 G.TECH TECHNOLOGY LTDWireless Dual Channel Wheel Mouse FCC ID : OO9TX198 To active the mouse, please refer to the method described as below: 1. Press connects key in the receiver, LEDs turn on 2. Click any key in the keyboard and mouse, LEDs turn off 3. At this time, you can use the mouse just as usual Mouse driver is just to active the wheel function in win95 and early win98 system. Mouse sending data to receiver just when you press any key or move it.

FCC ID:OO9TX198 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F01004 APPLICATION FOR CERTIFICATION On Behalf of G.Tech Technology. Ltd. Wireless Dual Channel Wheel Mouse Model : DTWM01 Prepared for : G.Tech Technology. Ltd. 7/F, Dongqu Bld., 7, Hai Hong Rd., Xiang Zhou, Zhuhai Sze, Guangdong, China. Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6 Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755)663-9496 Report Number
ACS-F01004 Date of Test
Jan. 13/15, 2001 Date of Report
Jan. 15, 2001 FCC ID:OO9TX198 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F01004 TABLE OF CONTENTS DescriptionPage Test Report Certification 1.GENERAL INFORMATION ............................................................................................................. 1-1 1.1. Description of Device (EUT) .................................................................................................................... 1-1 1.2. Tested Supporting System Details ............................................................................................................ 1-1 1.3. Test Facility............................................................................................................................................... 1-3 1.4. Measurement Uncertainty ......................................................................................................................... 1-3 2.POWER LINE CONDUCTED EMISSION TEST .......................................................................... 2-1 3.RADIATED EMISSION MEASUREMENT .................................................................................... 3-1 3.1. Test Equipment ......................................................................................................................................... 3-1 3.2. Block Diagram of Test Setup .................................................................................................................... 3-1 3.3. Radiated Emission Limit (Class B)........................................................................................................... 3-2 3.4. EUT Configuration on Measurement........................................................................................................ 3-2 3.5. Operating Condition of EUT..................................................................................................................... 3-3 3.6. Test Procedure........................................................................................................................................... 3-3 3.7. Radiated Emission Noise Measurement Result ........................................................................................ 3-4 4.PHOTOGRAPH................................................................................................................................... 4-1 4.1. Photos of Radiated Measurement.............................................................................................................. 4-1 APPENDIX I(9 Pages) FCC ID:OO9TX198 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F01004 TEST REPORT CERTIFICATION Applicant
G.Tech Technology. Ltd. Manufacturer
G.Tech Technology. Ltd. EUT Description
Wireless Dual Channel Wheel Mouse (A) MODEL NO. : DTWM01 (B) SERIAL NO. : N/A (C) POWER SUPPLY : +3V DC Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C October 1998 & ANSI C63.4-1992 The device described above is tested by AUDIX TECHNOLOGY (SHENZHEN) CO., LTD. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits both radiated and conducted emissions. The measurement results are contained in this test report and AUDIX TECHNOLOGY (SHENZHEN) CO., LTD. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of AUDIX TECHNOLOGY (SHENZHEN) CO., LTD. Date of Test :Dec. 12-13, 2000 FCC ID:OO9TX198 Page Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F01004 1-1 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Description : Wireless Dual Channel Wheel Mouse (This report is about transmitter and the receiver FCC DOC report please refer to AUDIX Number F01006.) Model Number : DTWM01 Applicant : G.Tech Technology. Ltd. 7/F, Dongqu Bld., 7, Hai Hong Rd, Xiang Zhou, Zhuhai Sze, Guangdong, China Manufacturer : G.Tech Technology. Ltd. 7/F, Dongqu Bld., 7, Hai Hong Rd, Xiang Zhou, Zhuhai Sze, Guangdong, China Date of Test : Jan. 13 / 15, 2001 1.2. Tested Supporting System Details 1.2.1. PERSONAL COMPUTER Model Number
