T HE VC OM AP5857 S TRAND R ADIO S YSTEM The VCom AP5857strand radio system wirelessly extends the CATV HFC network into underserved and hard to reach areas. Operating in the 5.8 GHz unlicensed UNII band, the system provides a transparent full-duplex link for DOCSIS TM service with the same 64 QAM/256 QAM (downstream) and QPSK/16 QAM (upstream) signals that are used on the wired network. The AP5857, working in conjunction with the VCom TRI5758, significantly enhances market penetration of broadband wireless DOCSIS TM services while minimizing the infrastructure investment and maintaining advanced services. Product Features • Wirelessly extend CATV HFC networks to provide broadband wireless DOCSIS TM services to areas outside the reach of the wired plant • Strand mount design with fully weather-proof enclosure for quick and easy integration into the outdoor CATV HFC network • Supports SNMP management for remote control as well as local control via RS-232 interface for on site configuration and monitoring • Internal demodulator/remodulator ensures excellent downstream signal, independent of CATV downstream signal quality • Incorporates a number of features to control upstream ingress, protecting current wired customers and ensuring network integrity, such as: - Automatic upstream muting - Remote monitoring of upstream levels - Control of upstream gain and muting VCom Inc. (formerly WaveCom Electronics Inc.) 150 Cardinal Place Saskatoon, SK, Canada S7L 6H7 TEL: (306) 955-7075 FAX: (306) 955-9919 Website: www.vcom.com E-mail: [email protected] Distributed by: Specifications subject to change without notice — Printed in Canada br_ap5857_05 (Oct 2005) 150 C ARDINALPLACE, SASKATOON, SKS7L 6H7 T EL: (306) 955-7075 FAX: (306) 955-9919 E-MAIL: [email protected]: WWW.VCOM.COM br_ap5857_05 (Oct 2005) Specifications subject to change without notice. - Printed in Canada. S PECIFICATIONS —VC OM AP5857 S TRAND R ADIO S YSTEM The DOCSIS TM acronym belongs to CableLabs® ACCESSPOINT AP5857 SUBSCRIBERUNIT TRI5758 (WITH OPTIONAP) DOWNSTREAM Transmit RF Output Frequency Range 5799 to 5823 MHz Transmit EIRP +15 to +28 dBm IF Input Frequency Range91 to 857 MHz IF Input Level Range0 to +20 dBmV per channel Downstream Modulation64QAM, 5.06 MSym/sec or 256QAM, 5.36 MSym/sec Downstream Flatness1 dB p-p over 5 MHz, typical UPSTREAM Receive RF Input Frequency Range5727 to 5751 MHz Noise Figure (at RF connector)6 dB max at max gain Image Rejection90 dB minimum IF Output Frequency Range18 to 42 MHz Gain Range36 ± 2 dB to 76 ± 2 dB