom. 4) Following instruction step by step. 5) After completing driver installation, cursor will respond for touch on touch screen panel. 6) Please execute A:\setup.exe for adding calibration & swap button application for touch .Screen and let doubleclick more easy. and let double click more easy. 7) Execute the correcting coordinates program to configure the screen by instruction. 3. How To Use After setup up, Touch The Screen to let cursor move. Appendix Sepecification of ET2032C. Resolution: 12bit ADC TouchPanel Type: 4-wire Interface: COM port LED: Touch/ Untouch indication Power: derived from COM port Power consumption: Idle: 10mA Active: 12mA Dimension: 79 x 38 x 21mm 3.11"x1.50"x0.83" Operation Temperature: 0 ~ 70 Storage Terpeature: -55 ~ 125 Regulatory Approvals: FCC-B CE and BCIQ














NEUTRON EMC LAB. Report No.NEI-FCC-E-03240 23/30 Photo # 1 NEUTRON EMC LAB. Report No.NEI-FCC-E-03240 24/30 Photo # 2

NEUTRON EMC LAB. Report No.NEI-FCC-E-03240 29/30 n FCC ID label – The remained portion of label statement required by FCC is attached in the user’s manual. -- Location of Label on EUT -- 0.17 cm 0.03 cm

NEUTRON EMC LAB. Report No.NEI-FCC-E-03240 25/30 Photo # 3 NEUTRON EMC LAB. Report No.NEI-FCC-E-03240 26/30 Photo # 4

Product Descriptions(Application/Features/Specification) The EUT is a Touch Screen Controller. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual (Attachment - E.)

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 19-Nov-2003 Sheet of File: D:\My Documents\..\ET2032C.sch Drawn By: R2110M OSC1 4M C17 20pF C15 20pF VCC ETouch2032 XX' Y' YNote:Tough R13100K D2 LED (red) R31.8K VCC R9 xxx R10 xxx C9103pF C7103pF Q12N2907 Q2 2N2222 R75.1K R85.1K R610K R15.1K R21.8K D11N4148 D41N4148 + C110uF VCC RDTD RxdTxd 12345 J1CON5 TDRDDTRRTSGND 123456 J2CON6 X+X-Y-Y+Button RGND D9 5.6V D10 5.6V D7 5.6V D3 5.6V D12 5.6V TxdRxd D51N4148D61N4148 D85.1V C110.1uF + C14 220uF/16V VCC DTRRTS D115.1V X-Y+X+Y- PortPortPortPort R5 1K R19 1K C10103pF C12103pF R23xxx Button R Rxd GND R11xxxR150 Z1 xxx C60.1uF C410uF VCC 1/1Nick V1.20 X+X-Y-Y+ P04 44 P05 45 P06 46 P07 47 ADVRF 48 P20 2 P21 3 P22 4 P23 5 P24 6 P25 8 P26 9 P27 10 P36 11 P37 12 P10 14 P11 15 P12 16 P13 17 GND 18 P14 20 P15 21 P16 22 P17 23 CLKSEL 24 XIN 26 XOUT 27 EXTINT 28 RESET 29 P30 30 P31 32 P32 33 P33 34 P34 35 P35 36 P00 38 P01 39 P02 40 P03 41 VDD 42 U1 WT505F-48PIN Choose 6M or 4M OSC "000" --> 6M"001" --> 4M VCC R2010K P16,P15,P14 R4100K C130.1uF 123456 J3CON6 R2210K VCC C1610uF C2103pF C3103pF C5103pF C8103pF Note: Plug and Play DTR DSR Short R1610K If to slow will eat power then nonstable J1:2.0 5pin 180 度 J2:PhonejackJ3:2.0 6pin 90 度 R18 0 R14 0 R12100 R17100 left button(P0.2)right button(P0.0)
