OO9TXP24Low Power Transceiver

G.Tech Technology Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Sep 18, 2002
Application Purpose: Original Equipment
Date of Application: Sep 18, 2002
Equipment Note: Low Power Transceiver
Frequency Range: 26.96000000 - 27.28000000
Company: G.Tech Technology Ltd.
Country: China