at mid band IF Level17 to 50 dBmV Gain Flatness (frequency response)± 0.5 dB over 3.2 MHz, 2 dBpp full band Spectral InversionNo spectral inversion Return Loss (IF)13 dB: 5 to 42 MHz and 88 to 857 MHz GENERAL Upstream Ingress MitigationAutomatic upstream IF mute Upstream gain control Upstream mute control via remote access Upstream power detector IF ConnectorF female, 75 ohms Power Requirements35 to 90 VAC, 60 Hz Power Consumption27 W maximum ManagementRemote and local status monitoring and control SNMPv1.1 remote access RS232 command line local craft interface Operating Temperature Range -40 to +60 °C Antenna Integrated: 60° horz. & 30° vert. beamwidth Downstream Link Margin (line of sight) 16.5 dB (64QAM, 1 mile); 3.8 dB (256QAM, 2 miles) EMC ComplianceFCC CFR 47, Part 15, Subpart B FCC Part 15 subpart E, section 15.401 Industry Canada RSS-210 6.2.2 (q1) LELAN devices ConfigurationsStrand mount, utility pole mount, pipe mount (options STRAND, POLE, PIPE) Size60.2 x 22.3 x 12.4 cm (23.7 x 8.8 x 4.9”) Weight7.1 kg (15.6 lbs) DOWNSTREAM RF Input Frequency5799 to 5823 MHz IF Output Frequency540 to 564 MHz Gain (Integrated)36 dBi ± 2 dB Gain Flatness (Frequency Response)± 1.5 dB full range ± 0.5 dB any 6 MHz range Gain Stability Over Temperature± 2.0 dB Noise Figure6.0 dB typical, 7dB max Image Rejection90 dB minimum Discrete Spurious (at IF port)-80 dBm between 540 and 564 MHz -50 dBm from 5 MHz to 540 MHz and from 564 MHz to 860 MHz Phase Noise (IF)<-85 dBc/Hz @ 10 kHz typical Spectral InversionNo spectral inversion U PSTREAM IF Input Frequency18 to 42 MHz RF (upstream) Output Frequency5727 to 5751 MHz Gain (Integrated)26 dBi ± 2 dB Gain Flatness (Frequency Response)± 1 dB full band ± 0.5 dB over any 3.2 MHz band Gain Stability Over Temperature± 2.0 dB Linear Output Power+5 dBm into antenna (16 QAM, QPSK) Spurious (at transmit port)-40 dBm 9 kHz to 21.4 GHz Phase Noise< -85 dBc/Hz @ 10 KHz typical Spectral InversionNo spectral inversion Return Loss (IF)10 dB in transmit and receive bands IF Level for RF Activation+ 5 dBmV RF Activation/Mute Response Time<2 microseconds G ENERAL Integrated Flat Panel Antenna Gain 23 dBi Beamwidth 9.0 degrees PolarityVertical or horizontal Cross Polarization Isolation20 dB Front/Back Ratio30 dB IF ConnectorF female, 75 ohms DC Supply18 to 24 VDC, 12W max. Operating Temperature-40°C to +60°C Size30.5 x 30.5 x 7.5 cm (12 x 12 x 3") MountingPole mount 1" to 2.5" dia. pole or wall mount with 90 deg pol, az and el adjustment Weight2.7 kg max. Part NumberTRI5758, option AP

INSTALLATION AND OPERATION GUIDE FOR SYSTEM OPERATORS VCom Inc. AP5857 Manual; ml_ap5857_08 (Oct 2005) Approved: R.B. 2 Proprietary to VCom Inc. All rights reserved. No part of this publication may by reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from VCom Inc. VCom Inc. reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of VCom Inc. to provide notification of such revision or change. VCom Inc. provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. VCom Inc. may make improvements or changes in the product(s) described in this manual at any time. AP5857 Manual; ml_ap5857_08 (Oct 2005) Approved: R.B. Specifications subject to change without notice — Printed in Canada VCom Inc. AP5857 Manual; ml_ap5857_08 (Oct 2005) Approved: R.B. 3 Thank-you for purchasing this product and welcome to VCom! You have chosen an innovative solution from a leading technology design center in the ongoing TV & data delivery revolution. No doubt you’ve been thinking that the future of your television delivery system includes new technologies such as Digital TV, Internet Over Cable, Wireless Cable. By selecting VCom, you are benefiting from the same design powerhouse that since 1988 has created custom RF and digital products for technology leaders such as AT&T, Cisco Systems, Cogeco, Comcast, and Cox Communications. VCom Inc. designs and manufactures:



Agile CATV Modulators



256 QAM Upconverters



Digital Video Modulators



Frequency Translators



Spread Spectrum Devices



MMDS Transceivers



Off Air/CATV Demodulators



Wireless Cable MMDS



Wireless Cable LMDS



Video On Demand Products and more! Designs to fill the market needs of the CATV industry – both foreign and domestic. For additional product or corporate information, contact us: On the web at: www.vcom.com By sending email to: [email protected] By telephone: (306) 955-7075 By fax: (306) 955-9919 By snail mail: VCom Inc. 150 Cardinal Place Saskatoon, SK Canada S7L 6H7 VCom Inc.'s Corporate Mandate is to be a leading worldwide designer and manufacturer of state-of-the- art communications equipment and components. Through the remarkable success of our customers and business partners, VCom innovations are achieving this goal. VCom Inc. AP5857 Manual; ml_ap5857_08 (Oct 2005) Approved: R.B. 4 SAFETY PRECAUTIONS 1. Before installing and operating this equipment, read all Safety, Installation and Operating sections. Retain this manual for future reference. 2. Follow all instructions — Failure to do so may result in damage to the unit or severe personal injury. 3. Servicing should not be attempted by the user. There are no user serviceable parts inside. Refer all servicing to factory qualified personnel. 4. Shock Hazard — An electrical shock hazard exists when the chassis cover is removed as is required to set internal controls. Always disconnect power from the unit before removing the cover. 5. Cleaning — Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. LES PRÉCAUTIONS DE SÉCURITÉ 1. Avant d'installer ou d'opérer cet équipement, lisez, toutes les sections de sécurités, d'installations et d'opérations. Gardez ce manuel comme source de référence. 2. Suivez toutes instructions - si non, vous risquez d'endommager la machine ou de vous blesser sérieusement. 3. N'essayez, pas de réparer cet équipement vous même. Référez toutes revisions nécessaire au personnel qualifié de la manufacture. 4. Risque de choc - Il y a un risque de décharge électrique qui existe quand la couverture du châssis est enlevée, comme est nécessaire pour ajuster les contrôlcs internes. Il faut toujours couper l'électricité avant d'enlever le couvercle pour faire aucun ajustage. 5. Le nettoyage - n'utilisez pas de nettoyeurs aérosols ou liquides. Utilisez un tissu humide pour nettoyer.
Caution: To comply with FCC RF exposure limits in Section 1.1307, the AP5857 requires a minimum distance of 0.2 meters between it and all persons.
Modifications not expressly approved by the manufacturer may void the user’s authority to operate this equipment. This device complies with FCC Part 15, Subparts B and E. This device complies with Industry Canada RSS 210, Issue 5 including Amendments 1, 2, 3, and 4.
Important Installation Instructions VCom Inc. AP5857 Manual; ml_ap5857_08 (Oct 2005) Approved: R.B. 5 INDEX 1.0 GENERAL INFORMATION............................................................ 7 1.1 Overview ..................................................................................................................................................7 1.2 Module Features......................................................................................................................................7 1.3 System Features.......................................................................................................................................7 1.4 Specifications ...........................................................................................................................................8 1.5 Options .....................................................................................................................................................9 2.0 INSTALLATION......................................................................... 10 2.1 Unpacking the unit................................................................................................................................10 2.2 Operating Environment........................................................................................................................10 2.3 Power Requirements ..........................................…

Text truncated - open the document above for the full version.

RF Safety Exhibit Revision: 02 Date: 4 November 2005 Equipment: CommScope Airbridge Access Point, model AP5800 FCC ID: TOU-AIRBRIDGE-AP The maximum safe distance from the antenna at which MPE is met or exceeded is calculated from the equation relating field strength in V/m, transmit power in Watts, transmit antenna gain, and separation distance in meters. Basis of calculations: Prediction of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01: where: S = power density (mW/cm^2) P = power input to the antenna (mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm) Maximum average output power at antenna input terminal: 16.0 (dBm) Maximum average output power at antenna input terminal: 39.81 (mW) Antenna gain (typical): 14 (dBi) Maximum antenna gain: 25.1 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5799-5823 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.199 (mW/cm^2) Maximum allowable antenna gain: 21.0 (dBi) Margin of Compliance at 20cm = 7.0 (dB) Installation Requirements: The AP5800 is supplied with an integrated antenna. Installation of the AP5800 is described in the user manual, which is supplied with each AP5800. 2 4R PG S π = The following statement is included in the user manual, see “Information to User” section on page 4 of “INSTALLATION AND OPERATION MANUAL”: WARNING: In order to comply with the FCC radio frequency exposure limits of Part 1.1310, this equipment must be installed in such a way as to provide a minimum separation distance of 2 ft. from the transmitting antenna to persons nearby.

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 14.17 (dBm) Maximum peak output power at antenna input terminal: 26.12161354 (mW) Antenna gain(typical): 14 (dBi) Maximum antenna gain: 25.11886432 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5802 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.130536 (mW/cm^2) Maximum allowable antenna gain: 22.84269855 (dBi) Margin of Compliance: 8.842698554 2 4 R PG S π =

FCC Part 15 Subpart E : October 2005 Test Report: 5W53075 Issue 2 Applicant: CommScope, Inc of North Carolina 1100 CommScope Place SE Hickory, North Carolina 28603-1729 Apparatus: CommScope AirBridge Access Point (M/N: AP5800) FCC ID: TOU-AIRBRIDGE-AP In Accordance With: FCC Part 15 Subpart E, 15.407 Unlicensed National Information Infrastructure Devices Tested By: Nemko Canada Inc. 303 River Road Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, Resource Manager Date: 31 October 2005 Total Number of Pages: 32 Nemko Canada Inc. REPORT SUMMARY Report Number: 5W53075 Issue 2 FCC ID: TOU-AIRBRIDGE-AP Specification: FCC Part 15 Subpart E, 15.407 Page 2 of 32 Report Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart E, 15.407. Radiated tests were conducted in accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: CommScope AirBridge Access Point (M/N: AP5800) Specification: FCC Part 15 Subpart E, 15.407 Compliance Status: Complies Exclusions: None Non-compliances: None Report Release History: Issue 2: Updated product descriptions Author: Jason Nixon, Telecom Specialist Jin Xu, Wireless Specialist Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Nemko Canada Inc. REPORT SUMMARY Report Number: 5W53075 Issue 2 FCC ID: TOU-AIRBRIDGE-AP Specification: FCC Part 15 Subpart E, 15.407 Page 3 of 32 TABLE OF CONTENTS Report Summary......................................................................................................................................... 2 Section 1 : Equipment Under Test............................................................................................................. 4 1.1 Product Identification .................................................................................................................................4 1.2 Samples Submitted for Assessment............................................................................................................4 1.3 Theory of Operation ...................................................................................................................................4 1.4 Technical Specifications of the EUT ..........................................................................................................5 1.5 Block Diagram of the EUT.........................................................................................................................5 Section 2 : Test Conditions......................................................................................................................... 6 2.1 Specifications .............................................................................................................................................6 2.2 Deviations From Laboratory Test Procedures ............................................................................................6 2.3 Test Environment .......................................................................................................................................6 2.4 Test Equipment...........................................................................................................................................6 Section 3 : Observations ............................................................................................................................. 7 3.1 Modifications Performed During Assessment ............................................................................................7 3.2 Record Of Technical Judgements ...............................................................................................................7 3.3 EUT Parameters Affecting Compliance .....................................................................................................7 3.4 Test Deleted................................................................................................................................................7 3.5 Additional Observations .............................................................................................................................7 Section 4 : Results Summary ..................................................................................................................... 8 4.1 FCC Part 15 Subpart E : Test Results.........................................................................................................9 Appendix A : Test Results ........................................................................................................................ 10 Clause 15.209(a) Radiated Emissions within Restricted Bands ..........................................................................10 Clause 15.403(i) Emission Bandwidth ................................................................................................................11 Clause 15.407(a)(3) Power Limits in the 5.725 to 5.825GHz band.....................................................................14 Clause 15.407(b) Spurious Emissions .................................................................................................................2…
